USE AND CARE MANUAL
MANUEL D’UTILISATION ET
D’ENTRETIEN
MANUAL DE USO Y CUIDADO
BUILT-IN DISHWASHER
LAVE-VAISSELLE ENCASTRÉ
LAVAVAJILLAS EMPOTRABLE
CATALOG NUMBER
NUMÉRO DE CATALOGUE
NÚMERO DE CATÁLOGO
BDW100M
Thank you for choosing BLACK+DECKER!
Merci d’avoir choisi BLACK+DECKER!
¡Gracias por elegir BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
VEUILLEZ LIRE AVANT DE RETOURNER CE PRODUIT POUR QUELQUE
RAISON.
POR FAVOR, LEA ESTE MANUAL ANTES DE DEVOLVER EL PRODUCTO POR
CUALQUIER RAZÓN.
If you have a question or experience a problem with your BLACK+DECKER purchase, go to www.blackanddecker.com/
instantanswers If you can’t find the answer or do not have access to the Internet, call 844-299-0879 from 10:30 a.m. to 6:30
p.m. EST Mon. - Fri. to speak with an agent. Please have the catalog number available when you call.
Si vous avez une question ou rencontrez un problème avec votre achat Black+Decker, allez sur
www.blackanddecker.com/instantanswers Si vous ne trouvez pas la réponse ou n’avez pas accès à l’Internet, appelez au
844-299-0879 de 10h30 à 18h30 HNE du lun. au ven. pour parler avec un agent. Veuillez avoir le numéro de catalogue
disponible lorsque vous appelez.
Si tiene una pregunta o experimenta un problema con tu compra de BLACK+DECKER, vaya a
www.blackanddecker.com/instantanswers Si no puede encontrar las respuestas que necesita o no tiene acceso a Internet, llame
al 844-299-0879 desde las 10:30 a.m. a las 6:30 p.m. EST de lunes a viernes para hablar con un agente. Por favor, tenga el
número de catálogo a mano cuando llame.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CONSERVEZ CE MANUEL POUR TOUTE CONSULTATION ULTÉRIEURE.
GUARDE ESTE MANUAL PARA SU REFERENCIA FUTURA.
ACTIVATE
WARRANTY
Page 2
Page 3
ENGLISH
Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
product.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
Page 4
ENGLISH
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USING THE DISHWASHER
2. Use the dishwasher only for its intended function.
3. Use only detergents or wetting agents recommended for use in a
dishwasher and keep them out of the reach of children.
4. When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door
seal;
2) Warning: Knives and other utensils with sharp points must be
loaded in the basket with their points down or placed in a horizontal
position.
5. Check that the detergent receptacle is empty after completion of the
wash cycle.
6. Use only detergent and rinse additives designed for an automatic
dishwasher.
7. Never use soap, laundry detergent, or hand washing detergent in
your dishwasher. Keep these products out of the reach of children.
8. Keep children away from detergent and rinse aid. Keep children
away from the open door of the dishwasher, there could still be some
detergent left inside.
9. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
10. Children should be supervised to ensure that they do not play with
the appliance.
11. Dishwasher detergents are strongly alkaline, they can be extremely
dangerous if swallowed. Avoid contact with skin and eyes and keep
children away from the dishwasher when the door is open.
12. The door should not be left in the open position since this could
present a tripping hazard.
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using your dishwasher, follow basic precautions,
including the following
Page 5
ENGLISH
SAFETY INFORMATION
13. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
14. Remove the door to the washing compartment when removing an
old dishwasher from service or discarding it.
15. Please dispose of packing materials properly.
16. Use the dishwasher only for its intended function.
17. During installation, the power supply must not be excessively or
dangerously bent or flattened. Do not tamper with controls.
18. The appliance is to be connected to the water mains using new hose
sets and that old hose-sets should not be reused.
19. The maximum number of place settings to be washed is 12.
20. Do not use this dishwasher outdoors.
21. This appliance must be properly installed in accordance with the
installation instructions before its use.
22. This appliance must be connected to a proper electrical outlet with
the correct electrical supply.
23. Disconnect electrical power and water intake hose to dishwasher
before cleaning and/or servicing.
24. Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the dishwasher turn on
all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the gas
is flammable, do not smoke or use an open flame during this time.
25. Do not wash plastic items unless they are marked as dishwasher
safe. For plastic items not so marked, check the manufacturer’s
recommendations.
26. Do not touch the HEATING ELEMENT during or immediately after
use.
27. Do not operate your dishwasher unless all ENCLOSURE panels are
properly in place.
28. Do not tamper with controls.
Do not abuse, sit on, or stand on the door or dish rack of the
dishwasher.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
GROUNDING INSTRUCTIONS
Page 6
ENGLISH
SAFETY INFORMATION
ELECTRICAL REQUIREMENTS
This appliance must be grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance
for electric current. This appliance is equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is installed and grounded in accordance with all local codes
and ordinances.
POWER SUPPLY CORD
• If the power supply cord is too short, do not use an extension cord.
Have a qualified electrician or serviceman install an outlet near the appliance.
WARNING
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service representative if you are
in doubt whether the appliance is properly grounded. Do not modify the plug
provided with the appliance, if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
Page 7
ENGLISH
SET UP & USE
INSTALLATION INSTRUCTIONS
CAUTION: The installation of the pipes and electrical equipment should be done by
professionals.
The installation position of dishwasher should be near the existing inlet and drain
hoses and power cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain
hoses of the dishwasher.
Position the appliance in the desired location. The back should rest against the
wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is
equipped with water supply and drain hoses that can be positioned to the right or the
left to facilitate proper installation.
WARNING: DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH
THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
GROUND CONNECTION FROM THE POWER CORD.
State of California Proposition 65 Warnings:
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov.
WARNING
Electrical Shock Hazard - Disconnect electrical power before installing dishwasher.
Failure to do so can result in death or electric shock.
WARNING
Tip Over Hazard
• Do not use dishwasher until completely installed.
• Do not push down on open door.
• Doing so can result in serious injury or cuts.
Page 8
ENGLISH
SET UP & USE
WARNING
Suocation Hazard-Before you throw away your old appliance, remove the door or
lid so that children cannot hide or get trapped inside your old appliance. Failure to
follow these instructions can result in death or brain damage.
