Hikvision DS-KD9203-MFE6 Facial Recognition Door station

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Specification Installation Instruction
DS-KD9203-MFE6 photo

User Manual

This is the main product document for model DS-KD9203-MFE6.

The file format is pdf, 72 pages, you can download this manual here .

background
Video Intercom Face Recognion Door
Staon
User Manual
background
Legal Informaon
About this Document
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other informaon hereinaer are for descripon and explanaon only.
The informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
Acknowledgment of Intellectual Property Rights
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without wrien permission.
and other Hikvision's trademarks and logos are the properes of Hikvision in
various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
Video Intercom Face Recognion Door Staon User Manual
i
background
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
Video Intercom Face Recognion Door Staon User Manual
ii
background
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Video Intercom Face Recognion Door Staon User Manual
iii
background
Safety Instrucon
Warning
All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
When the product is installed on wall or ceiling, the device shall be rmly xed.
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauon
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
Video Intercom Face Recognion Door Staon User Manual
iv
background
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in case of some lithium baery types).
Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
Do not leave the baery in an extremely high temperature surrounding environment, which may
result in an explosion or leakage of ammable liquid or gas.
Do not subject the baery to extremely low air pressure, which may result in an explosion or the
leakage of ammable liquid or gas.
CAUTION: Risk of explosion if the baery is replaced by an incorrect type. If a power adapter is
provided in the device package, use the provided adapter only.
If no power adapter is provided, ensure the power adapter or other power supply complies with
Limited Power Source. Refer to the product label for the power supply output parameters.
Video Intercom Face Recognion Door Staon User Manual
v
background
Regulatory Informaon
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2. l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Video Intercom Face Recognion Door Staon User Manual
vi
background
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
Video Intercom Face Recognion Door Staon User Manual
vii
background
Contents
Chapter 1 About this Manual ...................................................................................................... 1
Chapter 2 Appearance ................................................................................................................ 2
Chapter 3 Terminal and Wiring Descripon ................................................................................. 6
3.1 Terminal Descripon .............................................................................................................. 6
3.2 Wiring Descripon ................................................................................................................. 7
3.2.1 Door Lock Wiring .......................................................................................................... 7
3.2.2 Exit Buon Wiring ......................................................................................................... 8
3.2.3 Door Contact Wiring ..................................................................................................... 8
Chapter 4 Installaon ............................................................................................................... 10
4.1 Gang Box .............................................................................................................................. 11
4.2 Flush Mounng with Gang Box ............................................................................................ 12
Chapter 5 Acvaon ................................................................................................................. 14
5.1 Acvate Device Locally ......................................................................................................... 14
5.2 Acvate Device via Client Soware ...................................................................................... 15
5.3 Acvate Device via Web ....................................................................................................... 15
Chapter 6 Local Operaon ........................................................................................................ 17
6.1 Local Conguraon .............................................................................................................. 17
6.1.1 Edit Network Parameters ............................................................................................ 17
6.1.2 Local Sengs .............................................................................................................. 17
6.1.3 Add Residents ............................................................................................................. 18
6.1.4 About .......................................................................................................................... 19
6.2 Video Intercom Operaon ................................................................................................... 19
6.2.1 Call Resident ............................................................................................................... 19
6.2.2 Call Center ................................................................................................................... 20
6.3 Unlock Door ......................................................................................................................... 20
6.3.1 Unlock by Password .................................................................................................... 20
Video Intercom Face Recognion Door Staon User Manual
viii
background
6.3.2 Unlock by Presenng Card .......................................................................................... 20
6.3.3 Unlock by Fingerprint .................................................................................................. 21
6.3.4 Unlock by Face ............................................................................................................ 21
Chapter 7 Remote Conguraon via Web ................................................................................. 22
7.1 Live View .............................................................................................................................. 22
7.2 User Management ............................................................................................................... 22
7.3 Device Management ............................................................................................................ 23
7.4 Parameters Sengs ............................................................................................................. 23
7.4.1 System Sengs ........................................................................................................... 24
7.4.2 Network Sengs ......................................................................................................... 26
7.4.3 Video & Audio Sengs ............................................................................................... 31
7.4.4 Display Sengs ........................................................................................................... 34
7.4.5 Event Sengs .............................................................................................................. 35
7.4.6 Intercom Sengs ........................................................................................................ 39
7.4.7 Access Control Sengs ............................................................................................... 40
7.4.8 Smart Sengs ............................................................................................................. 44
Chapter 8 Conguraon via Client Soware ............................................................................. 47
8.1 Edit Network Parameters ..................................................................................................... 47
8.2 Add Device ........................................................................................................................... 47
8.2.1 Add Online Device ....................................................................................................... 47
8.2.2 Add Device by IP Address ............................................................................................ 49
8.2.3 Add Device by IP Segment .......................................................................................... 49
8.3 Remote Conguraon .......................................................................................................... 49
8.4 Device Management ............................................................................................................ 49
8.5 Organizaon Management .................................................................................................. 49
8.5.1 Add Organizaon ........................................................................................................ 49
8.5.2 Modify and Delete Organizaon ................................................................................. 50
8.6 Person Management ............................................................................................................ 50
Video Intercom Face Recognion Door Staon User Manual
ix
background
8.6.1 Add Person .................................................................................................................. 50
8.6.2 Modify and Delete Person .......................................................................................... 51
8.6.3 Import and Export Person Informaon ....................................................................... 51
8.6.4 Get Person Informaon from Device .......................................................................... 52
8.6.5 Change Person to Other Organizaon ........................................................................ 52
8.6.6 Issue Card in Batch ...................................................................................................... 53
8.6.7 Permission Sengs ..................................................................................................... 56
8.7 Video Intercom Sengs ....................................................................................................... 56
8.7.1 Receive Call from Door Staon ................................................................................... 57
8.7.2 Live View via Door Staon .......................................................................................... 57
8.7.3 Release Noce ............................................................................................................ 57
8.7.4 Search Video Intercom Informaon ............................................................................ 58
Appendix A. Appendix .............................................................................................................. 60
Video Intercom Face Recognion Door Staon User Manual
x
background
Chapter 1 About this Manual
Get the manual and related soware from or the ocial website (hp://www.hikvision.com).
