BAUMR-AG TILSAWBMRAX80 650W Electric Tile Saw Cutter User Manual

User Manual

[Revision 3.0 December 2023]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

BTS80 7” Electric Tile Saw

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

•

Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

•

Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

•

Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

•

Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

•

The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

General Electrical Safety

•

Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

•

Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

•

The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

General Power Tool Safety Warnings

• W

ARNING! READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. FAILURE TO FOLLOW THE WARNINGS AND INSTRUCTIONS

MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY.

• Save all warnings and instructions for future reference.

• The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

•

Keep the work area clean and well lit. Cluttered or dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical Safety

•

Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges, and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

• Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the power tool. Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords increase the risk of electric shock.

• When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of

electric shock.

• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the

risk of electric shock.

Personal Safety

•

Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under

the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.

• Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions will reduce personal injuries.

• Prevent unintentional starting. Ensure the switch is in the off position before connecting to power source and/or battery pack, picking up or

carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may

result in personal injury.

• Do not overreach. Always keep proper footing and balance. This enables better control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewellery or

long hair can be caught in moving parts.

• If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust

collection can reduce dust related hazards.

• Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can

cause severe injury within a fraction of a second.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Power Tool Use and Care

•

Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for

which it was designed.

• Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must

be repaired.

• Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or

storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the

power tool. Power tools are dangerous in the hands of untrained users.

• Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power

tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

• Use the power tool, accessories, and tool bits etc. in accordance with these instructions, considering the working conditions and the work to be

performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

• Keep handles and grasping surfaces dry, clean, and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe

handling and control of the tool in unexpected situations.

Battery Tool Use and Care

•

Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire

when used with another battery pack.

• Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.

• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws, or other small metal objects

that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts

eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.

• Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in

fire, explosion, or risk of injury.

• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion. NOTE

The temperature “130°C” can be replaced by the temperature “265°F”.

• Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging

improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.

Service

•

Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power

tool is maintained.

• Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorised service providers.

Specific Safety Instructions

•

Check your power tool for damage before starting your work, particularly the diamond blade. All parts must be fitted properly and must meet all

requirements to guarantee the tool’s smooth operation. Any safety guards or any lightly damaged parts must be checked to see if they still

function properly before continuing the use of the tool. Moving parts, and the diamond- blade guard, must be fitted properly and must not jam. Do

not use tools that cannot be switched on or off with the switch.

• The diamond-blade guard must not be jammed or removed.

• A jamming guard must be repaired immediately.

• The riving knife must not be removed.

• The diamond blade must NEVER be exposed to sideways pressure; they can break, and the flying pieces become projectiles!

• Do not attempt to cut extremely small pieces from the tiles. Always make sure that the full surface of the tile is on the work table. The supplied

mitre guide can be used to push the tiles through the cutter. In the early stages of cutting, the tile must remain absolutely level to avoid the tile

moving up.

• Do not overload your tool. It is better and safer to work within the indicated power range. Do not cut materials other than tiles.

• Maintain your tools carefully. Keep the tools sharp and clean to work properly and safely.

• Follow the maintenance instructions and the instructions for replacing the diamond blade.

• Stand safely and maintain your balance. Avoid any unnatural body angles. Remain alert and pay attention to your work. Use common sense. Do

not use the machine when you cannot concentrate or when you are tired.

• Cracked or distorted diamond blades must be replaced.

• Type of disk: a diamond blade with a diameter of 180mm.

• Do not use diamond blades that do not meet the specifications in these instructions.

• Ensure that the diamond blade is secured properly and rotates in the correct direction.

Electrical Safety

When using electric machines always observe the safety regulations applicable in your country to reduce the risk of fire, electric shock, and

per

sonal injury. Read the following safety instructions and the enclosed safety instructions. Always check that the power supply corresponds to the

voltage on the rating plate.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Connecting to the Power Supply

•

Check that the power supply and plug used in accordance with tour tool. Have a look at the rating plate on the tile cutter. Any changes should

always be carried out by a qualified electrician.

