1.8M HEAVY-DUTY STEEL WORKBENCH WITH
25MM MDF TOP
MODEL NO: AP0618.V5
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
workbench.
Wear protective gloves and goggles during assembly.
Locate workbench in a suitable work area.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use workbench on level and solid ground, preferably concrete.
Keep the workbench clean and tidy in accordance with good workshop practice.
Keep children and unauthorised persons away from the work area.
DO NOT use the workbench for any purpose other than that for which it is designed.
DO NOT use the workbench outdoors.
DO NOT place the workbench in a damp or wet location or an area where there is condensation.
DO NOT clean the workbench with any solvents which may damage the surfaces or the protective coating.
DO NOT move the workbench when there are items placed on it.
DO NOT overload the workbench.
DO NOT undertake work on the workbench without the workpiece being adequately secured. Use clamps or a vice (not included but
available from your Sealey stockist), to secure the workpiece.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but
must be applied by the operator.
2.
INTRODUCTION
Thick 25mm MDF worktop, used for adding extra rigidity and durability. Powder coated steel frame, for added corrosion resistance.
Four adjustable feet for levelling on uneven ground. Some simple assembly required.
3. SPECIFICATION
Model no: ..................................................... AP0618.V5
Size (W x D x H): ...........................1800 x 600 x 910mm
Maximum capacity (evenly distributed): ................ 500kg
4. CONTENTS
Refer to
instruction
manual
Wear protective
gloves
Wear goggles
No. Description Qty.
1 MDF Table Top 1
2 H Leg frame 2
3 Lower Beams 2
4 Upper Beams 2
5 Self Tapping Screws 12
1
2
2
3
4, 5
3
Original Language Version
© Jack Sealey Limited
AP0618.V5 Issue 2 (4,5) 09/08/23
5. ASSEMBLY
5.1. Fittopbeamstoeachlegsectionusingrubberhammer,noxingsrequired.
5.2. Fitbottombeamstoeachlegsectionusingrubberhammer,noxingsrequired.
5.3. Adjust feet to level worktop.
5.4. Fittop,xfromunderneathusing12suppliedself-tappingscrews.
6. MAINTENANCE
6.1. Regularly check full engagement of beams (items 3 and 4) with H Leg Frames (items 2) in
order to maintain stability of the bench.
6.2. Gentlybrushotheworksurfaceandbeamsafteruse.
6.3. Clean the work surface and beams with a soft cloth and a mild water/detergent solution.
.
Original Language Version
© Jack Sealey Limited
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
AP0618.V5 Issue 2 (4,5) 09/08/23
