1. SAFETY
9 Always load evenly with the centre of gravity of the load as near the centre and rear of the plate as possible.
9 Obtain additional support for large or wide loads to prevent tipping.
8 DO NOT overload the truck - see Specication.
8 DO NOT leave unattended, especially when loaded, unless the wheels are chocked or the truck is otherwise secured.
8 DO NOT use truck on uneven ground and do not run over curbs or steps - use a ramp.
8 DO NOT allow others to ride on the truck.
8 DO NOT use the truck if any part is damaged, paying particular attention to the wheels.
2. INTRODUCTION
Heavy-duty tubular steel construction with welded joints with a 200/250kg capacity. Puncture proof heavy-duty PU tyres with powder
coated steel hubs and tted with knuckle protecting D-shaped handle grips.
3. SPECIFICATION
Model No: ........................CST983HD ............................CST986HD ............................. CST987HD
Capacity: ..................................200kg .....................................250kg ......................................250kg
Height(s): ............................. 1150mm .................................1150mm ..................................1220mm
Overall Width: ........................470mm .................................. 525mm ....................................540mm
Platform Depth: ...................... 220mm .................................. 180mm ....................................250mm
Wheel Bore Size: .................. Ø16mm ..................................Ø16mm ................................... Ø16mm
Wheel Size: ......................... Ø210mm ................................Ø250mm ................................. Ø250mm
Wheel Width: ............................55mm .................................... 85mm ......................................85mm
HEAVY-DUTY SACK TRUCK WITH PU TYRES
MODEL NOS: CST983HD, CST986HD, CST987HD
CST983HD, CST986HD, CST987HD Issue 2 (H,2,F) 08/06/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear safety
footwear
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
CST983HD CST986HD CST987HD
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 3 years from purchase date, proof of which is required for any claim.
REGISTER YOUR
PURCHASE HERE
4. ASSEMBLY
4.1. WHEELS
4.1.1. Ensure axle is clean from dust and dirt to allow free movement of the wheel.
4.1.2. For Model No. CST987HD the axle (fig.1.1) needs to be put through the frame before the wheels can be attached.
4.1.3. Slide the wheel (fig.1.2) onto the axle, put on the washer (fig.1.3) and complete by pushing the split pin (fig.1.4) through the hole in the end of
the axle and bending over to retain.
4.1.4. Repeat for the other side.
g.1