Product Model
Door Staon DS-KD9203 Series
Scan the QR code to get the User Manual for detailed informaon.
Video Intercom Face Recognion Door Staon User Manual
1
background
Chapter 2 Appearance
Door Staon without Fingerprint Module
Figure 2-1 Appearance of Door Staon without Fingerprint Module
Video Intercom Face Recognion Door Staon User Manual
2
background
Table 2-1 Descripon
No. Descripon
1 Camera
2 IR Supplement Light
3 Screen
4 Loudspeaker
5 Buons
6 Microphone
7 Card Reading Area
8 TAMPER
Video Intercom Face Recognion Door Staon User Manual
3
background
Door Staon with Fingerprint Module
Figure 2-2 Appearance of Door Staon with Fingerprint Module
Table 2-2 Descripon
No. Descripon
1 Camera
2 IR Supplement Light
3 Screen
4 Loudspeaker
Video Intercom Face Recognion Door Staon User Manual
4
background
No. Descripon
5 Buons
6 Microphone
7 Card Reading Area/ Fingerprint Recognion Module
8 TAMPER
Video Intercom Face Recognion Door Staon User Manual
5
background
Chapter 3 Terminal and Wiring Descripon
3.1 Terminal Descripon
Figure 3-1 Terminal Descripon
Table 3-1 Descripon
Name Terminal Descripon
Network Interface LAN Network Signal Input
ALARM IN SEN1 Door Contact Input 1
SEN2 Door Contact Input 2
BTN1 Exit Buon Input 1
BTN2 Exit Buon Input 2
GND Grounding
RS-485 485A+ External RS-485 Card Reader
485A-
485B+ External Elevator Controller
485B-
DOOR NC1 Door Lock Relay Output 1(Normally Close)
COM1 Common Interface 1
Video Intercom Face Recognion Door Staon User Manual
6
background
Name Terminal Descripon
NO1 Door Lock Relay Output 1(Normally Open)
GND Grounding
NC2 Door Lock Relay Output 2(Normally Close)
COM2 Common Interface 2
NO2 Door Lock Relay Output 2(Normally Open)
GND Grounding
Power Supply DC 12 V 12 VDC Power Input
Note
Alarm input interface cannot be edited. Refers to the actual model.
You can only wire the SEN1/SEN2 terminal with the door contact. And wire the BTN1/BTN2
terminal with the exit buon.
3.2 Wiring Descripon
3.2.1 Door Lock Wiring
Figure 3-2 Door Lock Wiring
Video Intercom Face Recognion Door Staon User Manual
7
background
Note
Terminal NC1/COM1 is set as default for accessing electric bolt. Terminal NO1/COM1 is set as
default for accessing electric strike.
To connect electric lock in terminal NO2/COM2/NC2, it is required to set the output of terminal
NO2/COM2/NC2 to be electric lock with iVMS-4200 Client Soware.
3.2.2 Exit Buon Wiring
Wire the BTN1/BTN2 terminal with the door contact.
Here takes BTN1 for example.
Figure 3-3 Exit Buon Wiring
3.2.3 Door Contact Wiring
Wire the SEN1/SEN2 terminal with door contact.
Here takes SEN1 for example.
Video Intercom Face Recognion Door Staon User Manual
8
background
Figure 3-4 Door Contact Wiring
Video Intercom Face Recognion Door Staon User Manual
9
background
Chapter 4 Installaon
Note
Make sure the device in the package is in good condion and all the assembly parts are included.
The power supply the door staon supports is 12 VDC. Please make sure your power supply
matches your door staon.
Make sure all the related equipment is power-o during the installaon.
Check the product specicaon for the installaon environment.
Video Intercom Face Recognion Door Staon User Manual
10
background
4.1 Gang Box
Figure 4-1 Dimension of the Gang Box
Note
The dimension of the gang box is 364 mm (W) × 118 mm (H) × 40 mm (D).
The installaon hole should be bigger than the actual size. The suggested dimension of the
installaon hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm (D).
Video Intercom Face Recognion Door Staon User Manual
11
background
4.2 Flush Mounng with Gang Box
Steps
1.
Cave an installaon hole in the wall. Pull the cable out from the wall.
Note
The suggested dimension of the installaon hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm
(D).
The suggested length of the cables le outside is 250 mm.
2.
Install the gang box into the wall.
1) Remove the plasc sheet of the gang box with the tool.
2) Insert the gang box into the installaon hole. Mark the gang box screw holes' posion with a
marker, and take out the gang box.
3) Drill 4 holes according to the marks on the wall, and insert the expansion sleeves into the
screw holes.
4) Fix the gang box with 4 expansion bolts.
3.
Fix the gap between the gang box and wall with concrete. Remove the mounng ears with tool
aer concrete is dry. Connect the cables according to the Wiring Descripon.
4.
Insert the door staon into the gang box. Slide the door staon down and x it with 2 set
screws. Apply Silicone sealant among the joints between the device and the wall (except the
lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon User Manual
12
background
Figure 4-2 Flush Mounng with Gang Box
Video Intercom Face Recognion Door Staon User Manual
13
background
Chapter 5 Acvaon
5.1 Acvate Device Locally
You are required to acvate the device rst by sengs a strong password for it before you can use
the device.
Steps
1.
Power on the device to enter the acvaon page automacally.
2.
Create a password and conrm it.
Table 5-1 Number Buon Descripon
No. Descripon No. Descripon
1 1 6 6mnoMNO
2 2abcABC 7 7pqrsPQRS
3 3defDEF 8 8tuvTUV
4 4ghiGHI 9 9wxyzWXYZ
5 5jklJKL 0 0
Hold 0 to enter special characters.
