Video Intercom Face Recognion
Door Staon
User Manual
Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product.
Pictures, charts, images and all other informaon hereinaer are for
descripon and explanaon only. The informaon contained in the Manual
is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision
website (
hps://www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals
trained in supporng the Product.
Trademarks
and other Hikvision's trademarks and logos are the
properes of Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their
respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL
AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, ARE PROVIDED "AS IS" AND "WITH ALL FAULTS AND ERRORS".
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS
AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR
ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN
Video Intercom Face Recognion Door Staon User Manual
i
CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE
LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE
CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE,
FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION
OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN
THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR
FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATTER PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and
processed. To protect data, the development of Hikvision devices
incorporates privacy by design principles. For example, for device with facial
recognion features, biometrics data is stored in your device with
encrypon method; for ngerprint device, only ngerprint template will be
saved, which is impossible to reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer
data in accordance with the applicable data protecon laws and regulaons,
including without limitaon, conducng security controls to safeguard
personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the
eecveness of your security controls.
Video Intercom Face Recognion Door Staon User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note
Provides addional informaon to emphasize or
supplement important points of the main text.
Video Intercom Face Recognion Door Staon User Manual
iii
Safety Instrucon
Warning
●
All the electronic operaon should be strictly compliance with the electrical safety
regulaons, re prevenon regulaons and other related regulaons in your local
region.
●
Please use the power adapter, which is provided by normal company. The power
consumpon cannot be less than the required value.
●
Please make sure that the power has been disconnected before you wire, install or
dismantle the device.
●
If the product does not work properly, please contact your dealer or the nearest
service center. Never aempt to disassemble the device yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)
Cauon
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons
surface or places subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the specicaon of the device
or the detailed operang temperature), cold, dusty or damp locaons.
●
The device shall be kept from rain and moisture.
●
The device shall be kept from explosives.
●
Keep surfaces of the device clean and dry.
●
Avoid contact with exposed circuits. Do not touch the exposed contacts and
components when the product is powered on.
Cauon
●
Keep the device away from children and out of reach.
●
CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
●
Improper replacement of the baery with an incorrect type may defeat a
safeguard (for example, in case of some lithium baery types).
●
Do not dispose of the baery into re or a hot oven, or mechanically crush or cut
the baery, which may result in an explosion.
Video Intercom Face Recognion Door Staon User Manual
iv
●
Do not leave the baery in an extremely high temperature surrounding
environment, which may result in an explosion or leakage of ammable liquid or
gas.
●
Do not subject the baery to extremely low air pressure, which may result in an
explosion or the leakage of ammable liquid or gas.
●
Used baeries may result in polluon to the environment. Dispose of used
baeries according to the instrucons provided by the baery manufacturer.
Video Intercom Face Recognion Door Staon User Manual
v
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operaon.
Video Intercom Face Recognion Door Staon User Manual
vi
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Direcve
2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve 2011/
65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For more informaon
see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery
that cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specic
baery informaon. The baery is marked with this symbol,
which may include leering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the baery to your
supplier or to a designated collecon point. For more informaon
see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operaon is subject to the following two condions:
1.
this device may not cause interference, and
2.
this device must accept any interference, including interference that may
cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radioexempts de licence. L'exploitaon est autorisée aux deux
condions suivantes :
Video Intercom Face Recognion Door Staon User Manual
vii
1.
l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est suscepble d'en compromere le
fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmier by Industry Canada. To reduce potenal radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur
radio peut fonconner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émeeur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à l'intenon des autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20
cm entre le radiateur et votre corps.
Video Intercom Face Recognion Door Staon User Manual
viii
Contents
1 About this Manual ...................................................................................... 1
2 Appearance ................................................................................................ 2
2.1 Door Staon ...................................................................................................... 2
2.2 Keypad Module ................................................................................................. 3
2.3 Fingerprint Sub Module .................................................................................... 4
3 Terminal and Wiring Descripon ................................................................ 5
4 Installaon .................................................................................................. 7
4.1 Install Door Staon ........................................................................................... 7
4.1.1 Door Staon Installaon Accessories ....................................................... 7
4.1.2 Surface Mounng ..................................................................................... 9
4.1.3 Flush Mounng ....................................................................................... 10
4.2 Install Door Staon with Sub Module ............................................................. 11
4.2.1 Door Staon with Sub Module Installaon Accessories ......................... 11
4.2.2 Surface Mounng ................................................................................... 14
4.2.3 Flush Mounng ....................................................................................... 15
5 Sub Module Descripon ........................................................................... 17
6 Acvaon ................................................................................................. 18
6.1 Acvate Device Locally .................................................................................... 18
6.2 Acvate Device via Web .................................................................................. 18
6.3 Acvate Device via Client Soware ................................................................. 19
6.4 Acvate Device via Web .................................................................................. 20
Video Intercom Face Recognion Door Staon User Manual
ix
7 Local Conguraon ................................................................................... 21
7.1 Quick Conguraon ........................................................................................ 21
7.2 Authencaon via Admin ............................................................................... 26
7.3 Network Parameters Sengs .......................................................................... 27
7.3.1 Edit Wired Network Parameters ............................................................. 27
7.3.2 Cloud Service Sengs ............................................................................ 28
7.4 Device No. Sengs ......................................................................................... 29
7.5 User Management .......................................................................................... 30
7.6 Call Sengs ..................................................................................................... 31
7.7 Forget Admin Password .................................................................................. 32
7.8 System Sengs ............................................................................................... 33
7.8.1 Change Language .................................................................................... 33
7.8.2 Adjust Brightness .................................................................................... 34
7.8.3 Keypad Sound Sengs ........................................................................... 35
7.8.4 Channel Mode Sengs ........................................................................... 35
7.8.5 Theme Sengs ....................................................................................... 36
7.8.6 Restore Door Staon .............................................................................. 36
7.9 Device Informaon .......................................................................................... 37
8 Local Operaon ........................................................................................ 39
8.1 Call from the Device ........................................................................................ 39
8.1.1 Call Resident ........................................................................................... 39
8.1.2 Call Center .............................................................................................. 41
8.2 Unlock Door .................................................................................................... 41
8.2.1 Unlock by Password ................................................................................ 41
Video Intercom Face Recognion Door Staon User Manual
x
8.2.2 Unlock by Face ........................................................................................ 42
8.2.3 Unlock by Presenng Card ...................................................................... 42
8.2.4 Unlock by QR Code ................................................................................. 42
9 Remote Conguraon via Web ................................................................ 44
9.1 Live View ......................................................................................................... 44
9.2 User Management .......................................................................................... 44
9.3 Device Management ....................................................................................... 45
9.4 Parameters Sengs ........................................................................................ 47
9.4.1 Local Sengs .......................................................................................... 48
9.4.2 System Parameters ................................................................................. 49
9.4.3 Network Sengs .................................................................................... 55
9.4.4 Video & Audio Sengs ........................................................................... 60
9.4.5 Display Sengs ....................................................................................... 63
9.4.6 Card Security .......................................................................................... 64
9.4.7 Intercom Sengs .................................................................................... 65
9.4.8 Access Control Sengs ........................................................................... 68
9.4.9 Smart Sengs ......................................................................................... 71
9.4.10 Theme Sengs ..................................................................................... 74
10 Remote Conguraon via Client Soware ............................................. 77
10.1 Edit Device Network Parameters .................................................................. 77
10.2 Add Device .................................................................................................... 77
10.2.1 Add Online Device ................................................................................ 77
10.2.2 Add Device via IP Address .................................................................... 78
10.2.3 Add Device via IP segment ................................................................... 78
Video Intercom Face Recognion Door Staon User Manual
xi
10.2.4 Add Devices in Batch ............................................................................ 78
10.2.5 Add Device Via EHome ......................................................................... 79
10.3 Local Conguraon via Client Soware ........................................................ 79
10.4 Device Management ..................................................................................... 79
10.5 Live View ....................................................................................................... 80
10.6 Intercom Organizaon Structure Conguraon ............................................ 80
10.6.1 Add Organizaon .................................................................................. 80
10.6.2 Modify and Delete Organizaon ........................................................... 80
10.7 Person Management ..................................................................................... 80
10.7.1 Add Person ........................................................................................... 81
10.7.2 Modify and Delete Person .................................................................... 82
10.7.3 Import and Export Person Informaon ................................................ 82
10.7.4 Get Person Informaon ........................................................................ 83
10.7.5 Issue Card in Batch ............................................................................... 83
10.7.6 Permission Sengs ............................................................................... 84
10.8 Video Intercom Sengs ................................................................................ 84
10.8.1 Video Intercom ..................................................................................... 84
10.8.2 Search Video Intercom Informaon ..................................................... 86
10.8.3 Upload Arming Informaon ................................................................. 87
A. Communicaon Matrix and Device Command ....................................... 88
Video Intercom Face Recognion Door Staon User Manual
xii
1 About this Manual
Get the manual and related soware from or the ocial website (hp://
www.hikvision.com).
