Sealey CP108VMGBO 10.8V Cordless Multipurpose Mini Grinder User Manual

10.8V CORDLESS MULTIPURPOSE MINI

GRINDER & 50PC ACCESSORY KIT - BODY

ONLY

MODEL NO: CP108VMGBO

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Remove the battery pack from the cordless multipurpose mini grinder before changing accessories, servicing or

performing any maintenance.

9 Maintain the cordless multipurpose mini grinder in good condition. Check moving parts alignment on a regular basis.

9 Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be

dangerous and will invalidate the warranty.

9  Ensurethecordlessmultipurposeminigrinderisswitchedo󰀨beforeinstallingthebatterypack.

9 Keep the cordless multipurpose mini grinder clean for best and safest performance.

9  Removeillttingclothing.Removeties,watches,ringsandotherloosejewelleryandcontainlonghair.

9  Evaluateyourworkingareabeforeusingthecordlessmultipurposeminigrindere.g.ceilings,oorsandenclosuresmaycontain 

electrical items or water piping.

9 Ensure battery pack (sold separately) is correctly inserted into the cordless multipurpose mini grinder and latched in place before

attempting to switch on.

9 Secure loose work pieces with a clamp, vice or other adequate holding device (not supplied).

9 Avoid unintentional starting.

9 Wear approved safety eye protection (standard spectacles are not adequate).

9  Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-skidshoes.

9 Keep children and unauthorised persons away from the working area.

9 Store the cordless multipurpose mini grinder and accessories in the original box, in a safe, dry, childproof area where the

temperature will not exceed 104°F (40°C).

8 DO NOTusethecordlessmultipurposeminigrinderwherethereareammableliquids,solidsorgases,suchaspaintsolvents,etc.

8 DO NOT allow children to operate the cordless multipurpose mini grinder.

8 DO NOToperatethecordlessmultipurposeminigrinderifanypartsaremissingasthismaycausefailureand/orpersonalinjury.

8 DO NOT hold unsecured work piece in your hand.

8 DO NOT leave the cordless multipurpose mini grinder operating unattended.

8 DO NOTcarrythecordlessmultipurposeminigrinderwithyourngeronthepowerswitch.

8 DO NOT use the cordless multipurpose mini grinder for a task it is not designed to perform.

8 DO NOToperatethecordlessmultipurposeminigrinderwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicating

medication.

8 DO NOT get the cordless multipurpose mini grinder or battery wet or use in damp or wet locations.

8 DO NOTforcethecordlessmultipurposeminigrinder.Usethecorrecttoolforthejobitwasdesignedfor.

8 DO NOT use any accessories other than those supplied with the cordless multipurpose mini grinder.

8 DO NOT use any accessory tools which require any liquid coolant.

2. INTRODUCTION

Compact,lightweightcordlessmultipurposeminigrinderand50-pieceaccessorykit-bodyonly.Comfortablecompositehousingwithsoftgrip

toreducevibration.7-Speedsettingsprovidethecontrolrequiredtocompletevarioustasks.Quickreleasecolletandspindlelockforfasttool

changes.Suppliedwitha50-piecerangeoftips,wheels,discs,dressingstonesandachuckspanner.IntegralLEDworkinglightandLED

battery level indicator. Requires compatible 10.8V 2Ah or 4Ah battery and mains charger, sold separately.

3. SPECIFICATION

Model no: ....................................................... CP108VMGBO

Battery: ......................................................10.8V 2aH or 4Ah

Consumable parts (battery) ....................................................

2Ah ...................................................................... CP108VBP

4Ah .................................................................... CP108VBP4

Collets: .........1.0 (x1), 1.7 (x1), 2.0 (x1), 2.4 (x1), 3.2 (x1)mm

Free speed: ................................................. 5000-25000rpm

CP108VMGBOIssue107/04/21

Original Language Version

Refer to

instructions

Wear eye

protection

Wear protective

gloves

Wear a mask

4. CONTENTS

ACCESSORIES

HSS drill bits: ....................................................................... 6

Mandrels as tool holders: ..................................................... 2

Polishing discs: .................................................................... 3

Grinding discs: ..................................................................... 4

Metal brush: ......................................................................... 1

Cutting discs: ..................................................................... 16

Collet chucks: ...................................................................... 5

Synthetic brushes: ............................................................... 2

Milling bits ............................................................................ 3

Engraving bits: ..................................................................... 2

Grinding bits: ........................................................................ 5

Combination spanner: .......................................................... 1

5. OPERATION

Unpack the product and check contents. Should there be any damaged or missing parts contact your supplier immediately.

 Beforeuse,ensurethatyouhavereadandunderstoodsection1SafetyInstructions.

5.1. SWITCHING ON AND OFF

Also refer to sections 7 and 8.

