1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Contents
Page No.
2 Contents
3
3
Reading and Storing the User Manual
Important Safety Instructions for Proper Use
7 Explanation of symbols
8 Description of Parts
8 Preparing for Use
9 Charging Your Hand Blender
9 Using Your Hand Blender with the Blender Attachment
10 Removing the Blender Attachment
10 Using Your Hand Blender with the Whisk Attachment
10 Removing the Whisk Attachment
11 Using Your Hand Blender with the Chopper Attachment
11 Removing the Chopper Attachment
12 Indicator lights
12 Battery life during use
12 Charging indication
12 Overload indication
12 Care and Maintenance
13 Cleaning Tips
13 To store
13 Technical specification
13 Customer support
14 Recycling information
Back Page Warranty information
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, safety precautions
should always be followed.
Only use the product as described in this user manual. Any
other use is considered improper and may result in damage
to property or persons.
The manufacturer or vendor cannot be held liable for
damages or injury incurred through improper or incorrect
use.
Read and familiarise yourself with all operating
instructions before using this hand blender.
Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
DO NOT use this Hand Blender with an extension cable.
Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
Close supervision is required when using this appliance
near children.
Never leave this appliance within reach of children.
This appliance shall not be used by children.
Keep the appliance and its USB cable out of reach of
children.
Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have given supervision or instruction
concerning use of the appliance in a safe way and
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
understand the hazards involved.
Children shall not play with the appliance.
Children less than 3 years should be kept away unless
continuously supervised.
DO NOT immerse the appliance or its USB cable in water
or any other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the USB cable after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
USB Cable, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the USB
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
• If the USB cable is damaged, it should only be replaced by
the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard.
• DO NOT allow the USB cable to hang over sharp edges or
come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Always disconnect the blender from the supply if it is left
unattended and before assembling, disassembling or
cleaning.
• This appliance is intended for household use only and
should not be used for industrial purposes.
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Switch off the appliance and disconnect from the supply
before changing accessories or approaching parts that
move in use.
• Grasp the plug, not the cord.
• DO NOT touch the blades whilst the blender is connected
to the mains.
• Wash the blades in warm soapy water, rinse and dry
thoroughly.
• CAUTION: the blades on this blender are very sharp;
extreme caution should be taken when cleaning.
Do not pull or carry the Hand Blender by the USB cable.
Do not bend or damage the USB cable.
Never operate with wet hands, or submerge in water or
spill liquids onto the appliance.
Do not cover the appliance while in use.
Only use the attachments supplied.
Do not operate by the means of external timer or any type
of separate remote control system.
Avoid contact with moving parts.
Keep hands and utensils out of the mixing bowl while the
Hand Blender is in use.
Do not attempt to charge the Hand Blender with any
other charge than the one provided.
WARNING: Keep hands, hair, clothes and utensils away from
moving parts. Use caution when attaching and removing
the attachments.
WARNING: The blending shaft blades are very sharp,
handle the blades very carefully and keep them out of
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
reach of children.
WARNING: Exercise caution when attaching or removing
attachments from the Hand Blender and ensure the
appliance is turned off and unplugged whilst fitting
attachments.
NOTE: The Hand Blender should not be used for more than
1 minute intervals. Ensure you allow a 10 minute rest
period offer every 1 minute cycle.
CAUTION: Always remove the USB cable from the Hand
Blender before use.
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk to find your nearest recycling point.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
13
Description of Parts
Preparing For Use
Carefully unpack the motor housing unit and all parts. Remove any tape, labels
or packaging materials.
Wash all product attachments carefully except for the motor housing unit with
warm, soapy water. Rinse and dry thoroughly.
Wipe exterior surfaces of the motor housing with a soft, moist cloth to remove
dust particles collected during packing and handling.
NEVER IMMERSE THE MOTOR HOUSING, USB CHARGING CABLE IN WATER
OR ANY OTHER LIQUID.
Ensure all parts are properly assembled and in place before use.
7
8
5
12
3
1
4
2
2
6
5
9
10
11
1. Variable Speed Control
2. Speed Button
3. Power Lock Button
4. Power Indicator Lights
5. Motor Housing Unit
6. Blender Attachment
7. USB Charging Port
8. Whisk Attachment
9. Chopper Lid
10. Chopper Bowl
11. Chopper Blade
12. Beaker
13. USB Charging Cable
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Charging Your Hand Blender
1. Open the USB Charging Port (7) on the Motor Housing Unit (5). Attach micro
end of USB Charging Cable (13) to the motor housing.
2. Attach the USB connector (larger end) into a suitable USB charger rated to at
least 1 Amp. (NB most USB chargers are rated 1 Amp or above). The internal
battery will begin to charge.
