Honeywell HFD230B QuietClean 3-Speed Ionic Black Non-HEPA User Manual

IMPORTANT SAFETY

INSTRUCTIONS

READ AND SAVE THESE

SAFETY INSTRUCTIONS

BEFORE USING THIS AIR

PURIFIER

When using electrical appliances, basic

precautions should always be followed to

reduce the risk of fire, electric shock, and

injury to persons, including the following:

1. Read all instructions before operating the

air purifier.

2. Place air purifier where it is not easily knocked

over by persons in the household.

3. ALWAYS turn the air purifier controls to the

OFF position and unplug from the wall outlet

when not in use.

4. To disconnect the air purifier, press the

Power button to turn the unit off, grip the

plug and pull it from the wall outlet. NEVER

pull by the cord.

5. DO NOT use any product with a damaged cord

or plug, any product that malfunctions, or any

product that has been dropped or damaged in

any manner.

6. DO NOT use air purifier outdoors.

7. DO NOT use air purifier unless it is fully

assembled.

8. DO NOT run power cord under carpets, and DO

NOT cover with throw rugs. Arrange cord such

that it will not be a tripping hazard.

QUIETCLEAN

OSCILLATING TOWER

AIR PURIFIER

Model Series HFD230

9. DO NOT use air purifier where combustible

gases or vapors are present.

10. DO NOT expose the air purifier to rain, or use

near water, in a bathroom, laundry area or

other damp location.

11. The air purifier must be used in its upright

position.

12. DO NOT allow foreign objects to enter

ventilation or exhaust opening as this may

cause electric shock or damage to the air

purifier. DO NOT block air outlets or intakes.

13. Locate air purifier near the outlet and avoid

using an extension cord.

14. This appliance has a polarized plug (one blade

is wider than the other). To reduce the risk of

electric shock, this plug is intended to fit only

one way in a polarized outlet. If the plug does

not fit fully in the outlet, reverse the plug. If it

still does not fit, contact a qualified electrician.

DO NOT attempt to defeat this safety feature.

15. A loose fit between the AC outlet (receptacle)

and plug may cause overheating and a

distortion of the plug. Contact a qualified

electrician to replace loose or worn outlet.

16. DO NOT sit, stand or place heavy objects on

the air purifier.

17. Disconnect power supply before servicing.

Note: For FCC compliance information, please

see last page of this manual.

WARNING: To Reduce The Risk of Fire or

Electric Shock, Do Not Use This Air Purifier

With Any Solid-State Speed Control Device.

Owner’s Manual

2 3

OPERATION

• Ensure the air purifier is plugged into a working electrical outlet.

• Press the power button ( ) once. The unit will start at medium speed for a

few seconds and then automatically change to low speed (Fig. 2).

• Press the power button again to select a different cleaning level.

Portable air purifiers are more effective in rooms where all doors and

windows are closed. It is recommended that you run your air purifier while

you are at home to help clean the air.

Fig. 2

YOUR AIR PURIFIER

HOW YOUR AIR PURIFIER WORKS

ENHANCED ODOR REDUCTION

This model air purifier incorporates a 3-stage

cleaning system to clean the air that passes

through the filters in the unit (Fig. 1).

Stage 1: Washable or Odor-Reducing Pre-filter (your

choice) attaches to the rear grille. Captures

larger airborne particles and traps odors and

VOCs (when used with Optional

pre-filter).

Stage 2: Permanent Washable ifD

Particle Filter.

Captures microscopic airborne particles.

Stage 3: Electronic Ionizer boosts the cleaning power.

Washable or

Odor Reducing

Pre-Filter

ifD

Particle Filter

Fig. 1

SET-UP

• Select a firm, level and flat location. For best airflow, locate the unit 6 inches (15.2 cm) from any wall or furniture.

• When operating, large volumes of air are drawn toward the air purifier. Surrounding areas should be cleaned and/

or vacuumed frequently to prevent build-up of dust and other contaminants. This may also help prolong the life of

the filter. If the unit is placed on a light colored carpet, a small mat or rug should be used underneath to prevent

staining. This is especially important in homes with contamination from smoking or fireplaces.

ENERGY STAR

This product earned the ENERGY STAR

by meeting strict energy efficiency guidelines set

by the U.S. EPA. U.S. EPA does not endorse any manufacturer claims of healthier indoor air

from the use of this product.

The energy efficiency of this ENERGY STAR

qualified model is measured based on a ratio

between the model’s CADR for Dust and the electrical energy it consumes, or CADR/Watt.

DIMMER OPTION

The Dimmer Option ( ) allows you to adjust the brightness of the LED display

on the control panel. You may wish to adjust the brightness depending on the

room where the unit is placed.

• The unit always turns on with brightness on HIGH

• Press the ( ) button once and LED display will dim to Low setting (Fig. 3).

• The LED lights cannot be turned completely off

• Pressing the ( ) button a 2nd time will turn the LED brightness back to

HIGH.

Optional Odor

Reducing

Pre-filter

(packed in plastic bag)

(air intake is at the

rear of the grille and

output is from the

front of grille)

Fig. 3

OSCILLATION OPTION

To help circulate fresher, cleaner air through the room, this unit has an

oscillation feature.

• To turn Oscillation on, simply press the Oscillation button (

) (Fig. 4).

• To turn Oscillation off, press the button again.

Fig. 4

Permanant

Washable

ifD

Particle

Filters (2)

Rear

Grille

installed

Washable

Pre-filter

(1)

Control Panel

with Integrated

Carry Handle

The washable pre-filter comes installed in your air purifier and removes larger particles from the air that

passes through the filter. You may use this washable pre-filter, or you have the choice to use the Optional

Odor & VOC Reducing

Pre-filter that is packed in a bag that came with the air purifier. In addition to

capturing larger particles, the

Pre-filter will also trap common household odors and gases. If you choose

to use the

Pre-filter, you must remove the installed washable pre-filter then insert the

Pre-filter.

Remove

Pre-filter from plastic bag before use.

Note: the

Pre-filter cannot be washed and should be replaced every 3 months for optimum performance.