Product Model
Door Staon DS-KD9403-E6
Video Intercom Face Recognion Door Staon User Manual
1
2 Appearance
2.1 Door Staon
Note
Refers to the specic model for the appearance of the device.
Figure 2-1 Door Staon
Table 2-1 Appearance Descripon
No. Descripon No. Descripon
1 Wiring Terminal 7 Ambient Light Sensor
2 Network Interface 8 TAMPER
3 Reserved 9 Loudspeaker
4 IR Supplement Light 10 Debugging Port
Video Intercom Face Recognion Door Staon User Manual
2
No. Descripon No. Descripon
Note
The debugging port is
used for debugging only.
5 Microphone 11 MicroUSB Interface
Note
Micro USB interface is
used for debugging only.
6 Camera 12 TF Card Slot
2.2 Keypad Module
Note
Refers to the specic model for the appearance of the device.
Figure 2-2 Appearance of Keypad Module
Video Intercom Face Recognion Door Staon User Manual
3
Table 2-2 Appearance Descripon
No. Descripon
1 Type-A Interface
2 Keypad
2.3 Fingerprint Sub Module
Note
Refers to the specic model for the appearance of the device.
Figure 2-3 Appearance of Fingerprint Module
Table 2-3 Appearance Descripon
No. Descripon
1 Type-A Interface
2 Keypad
3 Fingerprint Reader
Video Intercom Face Recognion Door Staon User Manual
4
3 Terminal and Wiring Descripon
Door staon can be wired to alarm input interface, alarm input interface, door lock,
door contact and so on.
Figure 3-1 Terminal and Wiring Descripon
Wiring descripon:
Video Intercom Face Recognion Door Staon User Manual
5
●
AIN1: door contact connecon
●
AIN2: reserved
●
AIN3: exit buon connecon
●
AIN4: re alarm connecon
●
NO, COM and NC: door lock connecon
●
RS-485A: connect to card reader or elevator controller (congured via web).
●
RS-485B: connect to secure door control unit.
Note
The funcon of unmenoned interfaces are reserved.
Video Intercom Face Recognion Door Staon User Manual
6
4 Installaon
4.1 Install Door Staon
Note
●
Gang box is required for the installaon of door staon.
●
The power supply the door staon supports is 12 VDC. Please make sure your
power supply matches your door staon.
●
Complete wiring during installaon. Refers toTerminal and Wiring Descripon for
wiring details.
●
Make sure all the related equipment is power-o during the installaon.
●
Installaon Locaon: the lens of the device shall be 1.5 meters away from the
ground.
4.1.1 Door Staon Installaon Accessories
Video Intercom Face Recognion Door Staon User Manual
7
Mounng Plate
Figure 4-1 Mounng Plate
Note
The dimension of the mounng plate is 233 mm (W) × 112.4 mm (H) × 21
mm (D).
Video Intercom Face Recognion Door Staon User Manual
8
Gang Box
Figure 4-2 Gang Box
Note
●
The dimension of the gang box is 236.9 mm (W) × 128.4 mm (H) × 40.8
mm (D).
●
The installaon hole should be bigger than the actual size. The suggested
dimension of the installaon hole is 237.5 mm (W) × 128.9 mm (H) × 41.3
mm (D).
4.1.2 Surface Mounng
Steps
1. Paste the mounng template on the wall according to the installaon locaon
requirements. Drill holes according to the locaon of the screw holes of the
mounng template, and insert the expansion bolts into the screw holes.
2. Fix the mounng plate to the wall with 4 supplied screws.
3. Fix the device to the mounng plate, and x the device with the set screws.
Video Intercom Face Recognion Door Staon User Manual
9
Note
●
Do not touch the SD card slot and other devices during the process of plugging
in and unplugging the power interface.
●
Apply Silicone sealant among the joints between the device and the wall
(except the lower side) to keep the raindrop from entering.
Figure 4-3 Surface Mounng
4.1.3 Flush Mounng
Steps
1. Cave an installaon hole in the wall. The suggested dimension of the installaon
hole is 237.5 mm (W) × 128.9 mm (H) × 41.3 mm (D). Pull the cables out from the
wall. Insert the gang box into the installaon hole, and mark the gang box screw
holes' posion with a marker.
2. Take out the gang box. Drill 4 holes according to the marks on the wall, and insert
the expansion sleeves into the screw holes. Fix the gang box with 4 expansion
bolts.
3. Insert the door staon into the gang box, and x it with set screws.
Note
●
Do not touch the TF card slot and other devices during the process of plugging
in and unplugging the power interface.
●
Apply Silicone sealant among the joints between the device and the wall
(except the lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon User Manual
10
Figure 4-4 Flush Mounng
4.2 Install Door Staon with Sub Module
Note
●
Gang box is required for the installaon of door staon.
●
The power supply the door staon supports is 12 VDC. Please make sure your
power supply matches your door staon.
●
Complete wiring during installaon. Refers to Terminal and Wiring Descripon for
wiring details.
●
Make sure all the related equipment is power-o during the installaon.
●
Installaon Locaon: the lens of the device shall be 1.5 meters away from the
ground.
●
The installaon steps of door staon with dierent sub modules are the same,
and here takes door staon with keypad module for example.
4.2.1 Door Staon with Sub Module Installaon Accessories
Video Intercom Face Recognion Door Staon User Manual
11
Mounng Plate
Figure 4-5 Mounng Plate
Note
The dimension of the mounng plate is 233 mm (W) × 112.4 mm (H) × 21
mm (D).
Video Intercom Face Recognion Door Staon User Manual
12
Gang Box
Figure 4-6 Gang Box
Note
●
The dimension of the gang box is 312.9 mm (W) × 128.4 mm (H) × 40.8
mm (D).
●
The installaon hole should be bigger than the actual size. The suggested
dimension of the installaon hole is 313.5 mm (W) × 128.9 mm (H) × 41.3
mm (D).
Video Intercom Face Recognion Door Staon User Manual
13
●
The installaon hole should be bigger than the actual size. The suggested
dimension of the installaon hole is 313.5 mm (W) × 128.9 mm (H) × 41.3
mm (D).
●
The gang box for ush mounng of the door staon with sub module is
not contained in the package. Contact us or purchase need.
4.2.2 Surface Mounng
Steps
1. Loosen splice set screws, and separate the host from the keypad module. Paste
the mounng template on the wall according to the installaon locaon
requirements. Drill holes according to the locaon of the screw holes of the drill
template, and install the expansion bolts into the screw holes.
2. Fix the mounng plate to the wall with 4 supplied screws.
3. Fix the device to the mounng plate, and x the device with the set screws.
4. Put the Silicone sealant sleeve at the USB part of the keypad module in place.
Align the keypad module with the USB interface and install it into the device, and
x it with splice set screws.
Note
●
Do not touch the TF card slot and other devices during the process of plugging
in and unplugging the power interface.