3. The Power Indicator Lights (4) will flash while charging. The lights will stop
flashing once the unit is fully charged. See indicator Light section for details.
Note: The unit is shipped with approximately 30% charge in the batteries. One
or two lights will be illuminated during use. It is recommended to fully charge
before first use for best performance.
4. It will approximately 2.5 hours to fully charge the unit.
Using Your Hand Blender with the Blender Attachment
1.
Add ingredients to a mixing jug or bowl. For best results make sure you chop
larger ingredients into smaller pieces first.
2.
Hold the Motor Housing Unit (5) in one hand and the Blender Attachment (6) in
the other. Make sure the Motor Housing Unit (5) and Blender Attachment (6)
are facing up and away from the body. Align the locking tabs on the Blender
Attachment (6) with the grooves on the Motor Housing Unit (5) of the Hand
Blender and turn the Motor Housing Unit (5) clockwise until it locks completely
into place.
CAUTION: Unplug the USB Charging Cable (13) from the Hand Blender before use
and attaching or removing attachments.
WARNING: The blender blade is very sharp, use caution when handling.
3.
Grasp the Hand Blender by the top of the Motor Housing Unit (5) and make
sure the blades are facing away from you.
4.
Place the
Blender Attachment (6)
inside a mixing jug or bowl. Make sure the
blades are fully immersed in the mixture. To operate the Hand Blender,
press the
Power Lock Button
(3), and promptly press the
Speed Button
(2).
Once you release the
Speed Button
(2) the motor unit will stop and lock.
5.
To operate the Hand Blender on high speed, press the
Power Lock Button
(3)
and promptly press the
Speed Button
(2) then turn on the
Variable Speed
Control
(1) to choose your desired speed.
Once you release the
Speed Button
(2)
the motor unit will stop and lock.
NOTE: After pressing the Power Lock Button (3) the Power Indicator Lights (4)
will flash, indicating you can select your desired speed using the Variable Speed
Control (1). If you delay making your selection the Hand Blender will
automatically lock to prevent accidental operation, the Power Indicator Lights
(4) will extinguish, and you will need to press the Power Lock Button (3) again.
NOTE: The Hand Blender should not be used for more than 1 minute intervals.
Ensure you allow a 10 minute rest period after every 1 minute cycle.
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Removing the Blender Attachment
1. To remove the Blender Attachment (6), hold the Motor Housing Unit (5) in one
hand and the Blender Attachment (6) in the other.
2. Make sure the Motor Housing Unit (5) and Blender (6) are facing up and away
from the body.
3. Turn the Motor Housing Unit (5) anticlockwise until the tabs release from the
grooves and pull the Blender Attachment (6) away from the Motor Housing
Unit (5).
WARNING: The Blender Attachment (6) blade may continue to spin after the
Hand Blender has been switched off. Make sure the blades have come to a
complete stop and the unit is off before lifting the Hand Blender from the mixing
jug or bowl.
Using Your Hand Blender with the Whisk Attachment
1.
Add ingredients to a mixing jug or bowl.
2.
Hold the Motor Housing Unit (5) in one hand and the Whisk
Attachment
(8)
in the other. Make sure the Motor Housing Unit (5) and Whisk
Attachment
(8) are facing up and away from the body. Align the locking tabs on the Whisk
Attachment
(8) with the grooves on the Motor Housing Unit (5) of the Hand
Blender and turn the Motor Housing Unit (5) clockwise until it locks
completely into place.
CAUTION: Unplug the USB Charging Cable (13) from the Hand Blender before
use and attaching or removing attachments.
3.
Grasp the Whisk
Attachment
(8) by the top of the Motor Housing Unit (5).
4.
Place the
Whisk
Attachment
(8)
inside a mixing jug or bowl. To operate the
Hand Blender, press the
Power Lock Button
(3), and promptly press the
Speed Button
(2). Once you release the
Speed Button
(2) the motor unit will
stop and lock.
5.
To operate the Hand Blender on high speed, press the
Power Lock Button
(3)
and promptly press the
Speed Button
(2), then turn on the
Variable Speed
Control
(1) to choose your desired speed.
Once you release the
Speed Button
(2)
the motor unit will stop and lock.
Removing the Whisk Attachment
4. To remove the Whisk
Attachment
(8), hold the Motor Housing Unit (5) in one
hand and the Whisk
Attachment
(8) in the other.
5. Make sure the Motor Housing Unit (5) and Whisk
Attachment
(8) are facing up
and away from the body.
6. Turn the Motor Housing Unit (5) anticlockwise until the tabs release from the
grooves and pull the Whisk
Attachment
(8) away from the Motor Housing Unit
(5).
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Using Your Hand Blender with the Chopper Attachment
You can chop meat, cheese, vegetables, herbs, bread, biscuits and nuts.
