1
I. Button operation &
function instruction
5s
x2
Double-click
x1
Short press
Long press
1. Button operation
(1) Short press the button:
➀ When the screen is locked, short press
the power button to unlock it.
➁ When on Home page, short press the
power button to enter the function list.
➂ When on other pages, short press the
power button to return to the Home
page.
➃ When on Sports page, short press the
power button to end sports.
(2) Double-click the
button: When on
function list page,
double-click the
power button to
switch menu style.
(3) Long press the
button: Turn on/off
the watch
2
Supports full screen touch control, you
can swipe up/down/left/right, or long
press the screen.
Single click
Long press
Swipe up
Swipe down
Swipe left
Swipe right
Interface
requirement
Any page
Home page
Home page
Home page
Home page
Home page
Select, confirm
After long pressing for
2 seconds, swipe
left/right to switch
shortcut page
Check messages and
notifications
Check shortcut menu
Check date, weather,
APP QR code, recently
used functions, etc.
Use shortcut functions,
such as sports data,
heart rate
measurement, sleep
data, etc. You can also
customize the display
of shortcut functions
FunctionOperation
2. Screen control
3
1. Scan the QR
code below
with your
mobile phone
to download
the FitCloudPro
APP, register an
account and
log in.
2. Note: The phone system is required to
be Android 8.0 or iOS 12.0 or above.
3. Open the APP, select “Device→Add
Peripheral Now→Search Now→Bind
Success”.
II. Downloading APP and
pairing the watch
+Add
Peripheral Now
Device
Device MeHome
Device MeHome
Search Now
1 2
Binding
equipment
Binding
equipment
3 4
JR-FT3 Pro
4
4. After binding successfully, you can start
to use all the functions of the watch, and
the data generated by it can also be saved
to the APP synchronously.
5. If you need to unbind the watch, please
open the APP, and select “Device→
Unbind”.
Notes: ➀ Please keep the phone’s BT function
on during use, otherwise the messages on the
phone cannot be synchronized to the watch;
➁ Select "Device→Message Reminder→Enable
Related APP Permissions" on the APP, then
relevant messages will be synchronized to the
watch, such as call reminders and message
reminders.
Successful bind icon:
Bind
Success
Binding
5 6
18:3018:30
5
After binding with APP, data can be
synchronized between the watch and the
mobile phone.If you need to use the call
and audio function of the watch, please
enable “Audio Mode” on the watch, and
connect it to your phone’s BT. An audio
protocol will be automatically established
between the watch and the phone.Refer
to the figure below for the connection
method:
1. At the Home page: “Swipe Down→Call
Icon→Audio Mode→Enable”
III. Wireless connection
and pairing:
18:30
Audio Mode
开启后，即可正常使
用通话和音乐播放功
能。
1 2
3
Audio Mode
开启后，即可正常使
用通话和音乐播放功
能。
JR-FT3 Pro_LE
4
6
2. Turn on
your phone’s
BT function,
search for
“JR-FT3
Pro_LE” and
pair with it.
3. After connecting successfully, you can
start to answer/make calls via the watch.
4. If you are an Android user, please
enable the call and audio options in the
BT interface of your phone. Refer to the
figure below for related operation
method:
Note: After BT connection, the "Audio
Mode" of the watch should be kept on,
otherwise the call function cannot be
used.
For example: When disconnected from
the BT function, the "Audio Mode" of the
watch will automatically turn off and enter
power saving mode. At this time, you
need to connect the BT function again
according to above operation instructions.
JR-FT3
Pro_LE
Connected
JR-FT3
Pro_LE
通话
音频
JR-FT3
Pro_LE
7
1. Charging the watch: Align the magnetic
charging cable with the metal contact of
the watch, connect the other end to the
charger and connect power until the
screen displays charging capacity.
IV. Charging & turning
Note:
When the watch indicates
low battery, please charge it
in time. It is recommended
to use a charger with a
rated output of 5V/1A or a
computer USB port
together with the included
cable to charge it.