NOTE: Please only use one pre-filter in your air purifier at a time. You will need to choose whether you

want to use the permanent washable pre-filter or the replaceable pre-filter.

2 3

OPERATION

• Ensure the air purifier is plugged into a working electrical outlet.

• Press the power button ( ) once. The unit will start at medium speed for a

few seconds and then automatically change to low speed (Fig. 2).

• Press the power button again to select a different cleaning level.

Portable air purifiers are more effective in rooms where all doors and

windows are closed. It is recommended that you run your air purifier while

you are at home to help clean the air.

Fig. 2

YOUR AIR PURIFIER

HOW YOUR AIR PURIFIER WORKS

ENHANCED ODOR REDUCTION

This model air purifier incorporates a 3-stage

cleaning system to clean the air that passes

through the filters in the unit (Fig. 1).

Stage 1: Washable or Odor-Reducing Pre-filter (your

choice) attaches to the rear grille. Captures

larger airborne particles and traps odors and

VOCs (when used with Optional

pre-filter).

Stage 2: Permanent Washable ifD

Particle Filter.

Captures microscopic airborne particles.

Stage 3: Electronic Ionizer boosts the cleaning power.

Washable or

Odor Reducing

Pre-Filter

ifD

Particle Filter

Fig. 1

SET-UP

• Select a firm, level and flat location. For best airflow, locate the unit 6 inches (15.2 cm) from any wall or furniture.

• When operating, large volumes of air are drawn toward the air purifier. Surrounding areas should be cleaned and/

or vacuumed frequently to prevent build-up of dust and other contaminants. This may also help prolong the life of

the filter. If the unit is placed on a light colored carpet, a small mat or rug should be used underneath to prevent

staining. This is especially important in homes with contamination from smoking or fireplaces.

ENERGY STAR

This product earned the ENERGY STAR

by meeting strict energy efficiency guidelines set

by the U.S. EPA. U.S. EPA does not endorse any manufacturer claims of healthier indoor air

from the use of this product.

The energy efficiency of this ENERGY STAR

qualified model is measured based on a ratio

between the model’s CADR for Dust and the electrical energy it consumes, or CADR/Watt.

DIMMER OPTION

The Dimmer Option ( ) allows you to adjust the brightness of the LED display

on the control panel. You may wish to adjust the brightness depending on the

room where the unit is placed.

• The unit always turns on with brightness on HIGH

• Press the ( ) button once and LED display will dim to Low setting (Fig. 3).

• The LED lights cannot be turned completely off

• Pressing the ( ) button a 2nd time will turn the LED brightness back to

HIGH.

Optional Odor

Reducing

Pre-filter

(packed in plastic bag)

(air intake is at the

rear of the grille and

output is from the

front of grille)

Fig. 3

OSCILLATION OPTION

To help circulate fresher, cleaner air through the room, this unit has an

oscillation feature.

• To turn Oscillation on, simply press the Oscillation button (

) (Fig. 4).

• To turn Oscillation off, press the button again.

Fig. 4

Permanant

Washable

ifD

Particle

Filters (2)

Rear

Grille

installed

Washable

Pre-filter

(1)

Control Panel

with Integrated

Carry Handle

The washable pre-filter comes installed in your air purifier and removes larger particles from the air that

passes through the filter. You may use this washable pre-filter, or you have the choice to use the Optional

Odor & VOC Reducing

Pre-filter that is packed in a bag that came with the air purifier. In addition to

capturing larger particles, the

Pre-filter will also trap common household odors and gases. If you choose

to use the

Pre-filter, you must remove the installed washable pre-filter then insert the

Pre-filter.

Remove

Pre-filter from plastic bag before use.

Note: the

Pre-filter cannot be washed and should be replaced every 3 months for optimum performance.

NOTE: Please only use one pre-filter in your air purifier at a time. You will need to choose whether you

want to use the permanent washable pre-filter or the replaceable pre-filter.

4 5

CLEANING THE IFD

FILTERS

The ifD

filter should be cleaned approximately every 3 months.

Turn the power off and unplug the air purifier.

After removing the ifD

filter from the air purifier,

follow the steps below to clean the ifD

filter.

• Rinse the filter with clean tap water (Fig. 7)

• If the filter still appears dirty, proceed to “Washing,”otherwise

proceed to "Drying."

Washing:

• Remove the ifD

filters from the unit.

• Fill a sink with lukewarm water and add a few drops of mild dish soap.

• Gently swish the filters in the soap solution to clean.

• Soak the filters for 2-3 minutes. Do not leave for an extended period of time.

• Rinse the filters with clean tap water (Fig. 7) and proceed to "Drying."

Fig.7

REMOVING THE FILTERS

CAUTION: Turn off the air purifier and wait 60 seconds before removing the grille

to clean filters.

The ifD

filter is supplied within the air purifier.

• Turn-off the air purifier. Wait 60 seconds and unplug the unit before removing the grille.

• Press down on the tab on the rear grille, and pull the grille down and toward you.

Remove the grille (Fig. 6).

• With one hand, hold the air purifier steady and use other hand to grasp ifD

filter and

pull out. Repeat for second filter.

• To place the ifD

filter back into the air purifier housing, insert at bottom and ensure it

is pushed in as far as it can go, then push in from the top. Repeat with second filter.

Fig. 6

ELECTRONIC FILTER CLEAN REMINDER

Check Filters Button – When it is time to check and clean the filters, an indicator

light will illuminate. When this light comes on, you will need to clean the primary

ifD

filter and clean or replace the pre-filter. (See Filter Cleaning instructions on

pages 4-5). It is recommended that you periodically check the filters.

Depending on operating conditions, the filters should be cleaned every 3 months.

If you have chosen to use the Odor & VOC Reducing

Pre-filter, it is NOT

washable and should be replaced after 3 months. After you have cleaned or

replaced the filters, you will need to RESET the Electronic Filter Check.

To RESET the Electronic Filter Check:

After the ifD

filters and pre-filter have been cleaned/replaced and re-installed in the unit, plug the unit

into the power outlet with the unit remaining in POWER OFF mode, press and hold the CHECK FILTERS

button (see Fig. 5) for 3 seconds. The CHECK FILTERS LED will flash twice indicating the filter check

has been reset. The LED will no longer be illuminated.