CAUTION:
• Never use harsh chemicals to clean your dishwasher. Some chloride-containing
products can damage your dishwasher and may present health hazards!
• Never use steam cleaning products to clean your dishwasher. The manufacturer will
not be responsible for the possible damages or consequences.
• To avoid possible dishwasher damage, do not use harsh chemicals, abrasive
cleaners, scouring pads (metal or plastic), or abrasive cloths/paper towels to clean
your dishwasher’s exterior door panel. Your dishwasher’s exterior door panel can be
damaged by doing so.
• It is highly recommended that the user become familiar with the procedure to
shut o the incoming water supply and the procedure to shut o the incoming
power supply. See the Installation Instructions or contact your installer for more
information.
• If the dishwasher drains into a food disposer, make sure disposer is completely
empty before running dishwasher.
• NSF/ANSI 184 Certifed residential dishwashers are not intended for licensed food
establishments.
• Protect your dishwasher from the elements. Protect against freezing to avoid
possible damage to the fill valve. Damage caused by freezing is not covered by the
warranty.
• Not for outdoor use.
Page 9
ENGLISH
SET UP & USE
OPERATING REQUIREMENTS
ELECTRICAL REQUIREMENTS
This dishwasher is designed for operation on an adequately wired individual 120 V, 60
Hz, 15- or 20-amp fused electrical supply with copper wire only. It is recommended
that a time-delay fuse or circuit breaker is used, and that a separate circuit serving
only this appliance is provided. If an outlet is used, the outlet should be placed in
adjacent cabinet.
LOCATION REQUIREMENTS
• Install where dishwasher is protected from the elements. Protect against freezing to
avoid possible rupture of fll valve. Such ruptures are not covered by the warranty.
For winter storage information, see “Storing” in the “Dishwasher Care” section.
• Install and level dishwasher on a floor that will hold the weight and in an area
suitable for its size and use.
WATER SUPPLY REQUIREMENTS
• The water supply temperature should be 120°F to 150°F (49°C to 66°C).
• The water supply must maintain water pressure between 20 and 80 psi for sucient
flow.
WARNING
Electrical Shock Hazard-
• Electrically ground dishwasher.
• Connect ground wire to green ground connector in terminal box.
• Do not use an extension cord.
• Failure to follow these instructions can result in death, fire, or electrical shock.
Page 10
ENGLISH
SET UP & USE
PARTS AND FEATURES
Cup Shelf
Middle Spray Arm
Lower Rack
Upper Rack
Tub Gasket
Sliverware Basket
Heating Element
Rinse Aid
Dispenser
Lower Spray Arm
Detergent
Dispenser
SPECIFICATIONS
Capacity: 12 Place Settings
Dimensions (WxDxH): 23 3/5" x 22 7/10" x 33 3/4" (600x576x855mm)
Weight Unpacked: 81.35 lb (36.9kg)
Power Supply: 120 volts, 60 Hz
Rated Power Usage: Wash motor 50 W Heater 840 W
Water Feed Pressure: 20 - 80 psi (138 - 552 kPA)
Page 11
ENGLISH
SET UP & USE
FILTER SYSTEM
Your dishwasher has a multiple filter system, which helps your dishwasher perform
better using less water and less energy.
The flter system includes three filters that work in combination to separate dirty and
clean water into dierent chambers.
SMART WASH SYSTEM
Your dishwasher has a Smart Wash system which can be used by selecting the Auto
cycle.
The Smart Wash system senses the soil level of the load and adjusts the wash cycle
accordingly. Your dishwasher can determine the type of cycle required to clean the
dishes and will clean more eciently every time.
ADJUSTABLE UPPER RACK
The Adjustable Upper Rack feature allows you to load taller items in either the
upper or lower rack.
The upper rack of your dishwasher can be adjusted 2” (5.08 cm).
Adjusting the clearance of the Upper Rack increases or decreases the clearance
of the lower rack, as shown.
For instructions, see the “Adjustable Upper Rack” section.
a
Filter Location
a
2" (5.
08 cm)
Page 12
ENGLISH
SET UP & USE
START UP GUIDE
IMPORTANT!
• Properly dispose of/recycle all packing material.
• Read this entire User Manual. You will find important safety information and
useful operating tips.
HOW YOUR DISHWASHER CLEANS
Your dishwasher cleans by spraying a mixture of hot water and detergent through
the spray arms against soiled surfaces.
The dishwasher fills with water covering the filter area. Water is then pumped
through the multiple filters and spray arms. Soil particles are separated from the
water and go down the drain as the water is pumped out and replaced with clean
water.
The number of water fills will vary depending on the cycle selected.
BEFORE USING YOUR DISHWASHER
1. Check the filters for debris that may have been introduced from the packaging
or during installation. See the “Clean Filters” section.
2. Add Rinse Aid. See “Proper Use of Rinse Aid.”
USING YOUR NEW DISHWASHER
NOTE: To decrease cycle time and possibly improve performance, turn on the hot
water faucet nearest to the dishwasher until the water runs hot. Turn o
the water.
1. Load dishwasher. See “Dishwasher Loading.”
2. Add detergent. See “Proper Use of Detergent.”
3. Select desired CYCLE and OPTIONS. See “Cycle and Option Charts.”
• Only the Options available for the Cycle selected will illuminate.
• The controls of the selected Cycle and Options will glow to indicate they are
selected.
4. Close the door firmly to latch.
5. Press START.
Page 13
ENGLISH
SET UP & USE
CONTROLS
NOTE: when the door is closed.
A. Power
Press this button to turn on or turn o the dishwasher.
B. Cycle+ / Cycle-
Press this button to select corresponding washing program code.
Cycle+: Heavy Normal Delicate Quick Rinse Heavy
Cycle-: Heavy Rinse Quick Delicate Normal Heavy
Heavy
Heavy cycle is for pots, pans, casseroles and dinnerware with dried-on or baked
on soil.
Normal
Normal cycle with only the Heat Dry option selected is recommended to
completely wash and dry a full load of normally soiled dishes. The energy usage
label is based on this cycle and option combination with the upper rack in the
raised position.
Delicate
Delicate cycle is for items that need special care such as stemware or porcelain.
