WINDOW
AIR CONDITIONER
FOR MODELS:
1PAQ8000
Before using your air conditioner, please
read this manual carefully and keep it for
future reference, along with your receipt.
Specification and performance data is subject to change without notice.
Printed in China
PA/User_1PAQ8000/08302018
USER MANUAL
For your own records, please attach a copy of your sales receipt to this manual and complete the following:
Model Number:
_____________________________________ Serial Number: _______________________________________
Purchase Date: ____________________________________ Store Purchased: _____________________________________
Installation Date: ___________________________________ Installation Co.: _______________________________________
Installer Name:
_____________________________________ Installer Phone No.: ___________________________________
CONSUMER PRODUCT INFORMATION
SAFETY PRECAUTIONS ...................................................................1
IMPORTANT SAFETY INSTRUCTIONS
...........................................3
INSTALLATION INSTRUCTIONS
.....................................................4
NORMAL SOUNDS
...........................................................................9
AIR CONDITIONER FEATURES
.......................................................9
CARE AND CLEANING
....................................................................12
TROUBLESHOOTING
.......................................................................13
CONTENTS
This manual provides the information needed for proper use and mainte-
nance of this air conditioner. Basic preventative care can help extend the life
of this unit. The “Troubleshooting” section in this manual contains a chart
with solutions to the most common problems. Referring to this section may
save time and prevent the need for a service call in the event of a problem.
CAUTION
● Contactanauthorizedservicetechnicianforrepairormaintenanceofthisunit.
● Ifnecessary,contactaninstallerforinstallationofthisunit.
● Theairconditionerisnotintendedforusebyyoungchildrenwithoutadultsupervision.Youngchildrenshouldbe
supervised to ensure that they do not play with the air conditioner.
● Disabledpersonsmayrequireassistancewithsetup.
● Ifthepowercordistobereplaced,replacementworkshouldbeperformedbyauthorizedpersonnelonly.
● Installationandrepairworkmustbeperformedinaccordancewiththenationalwiringstandardsbyauthorized
personnel only.
● Donotoperateyourairconditionerinawetroomsuchasabathroomorlaundryroom.
NOTE:Alltheillustrationsinthismanualareforexplanationpurposesonly.Unitpurchasedmaybeslightlydierent.
Thedesignandspecicationsaresubjecttochangewithoutpriornoticeforproductimprovement.ContactConsumer
Services as 844-4PA-AIRE (844-472-2473) for details.
1
WARNINGS
Plug in power cord properly. Failuretodosomaycauseelectricshockorredueto
excess heat generation.
DO NOT operate or stop the unit by inserting or pull-
ing out the power plug directly from the wall.
Doingsomaycauseelectricshockorredueto
heat generation.
DO NOT use a damaged power cord.
Doingsomaycauseelectricshockorre.Ifthepower
cord is damaged, it must be replaced by the manufactur-
eroranauthorizedservicecenterorasimilarlyqualied
personinordertoavoidahazard.
DO NOT modify power cord length or share the
outlet with other appliances.
Doingsomaycauseelectricshockorredueto
heat generation.
DO NOT operate with wet hands or in
damp environment.
Doingsomaycauseelectricshock.
DO NOTdirectairowdirectlyatroomoccupants.
This could cause health issues.
Alwaysensureeectivegrounding. Incorrectgroundingmaycauseelectricshock.
DO NOT allow water to run into electric parts.
Doingsomaycausefailureofmachineorelectricshock.
Alwaysinstallcircuitbreakerandadedicated
power circuit.
Incorrectinstallationmaycausereandelectricshock.
Always unplug the unit if strange sounds, smell or
smokecomesfromtheunit.
Failuretodosomaycausereandelectricshock.
DO NOTusethesocketifitislooseordamaged.
Doingsomaycausereandelectricshock.
DO NOT open the unit during operation.
Doingsomaycauseelectricshock.
DO NOTuserearmsnearunit.
Doingsomaycausere.
DO NOT use the power cord close to
heating appliances.
Doingsomaycausereandelectricshock.
DO NOT disassemble, modify, or drill holes into
the air conditioner.
Doingsomaycausefailureandelectricshockandvoid
the manufacturer’s warranty.
Ventilate room before operating air conditioner if
thereisagasleakfromanotherappliancesuchas
a stove.
Failuretodosomaycauseexplosion,reandburns.
DO NOT
usethepowercordnearammablegasor
combustibles,suchasgasoline,benzene,thinner,etc.
Doingsomaycauseanexplosionorre.
READ SAFETY PRECAUTIONS BEFORE INSTALLATION
Topreventinjurytotheuserorotherpeopleandpropertydamage,thefollowinginstructionsmustbefollowed.