8
1. To assemble/disassemble the watch
band, please refer to the figure below:
2. To wear the watch properly, please refer
to the figure below:
Note:
When wearing the watch, please keep it in
comfortable contact with wrist skin (in proper
tightness). Do not wear it on the wrist joint.
V.Assembling/disassembling
1
Operation instructions:
1. Short press power button→Sports→Enter
Sports Mode
(Please wear the watch properly when
doing sports, and you can check such
data as sports time, heart rate, calorie
consumption, steps, etc. on the watch)
2. To quit Sports Mode, just short press the
power button and select “Quit”.
VI. Built-in with 20
Sports Modes
Yoga
Swimming
GolfHula
hoop
Football
Walking
Sit-ups
Tennis
Badminton
Long jump
Baseball
BasketballRunning
Rope
skipping
Volleyball
CyclingMountain
RugbyTable
tennis
Elliptical
2
Check sports record
After binding the watch to phone APP,
the sports data will be synchronized to the
APP. You can check the daily, weekly and
monthly sports data statistics on the APP’
Home Page. Click a sports record to check
the detailed sports data.
Set a sports goal
You can set a goal for your sports on the
phone APP. Open FitCloudPro APP and
select “My→Sports Goal” to set a goal for
steps, distance and calorie consumption.
3
To ensure the accuracy of the
measurement, please keep the wrist
skin clean, keep the watch in close
contact with your wrist, and keep the
screen upward and still.
VII. The watch can test
three health metrics: heart
rate, blood oxygen and
blood pressure
1. Heart rate measurement
85 BPM
Measurement
successful
4
4. Sleep quality monitoring
Sleep monitoring is to monitor the state
of people from they fall asleep to wake up
naturally. The watch can record the time
of deep sleep and light sleep.
Deep sleep refers to such a state as small
The measurement results are for reference only and
should not be taken as the basis for medical diagnosis.
If you feel unwell, please see a doctor in time.
2. Blood oxygen measurement
3. Blood pressure measurement
112
5
body movement and low heart rate
during sleep.
Light sleep refers to such a state as big
body movement and high heart rate
during sleep.
The default sleep monitoring starts from
9: 30 p.m. to 12: 00 p.m. of the next day.
When sleeping out of this time period, the
sleep data will not be recorded or
displayed. When sleeping, you need to
wear the watch properly.
Note: The monitoring results may differ
due to different watch wearing status.
13
1. Dial
The watch supports dialing function.
When you need to make a phone call, you
can enter the number on the watch →
Keypad to make calls;
Note: when using this function, you need
to keep: ➀ The phone APP and the watch
connected normally; ➁ BT function of the
phone and that of the watch connected
normally. (Please refer to the User Manual
for connection operation)
2. Frequent Contacts
The watch supports Frequent Contacts
function. After adding a frequent contact
number on the phone APP, you can select
the contact on the watch to make a call
with just one click, there’s no need to dial
on the keypad again.
➀ Short press the
power button,
select “Dial” in the
function list.
➁ Enter the phone
number in the
dialing interface,
then press to
make a call.
Operation instructions
14
3. Call Records
The watch supports call record search
function. In the Call Records, you can
check the recent call records (including
incoming, outgoing and missed calls).
When you click any one of them, you can
call it back.
➀ Open FitCloudPro APP, select “Device→
Frequent Contacts→Add”.
➁ Short press the power button, select
“Frequent Contacts” in the function list.
➂ Click the desired frequent contact to
make a call to it.
Operation instructions
➀ Short press the power button, select
“Call Records” in the function list.
➁ Swipe up or down to view the call
records, click a desired record to make a
call to it.
Operation instructions
Note: when using this function, you need
to keep: ➀ The phone APP and the watch
connected normally; ➁ BT function of the
phone and that of the watch connected
normally. (Please refer to the User Manual
for connection operation)
15
4. Voice Assistant
The watch supports Voice Assistant
function. You can click the Voice Assistant
on the watch to wake up Voice Assistant
of the phone.