Don’t chop hard foods such as coffee beans, ice cubes, spices or chocolate, you
will damage the blade.
1. Remove any bones and cut food into 1-2 inch cubes.
2. Place Chopping Blade (11) onto metal shaft in the bottom of the Chopping Bowl
(10).
3. Place food to be chopped into the Chopping Bowl (10). Do not overfill.
4. Fit the Chopper Lid (11), turn clockwise and lock.
6.
Align the locking tabs on the Chopper Lid (11) with the grooves on the Motor
Housing Unit (5) of the Hand Blender and turn the Motor Housing Unit (5)
clockwise until it locks completely into place.
7.
Press the
Power Lock Button
(3), and promptly press the
Speed Button
(2).
Once you release the
Speed Button
(2) the motor unit will stop.
8.
To operate the Hand Blender on high speed, press the
Power Lock Button
(3)
and promptly press the
Speed Button
(2), then turn on the
Variable Speed
Control
(1) to choose your desired speed.
Once you release the
Speed Button
(2)
the motor unit will stop.
Removing the Chopper Attachment
1. To remove the Chopper
Attachment
(8), hold the Motor Housing Unit (5) in
one hand and firmly hold the Chopper
Lid
(9) with the other.
2. Turn the Motor Housing Unit (5) anticlockwise until the tabs release from the
grooves and pull the Motor Housing Unit (5) away from the Chopper
Lid
(9) and
the Chopper Bowl (10).
3. Remove the Chopper
Lid
(9) by turning anti-clockwise.
4. Remove the Chopping Blade (11) by grasping the shaft firmly and lifting up. Be
carefully, the blades are sharp!
5. After the Chopping Blade (11) has been removed the ingredients can be
removed from the Chopper Bowl (10).
Do not use the chopper for longer than 1 minute continuously. After 1 minute of
continuous use, the unit may become over-heated. Allow the unit to rest for at
least 5 min before resuming use.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Indicator Lights
The motor housing indicator lights provide feedback for different situations:
Battery Life During Use:
As the Hand Blender is used and the battery begins to drain during performance,
the indicator lights will extinguish in sequence from the top to the bottom to
indicate how much battery capacity is left.
66% to 100% of capacity: Lights 1, 2 and 3 will illuminate.
33% to 65% of capacity: Light 1 & 2 will illuminate.
20% to 30% of capacity: Light 1 will illuminate.
If less than 20% of capacity: Light 1 flashes and the unit needs to be charged.
Charging Indicators:
Indicator lights will also provide feedback during the charging process:
If battery capacity is less than 33%, Lights 1, 2 and 3 will flash while charging.
If battery capacity is within 33%-65%, Light 1 will illuminate and Lights 2 and
3 will flash.
If battery capacity is within 66%-99%, Lights 1 and 2 will illuminate and only
Light 3 will flash.
If battery capacity is greater than 99%, Lights 1, 2 and 3 will illuminate.
Overloading Indication:
Note: The motor housing has an automatic protection system that will not
allow overloading. If the load is too large, the unit will automatically shut off. If
the unit senses an overload situation, all 3 lights will flash 5 times and the unit
will turn Off. Release the speed button and the lights will turn off. Reduce the
load on the blender or the chopper, allow it to rest for more than 15 minutes
and then resume use.
Do not expose a battery pack or appliance to fire or excessive heat. Exposure to
fire or temperatures above 130℃ may cause an explosion.
Care and Maintenance
CAUTION: Make
sure the
Hand Blender is locked. Unplug
the USB Charging
Cable (13) from the Hand Blender before cleaning.
Wash the attachments in warm soapy water and dry thoroughly.
Clean the outside of the motor housing with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
Do not submerge the Motor Housing Unit in water or any other liquids.
WARNING! DO NOT CLEAN ANY PART OF YOUR HAND BLENDER IN A
DISHWASHER. WASH IN WARM SOAPY WATER AND DRY THOROUGHLY.
13
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Cleaning Tips
To ease washing it is advised to rinse parts immediately after mixing.
Use a small brush (not supplied) to remove particles lodged in the
attachments.
To Store:
Ensure all parts are clean and dry before storing. Never store it while it is wet.
The unit can be stored for up to 3 months with a fully charged state. If storing for
longer than 3 months the unit should be charged before next use.
Store in a dry area in an ambient temperature of 5⁰C - 35⁰C.
Technical Specification
Model no.
SDA
263
3
Battery
2
0
00mAh Li
-
Ion
Rated Power
200W
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice visit www.recycle-more.co.uk enter your postcode to find your
nearest recycling site.
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
15
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Blender
Model no: SDA2633
User Manual
WARRANTY
Thank you for purchasing your Cordless Pro Handheld Blender
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition
to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty
vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the
retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