The intervals are intended as guidelines only. Performance of any filter media is dependent upon the

concentration of contaminants going through the system. High concentrations of contaminants such as

dust, pet dander, and smoke particles will reduce the useful performance of the filter and they may need

to be cleaned more frequently.

Drying:

• Shake the filters to remove any excess water.

• Place the filters with the honeycomb side down on a plush towel.

• Note that the filters may still be discolored even after washing.

This is acceptable and will not affect performance.

• Allow the ifD

filters to dry for a few hours or overnight.

• When the ifD

filters are completely dry, place back into the air purifier.

CAUTION:

• Never place wet ifD

filters in your air purifier.

• The ifD

filters are NOT dishwasher safe. DO NOT place the ifD

filters in a dishwasher or subject them

to other extreme hot water conditions.

• Do not use any solvents, strong cleaning agents or flammable liquids to clean the ifD

filters.

CLEANING THE IFD

FILTERS (Cont)

The pre-filter helps capture large airborne particles that

enter the rear grille. This pre-filter can be periodically

removed and shaken to clean it. Alternatively, it can be

rinsed by hand under warm water (Fig. 8). Let the

pre-filter air dry completely before inserting back into

the grille (Fig. 9). If you need to replace this item, please

call 1-800-477-0457.

OPTIONAL: Changing the Odor Absorbing Pre-Filter

If you choose to use the odor absorbing

pre-filter that came with your air

purifier, it will lose its effectiveness for odor absorption over time and will

need to be replaced.

To purchase additional

pre-filter, see Accessories and Replacent Filters

section below.

To install it in the unit, simply place it securely into the rear grille held in place

with plastic tabs in lieu of the standard pre-filter as shown in Fig. 9.

If using the odor absorbing pre-filter, it is recommended that you store the

original washable pre-filter in the event that you decide to use it in the future.

NOTE: The odor absorbing pre-filter is NOT washable.

Fig. 8

Fig.9

Washable

Pre-filter

Rear

Grille

MAINTAINING YOUR WASHABLE PRE-FILTER

We recommend that you clean the air purifier at least every 3 months and before extended storage. Use

only a dry cloth to wipe the external surfaces of the air purifier. DO NOT USE WATER, WAX POLISH, OR

ANY CHEMICAL SOLUTION.

CLEANING AND STORAGE

Fig. 5

4 5

CLEANING THE IFD

FILTERS

The ifD

filter should be cleaned approximately every 3 months.

Turn the power off and unplug the air purifier.

After removing the ifD

filter from the air purifier,

follow the steps below to clean the ifD

filter.

• Rinse the filter with clean tap water (Fig. 7)

• If the filter still appears dirty, proceed to “Washing,”otherwise

proceed to "Drying."

Washing:

• Remove the ifD

filters from the unit.

• Fill a sink with lukewarm water and add a few drops of mild dish soap.

• Gently swish the filters in the soap solution to clean.

• Soak the filters for 2-3 minutes. Do not leave for an extended period of time.

• Rinse the filters with clean tap water (Fig. 7) and proceed to "Drying."

Fig.7

REMOVING THE FILTERS

CAUTION: Turn off the air purifier and wait 60 seconds before removing the grille

to clean filters.

The ifD

filter is supplied within the air purifier.

• Turn-off the air purifier. Wait 60 seconds and unplug the unit before removing the grille.

• Press down on the tab on the rear grille, and pull the grille down and toward you.

Remove the grille (Fig. 6).

• With one hand, hold the air purifier steady and use other hand to grasp ifD

filter and

pull out. Repeat for second filter.

• To place the ifD

filter back into the air purifier housing, insert at bottom and ensure it

is pushed in as far as it can go, then push in from the top. Repeat with second filter.

Fig. 6

ELECTRONIC FILTER CLEAN REMINDER

Check Filters Button – When it is time to check and clean the filters, an indicator

light will illuminate. When this light comes on, you will need to clean the primary

ifD

filter and clean or replace the pre-filter. (See Filter Cleaning instructions on

pages 4-5). It is recommended that you periodically check the filters.

Depending on operating conditions, the filters should be cleaned every 3 months.

If you have chosen to use the Odor & VOC Reducing

Pre-filter, it is NOT

washable and should be replaced after 3 months. After you have cleaned or

replaced the filters, you will need to RESET the Electronic Filter Check.

To RESET the Electronic Filter Check:

After the ifD

filters and pre-filter have been cleaned/replaced and re-installed in the unit, plug the unit

into the power outlet with the unit remaining in POWER OFF mode, press and hold the CHECK FILTERS

button (see Fig. 5) for 3 seconds. The CHECK FILTERS LED will flash twice indicating the filter check

has been reset. The LED will no longer be illuminated.

The intervals are intended as guidelines only. Performance of any filter media is dependent upon the

concentration of contaminants going through the system. High concentrations of contaminants such as

dust, pet dander, and smoke particles will reduce the useful performance of the filter and they may need

to be cleaned more frequently.

Drying:

• Shake the filters to remove any excess water.

• Place the filters with the honeycomb side down on a plush towel.

• Note that the filters may still be discolored even after washing.

This is acceptable and will not affect performance.

• Allow the ifD

filters to dry for a few hours or overnight.

• When the ifD

filters are completely dry, place back into the air purifier.

CAUTION:

• Never place wet ifD

filters in your air purifier.

• The ifD

filters are NOT dishwasher safe. DO NOT place the ifD

filters in a dishwasher or subject them

to other extreme hot water conditions.

• Do not use any solvents, strong cleaning agents or flammable liquids to clean the ifD

filters.

CLEANING THE IFD

FILTERS (Cont)

The pre-filter helps capture large airborne particles that

enter the rear grille. This pre-filter can be periodically

removed and shaken to clean it. Alternatively, it can be

rinsed by hand under warm water (Fig. 8). Let the

pre-filter air dry completely before inserting back into

the grille (Fig. 9). If you need to replace this item, please

call 1-800-477-0457.

