1
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Explanation of Symbols
7 Description of Parts and Accessories
7 Attaching the Accessories
7 The Floor Attachment
8 The Crevice and Brush Tool
9 Using Your Vacuum Cleaner
10 Using the Crevice and Brush Tool
10 Emptying Your Vacuum Cleaner
12 Care and Maintenance of Your Vacuum Cleaner
12 Recommended Filter Cleaning Intervals
12 Troubleshooting Guide
13 Plug Wiring Information
13 Technical Specification
13 Recycling Information
14 Customer Support
15 Notes
Back Page Warranty Information
3
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the safety
instructions. Failure to do so may result in personal injury
or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product on
to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to property
or persons.
The manufacturer or vendor cannot be held liable for damages or
injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Vacuum Cleaner.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years when it is energised or cooling down.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
to the mains supply.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to
• ensure no damage is evident. Should there be any signs of
damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT pull or carry the Vacuum Cleaner by the electrical
cord, use the handle provided.
5
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Ensure fingers and other objects are never placed in any
part of the vacuum cleaner. Clothing or hair may become
trapped if the vacuum is used improperly.
• Keep hair, loose clothing, jewellery, fingers and all parts of
the body away from openings and moving parts.
• Keep all air vents clear and free of dust, lint, hair and
anything else that may reduce airflow.
• Avoid directing the appliance towards naked flames as the
air discharged may extinguish gas fires or pilot lights and
may disturb ashes in open fires.
• DO NOT Vacuum water or any other liquids with this
vacuum.
• DO NOT Vacuum hot ashes or lit cigarettes, etc.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol indicates that the appliance is electrically double
insulated and therefore does not require an earth connection.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol identifies voltage and the current rating for direct
current.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts & Accessories
Attaching the Accessories
CAUTION Ensure that the vacuum cleaner is not connected to the mains supply
before connecting the attachments.
The Floor Attachment
1. Push the Telescopic Tube (12) onto the Air Intake (11) as shown below:
1. On/Off Switch
2. Air Outlet
3. Handle
4. Crevice & Brush Tool
5. Upholstery Brush
6. Floor Tool
7. Wall Mount Bracket
8. Dust Compartment
9. Dust Release Catch
10. Cyclonic & Hepa Filters
11. Air Intake
12. Telescopic Tube
13. Wall Mount Bracket (with Screws
& Plugs)
1
2
3
10
12
4
5
6
7
8
9
11
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
2. Push the Floor Tool (6) onto the other end of the Telescopic Tube (12)
Adjust the lever on the Floor Tool (6) according to the type of floor being
cleaned. Push the lever down for use on hard floors (i.e. non carpeted), pull the
lever up for vacuum cleaning carpets:
3. Set the required height of the cleaner by pushing the catch down on the
Telescopic Tube (12) and adjusting the tube to the required length/height:
The Crevice & Brush Tool
1. Attach the Crevice & Brush Tool (4) onto the Telescopic Tube (12) to clean
carpet edges and hard to get at areas:
2. If the Telescopic Tube (10) is not required, attach the Crevice & Brush Tool (4)
directly to the cleaner, this useful whilst cleaning soft furnishings, stairs, etc.
Left: Adjust the lever on
the Floor Tool for
carpeted or hard floors:
Up for carpets
Down for hard floors
9
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rotate the brush on the end of the Crevice & Brush Tool (4) tool to
select between hard edges or the brush.
Using Your Vacuum Cleaner
1. Once you have assembled your
vacuum cleaner as desired
above, Insert the mains plug
into the nearest socket.
2. To operate the vacuum cleaner,
grip the vacuum by the Handle
(3) and press the On/Off Switch
(1) on the top of the vacuum to
the ‘I’ position – arrowed right.
3. Place your foot gently on the Floor
Tool (6) and pull the cleaner back by
the Handle (3) and start vacuum
cleaning.
Press the On/Off Switch (1) to the ‘O’
position at the end of cleaning to
switch the cleaner off.
1
2
3
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
1. Once the dust level reaches the
‘MAX’ mark on the Dust
compartment (8) it will need
emptying and the filters cleaned.
Using the Crevice & Brush Tool (4)
1. Attach the Crevice & Brush Tool (4) onto the Telescopic Tube (12) to clean
carpet edges and hard to get at areas:
Emptying Your Vacuum Cleaner
WARNING! Always disconnect the cleaner from the mains power supply before
cleaning.
WARNING! DO NOT continue to use your vacuum cleaner once the ‘MAX’
mark has been reached as permanent damage may occur to the appliance.
Left: Use the
crevice tool to
clean hard to get at
areas, carpet
edges, etc.
Right: Rotate the
brush down on the
tool to clean
curtains,
upholstery, etc.
1
11
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Once emptied, twist the Cyclonic
& Hepa Filters (10) off in an
anticlockwise direction and
remove.
2. To empty the cleaner, hold the Dust
Compartment (10) over a dust bin and unclip
the Dust Release Catch (9) (arrowed right)
and the base of the dust compartment will
swing open and allow the collected dust to
fall out into the dust bin.
4. Wash the Cyclonic & Hepa Filters
(10) in warm running water until
clean. Allow the filters to dry
thoroughly for 24 hours before reuse.
2
3
4
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
Care and Maintenance of Your Vacuum Cleaner
• Always disconnect the cleaner from the mains power supply before cleaning.
• Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
• Do not submerge the cleaner in water or any other liquids.
• Empty the Dust Compartment (4) as soon as the ‘MAX’ mark has been reached.*
• Wash the Cyclonic & Hepa Filters (10) regularly – see table below.
• Allow the filters to thoroughly dry out for 24 hours before reassembly and use.
* WARNING! DO NOT continue to use your vacuum cleaner once the ‘MAX’
mark has been reached as permanent damage may occur to the appliance.
Recommended filter cleaning intervals
Filter Type
Recommended cleaning period
WARNING! Ensure the filters are cleaned periodically according to the table
above, failure to clean the filters regularly will severely impair the performance
and permanent damage may occur to the appliance.
Troubleshooting Guide
Problem
Possible Cause
Possible Solution
Unit fails to turn on.
The unit may not be
properly plugged in.
The fuse may have
tripped.
Ensure the plug is fully
inserted into the socket and
the socket is switched on.
Check the fuse on the mains
board, if it has tripped, reset it.
Low suction or poor pick-up.
Cylinder is full.
Filters are clogged.
Blockage in the hose.
Empty the cylinder. Check and
clean the filters.
Check the Telescopic Tube and
clear if necessary.
The vacuum is making a “hissing”
sound.
The airflow is
restricted
Empty the cylinder. Check and
clean the filters.
Check the Telescopic Tube and
clear any blockages if
necessary.
• Shake
out
debris
when
you
empty
the dust
container
•
Rinse
under
war
m
water
once
a
month
• Allow to dry thoroughly for 24 hours before reuse.
Hepa Filter
Cyclonic Filter
• Shake
out
debris
once
a
month
•
Rinse
under
war
m
water
once
a month.
• Allow to dry thoroughly for 24 hours before reuse.
13
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Model Number
FLR00160
Supply Voltage
AC 220-240V ~ 50-60Hz
Rated Power
600W
Protection Class
II
Vacuum (max)
15kpa
Dust Compartment Capacity
0.8L
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
15
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes
16
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Essential 600W Corded Vacuum
Model No. FLR00160
User Manual
WARRANTY
Thank you for purchasing your Daewoo Vacuum.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