• WARNING! THIS MACHINE MUST BE EARTHED.

• If not properly earthed this machine can cause an electrical shock. Be sure that the power supply outlet is earthed. If there is any doubt, have it

checked by a qualified electrician.

• WARNING! AVOID CONTACT WITH THE TERMINALS ON THE PLUG WHEN INSTALLING (REMOVING) THE PLUG TO (FROM) THE

POWER SUPPLY OUTLET. CONTACT WILL CAUSE A SEVERE ELECTRICAL SHOCK.

Replacing Cables or Plugs

Immediately throw away old cables or plugs when they have been replaced by new ones. It is dangerous to insert the plug of a loose cable in the

wal

l outlet.

Using Extension Cables

Only use an approved extension cable suitable for the power input of the machine. The minimum conductor size is 1.5mm2. When using a cable

r

eel always unwind the reel completely.

Intended Use

This tool is suitable for cutting various wall and floor tiles. It is not permitted to use the tool for any other materials.

Vibration Level

The vibration emission level stated in this instruction manual has been measured in accordance with a standardized test given in EN 62841; it may

be us

ed to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications

mentioned.

• Using the tool for different applications, or with different or poorly maintained accessories, may significantly increase the exposure level.

• The times when the tool is switched off or when it is running but not actually doing the job, may significantly reduce the exposure level. Protect

yourself against the effects of vibration by maintaining the tool and its accessories, keeping your hands warm, and organizing your work patterns.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 6

Parts Identification ....................................................................................................................................... 9

Assembly ..................................................................................................................................................... 10

Mounting the cutting wheel ....................................................................................................................................... 10

Assembly of the Riving Knife .................................................................................................................................... 12

Installing the Guard ................................................................................................................................................... 13

Replacing the Cutting Wheel .................................................................................................................................... 14

Install the Parallel Guide ........................................................................................................................................... 16

Installing the Mitre Guide .......................................................................................................................................... 16

Installing the Overflow Drain ..................................................................................................................................... 17

Filling the Water Reservoir ....................................................................................................................................... 18

Changing the Reservoir Water ................................................................................................................................. 19

Operation ..................................................................................................................................................... 21

Switching ON/OFF .................................................................................................................................................... 21

Straight Cuts ............................................................................................................................................................. 22

Mitre Cut ................................................................................................................................................................... 23

Bevel Cut .................................................................................................................................................................. 24

Transporting the Tile Cutter ...................................................................................................................................... 26

Maintenance ................................................................................................................................................ 28

Specifications ............................................................................................................................................. 28

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Parts Identification

No. Name No. Name

1 ON/OFF switch 13 Parallel guide

2 Parallel guide scale 14 Parallel guide knob

3 Bevel table 15 Hex wrench

4 T

ransport handle 16 Spindle wrench

5 Bevel table handle 17 Wheel nut

6 T

able drain 18 Spindle

7 Cutting wheel 19 Lower blade guard

8 Riv

ing knife 20 Inner wheel flange

9 Guard knob 21 Outer wheel flange

10 G

uard 22 Overflow drain

11 Mitre guide knob 23 Max water fill line

12 M

itre guide 24 Water reservoir

Note: Some listed parts will be shown in the other images throughout this manual.

Spare parts available

for purchase, scan QR

code below:

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Assembly

CAUTION! FIRST REMOVE THE PLUG FROM THE MAINS BEFORE THE CUTTING WHEEL IS

ASSEMBLED OR REPLACED. CRACKED OR DISTORTED DIAMOND BLADES MUST BE REPLACED. DO

NOT USE DIAMOND BLADES THAT DO NOT MEET THE SPECIFICATIONS IN THESE INSTRUCTIONS.

ENSURE THAT THE DIAMOND BLADE IS SECURED PROPERLY AND ROTATES IN THE CORRECT

DIRECTION.