OPTIONAL: Changing the Odor Absorbing Pre-Filter

If you choose to use the odor absorbing

pre-filter that came with your air

purifier, it will lose its effectiveness for odor absorption over time and will

need to be replaced.

To purchase additional

pre-filter, see Accessories and Replacent Filters

section below.

To install it in the unit, simply place it securely into the rear grille held in place

with plastic tabs in lieu of the standard pre-filter as shown in Fig. 9.

If using the odor absorbing pre-filter, it is recommended that you store the

original washable pre-filter in the event that you decide to use it in the future.

NOTE: The odor absorbing pre-filter is NOT washable.

Fig. 8

Fig.9

Washable

Pre-filter

Rear

Grille

MAINTAINING YOUR WASHABLE PRE-FILTER

We recommend that you clean the air purifier at least every 3 months and before extended storage. Use

only a dry cloth to wipe the external surfaces of the air purifier. DO NOT USE WATER, WAX POLISH, OR

ANY CHEMICAL SOLUTION.

CLEANING AND STORAGE

Fig. 5

6 7

You should first read all instructions before

attempting to use this product.

A. This 5 year limited warranty applies to

repair or replacement of product found to be

defective in material or workmanship. This

warranty does not apply to damage resulting

from commercial, abusive, unreasonable use

or supplemental damage. Defects that are

the result of normal wear and tear will not

be considered manufacturing defects under

this warranty. KAZ IS NOT LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES

OF ANY NATURE, ANY IMPLIED WARRANTY

OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE ON THIS PRODUCT IS

LIMITED IN DURATION TO THE DURATION OF

THIS WARRANTY. Some jurisdictions do not

allow the exclusion or limitation of incidental or

consequential damages or limitations on how

long an implied warranty lasts, so the above

limitations or exclusions may not apply to you.

This warranty gives you specific legal rights,

and you also may have other rights which vary

from jurisdiction to jurisdiction. This warranty

applies only to the original purchaser of this

product from the original date of purchase.

B. At its option, Kaz will repair or replace this

product if it is found to be defective in material

or workmanship.

C. This warranty does not cover damage resulting

from any unauthorized attempts to repair

or from any use not in accordance with the

instruction manual.

D. This warranty does not cover the ifD

filters or

pre-filters except for material or workmanship

defects.

5 YEAR LIMITED WARRANTY

CONSUMER RELATIONS

Questions or comments:

Call us toll-free at: 1-800-477-0457

E-mail: [email protected]

Or visit our website at: www.HoneywellPluggedIn.com

Please be sure to specify the model number.

NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE

YOUR WARRANTY. DO NOT RETURN TO THE ORIGINAL PLACE OF PURCHASE. DO NOT ATTEMPT

TO OPEN THE MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND CAUSE

DAMAGE TO THE AIR PURIFIER OR PERSONAL INJURY.

How long should I run my Air Purifier?

It is recommended that you run your air purifier when you are at home to help purify the air. This unit

will be more effective when doors and windows are closed.

My Filter Check Light has not come on but when I checked my filter, it was really dirty.

In conditions where smoke, pets or air with a lot of contaminants are present it is possible that the filter

could be dirty sooner than indicated by the Check Filters light. The Check Filters light on your unit runs

on a timer and if there are more particles in your air than in an average home, your filter could require

cleaning sooner than indicated on the display. The indicator is intended to be used as

a guideline and individual environmental conditions will vary.

My unit will not turn on.

The air purifier has safety features to ensure that the unit is ready for operation. To make sure the IfD

filter and rear grille are installed correctly, check to make sure the filter is installed and is flush to the air

purifier. Check to make sure the rear grille is snapped into place. If your unit still won’t turn on, contact

Consumer Relations at 1-800-477-0457.

My Air Purifier is starting to make noise and the air output is less. What’s wrong?

The filters may be dirty. High amounts of contaminants can block the pores in the filter and stop the air

from moving through it. The filter and pre-filter should be cleaned.

Can I wash my Odor Reducing

Pre-filter?

No. Washing the Odor & VOC reducing

pre-filter will destroy it. You can, however, wash the

permanent pre-filter.

How do I use the additional pre-filter that is packed in the plastic bag?

Your air purifier came with an installed washable pre-filter that helps capture the larger airborne

particles before they reach the ifD

Particle filter. If you would like the additional benefit of Odor & VOC

Reduction, you may replace the washable pre-filter with the Odor & VOC Reducing

Pre-filter that was

packed in a plastic bag with the purifier. You must first remove the washable pre-filter that came in your

air purifier and replace it with the

pre-filter. This pre-filter is not washable and should be replaced

every 3 months for optimum performance.

How does the electronic filter check work?

The filter check LED will illuminate when it is time to check the filters after 3 months of continuous

operation. After the filters have been cleaned/changed, you should reset the Electronic Filter Check.

See instructions on page 4.

FREQUENTLY ASKED QUESTIONS

IMPORTANT NOTEACCESSORIES AND REPLACEMENT FILTERS

There is an optional pre-filter that can be purchased and used with this air purifier that will help reduce

common household odors and VOCs. The

Pre-filter (HRF-K2) can be used in lieu of the permanent

washable pre-filter that is supplied with the air purifier. The optional

Pre-filter

should be replaced

every 3 months for optimum odor and VOC reduction performance.

You may purchase Honeywell replacement Odor & VOC Reducing

Pre-filter Model HRF-K2

(2 pack) at the retailer where you purchased your air purifier or they can be ordered directly from

www.replacementfilters.com. To ensure stated product performance, use only Genuine Honeywell

Replacement Filters.

If you have any questions about ifD

Particle filter or the washable pre-filter, call Consumer Relations at

1-800-477-0457 or email [email protected].

The ionizing process used by the air purifier produces small amount of ozone as a byproduct. The air

purifier complies with the U.S. Government limits for acceptable levels of ozone (less than 50 parts

per billion by volume of air circulating through the product.)

This product is California ARB (Air Resource Board) certified and complies with Federal ozone emissions limits.

This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by

volume (ppmv) in a 24-hour period. The Health Canada Guideline 2010 recommends that the maximum

exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or less when tested in a sealed,

controlled room approximately 30 m

6 7

You should first read all instructions before

attempting to use this product.