Incorrectoperationduetoignoringofinstructionsmaycauseharmordamage.Theseriousnessisclassiedbythe
following indications.
THIS SYMBOL INDICATES THAT IGNORING INSTRUCTIONS MAY CAUSE
DEATH OR SERIOUS INJURY.
NEVER DO THIS.OTHER SYMBOLS: ALWAYS DO THIS.
THIS SYMBOL INDICATES THAT IGNORING INSTRUCTIONS MAY CAUSE
MODERATE INJURY TO YOUR PERSON, OR DAMAGE TO YOUR UNIT OR
OTHER PROPERTY.
SAFETY PRECAUTIONS
2
CAUTIONS
Whenremovingairlter,DO NOT touch metal parts of
the unit.
Doingsomaycauseaninjury.
DO NOT clean with water.
Water may enter the unit and degrade the insulation,
causinganelectricshock.
Ensure proper ventilation, especially in rooms with a
stove or other appliances.
Failure to do so may result in an oxygen shortage.
Unitandcircuitbreaker/fusemustbeswitchedOFF
when cleaning.
CleaningunitwhenpowerisONmaycausereand
electricshockandmaycauseaninjury.
DO NOT put a pet or house plant where it will be ex-
posedtodirectairow.
Thiscouldinjurethepetorplant.
Use ONLY as intended. This unit is NOT intended to preserve precision devic-
es,food,pets,plants,andartobjects.Itmaycause
deteriorationofquality,etc.
Stop operation and close the window in severe
storms or hurricanes.
Operationwithwindowsopenmaycausemoistureto
enter the room.
Hold the plug by the head of the power plug when
takingitout.
Failuretodosomaycauseelectricshock
and damage.
If unit will not be used for a long period of time,
unplug or turn OFF main power switch.
Leavingpoweronmaycauseunitfailureorre.
Do not place obstacles around air-inlets or inside of
air-outlet.
Obstaclesmaycauseappliancefailureoraccident.
Periodicallycheckinstallationbracketfordamage. Prolonged exposure to outdoor elements may cause
damagetoinstallationbracket,causingunittofall.
Alwaysinsertlter(s)securely.Cleanlter(s)AT LEAST
onceeverytwoweeks.
Operationwithoutsecurelyinstalledltersmay
causefailure.Adirtyltercancausetheunittonot
runeciently.
Use only a soft cloth to clean the unit. Cleaners or detergents may change the color or
scratch the surface of the unit.
Usecautionwhenunpackingandinstalling. Sharpedgescouldcauseinjury.
NEVERdrinkwaterdrainedfromairconditioner.
Water from unit contains contaminants and could
cause illness.
DO NOTplaceheavyobjectsonthepowercordand
always ensure that the cord is not compressed.
Thereisdangerofreorelectricshock.
If water enters the unit’s electrical components, turn
theunitoatthepoweroutletandswitchothecir-
cuitbreaker.Isolatesupplybytakingthepower-plug
outandcontactaqualiedservicedtechnician.
Thereisdangerofelectricshock.
3
IMPORTANT SAFETY INSTRUCTIONS
NOTE
:
The power supply cord with this air
conditioner contains a current detection
devicedesignedtoreducetherisk
ofre.Pleaserefertothesection
“OperationofCurrentDevice”(below)
for details. In the event that the power
supply cord is damaged, it cannot be
repaired. It must be replaced by an
authorizedrepairtechnicianwithacord
from the Product Manufacturer.
WARNING
Avoidrehazardsorelectricshock.
DO NOT use an extension cord or an
adapter plug. DO NOT remove any prong
from the power cord.
OPERATION OF
CURRENT DEVICE:
The power supply cord contains a
current device that senses damage
to the power cord. To test your power
supply cord, do the following:
1. Plug in the air conditioner.
2. The power supply cord will have
TWObuttonsontheplughead.Press
theTESTbutton.Youwillnoticea
clickastheRESETbuttonpopsout.
3. Press the RESET button. Again,
youwillnoticeaclickasthe
button engages.
4. The power supply cord is now
supplyingelectricitytotheunit.(On
some products this is also indicated
by a light on the plug head.)
WARNING
FORYOURSAFETY:Donotstoreorusegasolineorotherammable
vaporsandliquidsinthevicinityofthisoranyotherappliances.
WARNING - PREVENT ACCIDENTS
Toreducetheriskofre,electricalshock,orinjurytopersonswhenusing
your air conditioner, follow basic precautions, including the following:
● Besuretheelectricalserviceisadequateforthemodelyouhave
chosen. This information can be found on the serial plate, which is
located on the side of the cabinet and behind the grille.