Quick
Quick cycle is for lightly soiled or well-rinsed dish loads.
Rinse
Use for pre-rinsing dishes or glasses. This is only a rinse that keeps food from
drying on your dishes and reduces odor buildup in your dishwasher until you are
ready to wash a full load.
C. ADDITIONAL FEATURES
Delay
The Delay Time feature allows you to program the dishwasher to begin the
selected wash cycle 3, 6 or 9 hours later.
Press the DELAY control repeatedly to toggle between ( 3h/6h/9h ). The LED
next to the selected time will illuminate.
NOTE: To cancel the Delay feature, press and hold the START control for 3
seconds to Cancel. To begin the wash cycle immediately, press START
again.
A C C FEB D
Page 14
ENGLISH
SET UP & USE
Child Lock
Use to lock all controls and prevent children from accidently changing the dishwasher
cycle or starting the dishwasher.
• Press and hold for 3 seconds Child Lock to either activate or cancel the Child Lock
option. After the function is selected the control lock icon will illuminate. If the the
function is cancelled, the control lock icon will go o.
D. OPTIONS
Options enhance the wash cycle. Some Options are available with only certain
Wash Cycles. Refer to the “Cycle and Options Charts” to see which Options are
available for the wash cycle you selected.
• Press the desired Option control(s). The Option control(s) illuminates to indicate
which option(s) have been selected.
Sanitize
WARNING: Only sanitizing cycles have been designed to meet the requirements
for soil removal and sanitization ecacy. There is no intention, either
directly or indirectly, that all cycles on a certifed machine have passed
the sanitization performance test.
The sanitize option sanitizes dishes and glassware in accordance with NSF
International NSF/ANSI Standard 184 for Residential Dishwashers. Certifed
residential dishwashers are not intended for use in licensed food establishments.
When the Sanitize option is selected, the water temperature will reach 156.2°F
(69°C) maximum.
The Sanitize Control illuminates to indicate when the Wash cycle with the
Sanitize option is completed. The light will turn off after the door has been
opened for 30 seconds.
NOTE: It is possible that the water will not reach 156°F (69°C) in the Sanitize
mode if the temperature of the incoming hot water does not meet the
minimum requirement of 120°F (49°C).
Heated Dry
When the Heated Dry option is selected, the heater will work during the drying
process.
E. INDICATOR LIGHTS
Rinse Aid
The Rinse Aid indicator light illuminates when the rinse aid level is low. Rinse Aid
should be added to the Rinse Aid dispenser.
Sanitized
The Sanitized indicator light illuminates when using the Sanitize option is finished.
The light turns o turns o when the door is opened and then closed or when
any button is pressed.
Clean
Turns on after a cycle is finished. Turns o when the door is opened and then
closed or when any button is pressed.
Page 15
ENGLISH
SET UP & USE
F. START
The cycle will begin. Start - Close the door and press Start.
PAUSE - If you need to pause or cancel a dishwasher cycle in process:
IMPORTANT!
Open the door slightly, and then wait for the spray arms and wash action to stop
before opening the door completely. Doing this will help keep you from being
splashed with hot water.
1. Open the door slightly and wait a few seconds until the wash action stops.
2. Open the door to add or remove items.
3. Close the door and then Press START to resume the wash cycle.
CANCEL - To cancel a cycle when the dishwasher is running, press and hold Start for
3 seconds.
CYCLE AND OPTION CHARTS
Depending on the Cycle selected, the Options available for selection will
illuminate.
Cycle times are approximate and will vary depending on the wash cycle and
options selected.
NOTE: Added Options can add more time and use more water.
Hot Water is necessary to activate the dishwasher detergent and melt fatty food
residue.
An automatic sensor checks the temperature of the incoming water. If the water
is not hot enough, the cycle will be lengthened to heat the water for the main
wash.
The Smart Wash Sensor detects the soil level of the dish load and may increase
or decrease cycle time depending on the number of water lls required to clean
the load.
Cycle Options Available Water Usage Cycle Time
Heavy Heated Dry Sanitize 7.13 gal. 27 L 151 mins.
Normal Heated Dry Sanitize
3.04-7.04gal.
11.5-26.6 L
108-146 mins.
Delicate Heated Dry Sanitize 7.0gal. 26.5L 118 mins.
Quick Heated Dry Sanitize 4.11gal. 15.5L 60 mins.
Rinse N/A 2.0gal. 7.6 L 20 mins.
Page 16
ENGLISH
SET UP & USE
DISHWASHER LOADING
PREPARE DISHES
• Empty liquids from glasses and cups.
• Remove leftover food, bones, toothpicks and other hard items from the dishes and
discard.
• It is not necessary to hand-rinse dishes before loading them into the dishwasher
with the following exceptions:
• Foods such as mayonnaise, mustard, vinegar, lemon juice and tomato-based
products may discolor stainless steel and plastics if allowed to remain on them for
any length of time.
• Burned-on foods should be loosened before loading the cookware into the
dishwasher.
LOAD DISHES
• It is IMPORTANT for the water spray to reach all soiled surfaces.
• Load dishes so they are not stacked or overlapping if possible. For best drying
results, water must be able to drain from all surfaces.
• Load heavy pots and pans carefully. Heavy items can dent the stainless steel interior
of the door if they are dropped or bumped.
• Make sure pot lids and handles, pizza pans, cookie sheets, etc., do not interfere with
the spray arm rotation.
• Make sure both the upper and lower spray arms are not blocked and move freely.
QUIET OPERATING TIPS
To avoid thumping/clattering noises during operation:
• Make sure lightweight items are secured in the racks.
• Make sure pot lids and handles, pizza pans, cookie sheets, etc., do not touch
interior walls or interfere with the rotation of the spray arm.
• Load dishes so they do not touch one another.
NOTE: For built-in models, keep sink drain plugs closed during dishwasher
operation to prevent noise transfer through drains.
Page 17
ENGLISH
UPPER RACK
The upper dishwasher rack is designed for cups, glasses, small plates, bowls and
plastic items marked dishwasher safe.
The upper rack can be easily adjusted 2” (5 cm) up or down to accommodate taller
items in either in the top or bottom rack.
ADJUST UPPER RACK
IMPORTANT!