Mounting the cutting wheel

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

1. Pull the bevel table handle (5) and remove the bevel table (3).

2. Loosen the screw holding the lower blade guard (19), as shown on figure C.

3. Remove the lower blade guard (19).

4. Put the hex wrench (15) on the wheel nut (17) and the spindle wrench (16) on the spindle (18). Loosen the

nut with the wrenches, as shown on figure B.

5. Remove the nut (17) and the outside flange (21) from the spindle (18).

6. Mount the cutting wheel (7).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

7. Mount the outside flange (21) and afterwards add the wheel nut (17).

8. Tighten the nut by using the wrenches.

9. Now re-mount the lower blade guard (19) and fixate it by tightening the screw.

10. Put the bevel table (3) back in place. Ensure the notches on the left side of the bevel table (3) align with the

holes in the housing. Then press the table downwards, fixating the table.

Assembly of the Riving Knife

1. Unscrew the two (crosshead) screws and place the foot of the riving knife (8) on the table.

2. Mount the riving knife (8) by tightening the two screws.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Installing the Guard

1. Connect the guard to the riving knife (8) with the knob (9) and the locknut.

2. Tighten the knob (9).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Replacing the Cutting Wheel

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

1. Pull the bevel table handle (5) and remove the bevel table (3).

2. Loosen the safety guard’s knob (9) and remove the safety guard (10).

3. Loosen the screw holding the lower blade guard (19), as shown on figure C.

4. Remove the lower blade guard (19).

5. Put the hex wrench (15) on the wheel nut (17) and the spindle wrench (16) on the spindle (18). Loosen the

nut with the wrenches, as shown on figure B.

6. 6. Remove the nut (17) and the outside flange (21) from the spindle (18).

7. Replace the cutting wheel (7).

8. 8. Mount the outside flange (21) and afterwards add the wheel nut (17).

9. Tighten the nut by using the wrenches.

10. Now re-mount the lower blade guard (19) and fixate it by tightening the screw.

11. Put the bevel table (3) back in place. Ensure the notches on the left side of the bevel table (3) align with the

holes in the housing. Then press the table downwards, fixating the table.

12. Add the safety guard (10) on the riving knife (8) and tighten the knob (9).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Install the Parallel Guide

1. Turn knob (14) on parallel guide (13) anti-clockwise to loosen.

2. Attach the parallel guide (13) from the side of the table as shown on figure F.

3. Turn parallel guide knob (14) clockwise to tighten securely.

Installing the Mitre Guide

1. Slide mitre guide (12) onto parallel guide (13).

2. Adjust parallel guide to (13) desired position and secure.

3. Adjust to desired angle using angle scale and tighten securely with mitre guide knob (11).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Installing the Overflow Drain

(Fig. A & H)

1. Pull the bevel table handle (5) and remove the bevel table (3).

2. Push overflow drain (22) into hole firmly.

3. Put the bevel table (3) back in place. Ensure the notches on the left side of the bevel table (3) align with the

holes in the housing. Then press the table downwards, fixating the table.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Filling the Water Reservoir

1. Pull the bevel table handle (5) and remove the bevel table (3).

2. Fill water reservoir (24) with clean tap until the maximum fill line, as indicated on the overflow drain (22).

3. Put the bevel table (3) back in place. Ensure the notches on the left side of the bevel table (3) align with the

holes in the housing. Then press the table downwards, fixating the table.

Be aware that the overflow drain prevents overfilling. Water will overflow when you fill water above the fill line.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Changing the Reservoir Water

1. Pull the bevel table handle (5) and remove the bevel table (3).

2. Put the tile saw on a bucket.

3. Remove overflow drain (22).

4. Empty the reservoir (24) into the bucket.

5. Re-mount the overflow drain (22).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

6. Put the tile saw on a stable surface, for example on the ground.

7. Fill water reservoir (24) with clean tap water until the maximum fill line, as indicated on the overflow drain

(22).

8. Put the bevel table (3) back in place. Ensure the notches on the left side of the bevel table (3) align with the

holes in the housing. Then press the table downwards, fixating the table.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Operation

BEFORE STARTING THE JOB, PLEASE ENSURE THERE IS SUFFICIENT WATER IN THE WATER

RESERVOIR (24) I.E., THE DIAMOND BLADE MUST RUN THROUGH THE WATER. DURING THE JOB, THE

WATER RESERVOIR MUST BE TOPPED UP.