● Iftheairconditioneristobeinstalledinawindow,youwillprobably
wanttocleanbothsidesoftheglassrst.Ifthewindowisatriple-
tracktypewithascreenpanelincluded,removethescreencompletely
before installation.
● Besuretheairconditionerhasbeensecurelyandcorrectlyinstalled
according to the installation instructions in this manual.
●
Save this manual for possible future use in removing or installing this unit.
● Whenhandlingtheairconditioner,becarefultoavoidcutsfromsharp
metalnsonfrontandrearcoils.
WARNING - ELECTRICAL INFORMATION
The complete electrical rating of your new room air conditioner is
statedontheserialplate.Refertotheratingwhencheckingthe
electricalrequirements.
● Besuretheairconditionerisproperlygrounded.Tominimizeshock
andrehazards,propergroundingisimportant.Thepowercordis
equippedwithathree-pronggroundingplugforprotectionagainst
shockhazards.
● Yourairconditionermustbeusedinaproperlygroundedwall
receptacle.Ifthewallreceptacleyouintendtouseisnotadequately
groundedorprotectedbyatimedelayfuseorcircuitbreaker,havea
qualiedelectricianinstalltheproperreceptacle.
● Ensurethereceptacleisaccessibleaftertheunitinstallation.
● Donotrunairconditionerwithoutsideprotectivecoverinplace.This
could result in mechanical damage within the air conditioner.
● Donotuseanextensioncordoranadapterplug.
NOTE
:
Donotusetheplugtoturntheunitonoro.
● AlwaysmakesuretheRESETbuttonispushedinforcorrectoperation.
● ThepowersupplymustbereplacedifitfailsresetwheneithertheTEST
button is pushed or it cannot be reset.
● Ifpowersupplycordisdamaged,itcannotberepaired.Pleasecall
Consumer Services at 844-472-2473 to assist with replacement.
NOTE: This air conditioner is designed to be operated under the
following conditions:
Cooling
Operation
Outdoor Temp:
64–109°F/18–43°C
(64–125°F/18–52°Cforspecialtropicalmodels)
Indoor Temp:
62–90°F/17–32°C
Performance may be reduced outside of these operating temperatures.
Grounding Type
Wall Receptacle
Do not, under any
circumstances, cut,
remove, or bypass the
ground prong.
Power supply cord
with 3-prong grounding
plug and current
detection device
4
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT- Save these instructions.
IMPORTANT
-Observeallgoverningcodes
and ordinances.
Note to Installer- Be sure to leave these instructions with
the Consumer.
Note to Consumer- Keep these instructions for future
reference.
Skill level
-Installationofthisappliancerequiresbasic
mechanicalskills.
Completion time- Approximately 1 hour.
We recommend that two people install this product.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
YouMUSTuseallsuppliedpartsanduseproper
installation procedures as described in these
instructions when installing this air conditioner.
WINDOW REQUIREMENTS
Yourairconditionerisdesignedtoinstallinstandard
double hung windows with opening widths of 23 to 36
inches (584 mm to 914 mm).
Inner sill
Offset
Window
Sill
Exterior
Interior wall
23–36 in.
14 in.
Sash
CAUTION
DO NOT, under any circumstances, cut or remove the
third (ground) prong from the power cord.
DO NOT change the plug on the power cord of the
air conditioner.
Aluminum house wiring may present special problems-
consultaqualiedelectrician.
When handling unit, be careful to avoid cuts from sharp
metaledgesandaluminumnsonfrontandrearcoils.
TOOLS YOU WILL NEED
● PhillipsScrewdriver
● Level
TOOLS YOU MAY NEED
● FlatheadScrewdriver
● Pencil
● RulerorTapeMeasure
● ScissorsorKnife
HARDWARE
Included-packedwiththeunit.