Note: when using this function, you need
to keep: ➀ The phone APP and the watch
connected normally; ➁ BT function of the
phone and that of the watch connected
normally. (Please refer to the User Manual
for connection operation)
5. Message Notifications
The watch can synchronously receive calls
and text messages sent to the phone, as
well as messages sent to application
software as Wechat, QQ, Facebook,
Twitter, Instagram, Skype, WhatsApp,
Line, Kakao Talk etc., and prompt you by
vibration.
Note: When using this function, it is
necessary to keep the phone APP and the
watch connected normally.
➀ Short press the power button, select
“Voice Assistant” in the function list.
➁ Click , then you can give commands
to your watch, for example, "What's the
weather like today?"
Operation instructions
16
➀ Open FitCloudPro APP, select “Device→
Message Notifications” and turn on
related push notifications.
➁ When there is a new message
notification on the phone, the watch will
prompt you by vibration. You can swipe
up on the Home Page of the watch to
enter the Unread Message Center and
check the unread message.
Operation instructions
6. Music Control
The watch supports Music Control
function. You can operate on the watch to
control music on the phone, such as
pause, play, skip to previous/nest song
and adjust volume.
Note: when using this function, you need
to keep: ➀ The phone APP and the watch
connected normally; ➁ BT function of the
phone and that of the watch connected
normally. (Please refer to the User Manual
for connection operation)
Operation instructions
➀ Short press the power button, select
“Music” in the function list.
➁ Open the music APP on your phone
and play music.
➂ In the music playing interface, you can
click the watch screen to control music on
17
the phone, such as pause, play, skip to
previous/nest song and adjust volume.
7. Stopwatch
The watch supports complete timing and
segmented timing operation. For
segmented timing, the watch can store
up to 10 records.
Operation instructions
➀ Short press the power button, select
“Stopwatch” in the function list.
➁ Click to start counting.
➂ Click to record the time in
segments. After clicking Pause, click it
again to check the segmented records.
➃ Click to pause the stopwatch, and
click to reset it.
8. Timer
The watch supports specifying time
length and customizing timer operation.
Operation instructions
➀ Short press the power button, select
“Timer” in the function list.
➁ Select time length as needed, click to
start the timer.
➂ Click to pause the stopwatch, and
click to reset it.
18
Customizing timer
➀ Short press the power button, select
“Timer” in the function list.
➁ Swipe up/down on the Timer Page,
click Customize.
➂ After setting Hour, Minute and Second,
click Confirm to realize Timer
customization.
9. Alarm
The watch supports alarm reminder
function. After setting an alarm on the
APP, the watch will remind you on time
by vibration.
Operation instructions
➀ Open FitCloudPro APP, click “Device→
Watch Alarm→+ (in the top right corner)”,
and you can set the time and repeat cycle
of the alarm as needed.
➁ After setting successfully, click “Save” in
the top right corner.
Turn off and delete Alarm
➀ Open FitCloudPro APP, click “Device→
Watch Alarm→Existing Alarm→” to turn off
the alarm.
➁ Enter the “Existing Alarm→Delete
Alarm” to delete the alarm.
19
10. Settings
In Settings, you can customize the watch
menu style, screen display, language
switch, unlock password, etc.
(1) Menu style switch
Operation instructions
➀ Short press the power button, select
“Settings→Menu Style” in the function list.
➁ After selecting the desired menu style,
click it again, the menu style will be set
successfully.
(2) Screen display
Operation instructions
➀ Short press the power button, select
“Settings→Screen Display” in the function
list.
➁ In this interface, you can adjust the dial
style, screen brightness, auto-lock time
and tilt auto-lock time as needed.
(3) Language Switch
The watch supports switching between 10
languages, including Chinese, English,
German, Russian, Spanish, Portuguese,
French, Japanese, Italian and Polish.
The mobile phone supports simultaneous
20
upgrading of 27 languages, including:
Chinese, traditional Chinese, English,
German, French, Italian, Spanish,
Japanese, Polish, Russian, Portuguese,
Korean, Vietnamese, Arabic, Hebrew, Thai,
Croatian, Turkish, Czech, Dutch, Indonesia,
Malaysia, Finnish, Greek, Romanian, Hindi
and Persian.