• Remove all items before adjusting the rack. The rack must be empty. To adjust the
height of the upper rack, follow these steps:
SET UP & USE
1 Pull out the upper basket.
3 Re-attach the upper basket
to upper or lower rollers.
2 Remove the upper basket.
4 Push in the upper basket.
Page 18
ENGLISH
SET UP & USE
LOAD UPPER RACK
NOTE: The features on your dishwasher rack may vary from the drawings shown.
IMPORTANT!
Make sure the items loaded in the upper rack do not interfere
with the rotation of the middle spray arm located beneath the
upper rack. Check for interference by turning spray arm by hand.
• Place items so that the open ends face downward for cleaning
and draining.
• Load glasses and cups in upper rack only. The lower rack is not
designed for glasses and cups. Damage can occur.
• Place cups and glasses in the rows between tines. Placing them over the tines can
lead to breakage, water spots, and poor cleaning.
• Small bowls, pans and other utensils can be placed in the top rack. Load bowls in
the center section for best stability.
• China, crystal and other delicate items must not touch each other during dishwasher
operation. Damage may occur.
• Load plastic items so the force of the spray does not move them during the cycle.
8 Place Settings
12 Place Settings 8 Place Settings(DOE)
10 Place Settings
Page 19
ENGLISH
SET UP & USE
LOWER RACK
The lower rack is designed for plates, soup bowls, cookware and bakeware.
The adjustable upper rack allows you to load items up to 12.6” in height in the lower
rack.
IMPORTANT!
Items in the lower rack must be placed so that they do not interfere with the rotation
of the spray arms, block the water inlet, or keep the water spray from reaching the
detergent dispenser.
8 Place Settings
12 Place Settings
10 Place Settings
8 Place Settings(DOE)
Page 20
ENGLISH
SET UP & USE
LOAD LOWER RACK
NOTE: The features on your dishwasher rack may vary from the drawings shown.
• Do not load glasses, cups, or plastic items in the lower rack.
• Load small items in the lower rack only if they are secured in place.
• Load plates, soup bowls, etc. between tines. Do not nest bowls because the spray
will not reach all surfaces.
• Do not load items between the bottom rack and the side of the dishwasher tub.
• Place heavily soiled cookware face down in the rack.
ADJUSTABLE RACK TINES
The fold-down tines in the lower rack make it easier to load extra large or hard-to-fit
items such as serving bowls and roasters. The tines may be left in the up position for
normal use, or folded down for more flexible loading.
Page 21
ENGLISH
SET UP & USE
LOADING SILVERWARE
NOTES:
• Do not load silver or silver-plated silverware with stainless steel. These metals can
be damaged by contact with each other during washing.
• Some foods (such as salt, vinegar, milk products, fruit juices, etc.), can pit or corrode
silverware. DO NOT WASH ALUMINUM COOKWARE IN YOUR DISHWASHER.
THREE-PIECE SILVERWARE BASKET
The silverware basket consists of three separate sections. For optimum loading
fexibility, the center section of the basket can be used individually, joined with one or
both side sections or removed.
• Lift handle to remove the silverware basket and set the basket on a counter or table
top.
• Lift up on each side section to disengage the center section from the keyhole slots
in the side sections.
• Either replace the section(s) in the bottom rack and load the silverware, OR load the
silverware while the section(s) are on the countertop and then replace the basket in
the bottom rack.
a Keyhole Slots
b Prongs
a
b
Page 22
ENGLISH
SET UP & USE
For Best Results:
• Load items with handles down, using the separators to prevent silverware from
nesting.
• Place small items such as baby bottle caps, jar lids, corncob holders, etc. in the
section(s) with hinged cover(s). Close the cover to hold small items in place.
• Unload or remove the basket before unloading the racks to avoid water drops from
falling on the silverware.
• With handles up, mix items in each section of the basket with some pointing up and
some down to avoid nesting. Spray cannot reach nested items.
IMPORTANT!
Always load sharp items (knives, skewers, etc.) pointing down. Be sure that nothing
protrudes through bottom of the basket or rack that may block the wash arm.
Page 23
ENGLISH
SET UP & USE
1. Spoons
2. Knives
3. Salad Forks
4. Forks
5. Large Spoons
6. Large Forks
8 Place Settings
10 Place Settings
12 Place Settings
8 Place Settings(DOE)
Page 24
ENGLISH
DISHWASHER USE
PROPER USE OF DETERGENT
IMPORTANT!
• Use automatic dish washing detergent only. Other detergents can produce
excessive suds that can overfow out of the dishwasher and reduce washing
performance.
• Add detergent just before starting a cycle.
• Store detergent tightly closed in a cool, dry place. Fresh automatic dishwasher
detergent results in better cleaning.
DETERGENT DISPENSER
1. Push the dispenser cover release catch to open the main wash detergent
compartment.
NOTE: The flap is always open at the end of a dishwashing cycle.
2. Add the recommended amount of detergent to the detergent compartment.
SET UP & USE
Page 25
ENGLISH
3. Press down on the top of the cover to secure.
HOW MUCH DETERGENT TO USE
The amount of detergent to use depends on the soil level of your load, the type
of detergent used and the hardness of your water.
• If you use too little detergent, dishes won’t be clean.
• If you have soft water and use too much detergent, glassware will etch.
Water Hardness
Water hardness varies depending on your water source. For the best results,
your dishwasher is designed to operate with water that has a hardness of no
more than 7 grains per gallon. Test kits are available from all major appliance
parts retail outlets. If your water has a hardness over 8 grains per gallon, you may
consider installing a water softener or regularly use an additive to enhance the
performance of your detergent.
PROPER USE OF RINSE AID
Rinse aid prevents water from forming droplets that can dry as spots or streaks.
A small amount of the rinse aid is released into the final rinse water, which allows
water to drain from the dishes.
Rinse aid greatly improves drying performance after the fnal rinse.
Your dishwasher is designed to use a LIQUID rinse aid. Do not use a solid or bar-
type rinse aid.
RINSE AID DISPENSER
Under normal conditions, you will need to l the rinse aid dispenser
approximately once a month. Rinse aid is released through an opening in the
dispenser. You do not need to wait until the dispenser is empty to rel it. Try to
keep it full, but be careful not to overl it.
