IBUKI+
AIR PURIFIER
User Manual
MA-04WBN
MA-04GB
READ AND SAVE THESE INSTRUCTIONS
AND WARNINGS
FAILURE TO COMPLY WITH THE WARNINGS LISTED BELOW MAY
RESULT IN ELECTRIC SHOCK OR SERIOUS INJURY.
This product should be used only in accordance with the specifications out-
lined in this manual. Usage other than what has been specified here may result
in serious injury.
ATTENTION!
• IMPORTANT - This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
• To avoid fire or shock hazard, plug the appliance directly into the right AC
electrical outlet.
• Keep the cord out of heavy traic areas. To avoid fire hazard, NEVER put the
cord under rugs, near heat registers, radiator, stoves or heaters.
• The power plug must be connected in such a way as to avoid risks if the
humidifier is tipped over or liquid is spilled.
• To protect against electrical hazards, DO NOT immerse in water or other
liquids. Do not use near water.
• Children cannot recognize the hazards associated with the usage of elec-
trical appliances. For this reason, always supervise children when they are
near the unit.
• Always unplug the air purifier before moving it, opening the grill, changing
filters, cleaning or whenever the air purifier is not in use. Be sure to pull by
the plug and not the cord.
• NEVER drop or insert any object into any openings.
• DO NOT run cord under carpeting.
!
• DO NOT cover cord with throw rugs, runners, or similar coverings.
• DO NOT route cord under furniture or appliances. Arrange cord away from
traic area and where it will not be tripped over.
• DO NOT operate any appliance with a damaged cord or plug, if motor fan
fails to rotate, aer the appliance malfunctions, or if it has been dropped or
damaged in any manner. Send to Customer Service for assistance.
• Use appliances only for intended household use as described in this manual.
Any other use not recommended by the manufacturer may cause fie, electric
shock or injury to person.
• DO NOT use outdoors.
• DO NOT place anything on top of unit.
• NEVER block the air openings, grills/outlets or place on a so surface such as
a bed or sofa, as this could cause the unit to tip over, blocking the air intake
or outtake opening.
• DO NOT attempt to repair or adjust any electrical or mechanical functions
on this unit. Doing so will void your warranty. The inside of the unit contains
no user serviceable parts. All servicing should be performed by qualified
personnel only.
• WARNING: To reduce the risk of fire or electric shock, do not use this device
with any solid-state speed control device.
GET TO KNOW IBUKI+
Air outlet
Handle
(MA-04WBN only)
Filter
Bottom cover
Control Panel
Air Inlet
PRIOR TO FIRST USE
1. Carefully li your air purifier from box and remove the two packed plastic
bags from unit and filter.
2. Select a firm, level and flat location for the air purifier.
3. Plug the power cord into a right voltage AC outlet.
4. For proper air flow, locate the unit at least 1 foot from any wall or furniture.
5. Make sure none of the grills are blocked.
HOW TO OPERATE IBUKI+
POWER
FAN SPEEDS
Low / Med / High
TIMER
2hrs / 4hrs / 8hrs / Turn o.
AUTO
Ibuki+ monitors environment and
maintains it to a perfect air quality
SLEEP
Long press (2s) to enter sleep mode.
Press any button to wake up
CHILD LOCK
FILTER RESET
Lights on when filter lifetime is up. Aer
change filter, long press 3 secs to reset.
Press to lock. Long press (2s) to
unlock the buttons
AUTO
WIFI
Long press the power button to turn
on Ibuki’s wifi
PAIR IBUKI+ WITH YOUR PHONE
Before Pairing
• Make sure your phone is connected to WIFI and bluetooth is on during pairing.
• Long press WIFI button for 5 seconds to turn on Ibuki+ ’s WIFI. The button
blinks while WIFI is on and ready for connection.
1. Download “My Miko app” and register/log in your account.
2. Select ”add device” and add Ibuki+ to your Miko app.
3. Follow the instructions on the app to pair with your phone.
4. Select Ibuki+ on app’s device list. Now you can operate and schedule Ibuki+,
and monitor qir quality on your phone anytime anywhere.
INSTALLING & REMOVING FILTERS
• The FILTER icon lighting up on red indicates that it is time to replace the filter.
Follow the instruction below to change filter and reset the program.
Remark:
• Remember to tear o the packing bag of the new filter before replacing it.
• Combination Filter will last approximately 6 months.
1. Upside down the machine.
2. Flip the unit, then rotate and li the base cover.
3. Change the used filter to new filter.
4. Reattach the base to the unit.
5. Reset the filter timer by filter reset button.
• The machine should be cleaned at least once every month by a clean, dry,
• so cloth.
• More frequent cleaning may be required depending on environmental condi-
tions.
NOTE:
• Do NOT stick any foreign objects or your fingers inside of the unit.
• Do NOT use gasoline, benzine, thinner, harsh cleaners, etc. on and/or in
• the unit while cleaning as they will damage the product.
• NEVER use alcohol or other solvents.
HOW TO CLEAN IBUKI+
Model number: MA-04WBN/ MA-04GB
Product model: Miko IBUKI+ Air Purifier
Power output: DC24V/0.65A
Power consumption: 15.6W
Dimensions: 210*206*312 mm/ 8.3*8.1*12.3 in
Weight: 2.3 kgs / 5 lbs
Please dispose of this product aer its service life pursuant to the
Waste Electrical and Electronic Equipment Directive 2012/19/EU- WEEE.
The symbol on the product or its packaging indicates that this product
cannot be treated as normal household waste but must be returned to a
collection point for recycling electrical and electronic products.
TECHNICAL DATA
CORRECT DISPOSAL OF THIS PRODUCT
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Miko Brand LLC
1544 Ocean pkwy APT 7G, Brooklyn, NY 11230
+1-866-201-9816
Please note that changes or modifications of this product is not expressly ap-
proved by the party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
For all comments, questions or complaints reach out to us:
www.shopmiko.com
+1-866-201-9816
