Westinghouse WH10P NCCO Portable Air Purifier

Operation Manual - Transcript

• Page 1 - English - : CONTENT Basic Information Setting amp Operation Requirement Safety Instructions NCCO Technology Main Parts amp Components 0203 0810 Getting Started Firsttime Operation Operating Instructions Care amp Maintenance Cleaning Instructions Filter Replacement amp Maintenance Other Information FAQs Trouble Shooting Product Specification V2CAEN220825 Operation Manual Thank you for choosing Westinghouse NCCO Air Treatment Unit Before using and maintaining this appliance please read this manual carefully and thoroughly Please read the quotSafety Instructionsquot carefully before using this appliance Failure to follow the instructions to use this appliance may result in injury or property damage Please keep this manual in a safe place for future reference Please keep the warranty card for future repairs WARRANTY CARD ATTACHED NCCO Air Treatment Unit Model WHP
• Page 2 - English - : CONTENT Basic Information Setting amp Operation Requirement Safety Instructions NCCO Technology Main Parts amp Components 0203 0810 Getting Started Firsttime Operation Operating Instructions Care amp Maintenance Cleaning Instructions Filter Replacement amp Maintenance Other Information FAQs Trouble Shooting Product Specification V2CAEN220825 Operation Manual Thank you for choosing Westinghouse NCCO Air Treatment Unit Before using and maintaining this appliance please read this manual carefully and thoroughly Please read the quotSafety Instructionsquot carefully before using this appliance Failure to follow the instructions to use this appliance may result in injury or property damage Please keep this manual in a safe place for future reference Please keep the warranty card for future repairs WARRANTY CARD ATTACHED NCCO Air Treatment Unit Model WHP
• Page 3 - English - : Do not move the unit by pulling on the power cord Otherwise the power cord could be damaged resulting in fire or electric shock Do not damage the power line or the plug Do not cut refitting over twisting extruding power line Do not put the power line near to any heatsources do not put any heavy objects over the power line Otherwise the power line could be damaged resulting in fire or electric shock Do not use power source other than DCV A Otherwise the power line would overheated resulting in fire Do not put fingers metal or any other objects into air inlet outlet or gap Otherwise it could result in electric shock or injury Do not touch power plug with wet hand Otherwise it could result in electric shock Do not place the unit in a location near a water liquid source or where it can easily get wet Otherwise the unit may be shortcircuited and resulting in fire or electric shock It is prohibited to place small objects near any area of the unit where a child or infant might be liable to touch If the child or infant eat these small objects by mistake please immediately take the child or infant to hospital It is prohibited to place the battery in the fire or near heat Damage to the battery outer insulation cover or release valve could cause personal injury WARNING When any of the following situations occur please stop operating the unit and disconnect the power supply immediately Otherwise it may lead to electric shock fire or smoke When the power line is moved the unit stops operating If any control button fails If the circuit breaker works or the fuse burns out If the power line or plug is unusually hot If you notice burning odour or abnormal sound or vibration If there are any other abnormal phenomena or faults Stop operating unit pull out power plug and contact Customer Service Centre or distributor for inspection and maintenance Please clean the plug regularly If there is dust and moisture on the plug it may damage the insulation part of the plug and cause fire Pull out the power plug and wipe it with a dry cloth Pull out the power plug when the unit is not used for a long time Make sure disconnect the power supply before maintaining the unit Otherwise the unit may suddenly operate resulting in electric shock or injury Ensure that the power cord is securely and completely inserted into the power outlet before use Otherwise it may cause fire or electric shock if the power line is overheated Do not use damaged power plugs or power sockets Do not place the unit in the following places Unstable place Otherwise the unit may be fall off resulting in injury or damage to the unit Bathroom kitchen or other places with high humidity temperature Otherwise the unit may be damaged or suffer from electric leakage resulting in fire electric shock or personnel injury Places where oil or flammable gas may leak Otherwise fire may occur in the inhaled monitor leading to fire Near heater or other heat sources Otherwise the unit may be overheated leading to fire disaster Do not use gasoline or other volatile mixed solvents to wipe the unit Otherwise the unit may rupture or short circuited resulting in injury fire or electric shock Do not operating the unit while smoking pesticide is used Otherwise the pesticide may accumulate in the unit and then released from the outlet endangering health After using pesticide the room should be ventilated thoroughly before the unit can be operated Do not block the air inlet or outlet by placing clothes books or other obstacles Otherwise blocking