5.1.1. Insertthebattery.

5.1.2.  ToturnthecordlessmultipurposeminigrinderOnsettheOn/O󰀨switch(g1-1)to“I”.

5.1.3.  ToturnthecordlessmultipurposeminigrinderO󰀨settheOn/O󰀨switch(g1-1)to“O”.

5.2. SETTING THE SPEED RANGE

5.2.1. Setthespeedcontroldial(g1-5)toapositionbetween“1”and“MAX”.

5.3. CHECKING THE BATTERY CHARGE LEVEL

5.3.1.  Insertthebattery.

5.3.2.  SettheOn/O󰀨switch(g1-1)tothe“I”position.

5.3.3.  TheremainingchargewillbeshownonthebatterychargelevelLED(g1-2)asfollows:

Red/Orange/Green = maximum charge

Red/Orange = medium charge

  Red=lowcharge-re-chargethebattery

5.4. CHANGING THE COLLET CHUCK

5.4.1. Ensure the cordlessmultipurposeminigrinderisswitchedo󰀨andthebatteryremoved.

5.4.2.  Pressthespindlelockbutton(g1-4)andholditdown.

5.4.3.  Keepingpressureonthespindlelockbutton(g1-4)turnthecolletnut(g1-3)untilthespindlelockclicksintoplace.

5.4.4.  Undothecolletnut(g1-3)fromthethreadedoutputshaftusingthecombinationspannerandremove.

5.4.5.  Selecttheappropriatecolletchuck(g1-6)andinsertcentrallyintotheopeninginthethreadedoutputshaft.

5.4.6.  Replacethecolletnut(g1-3)andscrewngertightonly.Releasethespindlelockbutton(g1-4).

5.5. INSERTING THE ACCESSORY TOOL

5.5.1. Repeat sections 5.4.1 to 5.4.3.

5.5.2.  Selectthetoolrequiredandinsertthetoolshaftcentrallyintotheappropriatecolletchuck(g1-6).

5.5.3.  Fullytightenthecolletnut(g1-3)usingthecombinationspanner.Releasethespindlelockbutton(g1-4).

NOTE: Use the screwdriver end of the combination spanner to undo and tighten the screw on the mandrels.

5.6. OPERATING THE CORDLESS MULTIPURPOSE MINI GRINDER

5.6.1. Select the speed required. See section 5.2

5.6.2.  Selectcolletchuckandthetoolingaccessoryrequired.Seesections5.4and5.5.Re-insertthebatterypack.

5.6.3.  Holdthecordlessmultipurposeminigrinderrmlybytheinsulatedgrippingsurfacesandturnthecordlessmultipurposemini 

grinder ON. See section 5.1.

8 DO NOT switch the cordless multipurpose mini grinder ON if the accessory tool is in contact with the workpiece. Allow the cordless

multipurpose mini grinder to reach the required speed before applying it to the workpiece.

8 DO NOT press the spindle lock button when the cordless multipurpose mini grinder is running.

WARNING!Ensurethatthecolletnut(fig1-3)isfullytightened,andthatthetoolingspindleisexactlymatchedtothe  

corresponding collet chuck. Accessory tools which do not fit precisely with the collet chuck, or become loose, will rotate unevenly,

  vibrate,or“fly”offviolentlywhichcanleadtoalossofcontrolandtheriskofpersonalinjury.

 WARNING! The brush accessory tool can loose wire bristles during normal operation. DO NOT apply excessive pressure to the wire

brush as the discarded wire bristles can easily penetrate light clothing and/or skin.

g.1

CP108VMGBOIssue107/04/21

Original Language Version

CP108VMGBOIssue107/04/21

Original Language Version

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid

waste authority for recycling information.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

6. MAINTENANCE

6.1. Use a clean cloth to remove dirt, dust, oil, grease etc.

8 DO NOT use solvents to clean the cordless multipurpose mini grinder.

7. ROTATIONAL SPEED SELECTION

8. ACCESSORY TOOL SELECTION

SUGGESTED TOOL SELECTION

FUNCTION ACCESSORY USE

Drilling HSS drills Wood working

Milling Milling bit Recesses-Hollows-Grooves-Slits

Engraving Engraving bits Labelling-Handicrafts

Rust removal Metal brush Rust removal

Polishing Polishing discs Plastics-Preciousmetals

Cleaning Synthetic brushes Cleaning hard to access areas

Grinding Grindingdiscs-Grindingbits Stone-Wood-Ceramics-Alloysteel

Cutting Cutting discs Metal-Plastic-Wood

SUGGESTED SUITABLE SPEEDS

Speed control dial number Material

1-3 Plastics

4-5 Stone-Ceramics

5 Softwood-Metal

6 Hardwood

Max Steel