(Included - Packed with the Unit)
3/4ʺ(or1/2ʺ)
Screws
3/4ʺ (or 1/2ʺ)
Screws (7 pcs)
Lock Frame
(2 pcs)
Sash Lock
(1 pc)
Window
Sash Seal
Foam (1 pc)
Weather Stripping
10ʺx
3
/4ʺx
1
/12ʺ
(5 pcs)
7 pcs
LockFrame
3/4ʺ (or 1/2ʺ)
Screws (7 pcs)
Lock Frame
(2 pcs)
Sash Lock
(1 pc)
Window
Sash Seal
Foam (1 pc)
Weather Stripping
10ʺx
3
/4ʺx
1
/12ʺ
(5 pcs)
2 pcs
SashLock 1 pc
Window Sash
Seal Foam
3/4ʺ (or 1/2ʺ)
Screws (7 pcs)
Lock Frame
(2 pcs)
Sash Lock
(1 pc)
Window
Sash Seal
Foam (1 pc)
Weather Stripping
10ʺx
3
/4ʺx
1
/12ʺ
(5 pcs)
1 pc
Weather Stripping
10ʺx3/4ʺx1/12ʺ
3/4ʺ (or 1/2ʺ)
Screws (7 pcs)
Lock Frame
(2 pcs)
Sash Lock
(1 pc)
Window
Sash Seal
Foam (1 pc)
Weather Stripping
10ʺx
3
/4ʺx
1
/12ʺ
(5 pcs)
5 pcs
3/8ʺScrews
3/8" Screws
(4 pcs)
Top Rail
(1 pc)
Insulation
Panels (2 pcs)
4 pcs
Top Rail
3/8" Screws
(4 pcs)
Top Rail
(1 pc)
Insulation
Panels (2 pcs)
1 pc
Insulation Panels
3/8" Screws
(4 pcs)
Top Rail
(1 pc)
Insulation
Panels (2 pcs)
2 pcs
Accordion Panels
(one left, one right)
1 set
INSTALLATION INSTRUCTIONS
5
STEP 1:
PREPARE THE WINDOW
Lowersashmustopensucientlytoallowaclear
vertical opening of 13 inches (330 mm). Side louvers
and the rear of the AC must have clear air space to
allowenoughairowthroughthecondenserforheat
removal. The rear of the unit must be outdoors, not
inside a building or garage.
MOUNTING HARDWARE:
3/4" (or 1/2")
Screws (7 pcs)
Lock Frame
(2 pcs)
Sash Lock
(1 pc)
Window
Sash Seal
Foam (1 pc)
Weather Stripping
10"x
3
/4"x
1
/12"
(5 pcs)
STEP 2:
PREPARE AIR CONDITIONER
A. Remove the air conditioner from the carton and
placeonaatsurface.
B. Remove top rail and insulation panels from the
rearofthepackagingmaterialasshowninFig.A.
(Energy Star rated units only.)
TOP RAIL HARDWARE:
3/8" Screws
(4 pcs)
Top Rail
(1 pc)
Insulation
Panels (2 pcs)
C. Align the hole in the top rail with those in the top of
the unit as shown in Fig. B.
D. Securethetoprailtotheunitwiththe3/8″screws
as shown in Fig. C.
NOTE: For safety reasons, all four (4) screws MUST be
securely fastened.
STEP 3:
INSTALL THE ACCORDION PANELS
NOTE: Top rail and sliding panels on each side are
osettoprovidetheproperpitchof5/16″tothe
rear. This is necessary for proper condensed water
utilizationanddrainage.Ifyouarenotusingthe
side panels for any reason, this pitch to the rear must
be maintained.
B. Slide the free end “ ” section of the panel directly
into the cabinet as shown in Fig. 2. Slide the
panel down. Be sure to leave enough space to slip
the top and bottom of the frame into the rails on
the cabinet.
" "
FIG. A
Packaging
Top Rail
Insulation
Panels
FIG. B
FIG. C
FIG. 1
FIG. 2
A.
Placeunitonoor,a
bench or a table. Hold the
accordion panel in one hand
andgentlypullbackthe
centertolltheopenend.
See Fig.1.
6
C. Oncethepanelhasbeeninstalledonthesideof
thecabinet,makesureitsitssecurelyinsidethe
framechannelbymakingslightadjustments.Slide
the top and bottom ends of the frame into the top
and bottom rails of the cabinet. (Fig. 3)
D. Slide the panel all the way in and repeat on the
other side. (Fig 4)
NOTE:IfstormwindowblocksAC,seeFig.15,pg.8.
STEP 4:
SECURE THE ACCORDION PANELS
A.Keepingarmgripontheairconditioner,carefully
place the unit into the window opening so the
bottom of the air conditioner frame is against the
window sill (Fig. 5). Carefully close the window
behind the top rail of the unit.
NOTE:Checkthatairconditioneristiltedback
approximately3/4″to1″(Fig.5above)(tiltedabout
3° to 4° downward to the outside). If, after proper
installation, condensation does not drain from the
overowdrainholeduringnormaluse,adjustslope.
B. Extend the side panels out against the window
frame (Fig. 6).
STEP 5:
INSTALL SUPPORT BRACKET
A.Placethelockframebetweentheframeextensions
andthewindowsillasshowninFig.7.Drive3/4″
(19mm)or1/2″(12.7mm)lockingscrewsthrough
thelockframeandintothesill.
NOTE: Topreventwindowsillfromsplitting,drill1/8″
(3 mm) pilot holes before driving screws.
B. Drive3/4″(19mm)or1/2″(12.7mm)locking
screws through frame holes into window sash
(Fig. 8).