the air outlet may lead to smoke and fire Do not sit stand or lean on this product Otherwise the unit may be overturned resulting in injury or unit damage If children is around please supervised carefully Do not approach the unit with ignited cigarettes incense and others Otherwise flammables may be sucked into the unit and cause fire Do not spray flammable materials such as insecticides or air fresheners around this product WARNING WARNING NOTE Take note of the symbols below and follow accompanying instructions carefully PROHIBITION MANDATORY Do not disassemble repair or modify the unit on your own Otherwise it could result in fire or electric shock If maintenance work is needed please contact Customer Service Centre or the distributor WARNING This symbol indicates if not follow the warning it would cause injury or death PRECAUTION This symbol indicatesif not follow the precaution it would cause injury or property loss In order to avoid injury safety instructions must be followed The below symbols classify the risk or degree of injury that may occur as the result of incorrect operation Safety Instructions Basic Information Please Follow Instructions Below Before using the appliance please read the safety and operation instructions carefully and thoroughly This appliance is not intended for use by persons including children with reduced physical sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety Children should be supervised to ensure that they do not play with the appliance If the power cord is damaged it must be replaced by either the manufacturer a service agent or a qualified service professional Prior to cleaning or maintaining the appliance must be unplugged and disconnected from its power source WARNING
• Page 4 - English - : Do not move the unit by pulling on the power cord Otherwise the power cord could be damaged resulting in fire or electric shock Do not damage the power line or the plug Do not cut refitting over twisting extruding power line Do not put the power line near to any heatsources do not put any heavy objects over the power line Otherwise the power line could be damaged resulting in fire or electric shock Do not use power source other than DCV A Otherwise the power line would overheated resulting in fire Do not put fingers metal or any other objects into air inlet outlet or gap Otherwise it could result in electric shock or injury Do not touch power plug with wet hand Otherwise it could result in electric shock Do not place the unit in a location near a water liquid source or where it can easily get wet Otherwise the unit may be shortcircuited and resulting in fire or electric shock It is prohibited to place small objects near any area of the unit where a child or infant might be liable to touch If the child or infant eat these small objects by mistake please immediately take the child or infant to hospital It is prohibited to place the battery in the fire or near heat Damage to the battery outer insulation cover or release valve could cause personal injury WARNING When any of the following situations occur please stop operating the unit and disconnect the power supply immediately Otherwise it may lead to electric shock fire or smoke When the power line is moved the unit stops operating If any control button fails If the circuit breaker works or the fuse burns out If the power line or plug is unusually hot If you notice burning odour or abnormal sound or vibration If there are any other abnormal phenomena or faults Stop operating unit pull out power plug and contact Customer Service Centre or distributor for inspection and maintenance Please clean the plug regularly If there is dust and moisture on the plug it may damage the insulation part of the plug and cause fire Pull out the power plug and wipe it with a dry cloth Pull out the power plug when the unit is not used for a long time Make sure disconnect the power supply before maintaining the unit Otherwise the unit may suddenly operate resulting in electric shock or injury Ensure that the power cord is securely and completely inserted into the power outlet before use Otherwise it may cause fire or electric shock if the power line is overheated Do not use damaged power plugs or power sockets Do not place the unit in the following places Unstable place Otherwise the unit may be fall off resulting in injury or damage to the unit Bathroom kitchen or other places with high humidity temperature Otherwise the unit may be damaged or suffer from electric leakage resulting in fire electric shock or personnel injury Places where oil or flammable gas may leak Otherwise fire may occur in the inhaled monitor leading to fire Near heater or other heat sources Otherwise the unit may be overheated leading to fire disaster Do not use gasoline or other volatile mixed solvents to wipe the unit Otherwise the unit may rupture or short circuited resulting in injury fire or electric shock Do not operating the unit while smoking pesticide is used Otherwise the pesticide may accumulate in the unit and then released from the outlet endangering health After using pesticide the room should be ventilated thoroughly before the unit can be operated Do not block the air inlet or outlet by placing clothes books or other obstacles Otherwise blocking the air outlet may lead to smoke and fire Do not sit stand or lean on this product Otherwise the