●
Apply Silicone sealant among the joints between the device and the wall
(except the lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon User Manual
14
Figure 4-7 Surface Mounng
4.2.3 Flush Mounng
Steps
1. Cave an installaon hole in the wall. The suggested dimension of the installaon
hole is 313.5 mm (W) × 128.9 mm (H) × 41.3 mm (D). Pull the cables out from the
wall, insert the gang box into the installaon hole, and mark the gang box screw
holes' posion with a marker.
2. Take out the gang box. Drill 4 holes according to the marks on the wall, and insert
the expansion sleeves into the screw holes. Fix the gang box with 4 expansion
bolts. Remove the mounng ears of the gang box.
3. Fix the sub module to the door staon with 2 set screws. Wire the device and
cover the rear panel with 2 screws. Insert the door staon into the gang box, and
x it with set screws.
Note
●
Do not touch the TF card slot and other devices during the process of plugging
in and unplugging the power interface.
●
Apply Silicone sealant among the joints between the device and the wall
(except the lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon User Manual
15
Figure 4-8 Flush Mounng
Video Intercom Face Recognion Door Staon User Manual
16
5 Sub Module Descripon
Both keypad module and ngerprint module are supported by the door staon.
Select a sub module according to your actual needs.
Figure 5-1 Keypad Module
Figure 5-2 Fingerprint Module
Aer installaon, power on the device. Door staon will recognize the sub module
automacally.
Device will restart automacally in 10 s when the sub module is removed from the
door staon. Turn o the device before plugging the sub module to the door staon.
Video Intercom Face Recognion Door Staon User Manual
17
6 Acvaon
6.1 Acvate Device Locally
You are required to acvate the device rst by sengs a strong password for it
before you can use the device.
Steps
1. Power on the device to enter the acvaon page automacally.
2. Create a password and conrm it.
Note
You can tap to enable or disable password reveal.
3. Tap Next to nish acvaon.
Note
We highly recommend you to create a strong password of your own choosing
(using a minimum of 8 characters, including at least three kinds of following
categories: upper case leers, lower case leers, numbers, and special characters)
in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
What to do next
Aer acvang the device, the quick conguraon page will pop-up automacally.
Refers to Quick Conguraon for details.
6.2 Acvate Device via Web
Steps
1. The computer and the device should belong to the same subnet.
Note
Default IP Address: 192.0.0.65.
2. Enter the door staon IP address into the address bar of the web browser to enter
the acvaon page.
Video Intercom Face Recognion Door Staon User Manual
18
Cauon
In order to improve the network security, the set password must be from 8 to 16
digits, and be a combinaon of at least two or more types of numbers, lowercase
leers, uppercase leers, and special characters.
3. If there are mulple door staons in your network, please edit the IP address of
the door staon to prevent IP address conicts from causing abnormal access to
the door staon. Aer logging in the door staon, you can click Conguraon →
Network → TCP/IP to edit the door staon IP address, subnet mask, gateway and
other parameters.
6.3 Acvate Device via Client Soware
You can only congure and operate the door staon aer creang a password for
the device acvaon.
Default parameters of door staon are as follows:
●
Default IP Address: 192.0.0.65.
●
Default Port No.: 8000.
●
Default User Name: admin.
Steps
1. Run the client soware, click Maintenance and Management → Device
Management → Device to enter the page.
2. Click Online Device.
3. Select an inacvated device and click Acvate.
4. Create a password, and conrm the password.
Note
We highly recommend you to create a strong password of your own choosing
(using a minimum of 8 characters, including at least three kinds of following
categories: upper case leers, lower case leers, numbers, and special characters)
in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
5. Click OK to acvate the device.
Video Intercom Face Recognion Door Staon User Manual
19
Note
●
When the device is not acvated, the basic operaon and remote operaon of
device cannot be performed.
●
You can hold the Ctrl or Shi key to select mulple devices in the online
devices, and click the Acvate buon to acvate devices in batch.
6.4 Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before
you can use the device.
Default parameters of the door staon are as follows:
●
Default IP Address: 192.0.0.65.
●
Default Port No.: 8000.
●
Default User Name: admin
Steps
1. Power on the device, and connect the device to the network.
2. Enter the IP address into the address bar of the web browser, and click Enter to
enter the acvaon page.
Note
The computer and the device should belong to the same subnet.
3. Create and enter a password into the password eld.
4. Conrm the password.
5. Click OK to acvate the device.
Video Intercom Face Recognion Door Staon User Manual
20
7 Local Conguraon
7.1 Quick Conguraon
Aer acvang the device, the quick conguraon page will pop up automacally.
Steps
1. Select the system language and tap NEXT.
Figure 7-1 Select Language
2. Set network parameters and tap NEXT.
-
Set the IP address, Subnet Mask and Gateway manually.
-
Enable DHCP, the device will get network parameters automacally.
Video Intercom Face Recognion Door Staon User Manual
21
Figure 7-2 Network Parameters Sengs
3. Set password reset method and tap NEXT.
-
Enter the Reserved Email address, then you can reset the admin password by
email.
Note
On the security quesons sengs page, you can tap Change to Reserved Email
to modify the password reset method.
Video Intercom Face Recognion Door Staon User Manual
22
Figure 7-3 Password Reset by Seng Reserved Email Address
-
Tap Change to Security Queson. Select 3 security quesons from deciency
list and enter the answers of the quesons, then you can reset the password by
answering security quesons.
Video Intercom Face Recognion Door Staon User Manual
23
Figure 7-4 Password Reset by Seng Security Quesons
4. Enable the cloud service funcons and create a vericaon code. Tap NEXT.
Video Intercom Face Recognion Door Staon User Manual
24
Figure 7-5 Cloud Service
5. Select theme of the system.
Video Intercom Face Recognion Door Staon User Manual
25
Figure 7-6 Theme Sengs
6. Tap FINISH.
7.2 Authencaon via Admin
You can congure the parameters of the device on the menu page. You should
authencate to enter the menu.
If you want to authencate via face/card/ngerprints, you should add administrator
rst. Refers to
User Management for details.
Steps
1. Hold the screen to enter the authencaon page.
2. You can enter the admin password or authencaon via Face/Card/Fingerprints to
enter the menu.
Note
Admin password is set as acvaon password.
Video Intercom Face Recognion Door Staon User Manual
26
Figure 7-7 Menu Page
7.3 Network Parameters Sengs
The device support wired network, wireless network and cloud service sengs.
Note
Only parts of the devices support the wireless network, please refers to the actual
device for detailed informaon.
7.3.1 Edit Wired Network Parameters
The device should be connected to the network.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Video Intercom Face Recognion Door Staon User Manual
27
Steps
1. On the menu, tap Network → Wired Network to enter the sengs page.
Figure 7-8 Wired Network Sengs
2. Edit the wired network parameters.
-
Edit the wired network parameters manually.
-
Enable DHCP, and the system will get the parameters automacally.
7.3.2 Cloud Service Sengs
Enable the funcon, you can congure the device via mobile client remotely.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Network → Cloud Service to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
28
Figure 7-9 Cloud Service Sengs
2. Slide to enable the funcon.
3. Edit the Cloud Service Address and create a Vericaon Code.
4. Tap √ to save the sengs.
7.4 Device No. Sengs
Congure the No. of the device to make the communitcaon easily.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
29
Figure 7-10 Local Conguraon
2. Edit Community No., Building No., Unit No., Floor No. and No. according to the
actual needs.
7.5 User Management
On the user management page, you can add new users, congure the user's room
informaon, card informaon, face informaon, and ngerprint informaon.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Person Management to enter the sengs page.
2. Tap + to enter the add user page.
3. Set Room No.
4. Add Card.
Video Intercom Face Recognion Door Staon User Manual
30
1) Tap Card, and tap + to enter the add card page.
2) Enter the card No. manually or present the card in the card presenng area to
obtain the card No.