FIG. 3
FIG. 6
FIG. 7
FIG. 8
FIG. 4
FIG. 5
Top Left
Top Rail
Top Rail
Bottom Rail
Bottom Rail
Window
Frame
Measure from the cabinet edge
Wooden Windows
INSIDE
OUTSIDE
Top Right
Approx. 3/4″ to 1″
7
C. To secure lower sash in place, attach right angle sash
lockwith3/4″(19mm)or1/2″(12.7mm)screwas
shown (Fig. 9).
D. Cut window sash seal foam and insert it in the space
between the upper and lower sashes (Fig. 10).
STEP 6:
INSTALL INSULATION PANELS
Inordertominimizeairleaksandensureoptimal
insulation, it is necessary to install the included
Insulation panels to the accordion panels. Follow the 4
steps in these instructions:
STEP 6.1: After the unit is installed in the window,
measure the inner width of one of the accordion panels
as shown in Fig. 11.
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17
1
2 3 4 5 6
STEP 6.2:Markalineononeoftheprovidedinsulation
panels, matching the measured width in Step 6.1; Cut
the insulation panel along the line (Fig. 12).
or
STEP 6.3:Slidetheinsulationpanelyoujustcutintothe
accordion panel. The side of the insulation panel with
the pattern on it should face indoors. (Fig. 13)
STEP 6.4: Repeat on other side with the second
insulation panel.
FIG. 9
FIG. 12
FIG. 13
FIG. 10
FIG. 11
Foam Seal
Measure the
inner width
of one of the
accordion panels.
8
STEP 7:
INSTALL WEATHER STRIPPING
Inordertominimizeairleaksbetweentheroomair
conditioner and the window opening, install weather
stripping into any gaps as you see necessary by
trimming the weather stripping to the desired length,
peelingotheprotectivebackingandllingthese
gaps. (Fig. 14)
IF AC IS BLOCKED BY A
STORM WINDOW
Add wood as shown in Fig.15, or remove storm
window before air conditioner is installed.
If storm window frame must remain, be sure the
drainholesorslotsarenotcaulkedorpaintedshut.
Accumulated rain water or condensation must be
allowed to drain out.
FIG. 15
Sash
Storm window
frame or other
obstruction.
1½″ min
(38 mm)
Board thickness
as required, for
proper pitch to
rear, along entire
sill. Fasten with
nails or screws.
REMOVING AC FROM WINDOW
● TurnACo,anddisconnectpowercord.
● Removesashsealfrombetweenwindows,and
unscrewsafetysashlock.
● Removescrewsinstalledthroughframeand
frame-lock.
● RemovetheInsulationPanelsandclose(slide)side
accordion panels into frame.
● Keepingarmgriponairconditioner,raisesash
and carefully remove.
● Becarefulnottospillanyremainingwater
while lifting unit from window. Store parts WITH
air conditioner.
FIG. 14
9
NORMAL SOUNDS
VIBRATION
Unitmayvibrateandmakenoise
because of poor wall or window
construction or incorrect installation. This
DOESNOTindicateadefectiveunit.
PINGING OR SWITCHING
Droplets of water hitting condenser
during normal operation may cause
“pinging” or “switching” sounds.
This noise can be reduced by removing the
water plug at the bottom of the unit’s rear as
shown below. Removing this plug will lower
theEnergyEciencyofyourunit.NOTE:Do
not try to drill any holes on the base pan to
elimiate the normal sounds. Doing so will void
the warranty.
HIGH PITCHED CHATTER
Higheciency
compressors may have a
high pitched chatter during
the cooling cycle.
SOUND OF RUSHING AIR
At the front of the unit,
the sound of rushing air
being moved by the fan
may be heard.
GURGLE/HISS
“Gurgling” or “hissing”
noise may be heard due
to refrigerant passing
through evaporator during
normal operation.
NOTE:
Allofthepicturesinthismanualareforexplanatorypurposesonly.Theactualshape/lookoftheairconditioner
purchasedmaybeslightlydierent,buttheoperationsandfunctionsaresimilar.
AIR CONDITIONER FEATURES
Thoroughlyfamiliarizeyourselfwiththecontrolpanelshownbelowandallofitsfunctions.Afterwards,followthe
symbolforthefunctionsyoudesireBEFOREoperatingtheunit.Thisunitcanbecontrolledbytheunitcontrolorthe
remote control.