unit may be overturned resulting in injury or unit damage If children is around please supervised carefully Do not approach the unit with ignited cigarettes incense and others Otherwise flammables may be sucked into the unit and cause fire Do not spray flammable materials such as insecticides or air fresheners around this product WARNING WARNING NOTE Take note of the symbols below and follow accompanying instructions carefully PROHIBITION MANDATORY Do not disassemble repair or modify the unit on your own Otherwise it could result in fire or electric shock If maintenance work is needed please contact Customer Service Centre or the distributor WARNING This symbol indicates if not follow the warning it would cause injury or death PRECAUTION This symbol indicatesif not follow the precaution it would cause injury or property loss In order to avoid injury safety instructions must be followed The below symbols classify the risk or degree of injury that may occur as the result of incorrect operation Safety Instructions Basic Information Please Follow Instructions Below Before using the appliance please read the safety and operation instructions carefully and thoroughly This appliance is not intended for use by persons including children with reduced physical sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety Children should be supervised to ensure that they do not play with the appliance If the power cord is damaged it must be replaced by either the manufacturer a service agent or a qualified service professional Prior to cleaning or maintaining the appliance must be unplugged and disconnected from its power source WARNING
• Page 5 - English - : Patented NCCONano Confined Catalytic OxidationAir Purification Technology is invented by Member of HKUST Entrepreneurship Program and has obtained global patents Our technology can solve indoor air quality problems in an allround way create a home office environment with fresh air and protect you and your familys health NCCO Technologys Characteristics Patented NCCO Technology continuously removes bacteria and viruses efficiently Patented NCCO Technology effectively decomposes carcinogens in the air such as formaldehyde Hazardous pollutants will be decomposed into harmless water molecule and carbon dioxide and will not accumulate in the filter effectively avoiding rerelease into the air due to saturation and will not cause secondary pollution Under normal maintenance conditions NCCO Reactor can be used for a long time Since there is no need to replace NCCO Reactor frequently the operating cost is much lower than similar products on the market Effectively remove offensive odour Patented NCCO Technology has been widely used in different industries such as schools hospitals nursing centers and public toilets Indoors As dust falls on the floor it is recommended to place the unit on a flat surface in the room Excellent Air Circulation Placing the unit on a dry solid level surface and ensure the unit is provided with reasonable space of at least cm from any objects in order to operate effectively Do not put the unit in the following places In the direct sunlight blown by air conditioner high temperature area Otherwise it may cause deformation aging discoloration or reduction of service life Distance over meter to objects such as televisions and radios Otherwise it may lead to image disorders and lost of sound Do not place objects at air inlet and outlet Otherwise it may affect the operating performance Do not use the same power outlet with TV radio and other equipment Otherwise it may lead to image disorders and lost of sound Please plug into other power outlets Do not place any items on top of the unit Otherwise the unit may be malfunctioned Basic Information NCCO Technology Patented NCCO Air Purification Technology Brings Fresh and Clean Air About Intelligent PowerOff Protection System Placing Area Guideline bMOLA NCCO Air Treatment Unit is designed using an Intelligent PowerOff Protection System The unit will intelligently power off after continuous use over a period of 8 hours and then will restart automatically after 30 minutes downtime once connected to an external power supply The unit will use the intelligent system to poweroff after continuous use of 2 hours and then will restart automatically after 10 minutes of downtime when using its internal battery power supply Our intelligent poweroff system is able to effectively avoid excessive load and eliminate any risk during the supply of power Setting amp Operation Requirement PRECAUTION Please pull out the power plug at the hand plug position Otherwise the power line may be damaged resulting in fire or electric shock It is prohibited to disassemble battery There are protection mechanisms and protection circuits inside the battery to protect the user Any improper dismantling will damage the protection mechanisms and possibly cause the battery to get heated generate smoke and fire It is prohibited to heat or burn the battery This may cause the melting of the battery insulator with the loss of its safety function and burn the electrolyte within High temperatures might cause the battery to overheat distort the case and lead to smoke and possibly fire It is prohibited to wet the unit The unit is installed with an internal battery Wetting the unit or placing it into water may cause the loss of functionality