Table 5-2 Number Buon Descripon
No. Descripon No. Descripon
1 1,.#? 6 6_=+
2 2!@% 7 7[];:
3 3^$* 8 8"|<
4 4( )\ 9 9>{}
5 5&/-
Note
The password required 8 to 16 characters.
The way to enter the password, take buon 2 as an example: Press 2 to enter the number '2'
or hold 2 for 1.5 s and press 2 again to enter the character 'a'.
When you have entered the password, press # to switch to conrm the password.
Press * to delete the wrong charater.
3.
Press # to select language.
Video Intercom Face Recognion Door Staon User Manual
14
background
4.
Aer selecon, press # to nish acvaon.
5.2 Acvate Device via Client Soware
You can only congure and operate the door staon aer creang a password for the device
acvaon.
Default parameters of door staon are as follows:
Default IP Address: 192.0.0.65.
Default Port No.: 8000.
Default User Name: admin.
Steps
1.
Run the client soware, click Maintenance and Management → Device Management → Device
to enter the page.
2.
Click Online Device.
3.
Select an inacvated device and click Acvate.
4.
Create a password, and conrm the password.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case leers, lower
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can beer protect your product.
5.
Click OK to acvate the device.
Note
When the device is not acvated, the basic operaon and remote operaon of device cannot
be performed.
You can hold the Ctrl or Shi key to select mulple devices in the online devices, and click the
Acvate buon to acvate devices in batch.
5.3 Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before you can use
the device.
Default parameters of the door staon are as follows:
Default IP Address: 192.0.0.65.
Default Port No.: 8000.
Default User Name: admin
Video Intercom Face Recognion Door Staon User Manual
15
background
Steps
1.
Power on the device, and connect the device to the network.
2.
Enter the IP address into the address bar of the web browser, and click Enter to enter the
acvaon page.
Note
The computer and the device should belong to the same subnet.
3.
Create and enter a password into the password eld.
4.
Conrm the password.
5.
Click OK to acvate the device.
Video Intercom Face Recognion Door Staon User Manual
16
background
Chapter 6 Local Operaon
6.1 Local Conguraon
When entering conguraon page, the buon is used as follows.
Table 6-1 Buon Descripon
Buon Descripon Buon Descripon
2 Previous 8 Next
* Exit/Back # OK
6.1.1 Edit Network Parameters
Aer acvang, you should edit the network parameters.
Steps
1.
Hold * and # at the same me to enter the authencaon page.
2.
Authencate via administrator.
-
Authencate face/card/ngerprint to login.
-
Press # to enter the password to login.
3.
Swritch to Network sengs according to the ps on the page. Press # to enter the sengs page.
4.
Edit the parameters according to your needs.
5.
Press * to save and exit.
6.1.2 Local Sengs
Congure the local parameters (including but not limited to, edit numbers and edit recognion
parameters).
Steps
1.
Hold * and # at the same me to enter the authencaon page.
2.
Authencate via administrator.
-
Authencate face/card/ngerprint to login.
-
Press # to enter the password to login.
3.
Switch to Local Sengs according to the ps on the page.
4.
Press # to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
17
background
Door Staon Sengs
Edit the parameters of the door staon (including but not limited to, community No., building No.,
oor No., room No. and device mode).
Steps
1.
Congure the parameters according to the actual needs.
Note
Outer door staon can only edit the Community No., Project No. and No.
The No. of the main door staon is 0.
The No. of sub door staons should be larger than 0 and ranges from 1 to 8.
Each unit should add 1 main door staon. Up to 8 sub door staons can be added to the main
door staon.
2.
Oponal: Enable the Normally Open Mode according to your needs.
The door remains open.
3.
Oponal: Select the language.
4.
Aer conguraon, press * to save and exit.
Recognion with Mask
Steps
1.
Enable Face with Mask Detecon.
2.
Select the Passing Level of Face Mask Recognion.
3.
Edit the Fce with Mask & Face 1:N Matching Threshold and Fce with Mask & Face 1:N
Matching Threshold (ECO Mode).
6.1.3 Add Residents
User Management
You can add, edit and delete the informaons of the users.
Steps
1.
Hold * and # at the same me to enter the authencaon page.
2.
Authencate via administrator.
-
Authencate face/card/ngerprint to login.
-
Press # to enter the password to login.
3.
Switch to User Management according to the ps on the page.
4.
Press # to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
18
background
Add Users
You can add cards, permissions and room No. for the users.
Steps
1.
Select +Add, and press # to enter the adding page.
2.
Edit the room No.
3.
Add cards.
1) Switch to the card and press # or present cards on the card reading area to add.
2) Enter the card No. manually or present the card on the card reading area to get the card No.
automacally.
3) Press # to add.
4.
Switch to the permisson and press # to set.
5.
Press * to save and exit.
6.1.4 About
You can view the device model, system version and QR Code of the device.
Steps
1.
Hold * and # at the same me to enter the authencaon page.
2.
Authencate via administrator.
-
Authencate face/card/ngerprint to login.
-
Press # to enter the password to login.
3.
Swritch to About according to the ps on the page.
4.
Press # to enter the page.
6.2 Video Intercom Operaon
6.2.1 Call Resident
The door staon can work as main/sub door staon, and outer door staon, which correspond to
dierent calling resident modes respecvely.
Call Resident from Main/Sub Door Staon
Press any digit buon on the main/sub door staon page to enter the calling page.
Enter the room No. and press call buon.
Call Resident from Outer Door Staon
Press call buon on the outer door staon page to enter the calling page .
Video Intercom Face Recognion Door Staon User Manual
19
background
Enter Community No. + Building No. + # + Unit No. + # + Room No. and press call buon to call
resident.
Note
When Unit No. is one, it can be omied. When Unit No. is omied, Community No. must be
omied at the same me.
6.2.2 Call Center
Press any digit buon on the main/sub door staon page to enter the calling page.
Press center buon to call., and press * to cancel during calling management center.
6.3 Unlock Door
6.3.1 Unlock by Password
Unlock by Password
Tap Call/Open to enter the calling page.
Enter # + Room No. + Password + #, and tap unlock buon.
