PLATFORM TRUCKS
mODEL NO’S: CST991.v3, CST992.v3, CST993.v2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Always load evenly with the centre of gravity of the load as near the centre of the truck as possible.
9 Obtain additional support for large or wide loads to prevent tipping.
8 DO nOT overload the truck - see Specications.
8 DO nOT leave unattended, especially when loaded, unless the wheels are chocked or the truck is otherwise secured.
8 DO nOT use truck on uneven ground and do not run over curbs or steps - use a ramp.
8 DO nOT allow others to ride on the truck.
8 DO nOT use the truck if any part is signicantly damaged - pay particular attention to the wheels.
2. InTRODUCTIOn
Rigid platform trucks feature rubberised deck and bumper strip on CST991 and CST992 and heavy-duty wooden deck and tubular steel bumper
on CST993. Handles on CST991 and CST992 fold at for ease of storage. CST993 Handle detaches completely. Suitable for a variety of
warehouse, ofce and domestic applications.
3. SPECIFICATIOn
4. ASSEMbLY
numbers/letters in brackets refer to those on the relevant parts diagrams below.
4.1. CST991 & CST992
4.1.1. Remove the bolts and washers (C) from the underside corners of the deck and use them to attach the wheels (A, B).
note: Two wheels are swivel castors (B), these should be tted at the handle end of the deck.
4.1.2. To fold down the platform truck handle frame (CST 991.V3, CST 992.V3) push down the release bar (D) and fold the handle over
the base, release bar when in place.
4.2. CST993
4.2.1. Remove the bolts (C) and washers (D) from the underside corners of the deck and use them to attach the wheels (A, B).
note: Two wheels are swivel castors (B), these should be tted at the handle end of the deck.
4.2.2. Remove the two bolts (E) from the ends of the handle frame (F).
4.2.3. Locate the ends of the handle frame in the sockets in the deck frame and retain with the screws.
.
Refer to
instruction
manual
Model CST991.v3 CST992.v3 CST993.v2
Capacity 150kg 300kg 250kg
Height 815mm 870mm 960mm
Platform W X D 465 x 725mm 605 x 910mm 495 x 950mm
Platform height 140mm 185mm 225mm
Original Language Version
© Jack Sealey Limited
CST991.V3, CST992.V3, CST993.V2 | Issue:2 (H,F) 02/09/19
CST991 & CST992 CST993
Sealey Group, Kempson Way, Suffolk business Park, bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
EnvIROnMEnT PROTECTIOn
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. To obtain parts, please log on to
www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