of the battery protective circuits This could lead to an abnormal chemical reaction leading to possible heating of the battery giving off smoke and start a fire Please avoid charging or operating the unit near a source of fire or under direct strong sunlight Do not charge or operate the unit near the source of a fire or oven or in an environment of excessive high temperatures Overheating could ensue causing functionality loss short circuit of the battery together with an abnormal chemical reaction This could overheat the battery leading to smoke and possibly fire WARNING If one observes an undesirable odour from the installed battery or from other areas within the unit on firsttime operation please do not operate and return to the distributor Please keep the unit away from an environment involving a heat source a high barometric pressure or an increasing pressure on the surface of unit during its operation Place the unit in a secure and safe operating location and away from children Avoid the unit being shaken in a serious vibrating environment Please avoid storing or operating the unit in a strong sunlit and hot environment This will prevent the battery from overheating becoming distorted smoking or shortening its life Please avoid operating the unit in an environment which might conduct static electricity and induce the battery to overheat distort generate smoke or shorten its life Please only charge the battery with the dedicated charger and follow the recommended charging method Insert battery in correct polarities It is prohibited to arbitrarily disassemble or refit unit and battery For safety concern do not place unit at a wet location To keep the battery at halfcharged condition without any damage and place in the unit a cool dry location when stored for a long period of time Do not put unit into fire or water WARNING LITHIUM BATTERY SAFETY PRECAUTION
• Page 6 - English - : Patented NCCONano Confined Catalytic OxidationAir Purification Technology is invented by Member of HKUST Entrepreneurship Program and has obtained global patents Our technology can solve indoor air quality problems in an allround way create a home office environment with fresh air and protect you and your familys health NCCO Technologys Characteristics Patented NCCO Technology continuously removes bacteria and viruses efficiently Patented NCCO Technology effectively decomposes carcinogens in the air such as formaldehyde Hazardous pollutants will be decomposed into harmless water molecule and carbon dioxide and will not accumulate in the filter effectively avoiding rerelease into the air due to saturation and will not cause secondary pollution Under normal maintenance conditions NCCO Reactor can be used for a long time Since there is no need to replace NCCO Reactor frequently the operating cost is much lower than similar products on the market Effectively remove offensive odour Patented NCCO Technology has been widely used in different industries such as schools hospitals nursing centers and public toilets Indoors As dust falls on the floor it is recommended to place the unit on a flat surface in the room Excellent Air Circulation Placing the unit on a dry solid level surface and ensure the unit is provided with reasonable space of at least cm from any objects in order to operate effectively Do not put the unit in the following places In the direct sunlight blown by air conditioner high temperature area Otherwise it may cause deformation aging discoloration or reduction of service life Distance over meter to objects such as televisions and radios Otherwise it may lead to image disorders and lost of sound Do not place objects at air inlet and outlet Otherwise it may affect the operating performance Do not use the same power outlet with TV radio and other equipment Otherwise it may lead to image disorders and lost of sound Please plug into other power outlets Do not place any items on top of the unit Otherwise the unit may be malfunctioned Basic Information NCCO Technology Patented NCCO Air Purification Technology Brings Fresh and Clean Air About Intelligent PowerOff Protection System Placing Area Guideline bMOLA NCCO Air Treatment Unit is designed using an Intelligent PowerOff Protection System The unit will intelligently power off after continuous use over a period of 8 hours and then will restart automatically after 30 minutes downtime once connected to an external power supply The unit will use the intelligent system to poweroff after continuous use of 2 hours and then will restart automatically after 10 minutes of downtime when using its internal battery power supply Our intelligent poweroff system is able to effectively avoid excessive load and eliminate any risk during the supply of power Setting amp Operation Requirement PRECAUTION Please pull out the power plug at the hand plug position Otherwise the power line may be damaged resulting in fire or electric shock It is prohibited to disassemble battery There are protection mechanisms and protection circuits inside the battery to protect the user Any improper dismantling will damage the protection mechanisms and possibly cause the battery to get heated generate smoke and fire It is prohibited to heat or burn the battery This may cause the melting of the battery insulator with the loss of its safety function and burn the electrolyte within High temperatures