DO NOT START WORKING BEFORE THE MAXIMUM SPEED HAS BEEN REACHED. THE DIAMOND

BLADE MUST NEVER BE EXPOSED TO SIDEWAYS PRESSURE; THEY CAN BREAK, AND THE FLYING

PIECES BECOME PROJECTILES! ALWAYS KEEP THE MAINS CABLE AWAY FROM MOVING PARTS.

Switching ON/OFF

•

Press the switch (1) into position ‘1’ to put your machine into operation.

•

To switch OFF the machine the same switch (1) needs to be pressed to position ‘0’

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Straight Cuts

The parallel guide (13) enables you to cut parallel to the cutting blade and make straight cuts.

1. Loose the knob (14) and set the required distance.

2. Tighten the knob (14).

3. Position the tile on the table top.

4. Press the switch (1) into position ‘1’ to put your machine into operation.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

5. Maintain an even pressure, hold the tile against the cutting guide and push steadily through the cutting

wheel.

6. When the cut is complete, you can switch (1) OFF the machine.

Mitre Cut

Mitre 0-45° cuts can be made using the mitre guide (12).

1. Slide the mitre guide (12) into place on the parallel guide (13).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

2. Loose the knob (11) and set the required angle.

3. Tighten the knob (11).

4. Position the tile within the jaws of the mitre guide (12).

5. Press the switch (1) into position ‘1’ to put your machine into operation.

6. Push the mitre guide (12) steadily along the parallel guide (13), feeding the tile through the cutting wheel (7).

7. When the cut is complete, you can switch (1) OFF the machine.

Bevel Cut

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Beveled 22.5° and 45° cuts can be made by adjusting the angle of the bevel table (3).

1. Pull the bevel table handle (5).

2. Raise the bevel table (3) to the required angle, as shown on figure L1.

Make sure bevel table is locked firmly in place before beginning cut.

3. Position the tile on the bevel table (3), as shown on figure L2.

4. Press the switch (1) into position ‘1’ to put your machine into operation.

5. Maintain an even pressure, hold the tile against the cutting guide and push steadily through the cutting wheel

(7).

6. When the cut is complete, you can switch (1) off the machine.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Transporting the Tile Cutter

Before transporting the tile cutter, the following steps must be carried out:

1. Pull the mains plug.

2. Remove all accessories that cannot be mounted firmly to the power tool.

3. Wind the mains cable and bind it.

4. Remove bevel table (3).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

5. Put the tile saw on a bucket.

6. Remove overflow drain (22).

7. Empty the reservoir (24) into the bucket.

8. Replace overflow drain (22).

9. Put the tile saw on the ground.

10. For lifting or transport, use the transport handle (4).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

BTS80 7” Electric Tile Saw

Maintenance

Before cleaning and maintenance, always switch off the machine and remove the mains plug from the

mains.

•

Clean the machine casings regularly with a soft cloth, preferably after each use. Make sure that the

ventilation openings are free of dust and dirt.

•

Remove very persistent dirt using a soft cloth moistened with soapsuds. Do not use any solvents such as

gasoline, alcohol, ammonia, etc. Chemicals such as these will damage the synthetic components.

Specifications

Motor 650W Copper Rotor

Blade 180mm (7”) Diamond

Motor Speed 3000 RPM

Mitre Cuts 45°

Bevel Angles 22.5°, 45° (Edges only)

Max Cutting Depth 46mm @ 90°

Deck Size 345 x 345mm

Input Voltage 240V AC 50Hz

Power Plug Australian Standard

Note: Some Assembly Required

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

ideas, diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

BAUMR-AG TILSAWBMRAX80 650W Electric Tile Saw Cutter

Product's Documents

Product manual

Specifications

BAUMR-AG TILSAWBMRAX80 Questions and Answers