A. This 5 year limited warranty applies to

repair or replacement of product found to be

defective in material or workmanship. This

warranty does not apply to damage resulting

from commercial, abusive, unreasonable use

or supplemental damage. Defects that are

the result of normal wear and tear will not

be considered manufacturing defects under

this warranty. KAZ IS NOT LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES

OF ANY NATURE, ANY IMPLIED WARRANTY

OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE ON THIS PRODUCT IS

LIMITED IN DURATION TO THE DURATION OF

THIS WARRANTY. Some jurisdictions do not

allow the exclusion or limitation of incidental or

consequential damages or limitations on how

long an implied warranty lasts, so the above

limitations or exclusions may not apply to you.

This warranty gives you specific legal rights,

and you also may have other rights which vary

from jurisdiction to jurisdiction. This warranty

applies only to the original purchaser of this

product from the original date of purchase.

B. At its option, Kaz will repair or replace this

product if it is found to be defective in material

or workmanship.

C. This warranty does not cover damage resulting

from any unauthorized attempts to repair

or from any use not in accordance with the

instruction manual.

D. This warranty does not cover the ifD

filters or

pre-filters except for material or workmanship

defects.

5 YEAR LIMITED WARRANTY

CONSUMER RELATIONS

Questions or comments:

Call us toll-free at: 1-800-477-0457

E-mail: [email protected]

Or visit our website at: www.HoneywellPluggedIn.com

Please be sure to specify the model number.

NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE

YOUR WARRANTY. DO NOT RETURN TO THE ORIGINAL PLACE OF PURCHASE. DO NOT ATTEMPT

TO OPEN THE MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND CAUSE

DAMAGE TO THE AIR PURIFIER OR PERSONAL INJURY.

How long should I run my Air Purifier?

It is recommended that you run your air purifier when you are at home to help purify the air. This unit

will be more effective when doors and windows are closed.

My Filter Check Light has not come on but when I checked my filter, it was really dirty.

In conditions where smoke, pets or air with a lot of contaminants are present it is possible that the filter

could be dirty sooner than indicated by the Check Filters light. The Check Filters light on your unit runs

on a timer and if there are more particles in your air than in an average home, your filter could require

cleaning sooner than indicated on the display. The indicator is intended to be used as

a guideline and individual environmental conditions will vary.

My unit will not turn on.

The air purifier has safety features to ensure that the unit is ready for operation. To make sure the IfD

filter and rear grille are installed correctly, check to make sure the filter is installed and is flush to the air

purifier. Check to make sure the rear grille is snapped into place. If your unit still won’t turn on, contact

Consumer Relations at 1-800-477-0457.

My Air Purifier is starting to make noise and the air output is less. What’s wrong?

The filters may be dirty. High amounts of contaminants can block the pores in the filter and stop the air

from moving through it. The filter and pre-filter should be cleaned.

Can I wash my Odor Reducing

Pre-filter?

No. Washing the Odor & VOC reducing

pre-filter will destroy it. You can, however, wash the

permanent pre-filter.

How do I use the additional pre-filter that is packed in the plastic bag?

Your air purifier came with an installed washable pre-filter that helps capture the larger airborne

particles before they reach the ifD

Particle filter. If you would like the additional benefit of Odor & VOC

Reduction, you may replace the washable pre-filter with the Odor & VOC Reducing

Pre-filter that was

packed in a plastic bag with the purifier. You must first remove the washable pre-filter that came in your

air purifier and replace it with the

pre-filter. This pre-filter is not washable and should be replaced

every 3 months for optimum performance.

How does the electronic filter check work?

The filter check LED will illuminate when it is time to check the filters after 3 months of continuous

operation. After the filters have been cleaned/changed, you should reset the Electronic Filter Check.

See instructions on page 4.

FREQUENTLY ASKED QUESTIONS

IMPORTANT NOTEACCESSORIES AND REPLACEMENT FILTERS

There is an optional pre-filter that can be purchased and used with this air purifier that will help reduce

common household odors and VOCs. The

Pre-filter (HRF-K2) can be used in lieu of the permanent

washable pre-filter that is supplied with the air purifier. The optional

Pre-filter

should be replaced

every 3 months for optimum odor and VOC reduction performance.

You may purchase Honeywell replacement Odor & VOC Reducing

Pre-filter Model HRF-K2

(2 pack) at the retailer where you purchased your air purifier or they can be ordered directly from

www.replacementfilters.com. To ensure stated product performance, use only Genuine Honeywell

Replacement Filters.

If you have any questions about ifD

Particle filter or the washable pre-filter, call Consumer Relations at

1-800-477-0457 or email [email protected].

The ionizing process used by the air purifier produces small amount of ozone as a byproduct. The air

purifier complies with the U.S. Government limits for acceptable levels of ozone (less than 50 parts

per billion by volume of air circulating through the product.)

This product is California ARB (Air Resource Board) certified and complies with Federal ozone emissions limits.

This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by

volume (ppmv) in a 24-hour period. The Health Canada Guideline 2010 recommends that the maximum

exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or less when tested in a sealed,

controlled room approximately 30 m

8 9

CONSIGNES

DE SÉCURITÉ

IMPORTANTES

LISEZ ET CONSERVEZ

CES CONSIGNES DE

SÉCURITÉ AVANT

D’UTILISER CE

PURIFICATEUR D’AIR

Lorsque vous utilisez des appareils

électriques, vous devez toujours prendre

certaines précautions élémentaires pour

réduire les risques d’incendie, de choc

électrique et de blessure, notamment les

mesures suivantes :

1. Lisez les instructions au complet avant de faire

marcher le purificateur d’air.

2. Placez le purificateur d’air dans un endroit de

la maison où il sera difficile à toute personne

de le renverser au passage.

3. Lorsque le purificateur d’air ne sert pas,

éteignez-le en mettant le bouton en position

d’ARRÊT et débranchez-le de la prise électrique.