might cause the battery to overheat distort the case and lead to smoke and possibly fire It is prohibited to wet the unit The unit is installed with an internal battery Wetting the unit or placing it into water may cause the loss of functionality of the battery protective circuits This could lead to an abnormal chemical reaction leading to possible heating of the battery giving off smoke and start a fire Please avoid charging or operating the unit near a source of fire or under direct strong sunlight Do not charge or operate the unit near the source of a fire or oven or in an environment of excessive high temperatures Overheating could ensue causing functionality loss short circuit of the battery together with an abnormal chemical reaction This could overheat the battery leading to smoke and possibly fire WARNING If one observes an undesirable odour from the installed battery or from other areas within the unit on firsttime operation please do not operate and return to the distributor Please keep the unit away from an environment involving a heat source a high barometric pressure or an increasing pressure on the surface of unit during its operation Place the unit in a secure and safe operating location and away from children Avoid the unit being shaken in a serious vibrating environment Please avoid storing or operating the unit in a strong sunlit and hot environment This will prevent the battery from overheating becoming distorted smoking or shortening its life Please avoid operating the unit in an environment which might conduct static electricity and induce the battery to overheat distort generate smoke or shorten its life Please only charge the battery with the dedicated charger and follow the recommended charging method Insert battery in correct polarities It is prohibited to arbitrarily disassemble or refit unit and battery For safety concern do not place unit at a wet location To keep the battery at halfcharged condition without any damage and place in the unit a cool dry location when stored for a long period of time Do not put unit into fire or water WARNING LITHIUM BATTERY SAFETY PRECAUTION
• Page 7 - English - : Remove all packaging materials use a soft dry cloth to clean all the parts then reassemble parts back together Place the unit on a dry solid level surface and ensure the unit is provided with reasonable space of at least cm from any objects in order to operate effectively Check power sockets and any extension cords to confirm compliance with unit requirements Ensure that the unit is plugged in before usage The unit is equipped with a sensor If filters are not installed properly the unit will not operate When the unit is turned on for the first time warm air and mineral smell may be released from the air outlet This is normal as catalytic oxidation is taking place inside the NCCO Reactor and completely harmless to human body Getting Started Installation Procedures Take out HEPA Filter and NCCO Reactor from protective packaging material First put HEPA Filter into NCCO Reactor Frame Then install the filter set into unit body Close the Air Inlet Cover connect the unit with power supply then press the ON OFF Button to turn on unit Slightly push the concave upward to open Air Inlet Cover Illustrationg Diagram Basic Information Main Parts amp Components Firsttime Operation Air Inlet Cover HEPA Filter NCCO Reactor Unit Body ON OFF Button Air Outlet Power Adapter USB TypeC Power Cord Ribbon Optional Silicon Rubber Case Optional It is prohibited to clean soak or wet any parts or they could be damaged and so affect the unit operation
• Page 8 - English - : Remove all packaging materials use a soft dry cloth to clean all the parts then reassemble parts back together Place the unit on a dry solid level surface and ensure the unit is provided with reasonable space of at least cm from any objects in order to operate effectively Check power sockets and any extension cords to confirm compliance with unit requirements Ensure that the unit is plugged in before usage The unit is equipped with a sensor If filters are not installed properly the unit will not operate When the unit is turned on for the first time warm air and mineral smell may be released from the air outlet This is normal as catalytic oxidation is taking place inside the NCCO Reactor and completely harmless to human body Getting Started Installation Procedures Take out HEPA Filter and NCCO Reactor from protective packaging material First put HEPA Filter into NCCO Reactor Frame Then install the filter set into unit body Close the Air Inlet Cover connect the unit with power supply then press the ON OFF Button to turn on unit Slightly push the concave upward to open Air Inlet Cover Illustrationg Diagram Basic Information Main Parts amp Components Firsttime Operation Air Inlet Cover HEPA Filter NCCO Reactor Unit Body ON OFF Button Air Outlet Power Adapter USB TypeC Power Cord Ribbon Optional Silicon Rubber Case Optional It is prohibited to clean soak or wet any parts or they could be damaged and so affect the unit operation