SET UP & USE
Page 26
ENGLISH
SET UP & USE
To refill the rinse aid dispenser
1. Lift up the end tab of rinse aid cover to open.
2. Fill the rinse aid dispenser with liquid rinse aid until full.
DO NOT overfill.
NOTE:
Use the viewing port when filling the rinse aid reservoir.
3. Press the rinse aid cover down rmly to close.
WARNING
DO NOT FILL THE RESERVOIR ABOVE THE FULL LEVEL INDICATOR.
EXCESS RINSE AID CAN OVERFLOW DURING THE WASH CYCLE.
Page 27
ENGLISH
If you have doubts about washing a particular item, check with the dishware
manufacturer to make sure it is dishwasher safe.
CLEANING & CARE
Material Dishwasher Safe Comments
Aluminum Possible
High water temperature and detergents can aect
fnish of anodized aluminum. Unfnished aluminum
will be discolored.
Disposable
Aluminum
No
Do not wash disposable aluminum pans in the
dishwasher These might shift during washing and
transfer black marks to dishes and other items.
Bottles and cans No
Wash bottles and cans by hand. Labels attached
with glue can loosen and clog the spray arms or
pump and reduce washing performance.
Cast Iron No Seasoning will be removed and iron will rust.
China /
Stoneware
Yes
Always check manufacturer’s recommendations
before washing. Antique, hand-painted, or over-
the-glaze patterns may fade, gold leaf can discolor
or fade.
Crystal Yes
Check manufacturer’s recommendations before
washing. Some types of leaded crystal can etch
with repeated washing.
Gold No Gold-colored fatware will discolor.
Glass Yes
Milk glass yellows with repeated dishwasher
washing.
Hollow-Handle
Knives
No
Handles of some knives are attached to the blade
with adhesive that can loosen if washed in the
dishwasher.
Pewter Brass,
Bronze
No
High water temperatures and detergent can
discolor or pit the fnish.
Disposable
Plastics
No
Cannot withstand high water temperatures and
detergents.
Plastics Yes
Always check manufacturer’s recommendations
before washing. Plastics vary in their capacity to
withstand high temperatures and detergents. Load
plastics in top rack only.
Stainless
Steel
Yes
Run a rinse cycle if not washing immediately.
Prolonged contact with food containing salt,
vinegar, milk products, or fruit juice can damage
finish.
Sterling Silver or
Silver Plate
Yes
Run a rinse cycle if not washing immediately.
Prolonged contact with food containing salt, acid,
or sulfde (eggs, mayonnaise, and seafood) can
damage fnish.
Tin No Can rust.
Wooden Ware No
Wash by hand. Always check manufacturer’s
instructions before washing. Untreated wood can
warp, crack, or lose its finish.
Page 28
ENGLISH
CLEANING & CARE
DISHWASHER CARE
CLEANING
CLEANING THE EXTERIOR
In most cases, regular use of a soft, damp cloth or sponge and a mild detergent is all
that is necessary to clean outside of your dishwasher. Clean the stainless steel door
and handle regularly with a clean, soft cloth to remove debris.
IMPORTANT!
Do not use appliance wax, polish, bleach, or products containing chlorine to clean the
stainless steel door.
Control Panel
Gently clean the control panel with a clean, soft cloth.
CLEANING THE INTERIOR
The tub is made of stainless steel designed to resist rust and corrosion if the
dishwasher is scratched or dented.
Hard water minerals can cause a white film to build up on the inside surfaces,
especially just beneath the door area.
Do not clean the dishwasher interior until it has cooled. Wear rubber gloves. Do
not use any type of cleanser other than dishwasher detergent because it may
cause foaming or create suds.
DOOR GASKET
Clean the steel inner door and tub with a clean, soft damp cloth.
Using a damp cloth, clean around the door gasket regularly to remove food
particles.
CONTROL PANEL
Clean the Control Panel gently with a lightly dampened cloth.
Page 29
ENGLISH
CLEANING & CARE
CLEANING THE FILTERS
Check and clean the filters regularly for best performance.
1. Remove the lower dishwasher rack.
2. Rotate the Cylinder filter counterclockwise a quarter turn and lift up to remove.
3. Empty the Cylinder filter and rinse it under running water.
4. Remove the Fine filter.
5. Remove the Micro filter from the bottom of the tub.
6. Inspect both the Fine filter and the Micro filter for debris, and then clean them
by holding the filters under slow running water.
NOTE: A sti, plastic bristle brush may be needed to remove some debris.
7. Reinstall the filters in reverse order making sure the Cylinder filter locks into
place.
a
a Cylinder Filter
a
a Fine Filter
a
a Micro Filter
Page 30
ENGLISH
CLEANING & CARE
DRAIN AIR GAP
Check the drain air gap anytime your dishwasher isn’t draining well. Some state
or local plumbing codes require the addition of a drain air gap between a built-in
dishwasher and the home drain system. If a drain is clogged, a drain air gap prevents
water from backing up into the dishwasher.
The drain air gap is usually located on top of the sink or countertop near the
dishwasher.
NOTE: The drain air gap is an external plumbing device that is not part of your
dishwasher. The warranty provided with your dishwasher does not cover
service costs directly associated with the cleaning or repair of the external
drain air gap.
To Clean the Drain Air Gap:
Clean the drain air gap periodically to ensure proper drainage of your dishwasher.
Follow the cleaning instructions provided by the manufacturer.
With most types:
1. Turn o the dishwasher.
2. Lift o the metal cover, and then unscrew the plastic cap.
3. Clean the plastic cap with a toothpick.
STORING
STORING FOR THE SUMMER
Protect your dishwasher during the summer months by turning o the water
supply and power supply to the dishwasher.
WINTERIZING YOUR DISHWASHER
Protect your dishwasher and home against water damage caused by freezing
water lines. If your dishwasher is left in a seasonal dwelling or could be exposed
to near freezing temperatures, have your dishwasher winterized by authorized
service personnel.
Prepare for Storage:
1. Turn o electrical power to the dishwasher.
2. Turn o the water supply.
3. Place a pan under the inlet valve, and then disconnect the water line from the
inlet valve.