Unlock by Public Password
Note
Make sure you have created the public password via iVMS-4200 Client Soware remotely.
Tap Call/Open to enter the calling page.
Enter # + Public Password + #, and tap unlock buon.
6.3.2 Unlock by Presenng Card
Note
Make sure you have issued the card to the device. Refers to User Management for details.
Present the card on the card reading area to unlock.
Video Intercom Face Recognion Door Staon User Manual
20
background
6.3.3 Unlock by Fingerprint
Note
Make sure you have added the ngerprint to the device.
Fingerprint funcon may vary with dierent modules. Please refer to the actual devices.
Put your nger on the nger recognion module to unlock.
6.3.4 Unlock by Face
Note
Make sure you have added your face picture to the device. Refers to the User Management for
details.
Face forward at the camera to unlock.
Video Intercom Face Recognion Door Staon User Manual
21
background
Chapter 7 Remote Conguraon via Web
7.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter key to enter the
login page.
Enter the user name and password and click Login to enter the Live View page. Or you can click
Live View to enter the page.
Figure 7-1 Live View
You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
The stream type can be set as main stream or sub stream.
For IE (Internet Explorer) or Google users, the device support two-way audio communicaon.
Note
Live View funcon may vary with dierent models. Please refer to the actual product.
7.2 User Management
You can add, delete or search the informaon of the user.
Click User to enter the sengs page.
Click Add and enter the username, oor No. and room No. to add.
Click Edit to modify the informaons of the user.
Check the box of the user and click Delete to delete the selected user.
Enter the keyword and click Search. The informaon will display in the list.
Video Intercom Face Recognion Door Staon User Manual
22
background
7.3 Device Management
You can manage the linked device on the page.
Click Device Management to enter the sengs page.
Add Device
Click Add to add the indoor staon or sub door staon. Enter the parameters and click OK to
add.
Click Import. Enter the informaon of the device in the template to import devices in batch.
Note
Select the device and click Delete to remove the device from the list.
Export
Click Export to export the informaon to the PC.
Upgrade
Upgrade Automacally
Click Timing Upgrade to pop-up the sengs dialog.
Enable upgrading device automacally. Edit the start me and end me and click OK to save the
sengs.
The upgrading will start at the set me automacally.
Upgrade Manually
Click Upload Upgrading Package to import the upgrading package.
Click Upgrade Now to start upgrading.
View Version
Put the mouse on the Upgrading buon to view the upgrading version and me.
7.4 Parameters Sengs
Click Conguraon to set the parameters of the device.
Remote conguraon in iVMS-4200 and Batch Conguraon Tool is the same as that in Web. Here
takes the conguraon in web for example.
Note
Run the browser, click → Internet Opons → Security to disable the Protected Mode.
Video Intercom Face Recognion Door Staon User Manual
23
background
7.4.1 System Sengs
Follow the instrucons below to congure the system sengs, include System Sengs,
Maintenance, Security, and User Management, etc.
Click System to enter the sengs page.
Basic Informaon
Click System Sengs → Basic Informaon to enter the sengs page. On the page, you can edit
Device Name and Device No. Set the Language and System Type according to your needs.
Click Save to enable the sengs.
Time Sengs
Click System Sengs → Time Sengs to enter the sengs page. Select the Time Zone of your
locaon from the drop-down list.
Enable NTP, set the Server Address, NTP Port and Interval.
Enable Manual Time Sync., set the me manually or check the Sync. with computer me.
Click Save to enable the sengs.
DST
Click System Sengs → DST to check Enable DST. Set the parameters according to your needs and
click Save to enable the sengs.
Maintenance
Click Maintenance → Upgrade & Maintenance to enter the sengs page.
Figure 7-2 Maintenance
Video Intercom Face Recognion Door Staon User Manual
24
background
Reboot: Click Reboot to reboot the device.
Restore
Click Restore to reset all the parameters, except the IP parameters and user informaon, to
the default sengs.
Default
Click Default to restore all parameters to default sengs.
Export parameters:
1. Select Device Parameters, and click Export to pop up the dialog box.
2. Set and conrm the encrypon password.
3. Click OK to export parameters.
Import Cong. File:
1. Click browse icon to select the conguraon le.
2. Click Import and enter the encrypon password to import.
Upgrade: Click browse icon to select the upgrade le.
Note
The upgrading process will last 1 to 10 minutes, do not power o during the upgrading. The
device reboots automacally aer upgrading.
Authencaon
Click Security Authencaon to enter the sengs page. On the page, you can select RTSP
Authencaonaccording to your actual needs.
Click Save to enable the sengs.
Security Service
Click Security → Security Service to enter the sengs page. On the page, you can enable SSH
according to your actual needs.
Click Save to enable the sengs.
User Management
Click User Management to enter the sengs page.
Administrator can edit the permission for the users.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum of
8 characters, including at least three kinds of following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high security system, changing
the password monthly or weekly can beer protect your product.
Online Users
Click User Management → Online Users to enter the page.
Video Intercom Face Recognion Door Staon User Manual
25
background
Figure 7-3 Online Users
Click Refresh to get the present informaon.
Arming/Disarming Informaon
Click User Management → Arming/Disarming Informaon to view the informaon. Click Refresh
to get the present informaon.
7.4.2 Network Sengs
TCP/IP Sengs
TCP/IP sengs must be properly congured before you operate the device over network. The
device supports IPv4.
Steps
1.
Click Network → Basic Sengs → TCP/IP to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
26
background
Figure 7-4 TCP/IP Sengs
2.
Congure the network parameters.
-
Check DHCP, the device will get the parameters automacally.
-
Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway manually.
3.
Congure the corresponding DNS server parameters.
4.
Click Save to enable the sengs.
Port Sengs
Steps
1.
Click Network → Basic Sengs → Port to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
27
background
Figure 7-5 Port Sengs
2.
Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which is not occupied.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which is not occupied.
RTSP Port
The default port number is 554.
Server Port
The default server port number is 8000, and it can be changed to any port No. ranges from
2000 to 65535.
3.
