folding workbench 1000mm
model no: fwb1000
Thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAfeTY
9 maintain the workbench in good condition. Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9 Keep the workbench clean for best and safest performance and check moving parts alignment regularly.
9 locate the workbench in a suitable working area. Keep area clean and tidy and ensure there is adequate lighting.
9 ensure that any workpiece which extends beyond the bench is adequately supported.
9 maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
do noT use the workbench for any purpose other than that for which it is designed.
do noT get the workbench wet or use in wet weather conditions, and do noT expose the workbench to excessive heat.
do noT use the workbench if any parts are missing as this may cause failure and/or personal injury.
do noT stand on the top of workbench, or use it as standing platform or to support a platform.
9 When not in use store in a safe, dry, child proof area and ensure it will not topple over.
2. i inTroducTion
Powder coated steel foldable workbench with mdF work surface. Built-in
storage bar for easy storage and access to tools. Folds and unfolds in seconds
for quick set up wherever required. ergonomic composite handle and lightweight
at only 14kg for ease of carrying. Work top marked with 960mm measuring scale
and 180° protractor. Supplied with slot in cross bar for added stability.
maximum weight capacity 100kg.
ec
3. SpecificATion
model number ....................................................... FWB1000
net weight ................................................................... 14.5kg
length, width, height (mm) ..............................1000x600x745
maximum weight capacity ..............................................100kg.
4. ASSemblY
4.1. Unpack the product and check contents to ensure no parts are damaged.
Should there be any damaged or missing parts contact your supplier immediately.
4.2. With the bench on its side, lower end frames.
4.3. ensure all fixings are securely fitted.
4.4. locate latches over studs on end frame legs (2 places) (fig.1).
4.5. locate cross bar into holes in end frames cross member (fig.2).
FWB1000 Issue 1 30/07/18
Original Language Version
© Jack Sealey limited
Refer to
instruction
manual
Wear protective
gloves
fig.
1
Sealey group, kempson way, Suffolk business park, bury St edmunds, Suffolk. ip32 7Ar
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
environmenT proTecTion
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
important: no liability is accepted for incorrect use of this product.
warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
fig.
2
