SET OF 4 CORNER TRANSPORT DOLLIES
150KG CAPACITY
MODEL NO: CM4
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this corner moving
system.
WARNING! Use on a level and solid surface such as concrete.
8 DO NOT use the corner moving system for any purpose other than that for which it is designed.
8 DO NOT overload the corner movers, 37.5 kgs per corner mover.
8 DO NOT let go of the load whilst in motion.
9 Keep the general area where used clean, uncluttered and ensure there is adequate lighting.
9 Ensure that the corner movers are properly assembled before loading.
9 We recommend two operators for heavier loads.
9 Always push the loaded corner movers as near to bottom of the load as sensibly practical to avoid tipping hazard.
9 Always use all 4 corner movers to transport the load.
2. INTRODUCTION
Heavy-duty corner dollies manufactured from high quality steel with a maximum load weight of 150kg. Ideal for moving awkward rectangular
loads and provides increased mobility in locations where normal material handling equipment cannot be used. Each corner dolly is tted with
three free moving castor wheels for easy manoeuvrability and tted with a rubber covered load area to help secure loads. Ideal for moving
items such as cabinets, desks and much more. Sold in sets of four.
3. SPECIFICATION
Model No.: ..................................................................... CM4
Capacity ....................................................................... 150kg
4. ASSEMBLY
4.1. Place the 12 plain washers on to the 12 castor studs (fig.1).
4.2. Wind the castor studs into the 3 captive nuts in the corner platforms (fig.2). Ensure the castors are tight using “plumbers” pliers or
similar thin nosed grips on to the swivel ball race outer journal (fig.1).
4.3. Position the rubber pads as in fig.3.
Original Language Version
© Jack Sealey Limited
Refer to
instructions
g.1
g.2
g.3
Wear safety
footwear
CM4 Issue 2 (H,F) 26/02/20
5. OPERATION
5.1. Working on your own (two operators on heavy or tall loads), pivot the load and with your foot, roll the wheeled corner platforms
beneath as shown in fig.4. Nest fully and relocate (fig.5).
5.2. Remove as loaded and with your feet, steady the corner platforms. (Two operators on heavy or tall loads)
6. MAINTENANCE
6.1. Check swivel castor integrity regularly. See 4.2.
6.2. Keep clean with moistened cloth and mild detergent.
6.3. Smear ball journals with grease if required.
CM4 Issue 2 (H,F) 26/02/20
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.5
g.4