4. Disconnect the drain line from the pump and drain water into the pan.
Prepare for Use:
1. Reconnect the water, drain and electrical power supply.
2. Turn on water and electrical power supply.
3. Fill detergent cup and run the dishwasher through a heated wash cycle.
4. Check the connections for leaks.
Page 31
ENGLISH
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Dishwasher
does not run or
stops during a
cycle
There is no power to the dishwasher.
The door is not closed tightly and
latched.
Most cycles pause for 5 minutes near
the start of a cycle to let the dishes
soak.
Certain cycles repeatedly pause for 15
to 65 seconds during the main wash.
The Delay feature is selected.
Replace fuse or reset circuit breaker.
Close and latch the door.
This is normal, and reduces the
energy required to clean the dishes.
This is normal.
To reset, see “Options” in the
Controls section.
Dishwasher
does not start
a cycle
Control Lock feature is activated. Deactivate Control Lock. See
“Additional Features” in the
Controls section.
Dishwasher will
not fill
The water shuto valve is not turned
on.
The door is not closed tightly and
latched.
Water pressure is too low.
Turn on the water valve.
Close and latch the door.
Verify a minimum of 20 psi water
pressure is maintained during the
flling operation.
Dishwasher
seems to run
too long
The water supplied to the dishwasher
is not hot enough.
The dishwasher runs longer
while heating water and a delay
automatically occurs in some wash
and rinse cycles until the water
reaches the proper temperature.
The Sanitize option is selected.
The cycle time will vary depending on
soil level.
Dishwasher is connected to the Cold
water supply.
Run the water in the adjacent sink
until it gets hot before turning on
the dishwasher.
The cycle time increases to heat the
water to the correct temperature
for sanitizing.
When heavy soil is detected, the
Normal cycle will automatically
increase the cycle time.
Verify the dishwasher is connected
correctly to the Hot water supply.
Troubleshoot your problem by using the chart below. If the appliance still does not
work properly, contact W Appliance Co. customer service center or the nearest
authorized service center. Customers must never troubleshoot internal components.
DISHWASHER NOT OPERATING PROPERLY
TROUBLESHOOTING & WARRANTY
Page 32
ENGLISH
TROUBLESHOOTING & WARRANTY
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Water
remains in the
dishwasher.
NOTE: A small
amount of
clean water
around the
outlet in the
bottom of the
tub is normal. It
keeps the seal
lubricated.
The cycle is not complete
or it is in a pause.
The drain hose is kinked.
The knockout plug is still in
the garbage disposal.
Drain hose is connected to
the garbage disposal, and
the garbage disposal is not
empty.
Drain is clogged.
The water will drain when the cycle is
completed.
Straighten the drain hose.
Remove the knockout plug.
Run the garbage disposal until it is empty.
Check the air gap.
Detergent
remains in the
dispenser
The cycle has not completed.
The detergent is damp or has
clumped.
An item was blocking the
dispenser.
The spray arm is blocked.
Close the door and press START to
complete cycle.
Remove detergent and replace with fresh
dry dishwasher detergent.
Remove item. Remove detergent and
replace with fresh dry dishwasher
detergent.
Load the dishes in a manner that does not
block the spray arm from rotating freely.
Grinding,
grating,
crunching or
buzzing sounds
A hard object or powder
detergent granules have
entered the wash module.
IMPORTANT: Clear glass is hard to see in
water and could result in a cut wound.
Using care, remove the hard object. If the
noise was caused by detergent granules,
the noise should stop once the detergent is
ground up.
NOTE: If the noise persists after a complete
cycle, call for service.
Beeps Indicates the wash cycle is
completed.
NOTE: A rapid beep indicates
an error condition.
This is normal.
See “Error Codes” for further direction.
Suds in the
Tub
Used wrong type of
detergent.
Use only detergent approved for automatic
dishwashers.
Dishwasher
Leaks
Excessive suds caused by
using improper detergent.
Dishwasher is not level.
Use only detergent approved for automatic
dishwashers.
Level the Dishwasher. See Installation
Instructions.
Rinse Aid light
is on
The Rinse Aid level is low. Add liquid Rinse Aid.
Page 33
ENGLISH
TROUBLESHOOTING & WARRANTY
DISHES ARE NOT COMPLETELY CLEAN
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Food residue
remains on the
dishes
Dishwasher is not loaded correctly. See “Dishwasher Loading.”
The wrong wash cycle for the dish
load was selected.
Select the wash cycle based on the
most dicult soil in the dishwasher
load. If you have some items with
heavier soils, use a heavier washing
cycle.
Water temperature is too low. For best results, the temperature
of the incoming water should be a
minimum of 120°F (49°C).
Used incorrect amount of detergent. Use a minimum of 1 Tbsp. (15 g)
detergent per load. Heavy soil and/
or hard water generally requires
additional detergent.
Food residue
remains on the
dishes (cont.)
Detergent is too old. Detergent must be fresh to be
eective. Store detergent in a cool,
dry area.
Detergent is caked in the dispenser. Do not allow detergent to sit for
several hours in a wet dispenser.
Clean dispenser and refll with fresh,
dry detergent.
The pump or spray arm is clogged
with labels from bottles and cans.
Check pump and spray arm for labels
and remove the labels.
The pressure of the water coming
into the home is too low.
Water pressure should be 20 to
80 psi (138 to 552 kPa) for proper
dishwasher fill. A booster pump on
the water supply can be added if
pressure is too low.
High suds are slowing the wash arm. Use only detergent recommended
for the dishwasher. Do not use soap
or laundry detergents.
Page 34
ENGLISH
TROUBLESHOOTING & WARRANTY
SPOTS AND STAINS ON DISHES
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Spotting and
filming on
dishes
Rinse Aid dispenser is empty.
Hard water. High mineral content in
your water.
Water temperature is too low.
Did not use enough detergent.
Add a liquid rinse aid to the
dispenser.
Use a rinse aid and keep the
dispenser flled to help eliminate
spotting and flming. Increase setting
on Rinse aid dispenser 1 number per
cycle until spotting is eliminated.
NOTE: If your water hardness or
above, it is strongly recommended
that you install a home water
softener.
For best results, water should be a
minimum 120°F (49°C) as it enters
the dishwasher.
Use a minimum of 1 Tbsp. (15 g) of
detergent per load. Heavy soil and/
or hard water generally require extra
detergent.
Spotting and
filming on
dishes (cont.)