3) Tap OK to enable the sengs.
5. Add Face.
1) Tap Face Picture, and point the face at the camera.
2)
Tap
to add the face.
3)
Tap
to enable the sengs.
6. Add Fingerprint.
1) Select Fingerprint, and tap +.
2) Put your nger on the ngerprint reader and add the ngerprint.
7. Set User Permission as User or Administrator.
8. Exit the sengs page.
7.6 Call Sengs
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
31
Figure 7-11 Local Conguraon
2. Tap Shortcut Key to select call mode.
Calling Menu
Select call mode as Calling Menu. On the main page, tap call buon to enter
the calling page.
Call Specied Room
Select call mode as Call Specied Room and set the Specied Room No.. On
the main page, tap call buon to call the room you set.
Call Center
Select call mode as Call Center. On the main page, tap call buon to call the
management.
3. Exit the page to enable the sengs.
7.7 Forget Admin Password
Video Intercom Face Recognion Door Staon User Manual
32
Admin password is used for authencang to enter the local conguraon menu. If
you forget the password, you can change it by entering security quesons' answers.
Steps
1. Hold the main page to enter the authencaon page.
Figure 7-12 Authencaon Page
2. Tap Forgot Password.
3. Change the admin password via entering answers of security quesons or email
address.
4. Create and conrm a new password.
7.8 System Sengs
7.8.1 Change Language
Change language according to your actual needs.
Video Intercom Face Recognion Door Staon User Manual
33
Before You Start
Authencate and enter the menu rst. Refers to Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
Figure 7-13 Local Conguraon
2. Tap Select Language to switch the system language.
7.8.2 Adjust Brightness
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
34
Figure 7-14 Local Conguraon
2. Adjust the brightness of the device.
-
Enable the Auto Screen Brightness, the device will adjust the brightness
according to the environment automacally.
-
Edit the number to adjust the brightness manually.
7.8.3 Keypad Sound Sengs
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
On the menu, tap Local Conguraon to enter the sengs page.
Slide to enable or disable the Keypad Sound.
7.8.4 Channel Mode Sengs
Enable the funcon, the door stays open.
Video Intercom Face Recognion Door Staon User Manual
35
Before You Start
Authencate and enter the menu rst. Refers to Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
2. Slide to enable the funcon.
7.8.5 Theme Sengs
Select theme of the system to make the device user friendly.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Preference to enter the sengs page.
2. Select theme of the system.
Note
If you select theme 2, you can edit adversement or welcome words.
7.8.6 Restore Door Staon
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Steps
1. On the menu, tap Local Conguraon to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
36
Figure 7-15 Local Conguraon
2. Restore the device.
Restore to Default Sengs
Tap Restore to Default Sengs to reset all parameters, except IP address,
subnet mask and default gateway, to the default sengs.
Restore to Factory Sengs
Tap Restore to Factory Sengs to restore all parameters to default sengs.
7.9 Device Informaon
View the device model, system version, App version and open source soware
licenses.
Before You Start
Authencate and enter the menu rst. Refers to
Authencaon via Admin for
details.
Video Intercom Face Recognion Door Staon User Manual
37
Steps
1. On the menu, tap About to enter the page.
Figure 7-16 About
2. You can view the device model, system version, App version and open source
soware licenses.
3. Oponal: Scan the QR code to add the device to mobile client.
Video Intercom Face Recognion Door Staon User Manual
38
8 Local Operaon
8.1 Call from the Device
Door staon supports calling users or management center.
8.1.1 Call Resident
Call Resident from Main/Sub Door Staon
Figure 8-1 Call Resident
On the main page, tap to enter the calling page.
Enter the Room No., and tap to call residents.
Video Intercom Face Recognion Door Staon User Manual
39
Note
●
Both the main and sub door staon support the elevator control funcon,
that is, aer calling the residents successfully, tap the unlock buon on
the indoor staon, the elevator will automacally arrive at the oor
where the door staon is located, and the permission of the oor where
the household is located will be opened (The elevator calling will take
eect only aer the elevator control is congured and the corresponding
conguraon of the door machine is completed).
●
You can enter the related No. and tap
to call residents if the funcon is
enabled for the indoor staons. Refer to Device Management for details
about related No. sengs.
On the main page, tap contact buon to enter the contact list.
Figure 8-2 Contacts
Select a contact from the list to call. You can enter the name in the search
bar or tap the leer on the right side of the screen to nd a target contact.
Video Intercom Face Recognion Door Staon User Manual
40
Call Resident from Outer Door Staon
On the main page of the outer door staon, tap Call to enter the calling
page.
Enter Phase No. + # + Building No. + # + Unit No. + # + Room No., and tap
Call again to call residents.
Enter Phase No. + # + Room No., and tap Call again to call residents.
8.1.2 Call Center
Refers to
Call Sengs to set the calling shortcut key.
Call Center by Calling Menu
If you set call mode as Calling Menu.
Tap on the main/sub door staon page to enter the calling page.
Tap
to call management center administrator. Tap cancel buon to cancel
during calling management center.
Call Center by Shortcut Key
If you set call mode as Call Center, you can tap the call buon on the main
page to call.
8.2 Unlock Door
You can unlock door staon in following methods: Unlock by password, unlock by
presenng card, unlock by face, and unlock by ngerprint.
8.2.1 Unlock by Password
Tap call buon on the main page to enter the calling page.
Enter 【 # + Public Password 】, and tap unlock buon.
Video Intercom Face Recognion Door Staon User Manual
41
8.2.2 Unlock by Face
Note
Make sure that you have added your face picture to the device. Refers to the User
Management for details.
Face forward at the camera to unlock.
8.2.3 Unlock by Presenng Card
Note
Make sure you have issued the card to the device. Refers to User Management for
details.
Present the card on the card reading area to unlock.
8.2.4 Unlock by QR Code
Door staon supports unlock by QR code. You can generate a QR code through the
mobile phone client, and use the door staon camera to scan the mobile phone QR
code to open the door.
Steps
Note
●
Make sure that the door staon IP has been added to the indoor staon, and the
indoor staon and the door staon can communicate normally.
●
Make sure that the door staon is connected to the network.
●
QR code is for visitors only.
1. Installing Hik-Central Pro on your PC.
2. Register user accounts according to the prompts, and log in.
3. Follow the prompts to add the indoor staon by scanning the QR code/barcode or
manually entering the serial number.
4. Enter unlock by QR code page and generate the QR code.
5. On the main page of door staon, tap down buon to enter the unlock by QR
code page.
6. Aim the QR code generated by the phone at the camera and scan the code to
open the door.
Video Intercom Face Recognion Door Staon User Manual
42
Note
●
It is recommended that when installing the door staon, try to select a locaon
that does not cause reecons, otherwise it may aect the QR code scanning. If
it is acrylic door staon, make sure that the membrane on the surface of the
door machine has been torn o.
●
It is recommended to align the mobile phone's QR code with the door staon
camera horizontally when scanning the QR code.
●
QR code recognion is not supported at night.
Video Intercom Face Recognion Door Staon User Manual
43
9 Remote Conguraon via Web
9.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter
key to enter the login page.
Enter the user name and password and click Login to enter the Live View page. Or
you can click Live View to enter the page.
Figure 9-1 Live View
●
You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
●
The stream type can be set as main stream or sub stream.
●
For IE (Internet Explorer) or Google users, the device support two-way audio
communicaon.
Note
Live View funcon may vary with dierent models. Please refer to the actual
product.
9.2 User Management
You can manage user informaon on the page.
Steps
1. Click User to enter the page.
2. Click Add and complete related informaon to add users.
Video Intercom Face Recognion Door Staon User Manual
44
Figure 9-2 Add User
1) Enter Person ID, Name, Floor No.andRoom No.. Select Level.
2) Congure Start Time and End Time.
3) Check Administrator and the person added will be able to log in by face
recognion.
4) Click Add Card, enter Card No. and select Property. Or you can click Read and
place the card on the card-reding zone.