Operation instructions (watch)
➀ Short press the power button, select
“Settings→Language” in the function list.
➁ Swipe up or down to select the desired
language, √ indicates the currently set
language.
Note: This setting only changes the
language on the watch. If you need to
synchronize it to the phone, please
conduct the following operation steps on
the phone:
Operation instructions (phone)
➀ Change language in phone Settings.
➁ Open FitCloudPro APP on the phone,
make wireless connection with the watch
(For detailed connection steps, refer to
User Manual).
➂ After connecting successfully, the
watch language will automatically change
with the phone system.
Note: If the phone APP and the watch are
already connected, please open the
21
FitCloudPro APP and refresh it after the
mobile phone switches languages.
(4) Unlock Passcode
You can set an Unlock Passcode on the
watch to protect your privacy.
Operation instructions
➀ Short press the power button, select
“Settings→Passcode→Turn Passcode On” in
the function list. After setting the
password successfully, when the watch
screen is locked, you need to enter the
password to unlock it.
➁ The Unlock Passcode can also be
turned off according to above operations.
11. Find My Watch & Find My Phone
➀ Click "Find My Watch" function on the
phone APP. After finding the watch, the
watch will prompt you by vibration, so
that you can find it.
➁ Or click "Find My Phone" function on
the watch. After finding the phone, the
phone will prompt you by ringtone, so
that you can find it.
22
12. Shake to Take Pictures
Click “Shake to Take Pictures” on the
phone APP, a photography icon will
appear on the watch. When you shake
your wrist, you can count down to take a
picture.
Note: When using this function, you need
to keep the phone APP and the watch
connected normally.
Operation instructions
➀ Wear the watch properly on your wrist.
➁ Open FitCloudPro APP, select “Device→
Shake to Take Pictures”, click to enter the
function.
➂ Shake your watch, the phone will show
a 3-second countdown, after that, it will
prompt photography success.
23 24
1. Turning on and connecting
Q: Why can’t the watch be turned on?
A: ➀ It may be that you did not press it
long enough or you pressed at a wrong
position. Please press and hold the power
button for more than 5 seconds.
➁ Or that the battery of the watch is too
low. Please charge the watch for 1 hour
before use.
Q: Why the BT function is not connected
or cannot be connected?
A: ➀ The address code may be incorrect.
Please check whether the BT address
code of the watch is consistent with that
of the phone APP.
➁ The watch may be connected to
another phone. You need to delete or
disconnect the device name from the
phone before using. A watch can only be
connected to one mobile phone. Please
restart the BT function on your phone and
connect again.
➂ Please restart the BT function of the
watch and the phone and make a
reconnection.
2. Accuracy of measurement
Q: Why is the measurement of heart
FAQ
rate/blood pressure/blood oxygen
inaccurate?
A: Generally, it is caused by poor contact
between the sensor of the watch and the
human body. During measurement,
please keep the sensing area of the watch
in full contact with the wrist, no foreign
matter is allowed between. Do not wear it
on the wrist joint or wear it too loosely.
When doing sports, please wear the
watch a little bit more tightly than usual.
Q: Why is sleep data inaccurate?
A: ➀ Sleep monitoring is to monitor the
state of people from they fall asleep to
wake up. The watch must be worn
properly during sleep.
➁ If you go to sleep too late or start to
wear it just before falling asleep, the sleep
data may be inaccurate.
➂ The default sleep monitoring time
begins at 21:30 p.m. and stops at 12:00 p.m.
of the next day. Sleep data is not
monitored out of this period.
3. Message synchronization
Q: Why can't the watch sync phone
message?
A: ➀ The message reminder permission
may not be enabled. Please open
FitCloudPro APP, select “Device→Message
Reminder”, and check whether the
23 24
1. Turning on and connecting
Q: Why can’t the watch be turned on?
A: ➀ It may be that you did not press it
long enough or you pressed at a wrong
position. Please press and hold the power
button for more than 5 seconds.
➁ Or that the battery of the watch is too
low. Please charge the watch for 1 hour
before use.