Click Save to enable the sengs.
SNMP Sengs
Before You Start
Before seng the SNMP, please download the SNMP soware and manage to receive the camera
informaon via SNMP port. By seng the Trap Address, the camera can send the alarm event and
excepon messages to the security center.
Steps
1.
Click Network → Advanced → SNMP to enter the sengs page.
2.
Check the checkbox of Enable SNMPv1, Enable SNMP v2c to enable the feature correspondingly.
1) Edit Read SNMP Community and Write SNMP Community.
2) Enter the Trap Address, Trap Port and Trap Community.
Video Intercom Face Recognion Door Staon User Manual
28
background
Note
To lower the risk of informaon leakage, you are suggested to enable SNMP v3 instead of SNMP
v1 or v2.
3.
Check the check box of Enable SNMPv3 to set the SNMPv3 parameters.
4.
Click Save to enable the sengs.
FTP Sengs
Steps
1.
Click Network → Advanced → FTP to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
29
background
Figure 7-6 FTP Sengs
Video Intercom Face Recognion Door Staon User Manual
30
background
2.
Check Enable FTP.
3.
Select Server Type.
4.
Input the Server IP Address and Port.
5.
Congure the FTP Sengs, and the user name and password are required for the server login.
6.
Set the Directory Structure, Parent Directory and Child Directory.
7.
Set the picture naming rules.
8.
Click Save to enable the sengs.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Network → Advanced Sengs Plaorm Access to enter the sengs page.
2.
Check the checkbox of Enable to enable the funcon.
3.
Select the Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
4.
Create a Stream Encrypon/Encrypon for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
5.
Click Save to enable the sengs.
7.4.3 Video & Audio Sengs
Video Parameters
Steps
1.
Click Video/Audio → Video to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
31
background
Figure 7-7 Video Parameters
2.
Select the Stream Type.
3.
Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
Select the stream type to video stream, or video & audio composite stream. The audio signal
will be recorded only when the Video Type is Video & Audio.
Resoluon
Video Intercom Face Recognion Door Staon User Manual
32
background
Select the resoluon of the video output.
Bitrate Type
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are selectable.
Frame Rate
Set the frame rate. The frame rate is to describe the frequency at which the video stream is
updated and it is measured by frames per second (fps). A higher frame rate is advantageous
when there is movement in the video stream, as it maintains image quality throughout.
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to the higher video
quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
4.
Click Save to save the sengs.
Audio Parameters
Steps
1.
Click Video/Audio → Audio to enter the sengs page.
Figure 7-8 Audio Sengs
2.
Congure the stream type and the audio encoding type.
Stream Type
Video Intercom Face Recognion Door Staon User Manual
33
background
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3.
Adjust the Input Volume and Output Volume.
Note
Available range of volume: 0 to 10.
4.
Click Save to save the sengs.
7.4.4 Display Sengs
Congure the image adjustment, backlight sengs and other parameters in display sengs.
Steps
1.
Click Image → Display Sengs to enter the display sengs page.
Figure 7-9 Display Sengs
2.
Select the Format.
3.
Set the display parameters.
WDR
Wide Dynamic Range can be used when there is a high contrast of the bright area and the
dark area of the scene.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
Video Intercom Face Recognion Door Staon User Manual
34
background
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1 to 100.
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to 100.
4.
Set the Day/Night Mode.
Figure 7-10 Day/Night Mode
-
Set Day Mode or Night Mode manually.
-
Set the mode as Auto and edit the sensivity according to your needs.
-
Set the mode as Scheduled-Switch. Set the start me and end me.
Note
Dayme is from congured start me to congured me. The rest of the me is set as night by
default.
5.
Click Save to enable the sengs.
7.4.5 Event Sengs
Moon Detecon
Moon detecon detects the moving objects in the congured security area, and a series of
acons can be taken when the alarm is triggered.
Video Intercom Face Recognion Door Staon User Manual
35
background
Steps
1.
Click Event Moon to enter the sengs page.
Figure 7-11 Moon Detecon
2.
Slide Enable Moon Detecon to enable the funcon.
3.
Click Draw Area. Click and drag the mouse on the live video to draw a moon detecon area.
Click Save to save the sengs.
Clear Area Click X to clear all of the areas.
Video Intercom Face Recognion Door Staon User Manual
36
background
Adjust Sensivity Move the slider to set the sensivity of the detecon.
4.
Click Arming Schedule to edit the arming schedule.
5.
Click on the me bar and drag the mouse to select the me period. Click Save to save the
sengs.
Delete Schedule Click Delete to delete the current arming schedule.
6.
Click Linkage Method to enable the linkages.
Nofy Security Center
Send an excepon or alarm signal to the remote management soware when an event
occurs.
7.
Click Save to enable the sengs.
Event Linkage
Steps
1.
Click Event → Basic Event → Event Linkage to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
37
background
Figure 7-12 Event Linkage
Video Intercom Face Recognion Door Staon User Manual
38
background
2.
Select the Major Type as Device Event or Door Event.
3.
Select the type of the Normal Linkage for the event.
4.
Click Save to enable the sengs.
7.4.6 Intercom Sengs
Device ID Conguraon
Steps
1.
Click Device No. to enter the page.
Figure 7-13 Device ID Sengs
2.
Select the device type from the drop-down list, and set the corresponding informaon.
3.
Click Save to enable the device number conguraon.
Note
For main door staon (D series or V series), the serial No. is 0.
For sub door staon (D series or V series), the serial No. cannot be 0. Serial No. ranges from 1
to 99.
For each villa or building, at least one main door staon (D series or V series) should be
congured, and one sub door staons (D series or V series) can be customized.
For one main door staon (D series or V series), up to 8 sub door staons can be congured.
Video Intercom Face Recognion Door Staon User Manual
39
background
Linked Network Sengs
Steps
1.
Go to Intercom → Session Sengs to enter the sengs page.
2.
Set Register Number and Registraon Password.
3.
Set Main Staon IP and VideoIntercom Server IP.
4.
Enable Protocol 1.0.