5) Click Capture and make sure the face image of the person can be captured
properly. Or you can click + to upload local images.
Note
The picture format should be JPG, JPEG or PNG, and the size should be less than
200 k.
6) Click OK to complete person adding.
3. Delete or edit users.
-
Select users and click Delete to delete users.
-
Click
to edit user informaon.
4.
Input keywords in the bar and click
to search users, and the qualied users will
be displayed on the result list.
9.3 Device Management
Video Intercom Face Recognion Door Staon User Manual
45
You can manage the linked device on the page.
Click Device Management to enter the sengs page.
Figure 9-3 Device Management
Add Device
●
Click Add to add the indoor staon or sub door staon. Enter the
parameters and click OK to add.
●
Click Import. Enter the informaon of the device in the template to
import devices in batch.
Note
You can set related No. with uppercase leers (must be contained) and
digits for indoor staons. You can call residents or unlock door via related
No.
Export
Click Export to export the informaon to the PC.
Delete
Select the device and click Delete to remove the selected device from the
list.
Video Intercom Face Recognion Door Staon User Manual
46
Upgrade
Click Timing Upgrade, click to Enable Upgrading Device Automacally and
congure Start Time and End Time. The devices will upgrade automacally
at the set me.
Click Upload Updang Package, select Upgrade File and click Browse to
upload upgrading package.
Select devices to be upgraded, and click Upgrade Now to upgrade devices
manually.
Upgrading Status
Click Upgrading to view the upgrading status of the devices.
Synchronize
Click Synchronize and enable Synchronize for device synchronizaon.
Refresh
Click Refresh to get the device informaon.
Oponal: Set Device Informaon.
●
Click
to edit device informaon.
●
Click
to delete device informaon from the list.
●
Select Status and Device Type to search devices.
Search for Online Devices
Click Refresh and the online devices will be list.
Check to select the device and click Add to Device List, you can link the
device in the list to the door staon.
9.4 Parameters Sengs
Video Intercom Face Recognion Door Staon User Manual
47
Click Conguraon to set the parameters of the device.
Remote conguraon in iVMS-4200 and Batch Conguraon Tool is the same as that
in Web. Here takes the conguraon in web for example.
Note
Run the browser, click → Internet Opons → Security to disable the Protected
Mode.
9.4.1 Local Sengs
Live View Parameters
●
Stream Type: Select the stream type toMain StreamorSub Stream.
●
Play Performance: selectShortest Delay,BalanceorGood Fluencyaccording
to your needs.
●
Auto Start Live View: If you selectYes, when you enable preview, the page
will automacally play the preview image; if you selectNo, when you
enable the preview, you need to manually click the play buon to preview
image.
●
Image Format: Set the save format of captured images.
Record File Sengs
●
Record File Size: Select the packaged size of the video le according to
your needs.
●
Save record les to: Video le is stored locally, you can selectBrowseto
change the saving path. ClickOpento open the folder under the archive
path.
Picture and Clip Sengs
Save snapshots in live view to: Capture le is stored locally, you can
selectBrowseto change the saving path. ClickOpento open the folder under
the archive path.
Video Intercom Face Recognion Door Staon User Manual
48
Note
Only IE and Google browsers support saving path sengs. Other browsers
default to the C drive download path. Please refer to the actual device page
for more details.
9.4.2 System Parameters
Follow the instrucons below to congure the system sengs, include System
Sengs, Maintenance, Security, and User Management, etc.
Click Conguraon → System to enter the sengs page.
System Sengs
Click System Sengs to enter the sengs page.
Basic Informaon
Click Basic Informaon to enter the sengs page. On the page, you can edit
Device Name and Device No.. Set the Language according to your needs.
Video Intercom Face Recognion Door Staon User Manual
49
Figure 9-4 Basic Informaon
Click View QR Code, and you can use the mobile client to scan to add the
device.
You can view the quanes of added users, face pictures and cards in
Capacity.
Click Save to enable the sengs.
Time Sengs
Click Time Sengs to enter the sengs page. Select the Time Zone of your
locaon from the drop-down list.
Video Intercom Face Recognion Door Staon User Manual
50
●
Enable NTP, set the Server Address, NTP Port and Interval.
●
Enable Manual Time Sync., set the me manually or check the Sync. with
computer me.
Click Save to enable the sengs.
About
Click About to enter the page. Click View Licenses to view open source
soware Licenses.
Maintenance
Enter a short descripon of your concept here (oponal).
Click Maintenance → Upgrade & Maintenance to enter the sengs page.
Figure 9-5 Maintenance
Reboot
Click Reboot to reboot the device.
Restore Parameters
Default
Click Default to restore all parameters to default sengs.
Video Intercom Face Recognion Door Staon User Manual
51
Restore All
Click Restore All to reset all the parameters, except the IP parameters
and user informaon, to the default sengs.
Unlink APP Account
Click Unlink APP Account to unlink the account from the mobile client.
Export Parameters
1. Select Device Parameters, and click Export to pop up the dialog box.
2. Set and conrm the encrypon password.
3. Click OK to export parameters.
Import Cong File
1. Click browse icon to select the conguraon le.
2. Click Import and enter the encrypon password to import.
Upgrade
1. Click browse icon to select the upgrade le.
2. Click Upgrade.
Note
●
The upgrading process will last 1 to 10 minutes, do not power o during
the upgrading. The device reboots automacally aer upgrading.
●
You can select controller, display module and sub modules to upgrade.
Security Sengs
Set the security service and cercate of the device.
Security Service
The device support SSH, ADB and HTTP protocols.
Video Intercom Face Recognion Door Staon User Manual
52
Steps
1. Click Security → Security Service to enter the sengs page.
Figure 9-6 Security Service
2. On the page, you can enable SSH, ADB remote control and HTTP according to your
actual needs.
3. Click Save to enable the sengs.
Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an
alarm if the cercates are close to expiry date, or are expired/abnormal.
Create Cercate
Steps
1. Select Cercate Type from the drop-list.
2. Click Create.
3. Follow the prompt to enter Cercate ID, Country/Region, Hostname/IP, Validity
and other parameters.
Note
The cercate ID should be digits or leers and be no more than 64 characters.
4. Click OK
5. Oponal: Click Export to export the cercate, or click Delete to delete the
cercate to recreate a cercate.
Import Passwords
Video Intercom Face Recognion Door Staon User Manual
53
Steps
1. Select Cercate Type from the drop-list.
2. Click Browser and select the cercate les from the PC.
3. Click Install.
Import Communicaon Cercates
Steps
1. Select Cercate Type from drop-list.
2. Click Browser to select the cercate and click Install.
Note
●
Up to 16 cercates are allowed.
●
If certain funcons are using the cercate, it cannot be deleted.
●
You can view the funcons that are using the cercate in the funcons
column.
●
You cannot create a cercate that has the same ID with that of the exisng
cercate and import a cercate that has the same content with that of the
exisng cercate.
Import CA Cercate
Steps
1. Edit Custom ID.
2. Click Browser and select cercate les.
3. Click Install.
Note
Up to 16 cercates are allowed.
User Management
Enter a short descripon of your concept here (oponal).
This is the start of your concept.
Video Intercom Face Recognion Door Staon User Manual
54
9.4.3 Network Sengs
TCP/IP Sengs
TCP/IP sengs must be properly congured before you operate the device over
network. The device supports IPv4.
Steps
1. Click Network → Basic Sengs → TCP/IP to enter the sengs page.
Figure 9-7 TCP/IP Sengs
2. Select Network Card.
3. Congure the network parameters.
-
Check DHCP, the device will get the parameters automacally.
-
Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway manually.
4. Congure the DNS server.
5. Edit Alarm Center IP and Alarm Host Port.
6. Click Save to enable the sengs.
Port Sengs
Video Intercom Face Recognion Door Staon User Manual
55
Steps
1. Click Network → Basic Sengs → Port to enter the sengs page.
2. Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which is
not occupied.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which is
not occupied.