Q: Why the BT function is not connected
or cannot be connected?
A: ➀ The address code may be incorrect.
Please check whether the BT address
code of the watch is consistent with that
of the phone APP.
➁ The watch may be connected to
another phone. You need to delete or
disconnect the device name from the
phone before using. A watch can only be
connected to one mobile phone. Please
restart the BT function on your phone and
connect again.
➂ Please restart the BT function of the
watch and the phone and make a
reconnection.
2. Accuracy of measurement
Q: Why is the measurement of heart
FAQ
rate/blood pressure/blood oxygen
inaccurate?
A: Generally, it is caused by poor contact
between the sensor of the watch and the
human body. During measurement,
please keep the sensing area of the watch
in full contact with the wrist, no foreign
matter is allowed between. Do not wear it
on the wrist joint or wear it too loosely.
When doing sports, please wear the
watch a little bit more tightly than usual.
Q: Why is sleep data inaccurate?
A: ➀ Sleep monitoring is to monitor the
state of people from they fall asleep to
wake up. The watch must be worn
properly during sleep.
➁ If you go to sleep too late or start to
wear it just before falling asleep, the sleep
data may be inaccurate.
➂ The default sleep monitoring time
begins at 21:30 p.m. and stops at 12:00 p.m.
of the next day. Sleep data is not
monitored out of this period.
3. Message synchronization
Q: Why can't the watch sync phone
message?
A: ➀ The message reminder permission
may not be enabled. Please open
FitCloudPro APP, select “Device→Message
Reminder”, and check whether the
25 26
message reminder permission of relevant
application software is enabled.
➁ The watch may be in "Do Not Disturb"
Mode. Please swipe down at Home Page→
- and close "Do Not Disturb" mode.
➂ The watch may be connected to
another phone. You need to delete or
disconnect it from the phone before
using. Note: A watch can only be
connected to one mobile phone.
Q: Why can't the phone sync watch data?
A: ➀ Please check whether "Allow APP to
Run in the Background" is opened on the
mobile phone. If not, after the
background exits the watch APP, the
mobile phone will not synchronize its data
and connections. You need to reopen and
refresh the APP to have it synchronize
data.
➁ The connection range between the
watch and the phone is 10 meters. If they
are kept beyond that range, they will
disconnect automatically.
4. Battery and charging
Q: Why can't the watch be charged?
A: ➀ Please check whether the charging
contact of the watch and the charging pin
of the cable are blocked by foreign
matters. If so, use an alcohol cotton swab
to clean them before charging;
➁ When charging, align the magnetic
charging cable with the metal contact of
the watch, connect the other end to the
charger and connect power until the
screen displays charging capacity.
➂ We recommend using a computer USB
port or a brand charger together with the
included cable to charge the watch.
For more FAQs, please select
“Me→FAQ” on the APP
25 26
message reminder permission of relevant
application software is enabled.
➁ The watch may be in "Do Not Disturb"
Mode. Please swipe down at Home Page→
- and close "Do Not Disturb" mode.
➂ The watch may be connected to
another phone. You need to delete or
disconnect it from the phone before
using. Note: A watch can only be
connected to one mobile phone.
Q: Why can't the phone sync watch data?
A: ➀ Please check whether "Allow APP to
Run in the Background" is opened on the
mobile phone. If not, after the
background exits the watch APP, the
mobile phone will not synchronize its data
and connections. You need to reopen and
refresh the APP to have it synchronize
data.
➁ The connection range between the
watch and the phone is 10 meters. If they
are kept beyond that range, they will
disconnect automatically.
4. Battery and charging
Q: Why can't the watch be charged?
A: ➀ Please check whether the charging
contact of the watch and the charging pin
of the cable are blocked by foreign
matters. If so, use an alcohol cotton swab
to clean them before charging;
➁ When charging, align the magnetic
charging cable with the metal contact of
the watch, connect the other end to the
charger and connect power until the
screen displays charging capacity.
➂ We recommend using a computer USB
port or a brand charger together with the
included cable to charge the watch.
For more FAQs, please select
“Me→FAQ” on the APP