Detergent is too old.
Home water pressure is too low to
fill dishwasher properly.
Detergent must be fresh and dry to
be eective. Store detergent in a
cool, dry area.
Water pressure to the home should
be 20 to 80 psi (138 to 552 kPa)
for proper dishwasher fll. A booster
pump on the water supply can be
added if pressure is too low.
Silica film or
etching
Using too much detergent.
The inlet water temperature exceeds
150°F (65°”C).
If you have soft water use less
detergent, but do not use less than 1
Tbsp. (15 g) per load.
Lower the incoming water
temperature.
Black or gray
marks on
dishes
Aluminum items rubbing dishes
during washing. Disposable
aluminum items can break down in
the dishwasher and cause marking.
Hand wash aluminum items. Remove
aluminum markings by using a mild
abrasive cleaner.
Orange stains
on plastic
dishes or
dishwasher
interior
Large amounts of tomato-based
foods on dishes placed in the
dishwasher.
Use a stain removal product to
remove stains from your dishwasher.
Stains will not aect dishwasher
performance.
Page 35
ENGLISH
TROUBLESHOOTING & WARRANTY
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Dishes are not
completely dry.
NOTE: Plastics
often need
towel drying.
Dishes are not loaded
properly to allow water
drainage.
Rinse Aid not used or
dispenser is empty.
Used an air dry or energy-
saving option.
Do not overload dishwasher. Place glasses
and cups in the rack so that the bottom
surface is slanted to allow water to run o.
Use a liquid rinse aid to speed drying and
keep the dispenser full.
For dryer dishes, select a Cycle that allows a
Heated Dry option.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Dishes are
chipped.
NOTE: Some
types of china
and glassware
might be too
delicate for
automatic dish
washing. Wash
by hand.
Dishes not loaded
properly.
Moving the rack in or out of
the dishwasher too quickly.
Load the dishes and glasses so they are
stable and will not strike together from
washing action.
Minimize chipping by moving the rack in
and out slowly.
DISHES DO NOT DRY COMPLETELY
DISHES ARE DAMAGED DURING A CYCLE
Page 36
ENGLISH
TROUBLESHOOTING & WARRANTY
ERROR CODES
When some malfunctions come on, the appliance will display error codes to warn
you:
CODES MEANINGS POSSIBLE CAUSE
Rinse light
flashes and
dishwasher
beeps for 30
seconds
Either the water flow
is insucient, or the
water pressure from
the incoming line is
too high.
• Faucet is not opened.
• Water pressure is too low.
• The drain hose is plugged.
• Other (parts failure of inlet or
drain system).
• Make sure
that the water is
turned on to the
dishwasher.
• Make sure that
the water pressure
is 20~100 psi.
• Check the drain
hose.
• Contact
Customer Service.
Delicate light
flashes and
dishwasher
beeps for 30
seconds
Overflow or leak
sensor activated
• A leak
• Too much water in the tub
Turn o water to
the dishwasher,
then check the
filter system for
blockage. Unblock
if necessary.
If there is no water
in the tub, contact
Customer Service
Normal,
Delicate, and
Rinse lights
flash and
dishwasher
beeps for 15
seconds
Communication
exception or issue
The display board can’t receive
or the main board can’t send a
signal for over 20 seconds.
Contact Customer
Service.
Page 37
ENGLISH
LIMITED WARRANTY
ACTIVATE WARRANTY
Any repair, replacement, or warranty service, and all questions about this product should be
directed to W Appliance Co. at 844-299-0879 from the US, including Puerto Rico, or Canada.
Some issues can be addressed without service. Before contacting regarding your warranty,
please visit the “Troubleshooting” section of your user manual.
All warranty service is provided exclusively by our authorized W Appliance Co. service providers.
For service in US, including Puerto Rico, and Canada call 1-844-299-0879 to create a ticket.
When calling, please have the following information available: date of purchase, model number,
proof of purchase and a brief description of the problem.
WHAT IS COVERED
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in
the country in which it was purchased:
ONE (1) YEAR FROM THE DATE OF DELIVERY OF THE ORIGINAL PURCHASE (PARTS AND LABOR INCLUDED):
W Appliance Co. will pay for factory-specied replacement parts and labor to correct defects in materials or workmanship that
existed when this major appliance was purchased, or at its sole discretion, replace the product with a new, or remanufactured,
unit equivalent to your original purchase. In the event of product replacement, your appliance will be warranted for the
remaining term of the original unit’s warranty period.
YEARS TWO (2) THROUGH FIVE (5) FROM DATE OF DELIVERY OF THE ORIGINAL PURCHASE (CERTAIN COMPONENT
PARTS ONLY - LABOR NOT INCLUDED): W Appliance Co. will pay for factory-specied replacement parts for the component
parts listed below to correct non- cosmetic defects in materials or workmanship in these parts that prevent function of this
major appliance and that existed when this major appliance was purchased:
DISHWASHER WASHING MACHINE DRYER
REFRIGERATORS AND
FREEZERS
MICROWAVE
Lower, Upper and
Third Level (where
applicable) Wire
Racks (excludes cup
shelves, silverware
basket, and third rack
trays), Chopper Blade,
Stainless Steel Tub and
Inner Door Liner
Drive Motor
(Stator and Rotor
Only)
Drive Motor
Only
Compressor
Only
Magnetron Tube
Only
ACTIVATE
WARRANTY
Page 38
ENGLISH
1. Commercial, non-residential or multiple family use or use
inconsistent with the product instructions and manuals.
2. In-home instruction on how to use your product.
3. Repair to correct improper maintenance, installation not
in accordance with installation instructions or electrical
or plumbing codes, or repair of household electrical or
plumbing systems.
4. Consumable parts (e.g., light bulbs, batteries, air or water
lters, preservation solutions, etc.).
5. Defects or damage resulting from accident, misuse, abuse,
alteration, re, oods, acts of God or improper installation.
6. Damages, defects, or repairs caused by unauthorized
servicers or use of non-genuine or third- party parts.
7. Any damage to the nish of appliance or home incurred
during installation, including but not limited to oors,
cabinets, walls, etc.
8. Cosmetic damage (e.g., scratches, dents, chips, and other
damage to appliance nishes), unless such damage results
from defects in materials and workmanship and is reported
to W Appliance Co., within 48 hours from date of delivery.