RTSP Port
The default port number is 554.
Server Port
The default server port number is 8000, and it can be changed to any port No.
ranges from 2000 to 65535.
3. Click Save to enable the sengs.
SIP Seng
Steps
1. Click Network → Basic Sengs → SIP to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
56
Figure 9-8 SIP Sengs
2. Check Enable VOIP Gateway.
3. Congure the SIP parameters.
4. Click Save to enable the sengs.
FTP Sengs
Steps
1. Click Network → Advanced → FTP to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
57
Figure 9-9 FTP Sengs
2. Check Enable FTP.
3. Select Server Type.
4. Input the Server IP Address and Port.
5. Congure the FTP Sengs, and the user name and password are required for the
server login.
6. Set the Directory Structure, Parent Directory and Child Directory.
7. Set the picture naming rules.
Video Intercom Face Recognion Door Staon User Manual
58
8. Click Save to enable the sengs.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1. Click Conguraon → Network → Advanced Sengs → Plaorm Access to enter
the sengs page.
Figure 9-10 Plaorm Access
2. Select plaorm access mode.
3. Check Enable, congure the server IP address and set Access Server IP Address
and Vericaon Code.
4. Click Save to enable the sengs.
Note
●
The vericaon code is used when adding devices to the mobile client. It can be
modied. Please keep it properly.
●
The vericaon code should contain 6 to 12 characters (it is recommended to
be the combinaon of numeric and leer, and more than 8 characters).
HTTP Listening
Video Intercom Face Recognion Door Staon User Manual
59
Click Conguraon → Network → Advanced → HTTP Listening to enter the sengs
page.
Figure 9-11 HTTP Listening Sengs
Enter the parameters according to the page and click Save to enable the funcon.
Capture Network Packet
Click Network → Capture Network Packet to enter the sengs page.
Slide to adjust the Capture Packet Duraon and Capture Packet Size.
Click Capture to get the network packet.
9.4.4 Video & Audio Sengs
Video Parameters
Steps
1. Click Video/Audio → Video to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
60
Figure 9-12 Video Parameters
2. Select the Stream Type.
3. Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
Select the stream type to video stream, or video & audio composite stream.
The audio signal will be recorded only when the Video Type is Video & Audio.
Resoluon
Select the resoluon of the video output.
Bitrate Type
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are
selectable.
Frame Rate
Set the frame rate. The frame rate is to describe the frequency at which the
video stream is updated and it is measured by frames per second (fps). A
higher frame rate is advantageous when there is movement in the video
stream, as it maintains image quality throughout.
Max. Bitrate
Video Intercom Face Recognion Door Staon User Manual
61
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to
the higher video quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
4. Click Save to save the sengs.
Audio Parameters
Steps
1. Click Video/Audio → Audio to enter the sengs page.
Figure 9-13 Audio Sengs
2. Congure the stream type and the audio encoding type.
Audio Channel
Select the audio channel to adjust the audio parameters.
Stream Type
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3. Adjust the Input Volume and Output Volume.
Note
Available range of volume: 0 to 10.
4. Click Save to save the sengs.
Video Intercom Face Recognion Door Staon User Manual
62
9.4.5 Display Sengs
Congure the image adjustment, backlight sengs and other parameters in display
sengs.
Steps
1. Click Image → Display Sengs to enter the display sengs page.
Figure 9-14 Display Sengs
2. Select the Format.
3. Set the display parameters.
WDR
Wide Dynamic Range can be used when there is a high contrast of the bright
area and the dark area of the scene.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1
to 100.
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to
100.
4. Click Day/Night Switch to set the parameters.
Video Intercom Face Recognion Door Staon User Manual
63
Figure 9-15 Day/Night Switch
Auto
Select Day/Night Switch as Auto, and set the Sensivity. The device will
switch between Day Mode and Night Mode automacally according to the
environment.
Dayme
Select Day/Night Switch as Dayme. The device will keep the mode as
dayme.
Night
Select Day/Night Switch as Night. The device will keep the mode as night.
Scheduled-Switch
Select Day/Night Switch as Scheduled-Switch and set the duraon. The
device will keep the mode as dayme during the duraon you set. And switch
to the night mode except the duraon.
5. Click Save to enable the sengs.
9.4.6 Card Security
Click General → Card Security to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
64
Figure 9-16 Card Security
Slide to enable card encrypon parameters.
Click Save to enable the sengs.
9.4.7 Intercom Sengs
Device No. Conguraon
Set the No. of the device, and linked devices can build a communicaon.
Steps
1. Click Intercom → Device No. to enter the sengs page.
Figure 9-17 Device No. Sengs
2. Select the device type from the drop-down list, and set the corresponding
informaon.
3. Click Save to enable the device number conguraon.
Video Intercom Face Recognion Door Staon User Manual
65
Note
●
For main door staon (D series or V series), the serial No. is 0.
●
For sub door staon (D series or V series), the serial No. cannot be 0. Serial No.
ranges from 1 to 99.
●
For each villa or building, at least one main door staon (D series or V series)
should be congured, and one sub door staons (D series or V series) can be
customized.
●
For one main door staon (D series or V series), up to 8 sub door staons can
be congured.
Linked Network Sengs
Steps
1. Click Intercom → Session Sengs to enter the sengs page.
Figure 9-18 Session Sengs
2. Set Registraon Password.
3. Set Main Staon IP and VideoIntercom Server IP.
4. Enable Protocol 1.0.
5. Click Save to enable the sengs.
Permission Password
Steps
1. Click Intercom → Password Sengs to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
66
Figure 9-19 Password Sengs
2. Click +Add to create a password.
1) Create a password.
2) Check to select unlock permission.
3) Oponal: Enter the remarks of the password.
3. Click OK to save the password.
Call Sengs
Click Intercom → Call Sengs to enter the page.
Congure the me parameters and click Save.
Note
●
For door staon, maximum call duraion and maximum message duraon should
be congured.
●
Maximum speaking me varies from 90s to 120s, and maximum message me
varies from 30s to 60s.
Ringbacktone Sengs
Click Intercom → Ringbacktone Sengs to enter the sengs page.
Click +Add to select the ringtone le from the local PC.
Video Intercom Face Recognion Door Staon User Manual
67
Figure 9-20 Ringtone Sengs
Note
Available Audio Format: WAV、AAC, Size: Less than 600 KB, Sample Rate: 8000Hz,
Mono.
Number Sengs
Steps
1. Click Intercom → Number Sengs , and you can view the No., room No., and SIP
number.
2. Add the number.
1) Click Add.
2) Enter Room No., and SIP.
3) Oponal: Click Add to add SIP according to the actual needs.
4) Click OK.
3.
Oponal: Click
to edit the number.
9.4.8 Access Control Sengs
Door Parameters
Set the parameters of the door which is linked to the device.
Steps
1. Click Access Control → Door Parameters to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
68
Figure 9-21 Door Parameters
2. Select Door No., and edit the Name.
3. Set Open Duraon. When the me to open over the open duraon you set, the
door will be locked again.
4. Select Relay Reverse as ON or Disable.
5. Click Save to enable the sengs.
Elevator Control
Before You Start
Make sure that the door staon is in the mode of main door staon. Only the main
door staon supports elevator control funcon.
Steps
1. Click Access Control → Elevator Control Parameter to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
69
Figure 9-22 Elevator Control
2. Check to enable elevator control funcon.
3. Select an Elevator No., and select an elevator controller type for the elevator.
4. Select Interface Type.
Note
If you select Interface Type as RS-485, you only need to enter Negave Floor
Capacity.
5. Enter Negave Floor Capacity, and select Alarm Receiver Type.
6. Enter the elevator controller's Server IP Address, Port No., User Name, and
Password.
7. Click Save to enable the sengs.
Video Intercom Face Recognion Door Staon User Manual
70
Note
●
Up to 4 elevator controllers can be connected to one door staon.
