1
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Explanation of Symbols
7 Description of Parts & Accessories
7 Before First Use of Your Hand Blender Set
7 Using the Blending Head
8 Releasing Attachment
8 Using the Chopper
9 Using the Whisk
9 For Best Whisking Result
9 Cleaning and Maintenance
9 Plug Wiring Information
10 Technical Specification
10 Recycling Information
11 Customer Support
Back Page Guarantee
3
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, safety precautions should always be
followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating instructions
before using this hand blender.
• Before plugging your unit into the mains, visually check that the
unit is intact and has not suffered any transit damage.
• DO NOT use this blender with an extension cable.
• Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
• Close supervision is required when using this appliance near
children.
• Never leave this appliance within reach of children.
• This appliance shall not be used by children.
• Keep the appliance and its cord out of reach of children.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
• Children less than 3 years should be kept away unless
continuously supervised.
• DO NOT immerse the appliance or its cord in water or any other
4
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected to
the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has
been used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by
qualified personnel. Improper repairs may place user at serious
risk.
• DO NOT operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
• Regular, periodic checks should be carried out on the power
cord to ensure no damage is evident. Should there be any signs
of damage the appliance should not be used.
• If the power cord is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order
to avoid a hazard.
• DO NOT allow the power cord to hang over sharp edges or
come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Always disconnect the blender from the supply if it is left
unattended and before assembling, disassembling or cleaning.
• This appliance is intended for household use only and should
not be used for industrial purposes.
• DO NOT use any accessories or attachments with this appliance
other than those supplied or recommended by the supplier.
• DO NOT use this appliance for anything other than its intended
use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Switch off the appliance and disconnect from the supply before
changing accessories or approaching parts that move in use.
5
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Grasp the plug, not the cord.
• DO NOT touch the blades whilst the blender is connected to the
mains.
• Wash the blades in warm soapy water, rinse and dry thoroughly.
• CAUTION: the blades on this blender are very sharp; extreme
caution should be taken when cleaning.
6
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This Class 2 symbol indicates that the product is electrically
double insulated and does not require an earth connection.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
7
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Speed Adjustment Control
2. Speed Button
3. Turbo Speed Button
4. Motor Unit
5. Blender Attachment
6. Blades & Guard
7. Whisk Attachment
8. Chopper Lid
9. Chopper Bowl
10. Chopper Blade
11. Beaker
Description of Parts & Accessories
Before First Use of Your Hand Blender Set
• Remove all packing materials and discard responsibly.
• Check that all parts are present – See ‘Description of Parts & Accessories’
above.
• Wash the Chopper Lid, Chopper Bowl, the Blender Attachment and the Whisk
Attachment in warm soapy water, rinse and dry thoroughly afterwards.
CAUTION: the blades on this hand blender set are very sharp; extreme caution
should be taken whilst cleaning.
• Do not clean any part of your hand blender set in a dishwasher.
• Never immerse the motor unit in water or any other liquids.
• Wipe over the motor unit with a damp sponge or cloth.
• Do not use harsh or abrasive cleaners.
Using the Blender Attachment (5)
For blending liquids such as dairy products, sauces,
soft fruit, soups, milk shakes and mixing soft
ingredients.
1. Attach the Blender Attachment (5) to the Motor
Unit (4) by turning anticlockwise until it ‘clicks’ into
place and at the locked position as shown right.
2. Insert the mains plug into the mains socket.
3. Add the ingredients to the Beaker (11).
4. Immerse the Blender Attachment (5) into the
ingredients making sure the Blades & Guard (6) are
completely covered.
2
3
4
5
6
7
8
9
10
11
1
8
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Press either the Speed Button (2) or the Turbo Speed Button (3) to blend the
ingredients. You may adjust the speed by rotating the Speed Adjustment
Control (1) and pressing the Speed Button (2).
The correct speed depends on the quantity and consistency of the ingredients.
Use the lower speeds for small amounts and the turbo speed for large amounts
and harder ingredients.
If you wish to blend in a saucepan, remove the pan from the heat and allow to
cool a little before using the blender. DO NOT leave or use the blender in a pan
whilst on the heat.
Do not run the blender in free air otherwise damage may occur.
Whilst blending heavier mixtures, do not use the blender for longer than 30
seconds with 3 minutes rest in between.
Releasing the Attachments
Using the Chopper
Use the Chopper for chopping ingredients such as nuts, meat, onions, hard
cheese, boiled eggs, garlic, herbs and dry bread.
WARNING! The blades are very sharp, so be careful whilst handling the blade
unit. Be especially careful when removing the blade from the chopper bowl for
emptying and cleaning.
To release attached accessory from the
Motor Unit (4), hold the accessory and
turn the Motor Unit (4) to the right:
1. Place the Chopper Blade (10) into the Chopper Bowl (9).
2. Place the ingredients into the Chopper Bowl (9).
3. Place the Chopper Lid (8) onto the Chopper Bowl (9).
8
10
9
4. Place the Motor Unit (4) onto the Chopper
Lid (8) by rotating clockwise until it “clicks”
into place and is in the ‘locked’ position as
shown circled left:
NB Rotate the Motor Unit (4) anticlockwise
to the ‘unlocked’ position in order to
remove it after use.
9
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Press either the Speed Button (2) or the Turbo Speed button (3) to blend the
ingredients.
Using the Whisk Attachment (7)
Use the whisk only for whipping cream, beating
egg whites, mixing cake sponges, etc.
1. Attach the Whisk Attachment (7) to the Motor
Unit (4) and rotate it anticlockwise until it
‘clicks’ into place and is in the ‘locked’ position
as shown circled right.
2. Add the ingredients to a mixing bowl.
3. Before pressing either the Speed Button (2) or
the Turbo Speed button (3) to blend the
ingredients, place the Whisk into the mixture
first and then start whisking.
For Best Whisking Results
• Do not use the beaker, use a wide bowl.
• Start with the low speed setting and progress to the turbo speed.
• Move the whisk by holding it a slight angle.
• Whisk up to a maximum of 400ml of cream at one time.
• Whisk up to a maximum quantity of 4 eggs at one time.
Cleaning and Maintenance
WARNING! The blades are very sharp, extreme caution should be taken
whilst cleaning.
• Always turn the power off and remove the plug from the socket outlet before
carrying out any cleaning.
• Do not immerse the Motor Unit (4) in water or any other liquids.
• Remove any accessories from the Motor Unit (4) and clean the motor unit with
a clean damp cloth, do not immerse in water.
• Wash the accessories only in warm soapy water and dry thoroughly afterwards.
• Do not use harsh or abrasive scouring pads, powders or cleaners.
• Do not place in a dishwasher.
• Store in a dry cool place away from direct heat or sunlight.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
10
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Model Number
SDA1622
Rated Voltage
220-240V~ 50-60Hz
Rated Power
600W
Protection Class
II
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
11
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
12
Hand Blender Set
Model No.: SDA1622
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