TIMER
ECO MODE
FILTER
On Off
Auto
Cool
Dry
Fan
Follow me
Auto
Low
Med
High
FAN SLEEP
“FOLLOW ME”
Indicator
Energy Saver
Mode
Sets Mode
Sleep Mode
Turns Unit
On or Off
Set Fan
Speed
Adjusts Temp.
or Time
Adjusts Temp.
or Time
Remote Signal
Receptor
Check Filter
Reset Button
Activates
Timer
Displays
Temperature or the
Time or Error Codes
TO TURN UNIT ON OR OFF:
Press ON/OFFbuttontoturntheunitonoro.
NOTE: The unit will automatically initiate the Energy
SaverfunctionunderCOOL,DRYandAUTO(only
AUTO-COOLINGandAUTO-FANmodes).
TO ADJUST FAN SPEEDS:
Press to select the Fan Speed in four steps: Auto,
Low, Med or High. Each time the button is pressed,
thefanspeedisshifted.InDRYmode,thefanspeed
is automatically controlled at Low.
TO CHANGE TEMPERATURE SETTING:
Press+/–UP/DOWNbuttontochangethe
temperature setting.
NOTE:
PressorholdeitherUP(+)orDOWN(–)button
until the desired temperature is seen on the display.
The temperature will be automatically maintained
anywhere between 62°F (17°C) and 86°F (30°C)
10
SLEEP FEATURE:
Press SLEEP button to initiate the SLEEP
mode. In this mode, the selected temperature will
increase by 2°F (1°C) 30 minutes after the mode is
selected. The temperature will then increase (cooling)
or decrease (units with heating only) by another
2°F (1°C) after an additional 30 minutes. This new
temperature will be maintained for 6 hours before it
returns to the originally selected temperature. This
ends the SLEEP mode and the unit will continue
to operate as originally programmed. The SLEEP
mode program can be canceled at any time during
operation by pressing the SLEEP button again.
CHECK FILTER FEATURE:
Press CHECK FILTER button to initiate this
feature. This feature is a reminder to clean the Air
Filterformoreecientoperation.TheLED(light)will
illuminate after 250 hours of operation. To reset after
cleaningthelter,presstheCHECK FILTER button
andthelightwillgoo.
ENERGY SAVER FEATURE:
Press ENERGYSAVER button to initiate this
function. This function is available on COOL, DRY
and AUTO (only AUTO-COOLINGand AUTO-FAN)
modes. In this mode, the fan will continue to run for 3
minutesafterthecompressorshutso.Thefanthen
cycles on for 2 minutes, at 10 minute intervals, until
the room temperature is above the set temperature,
atwhichtimethecompressorturnsbackonand
cooling starts.
FOLLOW ME FEATURE:
This feature can ONLY be activated
from the remote control. The
remote control serves as a remote
thermostat allowing for precise
temperature control at its location.
To activate the Follow Me feature, point the remote
control towards the unit and press the
FOLLOWME
button. The remote displays the actual temperature
at its location. The remote control will send this
signal to the air conditioner every 3 minutes until the
FOLLOWME button is pressed again. If the unit does
not receive the Follow Me signal during any 7 minute
interval, the unit will beep to indicate use of the
Follow Me feature has ended. The actual temperature
can be displayed at the unit by pressing the FAN only
mode.WhenintheCOOLmode,theunitdisplay
indicates the set temperature.
TO SELECT THE OPERATING MODE:
To choose operating mode, press the MODE
button. Each time you press the button, a mode is
selectedinasequencethatgoesfromAUTO,COOL,
DRY and FAN. The indicator light will be illuminated
and remain on once the mode is selected. The unit
will automatically initiate the Energy Saver function
under COOL, DRY, and AUTO (only AUTO-COOLING and
AUTO-FAN) modes.
TO OPERATE ON AUTO FEATURE:
When you set the air conditioner in AUTO mode, it
will automatically select cooling or fan only operation
depending on what temperature you have selected
and the room temperature. The air conditioner will
control room temperature automatically around the
temperature you set. In this mode, the fan speed
cannot be adjusted. It starts automatically at a speed
according to the room temperature. If the room does
not get too warm, it will stay at a “Low” speed.
TO OPERATE ON FAN ONLY:
Use this function ( ) only when cooling is not
desired, such as for room air circulation or to exhaust
staleair.Youcanchooseanyfanspeedyouprefer.
During this function, the display will show the actual
room temperature, not the set temperature as in the
coolingmode.Temperaturecannotbeadjustedinthe
FAN only mode.
TO OPERATE ON DRY MODE:
In this mode, the air conditioner will reduce air
humidity. If the space is a closed or sealed area,
some degree of cooling will continue.
TIMER: AUTO START/STOP FEATURE:
● Whentheunitisonoro,rstpress TIMER
button.TheTIMERONindicatorlightilluminates.It
indicates the Auto Start program is initiated.