●
Up to 10 negave oors can be added.
●
Make sure the interface types of elevator controllers, which are connected to
the same door staon are consistent.
RS-485 Sengs
Set the working mode to linked device.
Steps
1. Click Access Control → RS-485 to enter the sengs page.
Figure 9-23 RS-485 Sengs
2. Select the No.
3. Select the working mode.
4. Click Save to enable the sengs.
9.4.9 Smart Sengs
Biometrics Sengs
Adjust the face recognion parameters and ngerprint parameters according to your
needs.
Steps
1. Click Smart to enter the sengs page.
2. Enable face an-spoong to edit face capture advanced parameters.
Video Intercom Face Recognion Door Staon User Manual
71
Figure 9-24 Smart Sengs
Table 9-1 Face Capture Advanced Parameters
Parameter Descripon
Face An-spoong
Enable face an-spoong to detect real people face for
recognion.
Live Face
Detecon Security
Level
Aer enabling face an-spoong funcon, you can set the
matching security level when performing live face
authencaon.
Recognion
Distance
Set the valid distance between the user and the camera
when authencang.
Applicaon Mode Select either others or indoor according to actual
environment.
Connuous Face
Recognion
Interval
The me interval between two connuous face
recognions when authencang.
Note
You can input the number from 1 to 10.
1:N Matching
Threshold
Set the matching threshold when authencang via 1:N
matching mode. The larger the value, the smaller the false
accept rate and the larger the false rejecon rate.
Note
You can input the number from 1 to 99.
Video Intercom Face Recognion Door Staon User Manual
72
Parameter Descripon
Face Recognion
Timeout Value
When the face recognion me exceed the value you set,
the recognion will be determined as a meout operaon.
Note
You can input the number from 1 to 20.
ECO Sengs Aer enabling the ECO mode, the device will use the IR
camera to authencate faces in the low light or dark
environment. And you can set the ECO mode threshold,
ECO mode (1:N).
ECO Threshold
When enabling the ECO mode, you can set the ECO
mode’s threshold. The larger the value, the easier the
device entering the ECO mode.
Note
You can input the number from 1 to 7.
ECO Mode (1:N)
Set the matching threshold when authencang via
ECO mode 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false
rejecon rate.
Note
You can input the number from 1 to 100.
Force to Enable Night Mode
When the environment is not bright enough, you can
slide to force to enable the night mode.
3. Click Save to enable the sengs.
Area Conguraon
Click VCA Conguraon → Area Conguraon to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
73
Figure 9-25 Area Conguraon
Drag the frame or enter the digits behind the parameters to adjust the size of the
recognion area.
9.4.10 Theme Sengs
Set the adversement on the main page of the device.
Steps
1. Click Conguraon → Theme to enter the sengs page.
Video Intercom Face Recognion Door Staon User Manual
74
Figure 9-26 Theme Sengs
2. Check to enable screen saving funcon.
3. Set the adversement theme.
1) Click + Add Theme.
2) Create a theme name, and select the adversement body as picture or Video.
3) Click Save.
Note
●
The maximum video le size is 200 MB. The supported video formats
are .avi, .v and .mp4.
●
The maximum image le size is 10 MB. The supported image formats
are .jpg, .jpeg, .png and .bmp.
●
We recommend keeping the aspect rao of the image/video the same as that
of the screen, otherwise it will automacally stretch to ll the screen.
4. Click + to select a picture from the local as the material to be played in standby,
and click upload.
5. Set the play schedule.
Video Intercom Face Recognion Door Staon User Manual
75
1) Select a theme and drag the me interval to be played on the meline.
2) Oponal: Click the drawn area to edit the me manually.
3) Click Delete to delete the selected area. Click Delete All to delete all selected
areas.
6. Adjust Slide Show Interval.
Drag the block or enter the number to set the slide show interval. The picture will
be changed according to the interval.
7. Oponal: Slide to enable show custom content and edit custom content.
The custom content displays on the main page of the device.
8. Click Save.
Video Intercom Face Recognion Door Staon User Manual
76
10 Remote Conguraon via Client
Soware
You can set Video Intercom system and manage video intercom products including
indoor staon, door staon and main staon via iVMS-4200 client soware.
10.1 Edit Device Network Parameters
Before You Start
Before conguring the device remotely, make sure that the device is acvated.
Steps
1. On the person management page, click Online Device.
2.
Click
to pop up the network parameter sengs page.
3. Edit the device IP address, subnet mask, default gateway, etc.
4. Enter the device acvaon password.
5. Click Save to enable the sengs.
Note
Please keep the device IP address and the local computer IP address in the same
network segment.
10.2 Add Device
You can add devices via the following methods: add device online, add device via IP
address, add device via IP segment, add device in batch, and add device via EHome.
10.2.1 Add Online Device
Steps
1. Click Online Device.
2. In the online device area, select an acvated online device, or press the Shi or
Ctrl to select mulple acvated online devices.
3. Click Add.
Video Intercom Face Recognion Door Staon User Manual
77
4. Enter the device Name, User Name, Password, and click Add.
Note
●
Only when the doorphone is added to the client soware, you can remotely
congure the indoor staon.
●
Only online devices with the same user name and acvaon password can
support batch acvaon.
Aer the device is added, the device informaon will be listed in the device list
area.
10.2.2 Add Device via IP Address
Steps
1. In the device list area, click Add to pop up the device adding dialog box.
2. Select the adding mode as IP/Domain Name.
3. Enter the corresponding informaon of the device: Name, Address, User Name,
and Password.
4. Click Add.
10.2.3 Add Device via IP segment
Steps
1. In the device list area, click Add to pop up the device adding dialog box.
2. Select adding method as IP segment, and enter the corresponding informaon:
Starng IP Address. Ending IP Address, Port No., User Name, and Password.
3. Click Add.
Aer adding, the device informaon will be displayed in the device list area.
10.2.4 Add Devices in Batch
Steps
1. In the device list area, click Add to pop up the device adding dialog box.
2. Select the adding mode as Import in Batch.
3. Click Export Template, and enter the device parameters to be imported according
to the template.
Video Intercom Face Recognion Door Staon User Manual
78
4. Select the le and click Add to import.
Note
The le format for batch import is .csv format.
10.2.5 Add Device Via EHome
Steps
1. In the device list area, click Add to pop up the device adding dialog box.
2. Select the adding mode as EHome.
3. Enter the corresponding informaon of the device: Name, Device Account , and
ISUP login key.
4. Click Add.
10.3 Local Conguraon via Client Soware
Click Maintenance and Management → System Sengs → Access Control and
Video Intercom , and you can set the incoming ringtone, ring meout me, the
maximum speaking duraon with the indoor staon, and the maximum speaking
duraon with the access control device.
Note
●
Click the speaker icon to hear the test ringtone.
●
The imported ringtone must be in wav format.
●
Ringing Timeout Time: The maximum me that the client soware can ring the
bell when no one answers the call from the the door staon or indoor staon.
Ringing meout me ranges from 15 s to 60 s.
●
The maximum speaking duraon with indoor staon ranges from 120 s to 600 s.
Aer the speaking duraon exceeds the maximum speaking duraon, the call will
end automacally.
●
The maximum speaking duraon with door staon ranges from 90 s to 120 s. Aer
the speaking duraon exceeds the maximum speaking duraon, the call will end
automacally.
10.4 Device Management
Video Intercom Face Recognion Door Staon User Manual
79
You can add device, modify device, delete device, perform remote conguraon, etc.
in device management page. The specic method is similar to web conguraon .
For details, please refer to the iVMS-4200 client user manual.
Note
●
When adding a third-party door staon encoding device, the client only supports
the management of device informaon, and does not support direct preview.
Third-party encoding device must be used in conjuncon with the TV wall.
●
The client can add up to 256 door staons (including unit door staon and
doorphone).
