1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.
9 Locate bench in a suitable working area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use bench on level and solid ground, preferably concrete. Avoid tarmacadam since the bench may sink into the surface.
9 Keep the bench clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the bench for any purpose other than that for which it is designed.
8 DO NOT exceed maximum capacity of workbench.
8 DO NOT undertake work on the bench without the work piece being adequately secured. Use clamps or a vice (not included) to secure the
work piece. Available from your Sealey stockist.
8 DO NOT use the bench out of doors.
8 DO NOT get the bench wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the bench with any solvents which may damage the paint surface or the protective coating on the wooden top.
2. INTRODUCTION
Heavy-duty powder coated metal frame with a 40mm MDF work surface. Storage splits into 3-sections with a choice of cupboards,
drawers and an open space with two adjustable shelves. All cabinet drawers tted with ball-bearing slides and cupboards include a
hanging pegboard on the inside of the door. Fully lockable and features adjustable feet to help stability when placed on an uneven
surface. Supplied at-packed with two keys.
3. SPECIFICATION
4. CONTENTS
WORKSTATION WITH 2 DRAWERS, 2 CUPBOARD & OPEN
STORAGE
MODEL NO: AP1905A
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
AP1905A Issue 2 30/05/24
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Part Description Quantity
A Top 1
B1 Left side 1
B2 Right side 1
C Bottom 1
D1 Left support 1
D2 Right support 1
E Drawer 2
F1 Left door 1
F2 Right door 1
G Shelf 3
H Back 3
I Leg leveller assy. 4
J1 Left slide 2
J2 Right slide 2
K Rail 2
Wear eye
protection
Model no: AP1905A
Nett Weight: 76.1kg
Size (W x D x H): 1690 x 600 x 865mm
Drawer (x2): 415 x 160 x 415mm
Capacity: 300kg
4.1. HARDWARE CONTENTS
4.2. Before assembly check contents against the contents lists.
5. ASSEMBLY
AP1905A Issue 2 30/05/24
Original Language Version
© Jack Sealey Limited
Step 1 Step 2
Step 3.1
Step 3.2
Part Description Quantity
a Bolts ST4.8x10 14+2
b Plastic pin 8
AP1905A Issue 2 30/05/24
Original Language Version
© Jack Sealey Limited
Step 4
Step 5
Step 6 Step 7
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