● WhenthetimeofTIMERONisdisplayed,ifyou
press the TIMERbuttonagain,theTIMEROFF
indicator light illuminates. It indicates the Auto
Stop program is initiated.
● PressorholdtheUPorDOWNbuttontochange
the Auto time by 0.5 hour increments, up to 10
hours, then by 1 hour increments, up to 24 hours.
The control will count down the time remaining
until start.
● Theselectedtimewillregisterin5secondsand
thesystemwillautomaticallyrevertbacktodisplay
the previous temperature setting or the room
temperature (depending on whether the unit is
poweredonoroandthemodeitisin).
● TurningtheunitONorOFFatanytimeor
adjustingthetimersettingto0.0willcancelthe
AutoStart/Stopprogram.
A NOTE ABOUT THE TIMER:
When you set the timer, the
unitwillonlygoononceandoonce.Ifyouwantthe
airconditionertocycleonandobasedondesired
room temperature, you do not need to set the timer.
Instead, set your desired temperature and the unit will
cycleonandobasedonthattemperaturesetting.
Light
Flashing
Follow Me
11
DISPLAY:
Shows the set temperature in °F or °C and the Auto-
timer settings. While on FAN only mode, it shows the
room temperature.
ERROR CODES:
AS - Room Temperature Sensor Error - Unplug the
unitandplugitbackin.Iferrorrepeats,call
Consumer Services at 844-472-2473.
E7 - Unit Manfunction - Unplug the unit and plug it
backin.Iferrorrepeats,callConsumerServices
at 844-472-2473.
ES
- Evaporator Temperature Sensor Error - Unplug
theunitandplugitbackin.Iferrorrepeats,call
Consumer Services at 844-472-2473.
NOTE: If an error code occurs in Fan only mode, the
unitwilldisplay“LO”(looseconnection)or“HI”
(short circuit).
NOTE
:
Iftheunitbreaksounexpectedlyduetopowerbeing
cut, it will restart with the previous function setting
automatically when the power resumes.
AIR DIRECTIONAL LOUVERS:
Usethe4-waydirectionallouverstodirecttheairow
up or down and left or right throughout the room as
needed.Pivothorizontallouversuntilthedesiredup/
down direction is obtained.
Move the levers from side to side until the desired
Left/Rightdirectionisobtained.
ADDITIONAL THINGS YOU
SHOULD KNOW:
● TheCoolcircuithasanautomatic3minutetime-
delayedstartiftheunitisturnedoandonquickly.
Afterunitisturnedo,leaveunitoforaminimum
of3minutesbeforeattemptingtoturnbackon.
This prevents overheating of the compressor
andpossiblecircuitbreakertripping.Thefanwill
continue to run during this time.
● Thecontroliscapableofdisplayingtemperaturein
degrees Fahrenheit or degrees Celsius. To convert
from one to the other, press and hold the Up and
DownTemp/Timerbuttonsatthesametimefor
3 seconds.
Air Direction
Levers
Display
12
CARE AND CLEANING
CAUTION
Cleanairconditioneroccasionallytokeepitlookingandoperatinglikenew.
Be sure to unplug the unit before cleaning to prevent shock or fire hazards.
AIR FILTER CLEANING
Theairltershouldbecleanedatleasteverytwoweeksoras
necessary.Trappedparticlesintheltercanbuildupandcausean
accumulation of frost on the cooling coils.
● Openthefrontpanel.
● Graspthelterbythecenterandpullupandoutasshowninthe
diagram on the right.
● Washthelterusingliquiddish-washingdetergentandwarmwater.
Rinselterthoroughly.
● Gentlyshakeexcesswaterfromthelter.Besurethelteristhoroughly
dry before replacing.
● Asanalternativetowashingthelter,vacuumthelterclean.
NOTE: Never use hot water over 104°F (40°C) to clean the air filter. Never
attempt to operate the unit without the air filter.
CABINET CLEANING
● Besuretounplugtheairconditionertopreventshockorrehazard.The
cabinet and front may be dusted with an oil-free cloth or with a cloth
dampenedinasolutionofwarmwaterandmildliquiddish-washing
detergent. Rinse thoroughly and wipe dry.
● Neveruseharshcleaners,waxorpolishonthecabinetfront.
● Besuretowringexcesswaterfromtheclothbeforewipingthe
controls. Excess water in or around the controls may cause damage to
the air conditioner.
● Pluginairconditionerafterunithasdriedcompletely.
WINTER STORAGE
If air conditioner will be stored during the winter, remove it carefully from
the window according to the installation instructions. Cover it with plastic or
return it to the original carton.
ALWAYS STORE UNIT IN AN UPRIGHT POSITION AND IN A COOL, DRY LOCATION.