• Page 9 - English - : Getting Started Operation Method A Put the unit on a flat surface Operating Instructions Getting Started Operating Instructions ON OFF Button After connecting unit with power supply press ON OFF Button to switch on unit The white light indicates the unit operates with Silent Mode LED Indicator Fan Speed Highest Lowest Running amp Charging Running amp Charging Low Power Low Power Blue Indicator White Indicator Slow Flash Fast Flash When the power ONOFF indicator flashes in different colours they indicate following situations First insert the TypeC connector of the power cord into the TypeC jack at the bottom of the unit Insert the other end of the power cord into the plug of the car charger and then insert into the charger socket It is not recommended put the unit on the car dashboard where the surrounding higher temperature may damage the builtin battery No car charger will be provided Memory Function When the external power supply is stopped or interrupted unexpectedly the unit will automatically transfer to its internal battery power supply When the battery is exhausted and the unit stops running it will memorise the operation mode and will return to the previous mode when external power is reconnected to it When the indicator flashes white and then blue alternately it indicates that the unit is off and is charging If the filter set is not installed into the unit a DiDiDi alarm will sound Please ensure that the filters are properly installed before turning on the unit When the unit is first turned on activated there will be a slight mineral smellThis is perfectly normal and is due to special manufacturing technique of the NCCO Reactor The smell is harmless and will disappear after a period of time operating the unit Please check and ensure that the car power supply is correct The power input of this unit is DCV A Handle the unit with care Press ON OFF Button again the unit operates with Silent Mode indicated by blue light Press ON OFF Button for the third time to switch off unit The unit is designed with memory function to memorize the last operation mode before switching off InCar Installation ATTENTION
• Page 10 - English - : Getting Started Operation Method A Put the unit on a flat surface Operating Instructions Getting Started Operating Instructions ON OFF Button After connecting unit with power supply press ON OFF Button to switch on unit The white light indicates the unit operates with Silent Mode LED Indicator Fan Speed Highest Lowest Running amp Charging Running amp Charging Low Power Low Power Blue Indicator White Indicator Slow Flash Fast Flash When the power ONOFF indicator flashes in different colours they indicate following situations First insert the TypeC connector of the power cord into the TypeC jack at the bottom of the unit Insert the other end of the power cord into the plug of the car charger and then insert into the charger socket It is not recommended put the unit on the car dashboard where the surrounding higher temperature may damage the builtin battery No car charger will be provided Memory Function When the external power supply is stopped or interrupted unexpectedly the unit will automatically transfer to its internal battery power supply When the battery is exhausted and the unit stops running it will memorise the operation mode and will return to the previous mode when external power is reconnected to it When the indicator flashes white and then blue alternately it indicates that the unit is off and is charging If the filter set is not installed into the unit a DiDiDi alarm will sound Please ensure that the filters are properly installed before turning on the unit When the unit is first turned on activated there will be a slight mineral smellThis is perfectly normal and is due to special manufacturing technique of the NCCO Reactor The smell is harmless and will disappear after a period of time operating the unit Please check and ensure that the car power supply is correct The power input of this unit is DCV A Handle the unit with care Press ON OFF Button again the unit operates with Silent Mode indicated by blue light Press ON OFF Button for the third time to switch off unit The unit is designed with memory function to memorize the last operation mode before switching off InCar Installation ATTENTION
• Page 11 - English - : Getting Started B Hang at the back of car pillow Operating Instructions Always disconnect the power supply of the unit before any maintenance or care process is carried out except replacing filters Otherwise the unit might still be running and could cause an electrical shock or injury ATTENTION When cleaning the unit please follow instructions given by the cleaning product Use a damp clean cloth to wipe the unit During maintenance ensure the disassembled parts are kept in a safe and secure place Otherwise parts could be lost or damaged Do not operate the unit if Filters have not been installed since this could cause irreversible damage to the unit If the HEPA Filter is not replaced periodically as indicated in the instructions it may seriously affect the efficiency of the NCCO Reactor Cleaning Instructions Cleaning Instructions Care amp Maintenance WARNING First properly place the unit into Silicon Rubber Case Then unbuckle the ribbon and put it into case Insert the TypeC connector of the power cord into the TypeC jack at the bottom of the unit Tightly hang the unit with ribbon at the back of car pillow and ensure unit away from swinging After washing the air inlet cover please ensure that it is completely dry before replacing onto the main unit Tips A damp nonabrasive cloth can be used to clean the unit surface Please remove