4. Pour débrancher le purificateur d’air, appuyez

sur le bouton de mise en marche-arrêt pour

arrêter l’appareil, saisissez la fiche et retirez-la

de la prise électrique. NE tirez JAMAIS sur

le cordon.

5. DO NOT use any product with a damaged cord

or plug, any product that malfunctions, or any

product that has been dropped or damaged in

any manner.

6. N’UTILISEZ pas le purificateur d’air à l’extérieur

de la maison.

7. DO NOT use air purifier unless it is fully

assembled.

8. NE FAITES PAS passer le cordon d’alimentation

sous un tapis ou une carpette. Arrange cord

such that it will not be a tripping hazard.

9. N’UTILISEZ PAS le purificateur d’air là où il y a

des gaz ou des vapeurs.

10. N’EXPOSEZ PAS le purificateur d’air à la pluie,

et ne l’utilisez pas à proximité de l’eau, comme

QUIETCLEAN

PURIFICATEUR D’AIR

OSCILLANT À

COLONNE

MODÈLE DE LA SÉRIE HFD230

Guide d’utilisation

dans une salle de bains, une salle de lavage ou

tout autre endroit humide.

11. Le purificateur d’air doit demeurer en position

verticale.

12. Ne laissez pas des corps étrangers pénétrer

dans les ouvertures de ventilation ou

d’échappement, car ils risquent de causer un

choc électrique ou d’endommager l’appareil.

NE BLOQUEZ PAS les entrées ni les sorties d’air.

13. Placez le purificateur d’air près d’une prise et

n’utilisez pas de rallonge électrique.

14. Cet appareil est muni d’une fiche polarisée

(une des deux broches est plus large que

l’autre). To reduce the risk of electric shock,

this plug is intended to fit only one way in

a polarized outlet. Si les broches n’entrent

pas complètement dans les trous de la prise,

tournez la fiche dans l’autre sens. Si elles

n’entrent toujours pas, communiquez avec un

électricien qualifié. N’ESSAYEZ PAS d’altérer

ce dispositif de sécurité.

15. La présence d’un jeu entre la prise (réceptacle)

et la fiche peut causer une surchauffe et une

distorsion de celle-ci. Communiquez avec un

électricien qualifié pour remplacer la prise usée

ou instable.

16. NE VOUS ASSOYEZ ou ne montez pas sur

l’appareil; ne placez pas d’objets lourds

sur le purificateur d’air.

17. Débranchez l’appareil avant de procéder

à son entretien.

Remarque : Pour avoir de l’information sur la

conformité FCC, veuillez consulter la dernière

page de ce manuel.

AVERTISSEMENT : Pour réduire les risques

d’incendie ou de choc électrique, n’utilisez pas ce

purificateur d’air avec un dispositif de réglage de

vitesse à circuit intégré, quel qu’il soit.

VOTRE PURIFICATEUR D’AIR

FONCTIONNEMENT DE VOTRE PURIFICATEUR D’AIR

MEILLEURE RÉTENTION DES ODEURS

INSTALLATION

• Choisissez un endroit où le sol est ferme, plat et à niveau. Pour assurer une meilleure circulation de l’air, placez

l’appareil à 6 pouces (15,2 cm) de tout mur ou meuble.

Préfiltre

à rétention

d’odeurs

optionnel

(emballé dans un

sac de plastique)

(l’entrée d’air se

situe à l’arrière de

la grille et la sortie

se situe devant

la grille)

Permanant

Washable

ifD

Particle

Filters (2)

Grille

arrière

Préfiltre

lavable

préinstallé

(1)

Panneau de

commande

avec poignée

intégrée

The washable pre-filter comes installed in your air purifier and removes larger particles from the air that

passes through the filter. Vous pouvez utiliser ce préfiltre lavable, ou si vous préférez, utiliser le préfiltre

optionnel qui réduit les odeurs et les composés organiques volatils (COV). Le préfiltre

est emballé

dans un sac à part qui accompagne le purificateur d’air. En plus de retenir les plus grosses particules, le

préfiltre

est aussi capable de capter les odeurs et les fumées ménagères les plus courantes. Si vous

décidez d’utiliser le préfiltre

, vous devez retirer le préfiltre lavable préinstallé et mettre le préfiltre

sa place. Remove

Pre-filter from plastic bag before use.

Remarque : Le préfiltre

n’est pas lavable et doit être remplacé aux trois mois pour un rendement optimal.

REMARQUE : Veuillez n’utiliser qu’un seul préfiltre à la fois dans votre purificateur d’air. You will need to

choose whether you want to use the permanent washable pre-filter or the replaceable pre-filter.

Ce modèle de purificateur d’air comporte un système de

nettoyage de l’air en trois étapes, pour aider à purifier l’air

qui traverse le filtre de l’appareil (Fig. 1).

Étape 1 : Le préfiltre lavable ou le préfiltre

à rétention

d’odeurs et de COV (votre choix) se fixe à la grille

arrière. Capte les plus grosses particules dans

l’air et retient les odeurs et les COV (lorsqu’il est

utilisé avec le préfiltre optionnel).

Étape 2 : Permanent Washable ifD

Particle Filter.

Capte les particules microscopiques dans l’air.

Étape 3 : L’ioniseur électronique augmente la puissance de purification.

Préfiltre lavable ou

à rétention

d'odeurs

Air

ambiant

Air plus

propre

ifD

Particle Filter

Champ de

l'ioniseur

Système de purification en 3 étapes

Fig. 1

8 9

CONSIGNES

DE SÉCURITÉ

IMPORTANTES

LISEZ ET CONSERVEZ

CES CONSIGNES DE

SÉCURITÉ AVANT

D’UTILISER CE

PURIFICATEUR D’AIR

Lorsque vous utilisez des appareils

électriques, vous devez toujours prendre

certaines précautions élémentaires pour

réduire les risques d’incendie, de choc

électrique et de blessure, notamment les

mesures suivantes :

1. Lisez les instructions au complet avant de faire

marcher le purificateur d’air.

2. Placez le purificateur d’air dans un endroit de

la maison où il sera difficile à toute personne

de le renverser au passage.

3. Lorsque le purificateur d’air ne sert pas,

éteignez-le en mettant le bouton en position

d’ARRÊT et débranchez-le de la prise électrique.