5.
Click Save to enable the sengs.
Time Parameters
Go to Intercom → Time Parameters to enter the page.
Congure Max. Call Duraon, Max. Message Duraon, Max. Ring Duraon, and click Save.
Note
Max. call duraon between the module indoor staon and client ranges from 90 s to 120 s. The
call will end automacally when the actual calling duraon is longer than the congured one.
Max. message duraon ranges from 30 s to 60 s. The message will end automacally when the
actual message duraon is longer than the congured one.
Max. ring duraon refers to the maximum duraon of the module indoor staon when it is
called without being accepted. Max. ring duraon ranges from 65 s to 255 s.
Ring-Back Tone Sengs
Click Intercom → Ringbacktone Sengs to enter the sengs page.
Click Add to select the ring tone from PC.
Note
Available Audio Format: WAVAAC, Size: Less than 600 KB, Sample Rate: 8000Hz, Mono.
7.4.7 Access Control Sengs
Permission Password
Steps
1.
Click Access Control → Permission Password to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
40
background
Figure 7-14 Permission Password
2.
Select the password type.
3.
Change the password.
4.
Set the number of doorphone.
5.
Click Save to enable the sengs.
Door Parameters
Steps
1.
Click Access Control → Door Parameters to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
41
background
Figure 7-15 Door Parameters
2.
Select the door and edit the door name.
3.
Set Relay Reverse.
4.
Set Open Duraon.
5.
Click Save to enable the sengs.
Card Security
Go to Access Control → Card Security to enter the sengs page.
Slide to enable card encrypon parameters and CPU card reading content. Click Save to enable the
sengs.
Elevator Control
Before You Start
Make sure your door staon is in the mode of main door staon. Only the main door staon
support elevator control funcon.
Make sure your door staon has been connected to the elevator controller via RS-485 wire if you
want to use RS-485 interface.
Steps
1.
Click Access Control → Elevator Control to enter the corresponding conguraon page.
Video Intercom Face Recognion Door Staon User Manual
42
background
Figure 7-16 Elevator Control
2.
Check to enable elevator control funcon.
3.
Select an Elevator No., and select an elevator controller type for the elevator.
4.
Set the Negave Floor.
5.
Select the Interface Type as RS-485 or Network Interface. And enable the elevator control.
-
If you select RS-485, make sure you have connected the door staon to the elevator controller
with RS-485 wire.
-
If you select Network interface, enter the elevator controller's IP address, port No., user
name, and password.
6.
Click Save to enable the sengs.
Note
Up to 4 elevator controllers can be connected to one door staon.
Up to 10 negave oors can be added.
Make sure the interface types of elevator controllers, which are connected to the same door
staon are consistent.
RS-485 Sengs
Set the working mode to linked device.
Steps
1.
Click Access Control → RS-485 to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
43
background
Figure 7-17 RS-485 Sengs
2.
Select the No.
3.
Select the working mode.
4.
Click Save to enable the sengs.
7.4.8 Smart Sengs
Biometrics Sengs
Adjust the face recognion parameters and ngerprint parameters according to your needs.
Steps
1.
Click Smart to enter the sengs page.
2.
Enable face an-spoong to edit face capture advanced parameters.
Figure 7-18 Smart Sengs
Video Intercom Face Recognion Door Staon User Manual
44
background
Table 7-1 Face Capture Advanced Parameters
Parameter Descripon
Face An-spoong Enable face an-spoong to detect real people face for recognion.
Live Face Detecon
Security Level
Aer enabling face an-spoong funcon, you can set the matching
security level when performing live face authencaon.
Recognion Distance Set the valid distance between the user and the camera when
authencang.
Applicaon Mode Select either others or indoor according to actual environment.
Connuous Face
Recognion Interval
The me interval between two connuous face recognions when
authencang.
Note
You can input the number from 1 to 10.
1:N Matching
Threshold
Set the matching threshold when authencang via 1:N matching
mode. The larger the value, the smaller the false accept rate and the
larger the false rejecon rate.
Note
You can input the number from 1 to 99.
Face Recognion
Timeout Value
When the face recognion me exceed the value you set, the
recognion will be determined as a meout operaon.
Note
You can input the number from 1 to 20.
ECO Sengs Aer enabling the ECO mode, the device will use the IR camera to
authencate faces in the low light or dark environment. And you can
set the ECO mode threshold, ECO mode (1:N).
ECO Threshold
When enabling the ECO mode, you can set the ECO mode’s
threshold. The larger the value, the easier the device entering the
ECO mode.
Note
You can input the number from 1 to 7.
ECO Mode (1:N)
Video Intercom Face Recognion Door Staon User Manual
45
background
Parameter Descripon
Set the matching threshold when authencang via ECO mode 1:N
matching mode. The larger the value, the smaller the false accept
rate and the larger the false rejecon rate.
Note
You can input the number from 1 to 100.
Force to Enable Night Mode
When the environment is not bright enough, you can slide to force
to enable the night mode.
3.
Click Save to enable the sengs.
Area Conguraon
Click VCA Conguraon → Area Conguraon to enter the sengs page.
Drag the frame to adjust the size of the recognion area.
Video Intercom Face Recognion Door Staon User Manual
46
background
Chapter 8 Conguraon via Client Soware
8.1 Edit Network Parameters
To operate and congure the device via LAN (Local Area Network), you need connect the device in
the same subnet with your PC. You can edit network parameters via iVMS-4200 client soware.
Steps
1.
Select an online acvated device and click the Modify Nenfo.
2.
Edit the device IP address and gateway address to the same subnet with your computer.
3.
Enter the password and click OK to save the network parameters modicaon.
Note
The default port No. is 8000.
The default IP address of the door staon is 192.0.0.65.
Aer eding the network parameters of device, you should add the devices to the device list
again.
8.2 Add Device
You should add device to the soware so as to congure the device remotely.
8.2.1 Add Online Device
Before You Start
Make sure the device to be added is in the same subnet with your computer. Otherwise, please
edit network parameters rst.