Air Inlet Cover before washing it with water only Air Inlet Cover can be washed with water The main body of the unit can be wiped with a soft dry cloth but avoid dust falling on the unit改avoid having dust fall onto the unit during cleaning Cleaning External Surfaces of Unit Body ATTENTION WARNING Never rinse or soak HEPA Filter or NCCO Reactor in water When the unit has not been used for a long period of time ➀ Stop operating unit and pull power plug from power source ➁ Carry out any maintenance or care work ➂ Place the unit in a plastic or box carton and store in a cool dry place Use a soft brush or light vacuum to clean the air inlet and air outlet Cleaning Air Inlet and Air Outlet ATTENTION Location 1 Location 3 Location 2 Location 4 If user do not place the unit into Silicon Rubber Case it is suggested to paste Rubber Pads at the back side in order to protect unit Rubber Pads Operation Instruction
• Page 12 - English - : Getting Started B Hang at the back of car pillow Operating Instructions Always disconnect the power supply of the unit before any maintenance or care process is carried out except replacing filters Otherwise the unit might still be running and could cause an electrical shock or injury ATTENTION When cleaning the unit please follow instructions given by the cleaning product Use a damp clean cloth to wipe the unit During maintenance ensure the disassembled parts are kept in a safe and secure place Otherwise parts could be lost or damaged Do not operate the unit if Filters have not been installed since this could cause irreversible damage to the unit If the HEPA Filter is not replaced periodically as indicated in the instructions it may seriously affect the efficiency of the NCCO Reactor Cleaning Instructions Cleaning Instructions Care amp Maintenance WARNING First properly place the unit into Silicon Rubber Case Then unbuckle the ribbon and put it into case Insert the TypeC connector of the power cord into the TypeC jack at the bottom of the unit Tightly hang the unit with ribbon at the back of car pillow and ensure unit away from swinging After washing the air inlet cover please ensure that it is completely dry before replacing onto the main unit Tips A damp nonabrasive cloth can be used to clean the unit surface Please remove Air Inlet Cover before washing it with water only Air Inlet Cover can be washed with water The main body of the unit can be wiped with a soft dry cloth but avoid dust falling on the unit改avoid having dust fall onto the unit during cleaning Cleaning External Surfaces of Unit Body ATTENTION WARNING Never rinse or soak HEPA Filter or NCCO Reactor in water When the unit has not been used for a long period of time ➀ Stop operating unit and pull power plug from power source ➁ Carry out any maintenance or care work ➂ Place the unit in a plastic or box carton and store in a cool dry place Use a soft brush or light vacuum to clean the air inlet and air outlet Cleaning Air Inlet and Air Outlet ATTENTION Location 1 Location 3 Location 2 Location 4 If user do not place the unit into Silicon Rubber Case it is suggested to paste Rubber Pads at the back side in order to protect unit Rubber Pads Operation Instruction
• Page 13 - English - : The lifetime of the filter will vary depending on the environment amount of usage and location of the unit To maintain optimal operating condition of the unit only use the recommended filter Turn off the unit before replacing filters Please follow HEPA Filter Surface Color Changing Indicator to dispose HEPA Filter The filters cleaning and replacement cycle may vary depending on the operating area If the HEPA Filter has not been replaced periodically or it has been damaged the surface of the NCCO Reactor is covered with dust or oily substances after disassembling the removal capacity of the NCCO Reactor may be badly reduced and should be replaced Filters HEPA Filter NCCO Reactor Cycle Every Months Substantial Method Replacement Substantial Recommended Filter Cleaning and Replacement Cycles and Methods No replacement needed Replacement is recommended Replacement is needed HEPA FILTER SURFACE COLOR CHANGING INDICATOR Care amp Maintenance Filter Replacement amp Maintenance Can HEPA Filter be washed with water HEPA Filter is made of composite material water would seriously affect the purifica tion effect Q2 A The air quality has not improved even after the unit has been turned on for a long time If the unit is used in a severely polluted area the treatment process will take longer It is recommended to use the HIGH FLOW MODE or extend the operational time until the pollution diminishes Q3 A The unit emits an unusual smell or smog eg smoke flame or burning Turn off the unit and disconnect it from power supply right away Call the customer service center immediately or contact a qualified service agent Q4 A Q1 Unit is making DiDiDi sound and not operating Please check if filters have been properly installed If not please reinstall them A Other Information FAQs