4. Pour débrancher le purificateur d’air, appuyez

sur le bouton de mise en marche-arrêt pour

arrêter l’appareil, saisissez la fiche et retirez-la

de la prise électrique. NE tirez JAMAIS sur

le cordon.

5. DO NOT use any product with a damaged cord

or plug, any product that malfunctions, or any

product that has been dropped or damaged in

any manner.

6. N’UTILISEZ pas le purificateur d’air à l’extérieur

de la maison.

7. DO NOT use air purifier unless it is fully

assembled.

8. NE FAITES PAS passer le cordon d’alimentation

sous un tapis ou une carpette. Arrange cord

such that it will not be a tripping hazard.

9. N’UTILISEZ PAS le purificateur d’air là où il y a

des gaz ou des vapeurs.

10. N’EXPOSEZ PAS le purificateur d’air à la pluie,

et ne l’utilisez pas à proximité de l’eau, comme

QUIETCLEAN

PURIFICATEUR D’AIR

OSCILLANT À

COLONNE

MODÈLE DE LA SÉRIE HFD230

Guide d’utilisation

dans une salle de bains, une salle de lavage ou

tout autre endroit humide.

11. Le purificateur d’air doit demeurer en position

verticale.

12. Ne laissez pas des corps étrangers pénétrer

dans les ouvertures de ventilation ou

d’échappement, car ils risquent de causer un

choc électrique ou d’endommager l’appareil.

NE BLOQUEZ PAS les entrées ni les sorties d’air.

13. Placez le purificateur d’air près d’une prise et

n’utilisez pas de rallonge électrique.

14. Cet appareil est muni d’une fiche polarisée

(une des deux broches est plus large que

l’autre). To reduce the risk of electric shock,

this plug is intended to fit only one way in

a polarized outlet. Si les broches n’entrent

pas complètement dans les trous de la prise,

tournez la fiche dans l’autre sens. Si elles

n’entrent toujours pas, communiquez avec un

électricien qualifié. N’ESSAYEZ PAS d’altérer

ce dispositif de sécurité.

15. La présence d’un jeu entre la prise (réceptacle)

et la fiche peut causer une surchauffe et une

distorsion de celle-ci. Communiquez avec un

électricien qualifié pour remplacer la prise usée

ou instable.

16. NE VOUS ASSOYEZ ou ne montez pas sur

l’appareil; ne placez pas d’objets lourds

sur le purificateur d’air.

17. Débranchez l’appareil avant de procéder

à son entretien.

Remarque : Pour avoir de l’information sur la

conformité FCC, veuillez consulter la dernière

page de ce manuel.

AVERTISSEMENT : Pour réduire les risques

d’incendie ou de choc électrique, n’utilisez pas ce

purificateur d’air avec un dispositif de réglage de

vitesse à circuit intégré, quel qu’il soit.

VOTRE PURIFICATEUR D’AIR

FONCTIONNEMENT DE VOTRE PURIFICATEUR D’AIR

MEILLEURE RÉTENTION DES ODEURS

INSTALLATION

• Choisissez un endroit où le sol est ferme, plat et à niveau. Pour assurer une meilleure circulation de l’air, placez

l’appareil à 6 pouces (15,2 cm) de tout mur ou meuble.

Préfiltre

à rétention

d’odeurs

optionnel

(emballé dans un

sac de plastique)

(l’entrée d’air se

situe à l’arrière de

la grille et la sortie

se situe devant

la grille)

Permanant

Washable

ifD

Particle

Filters (2)

Grille

arrière

Préfiltre

lavable

préinstallé

(1)

Panneau de

commande

avec poignée

intégrée

The washable pre-filter comes installed in your air purifier and removes larger particles from the air that

passes through the filter. Vous pouvez utiliser ce préfiltre lavable, ou si vous préférez, utiliser le préfiltre

optionnel qui réduit les odeurs et les composés organiques volatils (COV). Le préfiltre

est emballé

dans un sac à part qui accompagne le purificateur d’air. En plus de retenir les plus grosses particules, le

préfiltre

est aussi capable de capter les odeurs et les fumées ménagères les plus courantes. Si vous

décidez d’utiliser le préfiltre

, vous devez retirer le préfiltre lavable préinstallé et mettre le préfiltre

sa place. Remove

Pre-filter from plastic bag before use.

Remarque : Le préfiltre

n’est pas lavable et doit être remplacé aux trois mois pour un rendement optimal.

REMARQUE : Veuillez n’utiliser qu’un seul préfiltre à la fois dans votre purificateur d’air. You will need to

choose whether you want to use the permanent washable pre-filter or the replaceable pre-filter.

Ce modèle de purificateur d’air comporte un système de

nettoyage de l’air en trois étapes, pour aider à purifier l’air

qui traverse le filtre de l’appareil (Fig. 1).

Étape 1 : Le préfiltre lavable ou le préfiltre

à rétention

d’odeurs et de COV (votre choix) se fixe à la grille

arrière. Capte les plus grosses particules dans

l’air et retient les odeurs et les COV (lorsqu’il est

utilisé avec le préfiltre optionnel).

Étape 2 : Permanent Washable ifD

Particle Filter.

Capte les particules microscopiques dans l’air.

Étape 3 : L’ioniseur électronique augmente la puissance de purification.

Préfiltre lavable ou

à rétention

d'odeurs

Air

ambiant

Air plus

propre

ifD

Particle Filter

Champ de

l'ioniseur

Système de purification en 3 étapes

Fig. 1

10 11

MISE EN MARCHE

Les purificateurs d’air portatifs sont plus efficaces dans des pièces dont

toutes les portes et fenêtres sont fermées. It is recommended that you run your air purifier while

you are at home to help clean the air.

• Assurez-vous que le purificateur d’air est bien branché à une prise électrique

fonctionnelle.

• Appuyez une fois sur le bouton de mise en marche (

). L’appareil se met

en marche à vitesse moyenne pour quelques secondes, puis passe

automatiquement en basse vitesse (Fig. 2).

• Enfoncez à nouveau le bouton de mise en marche pour sélectionner un autre

niveau d’épuration de l’air.