9. If the appearance or exterior of the product has been
damaged or defaced, altered or modied in design or
construction.
10. Discoloration, rust or oxidation of surfaces resulting
from caustic or corrosive environments (e.g., high salt
concentrations, high moisture or humidity or exposure to
chemicals).
11. Product pick-up or delivery. This warranty is for in-home
repair only.
12. Travel or transportation expenses for service in remote
locations where an authorized servicer is not available.
13. Products not accessible to provide required service or for
expenses making the product accessible for servicing.
14. Surcharges including but not limited to, any after hour,
weekend, or holiday service calls, tolls, ferry trip charges,
or mileage expenses for service calls to remote areas,
including the state of Alaska.
15. Repair, removal or reinstallation of inaccessible appliances
or built-in xtures (e.g., trim, decorative panels, ooring,
cabinetry, islands, countertops, drywall) that interfere with
servicing, removal or replacement of the product.
16. Appliances with original, factory installed model/serial
numbers removed, altered or not easily determined.
17. Incidental or consequential damages (e.g., loss of food or
medicine) resulting from appliance breakdown or delay in
service, repair or replacement.
18. Transportation and shipping costs associated with the
replacement of the unit.
19. Glass parts and other accessory items included with the
unit.
20. Products that have been purchased as refurbished, like
new, second-hand, under “as is” or “nal sale” terms.
21. Units that have been transferred from the original owner/
purchaser.
22. If there is damage due to power line surge, user damage
to the AC power cord or connection to improper voltage
source.
23. Products which are not defective or broken, or which are
working as described in the owner’s manual.
WHAT IS NOT COVERED / EXCLUSIONS
LIMITED WARRANTY
DISCLAIMER OF IMPLIED WARRANTIES
Repair or replacement as provided under this warranty is the exclusive remedy to the customer. W. Appliance Co. shall not
be liable for any incidental or consequential damages for breach of any express or implied warranty on this product, except to
the extent prohibited by applicable law. Any implied warranties, including any implied warranty of merchantability or implied
warranty of tness for a particular purpose, are limited to the duration of this warranty or the shortest period allowed by law.
Some states do not allow the exclusion or limitations of consequential damages, or limitations on how long the warranty lasts.
In these cases, the above exclusions or limitations may not apply to you. This warranty gives you specic legal rights and you
may also have other rights which may vary from state to state.
W. Appliance Co. does not warrant that the appliance will work properly in all environmental conditions and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or tness
for a particular purpose other than the purpose identied within this user’s manual. W Appliance Co. has made every effort
to ensure that this user’s manual is accurate and disclaims liability for any inaccuracies or omissions that may have occurred.
Information in this user’s manual is subject to change without notice and does not represent a commitment on the part of
W Appliance Co. W Appliance Co. reserves the right to make improvements to this user’s manual and/or to the product
described at any time without notice. If you nd information in this manual that is incorrect, misleading or incomplete, please
call 844-299-0879.
W Appliance Co.
New York, NY 10018
Page 39
ENGLISH
EXTENDED WARRANTY COVERAGE
Protect Your Appliance with Extended Warranty Coverage
Thank you for purchasing your new appliance! Your product comes with our one-year limited
warranty, but why stop there? With our Extended Warranty and Accidental Damage Protection
Plan, provided by Mulberry, you can ensure your appliances are covered for longer—without
worrying about unexpected breakdowns or accidents.
Why Upgrade to the Extended Warranty Plan?
• Comprehensive Protection – Extend your warranty coverage
and get full protection for accidental damage and mechanical/
electrical failures, giving you peace of mind well beyond the
rst year.
• No Hidden Costs – You won’t pay any deductibles or service
fees for repairs or replacements. We’ve got you covered!
• Avoid Expensive Repairs – Appliances like refrigerators,
air conditioners, and dishwashers can be costly to repair.
Keep your products running smoothly without the worry of
unexpected repair bills.
• Quick & Easy Claims – Mulberry offers hassle-free claims and
quick, reliable service when you need it most—no complicated
paperwork, just fast and efcient help.
Coverage Basic Warranty Protection +
Mechanical / Electrical Failure
Coverage
Yes
(1 year)
Yes
(2 - 4 years)
Service Fee or Deductible
Yes
(may apply)
No
Parts & Labor
Costs Covered
Yes
(limited to 1 year)
Yes
(2 - 4 years)
Hassle-Free
Claims Process
Standard
Priority
(faster service)
Repair / Replacement Options
Yes
(limited to 1 year)
Yes
(2 - 4 years)
Convenience &
Peace of Mind
Limited to 1 year
Guaranteed for
up to 4 years
ACTIVATE
WARRANTY
BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER
logos and product names and the orange and black color scheme are trademarks of
The Black & Decker Corporation, used under license. All rights reserved.
BLACK & DECKER, BLACK+DECKER, y los logos y nombres de productos de BLACK
& DECKER y BLACK+DECKER y el esquema de colores naranja y rojo son marcas
registradas de The Black & Decker Corporation, usados bajo licencia. Todos los
derechos reservados.
BLACK & DECKER, BLACK + DECKER, les logos et noms de produits BLACK & DECKER
et BLACK + DECKER, ainsi que la palette de couleurs orange et noir sont des marques
de commerce de The Black & Decker Corporation, utilisées sous licence. Tout droit
réservé.
Product in this box may differ slightly from that pictured. Does not affect function. Not
all accessories shown in photography are included in this package.
El producto en esta caja puede diferir ligeramente del representado en las imágenes.
Esto no afecta su función. No todos los accesorios mostrados en las fotografías son
incluidos en este paquete.
Le produit dans cette boîte peut différer légèrement de celui illustré. N’affecte pas la
fonction. Pas tous les accessoires présentés dans la photographie sont inclus dans ce
paquet.
Imported by W Appliance, Inc., 1356 Broadway, New York, NY 10018
Customer Service: 844-299-0879
Importado por W Appliance, Inc., 1356 Broadway, New York, NY 10018
Servicio al Cliente: 844-299-0879
Importé par W Appliance, Inc., 1356 Broadway, New York, NY 10018
Service À La Clientèle: 844-299-0879
October 2024 Printed in China