Steps
1.
Click Online Device to select an acve online device.
2.
Click Add.
3.
Enter corresponding informaon, and click Add.
Video Intercom Face Recognion Door Staon User Manual
47
background
Figure 8-1 Add to the Client
Video Intercom Face Recognion Door Staon User Manual
48
background
8.2.2 Add Device by IP Address
Steps
1.
Click +Add to pop up the adding devices dialog box.
2.
Select IP/Domain as Adding Mode.
3.
Enter corresponding informaon.
4.
Click Add.
8.2.3 Add Device by IP Segment
You can add many devices at once whose IP addresses are among the IP segment.
Steps
1.
Click +Add to pop up the dialog box.
2.
Select IP Segment as Adding Mode.
3.
Enter corresponding informaon, and click Add.
8.3 Remote Conguraon
Select the device, click to congure the parameters remotely.
8.4 Device Management
Device management includes device acvaon, adding device, eding device, and deleng device,
and so on.
Aer running the iVMS-4200, video intercom devices should be added to the client soware for
remote conguraon and management.
8.5 Organizaon Management
On the main page of the Client Soware, click PersonalManagement to enter the
conguraon page.
8.5.1 Add Organizaon
Steps
1.
In the organizaon list on the le, click +Add.
2.
Enter the Organizaon Name as desired.
3.
Click OK to save the adding.
4.
Oponal: You can add mulple levels of organizaons according to the actual needs.
Video Intercom Face Recognion Door Staon User Manual
49
background
1) You can add mulple levels of organizaons according to the actual needs.
2) Then the added organizaon will be the sub-organizaon of the upper-level organizaon.
Note
Up to 10 levels of organizaons can be created.
8.5.2 Modify and Delete Organizaon
You can select the added organizaon and click to modify its name.
You can select an organizaon, and click X buon to delete it.
Note
The lower-level organizaons will be deleted as well if you delete an organizaon.
Make sure there is no person added under the organizaon, or the organizaon cannot be
deleted.
8.6 Person Management
Aer adding the organizaon, you can add person to the organizaon and manage the added
person such as issuing cards in batch, imporng and exporng person's informaon in batch, etc.
Note
Up to 2,000 persons can be added.
Up to 5 cards can be added to each person.
8.6.1 Add Person
Person informaon is necessary for the video intercom system. And when you set linked device for
the person, the intercom between intercom devices can be realized.
Steps
1.
Select an organizaon in the organizaon list and click Add on the Person panel to pop up the
adding person dialog.
Note
The Person No. will be generated automacally and is editable.
2.
Set basic person informaon.
1) Enter basic informaon: name, tel, birthday details, eecve period and email address.
Note
The length of person name should be less than 15 characters.
Video Intercom Face Recognion Door Staon User Manual
50
background
2) Click Add face to upload the photo.
Note
The picture should be in *.jpg format.
Click Upload Select the person picture from the local PC to upload it to the
client.
Click Take Phone Take the person's photo with the PC camera.
Click Remote Collecon Take the person's photo with the collecon device.
3.
Issue the card for the person.
1) Click Credenal → Card .
2) Click + to pop up the Add Card dialog.
3) Select Normal Card as Card Type.
4) Enter the Card No.
5) Click Read and the card(s) will be issued to the person.
4.
Link the device to the person.
1) Set the linked devices.
Linked Device
You can bind the indoor staon to the person.
Note
If you select Analog Indoor Staon in the Linked Device, the Door Staon eld will display
and you are required to select the door staon to communicate with the analog indoor
staon.
Room No.
You can enter the room No. of the person.
2) Click OK to save the sengs.
5.
Click Add to save the sengs.
8.6.2 Modify and Delete Person
Select the person and click Edit to open the eding person dialog.
To delete the person, select a person and click Delete to delete it.
Note
If a card is issued to the current person, the linkage will be invalid aer the person is deleted.
8.6.3 Import and Export Person Informaon
The person informaon can be imported and exported in batch.
Video Intercom Face Recognion Door Staon User Manual
51
background
Steps
1.
Exporng Person: You can export the added persons' informaon in Excel format to the local PC.
1) Aer adding the person, you can click Export Person to pop up the following dialog.
2) Click ... to select the path of saving the exported Excel le.
3) Check the checkboxes to select the person informaon to export.
4) Click OK to start exporng.
2.
Imporng Person: You can import the Excel le with persons informaon in batch from the local
PC.
1) Click Import Person.
2) You can click Download Template for Imporng Person to download the template rst.
3) Input the person informaon to the downloaded template.
4) Click ... to select the Excel le with person informaon.
5) Click OK to start imporng.
8.6.4 Get Person Informaon from Device
If the added device has been congured with person informaon (including person details,
ngerprint, issued card informaon), you can get the person informaon from the device and
import to the client for further operaon.
Steps
Note
This funcon is only supported by the device the connecon mothod of which is TCP/IP when
adding the device.
1.
In the organizaon list on the le, click to select an organizaon to import the persons.
2.
Click Get from Device to pop up the dialog box.
3.
The added device will be displayed.
4.
Click to select the device and then click Get to start geng the person informaon from the
device.
Note
The person informaon, including person details, person's ngerprint informaon (if
congured), and the linked card (if congured), will be imported to the selected organizaon.
If the person name stored in the device is empty, the person name will be lled with the
issued card No. aer imporng to the client.
8.6.5 Change Person to Other Organizaon
You can move the person to another organizaon if needed.
Video Intercom Face Recognion Door Staon User Manual
52
background
Steps
1.
Select the person in the list and click Change Organizaon.
2.
Select the organizaon to move the person to.
3.
Click OK to save the sengs.
8.6.6 Issue Card in Batch
You can issue mulple cards for the person with no card issued in batch.
Steps
1.
Click Batch Issue Cards to enter the dialog page. All the added person with no card issued will
display in the Person(s) with No Card Issued list.
Video Intercom Face Recognion Door Staon User Manual
53
background
Figure 8-2 Issue Card in Batch
2.
Click Sengs.