Take out the filter
Pull out the front panel
13
NOTE
Ahighlyrecommendedtroubleshootforanyissueingeneralconsistsofturningounitandunpluggingfor5
minutes. It is also recommended to try another wall outlet. For further assistance, contact Consumer Services at
844-472-2473.
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE, PLEASE REVIEW THE CHART BELOW
ISSUE POSSIBLE CAUSES
AIR CONDITIONER NOT
COOLING ROOM, OR NOT BLOWING
COLD AIR
•Besureunitisnottoolargeortoosmallfortheareaoftheroom.
•Verifythatalldoors,windows,curtainsandanyotheropeningsareclosed.
Verify nothing is obstructing the front grille of unit, such as curtains, etc.
•Allowenoughtimeforroomtocool,especiallyifoutsidetempisveryhigh.
•Checkthatthelterisnotdirtyandlouversareopenallthewayandblowinginthe
desired direction.
•CheckthatunitissettoCOOLmodeandthattemperatureisdownenough(but
not too low).
•Ifunitisnearaheatsource,suchasastove,etc.,relocateunit.
•Ifaircomingfromunitiscooltothetouch,thenunitisworkingproperly;please
doublechecktherstthreebulletpointsabove.
•IfusingFollowMeremotefeature,moveremoteawayfromunit.
•Temperaturesensorbehindairltertouchingcoldcoil.Thesetwoelementsshould
not be touching. Carefully straighten tube away from coil.
•Unplugunitforatleast5minutes.FollowResetinstructionsonplug.
AIR CONDITIONER COOLING
BUT ROOM IS TOO WARM - ICE
FORMING ON COOLING COIL
BEHIND DECORATIVE FRONT
•Outdoortemperatureisbelow64ºF(18ºC).Todefrostthecoil,settoFAN
only mode.
•Airltermaybedirty.Cleanlter.RefertoCareandCleaningsection.Todefrost,
set to FAN only mode.
•Thermostatissettoocoldfornight-timecooling.Todefrostthecoil,settoFAN
only mode. Then, set temperature to a higher setting.
AIR CONDITIONER CYCLING ON
AND OFF TOO FREQUENTLY OR
NOT ENOUGH
•Besureunitisnottoolargeortoosmallfortheareaoftheroom.
•Removegrilleandmakesurethetemperaturesensorisnottooclosetothecoils.
These two elements should not be touching. Carefully straighten tube away
from coil.
•Makesurenothingisblockingthegrilleorsidevents.
•Makesurethereisnodirtordebrisinsidetheunitoronthelter.
UNIT WILL NOT TURN ON
•Resetcircuitbreaker.Makesuretherearenottoomanyitems(i.e.lamps,TV’s,
etc.)workingothesamebreaker.
•Checkplugconnection.
•Ifplugisoperatingonanon/oswitch,besurethattheswitchis‘on’.
•Trypluggingunitintoanotheroutlet.
•Unplugunitforatleast5minutes.FollowResetinstructionsonplug.
UNIT BLOWS FUSES OR POPS
CIRCUIT BREAKER
•Makesurethereareenoughavailableampsonthecircuitfortheairconditioner.
•Largeunitswhichrunona230vwillrequireadedicated20or30ampcircuit.
AIR CONDITIONER IS
MAKING NOISES
•Checktobesuretheunitisfreefromdebrissuchasleaves,sticks,etc.Verify
nothing is obstructing the unit.
•Checkthefanbladeforcracksorchips.
•Makesuretheunitisproperlyandsecurelymountedinsidethewindoworwall.
•Cleantheairlter.
WATER PUDDLES INSIDE UNIT OR IS
COMING INTO ROOM
•Adjusttheslopeoftheunitsothatitdrainsdownwardtowardtheexteriorofthe
home. (See Installation Instructions.)
•Makesurethatthereisnodebrisblockingthedrainageareaoftheunit.
WATER DRIPPING OUTSIDE
•Unitisremovingalargequantityofmoisturefromahumidroom.Thisisnormal
during excessively humid days.
REMOTE SENSING / FOLLOW ME
DEACTIVATING PREMATURELY
•Remotecontrolnotlocatedwithinrange.Placeremotecontrolwithin20ftand
180ºradiusofthefrontoftheunit.
•Remotecontrolsignalobstructed.Removeobstruction.
The design and specifications are subject to change without prior notice for
product improvement. Consult with the sales agency or manufacturer for details.
Distributed by:
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
WINDOW
AIR CONDITIONER
FOR MODELS:
1PAQ8000
Before using your air conditioner, please
read this manual carefully and keep it for
future reference, along with your receipt.
Specification and performance data is subject to change without notice.
Printed in China
PA/User_1PAQ8000/08302018
USER MANUAL