Fig. 2

ENERGY STAR

Cet appareil a reçu l’homologation ENERGY STAR

, car il satisfait aux exigences d’efficacité

énergétique très sévères édictées par l’Agence pour la protection de l’environnement (EPA)

des États-Unis. L’EPA ne se porte aucunement garante des allégations du fabricant quant à la

capacité de ce produit d’assainir l’air.

L’efficacité énergétique de ce modèle homologué ENERGY STAR

est mesurée par un calcul du rapport

entre le débit d’air purifié (DAP) pour la poussière et l’énergie électrique consommée, soit DAP/watt.

OPTION DE GRADATION DE L’INTENSITÉ LUMINEUSE

Le gradateur ( ) vous permet de régler la luminosité des voyants DEL sur le

panneau de commande, si vous voulez la moduler en fonction de la pièce où

l’appareil se trouve.

• L’appareil se met toujours en marche avec la luminosité réglée à l’intensité ÉLEVÉE

• Appuyez une fois sur le bouton ( ) pour passer à une faible intensité

lumineuse (Fig. 3).

• Les voyants DEL ne peuvent pas être complètement éteints.

• Pressing the (

) button a 2nd time will turn the LED brightness back to HIGH.

Fig. 3

OPTION D’OSCILLATION

Pour faciliter la circulation d’un air plus frais et plus propre dans toute la

pièce, cet appareil est doté d’une fonction d’oscillation.

• Pour mettre l’oscillation en marche, il suffit d’appuyer sur le bouton

d’oscillation (

) (Fig. 4).

• Pour arrêter l’oscillation, appuyez de nouveau sur ce bouton.

Fig. 4

NETTOYAGE DES FILTRES ifD

Le filtre ifD

doit être nettoyé environ tous les 3 mois.

Éteignez et débranchez le purificateur d’air. Après avoir retiré le filtre ifD

du purificateur d’air, lavez-le en suivant les instructions ci-dessous.

• Rincez le filtre à l’eau claire du robinet (Fig. 7).

• Si le filtre semble encore sale, passez à la section « Nettoyage »; s’il est propre,

passez à la section « Séchage ».

Nettoyage :

• Retirez les filtres ifD

de l’appareil.

• Remplissez l’évier d’eau tiède et ajoutez quelques gouttes de détergent doux pour la vaisselle.

• Agitez les filtres doucement dans la solution savonneuse pour les nettoyer.

• Laissez tremper les filtres pendant 2 ou 3 minutes. Ne les laissez pas tremper trop longtemps.

• Rincez les filtres à l’eau claire du robinet (Fig. 7) et passez au séchage.

Fig.7

COMMENT ENLEVER LES FILTRES

AVERTISSEMENT : Éteignez le purificateur d’air et attendez 60 secondes avant d’enlever la grille pour

nettoyer les filtres.

Le filtre ifD

est fourni avec le purificateur d’air.

• Éteignez le purificateur d’air. Attendez 60 secondes et débranchez l’appareil avant

d’enlever la grille.

• Tout en appuyant sur la languette de la grille arrière, tirez celle-ci vers vous pour

l’enlever (Fig. 6).

• D’une main, tenez le purificateur d’air solidement et de l’autre main, saisissez le filtre

ifD

et retirez-le. Répétez l’opération pour le second filtre.

• Pour replacer le filtre ifD

dans le boîtier du purificateur d’air, insérez-le par le bas et

assurez-vous de le pousser le plus loin possible, puis insérez-le par le haut. Répétez

l’opération pour le second filtre.

Fig. 6

RAPPEL ÉLECTRONIQUE D’ENTRETIEN DES FILTRES

Bouton de vérification des filtres - Lorsqu’il est temps de vérifier et de nettoyer

les filtres, un voyant s’allume. Lorsque le voyant est allumé, vous devez nettoyer

le filtre ifD

et nettoyer ou remplacer le préfiltre. (Voir les instructions sur le

nettoyage des filtres aux pages 11 et 12.) Nous vous recommandons de vérifier

périodiquement les filtres.

Selon les conditions d’utilisation de l’appareil, vous devriez nettoyer les filtres tous

les trois mois. Si vous avez choisi d’utiliser le préfiltre

à rétention d’odeurs et

de VOC, celui-ci n’est PAS lavable et devrait être remplacé après 3 mois. Après

avoir nettoyé ou remplacé les filtres, vous devrez RÉINITIALISER l’indicateur

électronique d’entretien des filtres

RÉINITIALISATION de l’indicateur électronique d’entretien des filtres :

Une fois que les filtres ifD

et le préfiltre ont été nettoyés ou remplacés et replacés dans l’appareil,

branchez celui-ci mais laissez-le éteint. Appuyez sur le bouton de vérification des filtres (voir la fig. 5) et

maintenez-le enfoncé pendant 3 secondes. Le voyant DEL de VÉRIFICATION DES FILTRES clignotera deux

fois indiquant que l’indicateur d’entretien des filtres a été réinitialisé. Le voyant DEL ne sera plus allumé.

Ces intervalles d’entretien ne sont fournis qu’à titre d’indication. Le rendement de n’importe quel

système de filtration d’air dépend de la teneur en contaminants de l’air qui traverse les filtres. De fortes

concentrations en contaminants tels que la poussière, les squames des animaux familiers et la fumée de

tabac réduisent la durée de vie utile d’un filtre qui peut devoir être nettoyé plus souvent.

Fig. 5

INSTALLATION (SUITE)

• Pendant que le purificateur est en marche, de grands volumes d’air sont attirés vers l’appareil. La zone

environnante devrait être nettoyée ou passée à l’aspirateur fréquemment, afin d’empêcher l’accumulation de

poussière et d’autres contaminants. Cette mesure pourrait aussi aider à prolonger la durée de vie du filtre. Si

l’appareil est placé sur un tapis de couleur pâle, il est conseillé de placer une petite natte ou carpette en dessous

pour prévenir des taches sur le tapis. Cette recommandation est particulièrement importante dans les foyers où

l’air est contaminé par la fumée de tabac ou de cheminée.