Video Intercom Face Recognion Door Staon User Manual
54
background
Figure 8-3 Card Sengs
3.
Select Card Type and Card No. Type.
4.
Click OK to save the sengs.
Result
Aer issuing the card to the person, the person and card informaon will display in the Person(s)
with Card Issued list.
Video Intercom Face Recognion Door Staon User Manual
55
background
8.6.7 Permission Sengs
Add Permissions
Steps
1.
On the main page, click AccessControlInfo → Access Group to enter the page.
2.
Click +Add to pop up the adding dialog box.
3.
Congure the parameters.
1) Enter the Name of the permission.
2) Select the Template of the schedule.
3) Check the person to Selected according to your needs.
4) Check the device to Selected according to your needs.
4.
Click Save.
5.
Check the permission and click Apply All to Device.
The status of the permission displays as Applied.
6.
Oponal: Click Applying Status to check the details.
Modify/Delete Permissions
On the page of the permission sengs, click to edit the parameters of the permission.
Select one or more permissions, click Delete to remove the permissions.
8.7 Video Intercom Sengs
The Video Intercom Management module provides the funcon of video intercom, checking call
logs and managing noce via the iVMS-4200 Client Soware.
Note
For the user with access control module permissions, the user can enter the Access Control
module and manage video intercom and search informaon.
You should add the device to the soware and congure the person to link the device in Access
Control module before your conguraon remotely.
On the main page, click AccessControlInfo → Video Intercom → Video Intercom on the le
bar to enter the Video Intercom page.
Video Intercom Face Recognion Door Staon User Manual
56
background
8.7.1 Receive Call from Door Staon
Steps
1.
Select the client soware in the device page to start calling the iVMS-4200 Client Soware and
an incoming call dialog will pop up in the client soware.
2.
Click Answer to answer the call. Or click Hang Up to decline the call.
3.
Aer you answer the call, you will enter the In Call window.
Click to adjust the volume of the loudspeaker.
Click to adjust the volume of the microphone.
Click Hang Up to hang up the dialog.
Click to open the door remotely.
Note
One video intercom device can only connect with one client soware.
The maximum ring duraon can be set from 15s to 60s via the Remote Conguraon of the
video intercom device.
The maximum speaking duraon between indoor staon and iVMS-4200 can be set from 120s
to 600s via the Remote Conguraon of indoor staon.
The maximum speaking duraon between door staon and iVMS-4200 can be set from 90s to
120s via the Remote Conguraon of door staon.
8.7.2 Live View via Door Staon
Steps
1.
On the main page of the client soware, click Main View to enter the Live View page.
2.
In the le list of the window, double-click the device IP or click the play icon to live view.
3.
Oponal: On the Live View page, control-click and select Capture to get the picture of the live
view.
8.7.3 Release Noce
You can create dierent types of noces and send them to the residents. Four noce types are
available, including Adversing, Property, Alarm and Noce Informaon.
Before You Start
Make sure the person has been added to the client.
Steps
1.
On the video intercom sengs page, click Noce to enter the page.
2.
Click +Add to pop up the adding dialog box.
3.
Select the person according to your needs.
4.
Edit the Subject, Type and Informaon.
Video Intercom Face Recognion Door Staon User Manual
57
background
5.
Click View to select the picture.
6.
Click Send.
Note
Up to 63 characters are allowed in the Subject eld.
Up to 6 pictures in the JPGE format can be added to one noce. And the maximum size of one
picture is 512KB.
Up to 1023 characters are allowed in the Informaon eld.
8.7.4 Search Video Intercom Informaon
Search Call Logs
Steps
1.
On the Video Intercom page, click Call Log to enter the page.
Figure 8-4 Search Call Logs
2.
Set the search condions, including call status, device type, start me and end me.
Call Status
Click ˅ to unfold the drop-down list and select the call status as Dialed, Received or Missed.
Or select All to search logs with all statuses.
Video Intercom Face Recognion Door Staon User Manual
58
background
Device Type
Click ˅ to unfold the drop-down list and select the device type as Indoor Staon, Door
Staon, Outer Door Staon or Analog Indoor Staon. Or select All Devices to search logs
with all device types.
Start Time/End Time
Click the me icon to specify the start me and end me of a me period to search the logs.
Reset the Sengs Click Reset to reset all the congured search condions.
3.
Click Search and all the matched call logs will display on this page.
4.
Oponal: Check the detailed informaon of searched call logs, such as call status, ring/speaking
duraon, device name, resident organizaon, etc.
5.
Oponal: Input keywords in the Search eld to lter the desired log.
6.
Oponal: Click Export to export the call logs to your PC.
Search Noce
Steps
1.
On the Video Intercom page, click Noce to enter the page.
2.
Set the search condions, including noce type, start me and end me.
Type
Select Adversing Informaon, Property Informaon, Alarm Informaon or Noce
Informaon as Type according to your needs.
Start Time/End Time
Click the me icon to specify the start me and end me of a me period to search the logs.
Reset the Sengs Click Reset to reset all the congured search condiions.
3.
Click Search and the matched noce will display on this page.
4.
Oponal: Click Export to export the noces to your PC.
Video Intercom Face Recognion Door Staon User Manual
59
background
Appendix A. Appendix
Tips When Collecng/Comparing Face Picture
Keep your expression naturally when collecng or comparing face pictures.
Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
In order to get a good quaillty and accurate face picture, posion your face looking at the
camera when collecng or comparing face pictures.
Make sure your face is in the middle of the collecng window.
The recommended distance when collecng/comparing face pictures is between 400 mm and
500 mm.
Tips When Imporng Face Picture
The requirements of the face pictures are the same as the requirements for collecng.
Picture format: JPG.
The photo scale is 5:7. The pixel size is a minimum of 480 and the height is a minimum of 640.
Picture size cannot exceed 200 KB.
A pure background color is required. White is the best.
Video Intercom Face Recognion Door Staon User Manual
60
background
UD35069B

Specifications

Hikvision DS-KD9203-MFE6 Questions and Answers