• Page 14 - English - : The lifetime of the filter will vary depending on the environment amount of usage and location of the unit To maintain optimal operating condition of the unit only use the recommended filter Turn off the unit before replacing filters Please follow HEPA Filter Surface Color Changing Indicator to dispose HEPA Filter The filters cleaning and replacement cycle may vary depending on the operating area If the HEPA Filter has not been replaced periodically or it has been damaged the surface of the NCCO Reactor is covered with dust or oily substances after disassembling the removal capacity of the NCCO Reactor may be badly reduced and should be replaced Filters HEPA Filter NCCO Reactor Cycle Every Months Substantial Method Replacement Substantial Recommended Filter Cleaning and Replacement Cycles and Methods No replacement needed Replacement is recommended Replacement is needed HEPA FILTER SURFACE COLOR CHANGING INDICATOR Care amp Maintenance Filter Replacement amp Maintenance Can HEPA Filter be washed with water HEPA Filter is made of composite material water would seriously affect the purifica tion effect Q2 A The air quality has not improved even after the unit has been turned on for a long time If the unit is used in a severely polluted area the treatment process will take longer It is recommended to use the HIGH FLOW MODE or extend the operational time until the pollution diminishes Q3 A The unit emits an unusual smell or smog eg smoke flame or burning Turn off the unit and disconnect it from power supply right away Call the customer service center immediately or contact a qualified service agent Q4 A Q1 Unit is making DiDiDi sound and not operating Please check if filters have been properly installed If not please reinstall them A Other Information FAQs
• Page 15 - English - : Airflow Volume m hr Power Supply Power Consumption W Noise Level dB Product Dimension L x W x H mm Net Weight kg Treatment System Active Oxygen Generator NCCO Reactor Sterilization amp Disinfection Remove odour and decompose harmful pollutants such as formaldehyde and VOCs HEPA Filter Remove dust hair and airborne particles such as allergens and pollen bacteria viruses and fungus Lowest Highest Lowest Highest Lowest Highest Mode Mode Mode Lx Wx H DC V A Problems Solutions The unit does not operate Check if the unit is correctly connected to its power supply Turn on the unit Unit is making DiDiDi sound and not operating No air is blowing through air outlet Check if the unit is correctly connected to its power supply Check if the power cord interface is in good service condition Check if the filters have been correctly installed Reinstall all filters The unit makes an abnormal noise The unit emits an unusual smell or smog eg smoke flame or burning The unit may malfunction Call the customer service center for advice or consult with a qualified service provider Make sure the air inlet and outlet are not blocked by external objects Remove all adjacent objects that block the air inlet and outlet Turn off the unit and disconnect it from power supply Call the customer service center immediately or contact with a qualified service provider The air quality has not improved after a long operation time The Filter may require cleaning and replacement If the unit is used in a severely polluted area the treatment process will take longer It is recommended to use the HIGH FLOW MODE or extend the operational time until the pollution diminishes The airflow from air outlet becomes slow Make sure all packaging materials are removed Make sure all packaging materials are removed Filter may be blocked Replace the filter For the method to install filters please refer to Page Other Information Trouble Shooting Other Information Product Specification
• Page 16 - English - : Airflow Volume m hr Power Supply Power Consumption W Noise Level dB Product Dimension L x W x H mm Net Weight kg Treatment System Active Oxygen Generator NCCO Reactor Sterilization amp Disinfection Remove odour and decompose harmful pollutants such as formaldehyde and VOCs HEPA Filter Remove dust hair and airborne particles such as allergens and pollen bacteria viruses and fungus Lowest Highest Lowest Highest Lowest Highest Mode Mode Mode Lx Wx H DC V A Problems Solutions The unit does not operate Check if the unit is correctly connected to its power supply Turn on the unit Unit is making DiDiDi sound and not operating No air is blowing through air outlet Check if the unit is correctly connected to its power supply Check if the power cord interface is in good service condition Check if the filters have been correctly installed Reinstall all filters The unit makes an abnormal noise The unit emits an unusual smell or smog eg smoke flame or burning The unit may malfunction Call the customer service center for advice or consult with a qualified service provider Make sure the air inlet and outlet are not blocked by external objects Remove all adjacent objects that block the air inlet and outlet Turn off the unit and disconnect it from power supply Call the customer service center immediately or contact with a qualified service provider The air quality has not improved after a long operation time The Filter may require cleaning and replacement If the unit is used in a severely polluted area the treatment process will take longer It is recommended to use the HIGH FLOW MODE or extend the operational time until the pollution diminishes The airflow from air outlet becomes slow Make sure all packaging materials are removed Make sure all packaging materials are removed Filter may be blocked Replace the filter For the method to install filters please refer to Page Other Information Trouble Shooting Other Information Product Specification