10.5 Live View
10.6 Intercom Organizaon Structure Conguraon
10.6.1 Add Organizaon
Steps
1. On the main page of the client, click User Management to enter the sengs page.
2. Click Add, enter the organizaon name to add the organizaon.
10.6.2 Modify and Delete Organizaon
●
You can select the added organizaon and click
to modify its name.
●
You can select an organizaon, and click X to delete it.
Note
●
Make sure there is no person added under the organizaon, or the organizaon
cannot be deleted.
●
The lower-level organizaons will be deleted as well if you delete an organizaon.
10.7 Person Management
You can add, edit, import, and export person informaon.
Video Intercom Face Recognion Door Staon User Manual
80
10.7.1 Add Person
Steps
1. On the main page of the client, click Person Management to enter the person
informaon conguraon page.
2. Select an organizaon in the organizaon list and click Add on the person panel to
pop up the adding person dialog.
Note
The Person No. will be generated automacally, and it is editable.
3. Set the person basic informaon.
1) Enter basic informaon: name, tel, eecve period and E-mail address.
Note
Up to 15 characters are allowed for person name.
2) Click Add face to upload the photo.
Note
The picture should be in *.jpg format.
Upload Click Upload, select the person picture from the local PC to
upload it to the client.
Take Photo Click Take Photo, and slide to enable device vericaon. Aer
the face collector is inialized successfully, you can take a
photo to obtain a face picture.
Remote
Collecon
Click Remote Collecon, select the collecon device, click the
photo to get the photo, and click OK to complete the
collecon.
4. Issue the card for the person.
1) Click Credenal → Card.
2) Click + to pop up the Add Card dialog, select Normal Card as Card Type, and
enter the Card No.
3) Click Read and the card(s) will be issued to the person.
5. Add ngerprint permissions for the person.
1) Click Credenal → Fingerprint.
2) Select Collecon Mode and Collecon Recorder.
Video Intercom Face Recognion Door Staon User Manual
81
3) Click Start to Scan to add the ngerprint.
4) Click Add to save the ngerprint.
Note
Only some models of the devices support ngerprint funcon, please refer to
the specic product.
6. Click Access Control and check the access control permissions that need to be
congured.
7. Linked Device
1) Click Resident Informaon, and select the device to be bound.
2) Set the oor No. and room No.
8. Click Save to enable the sengs.
10.7.2 Modify and Delete Person
Steps
1. Select the person and click Edit to open the eding person dialog.
2. Modify the person informaon in the pop-up window and click OK to save the
sengs.
3. Select the person in the organizaon, and click Delete to delete the person.
4. Select the person in the organizaon, click Change Organizaon, search or select
the organizaon to be moved to, and click OK to complete the organizaon
change.
10.7.3 Import and Export Person Informaon
Import Person Informaon
Steps
1. On the person management page, click Import.
2. In the pop-up dialog box, click ..., and select the CVS le to import.
3. Click OK, and the system will display the imported results.
4. Click Close to complete the import.
Video Intercom Face Recognion Door Staon User Manual
82
Note
●
Click Download Template for Imporng Person to download the template.
●
The import template contains the following informaon: person name,
department code, cercate type, cercate number, phone number and
address.
●
The number of persons can not exceed 5000 in a single import.
●
If the imported person No. already exists in the client database, the system will
automacally replace the original person informaon.
Export Person Informaon
Steps
1. On the person management page, click Export.
2. Select Person Informaon or Face Picture.
Note
Check the checkboxes to select the person informaon to export.
3. Click Export, select the saving path of the exported le and click Save.
All person informaon will be exported to specied locaon.
10.7.4 Get Person Informaon
Steps
1. In the person management page, click Get Person Informaon.
2. Select device(s) to get person informaon.
3. Click Get, the person informaon will be imported to the client soware.
Note
The device added using COM or ISUP connecon mode does not support get
person informaon funcon.
10.7.5 Issue Card in Batch
Steps
1. On the person management page, click Batch Issue Cards.
Video Intercom Face Recognion Door Staon User Manual
83
2. Click Sengs to set issue card paramrters.
-
If you set issue card Mode as Local, you need to set Card Issuer, Card Type and
Card No., and enable Buzzer and M1 Card Encrypon and click OK to issue
card.
-
If you set Issue Card Mode as Remote, select card issuing device, and click OK
to issue card.
10.7.6 Permission Sengs
Add Permissions
Steps
1. On the main page of the client, click Access Control → Access Group to enter the
sengs page.
2. Click Add to pop up the adding dialog box.
3. Congure the parameters.
1) Enter Name of the permission.
2) Select the Schedule Template.
3) Check the person to Selected according to your needs.
4) Check the device to Selected according to your needs.
4. Click Save.
5. Check the permission and click Apply All to Device.
The status of the permission displays as Applied.
6. Oponal: Click Applying Status to check the details.
Modify/Delete Permissions
On the page of the permission sengs, click
to edit the parameters of the
permission.
Select one or more permissions, click Delete to remove the permissions.
10.8 Video Intercom Sengs
10.8.1 Video Intercom
Video Intercom Face Recognion Door Staon User Manual
84
You can call residents on the video intercom page, and the residents can also call the
client soware through the indoor staon. The door staon can also call the client
soware.
Steps
1. On the main page, click Access Control → Video Intercom → Video Intercom to
enter the video intercom page.
2. Select an organizaon from the list, and the residents list on the right displays the
residents informaon under the organizaon.
3.
Select a resident from the list, and click
to call the corresponding resident.
4. If the indoor staon calls the client soware, you can click Answer or Hang Up.
Figure 10-1 Answer the Call
5. Aer the call is connected, the device will enter the dialog page.
Adjust the
Volume
Click
to adjust the volume of the microphone.
Click
to adjust the volume of the microphone.
Hang up the
Dialog
Click Hang Up to hang up the dialog.
Unlock Remotely If the indoor staon is connected to the door staon, click
to open the door associated with the door staon.
Video Intercom Face Recognion Door Staon User Manual
85
Note
●
One video intercom device can only connect with one client soware.
●
The maximum ring duraon can be set from 15 s to 60 s.
●
The maximum speaking duraon between the client soware and indoor
staon can be set from 120 s to 600 s.
10.8.2 Search Video Intercom Informaon
Search Call Logs
Steps
1. On the Video Intercom page, click Access Control → Video Intercom → Call Log to
enter the page.
2. Set the search condions.
Call Status
You can select the call status as dialed, received or missed.
Device Type
Select the device type as indoor staon, door staon, outer door staon or
analog indoor staon.
Time
Set the start me and end me of a me period to search the logs.
3. Click Search.
4. Oponal: You can reset the sengs or export the noce aer the search.
Reset the Sengs Click Reset to reset search condions.
Export Search Results Click Export to export the search results to your PC.
Search Noce
Steps
1. On the Video Intercom page, click Access Control → Video Intercom → Noce to
enter the page.
2. Set the search condions.
Informaon Type
Video Intercom Face Recognion Door Staon User Manual
86
You can set the informaon type as all, adversing Informaon, property
informaon, alarm informaon or noce informaon according to your needs.
Time
Set the start me and end me of a me period to search the logs.
3. Click Save.
4. Oponal: You can reset the sengs or export the noce aer the search.
Reset the Sengs Click Reset to reset all the congured search condions.
Export Search
Results
Click Export to export the noces to your PC.
10.8.3 Upload Arming Informaon
Steps
1. On the upper-right corner of menu page of the client soware, click
→ Tool
→ Device Arming Control to enter the sengs page.
2. Slide the slider to set the arming state of the device.
Cauon
●
When the device is added to the client soware, the client soware will
automacally establish an arming connecon, and the device is automacally in
the arming state.
●
Only support 1-channel arming connecon. If the device is added to client
soware A and the automac arming is successful, the arming connecon
cannot be established if you add device to client soware B at this me. The
alarm informaon will only be uploaded to client soware A.
Note
●
Aer the arming seng, when an alarm occurs, the alarm informaon can be
automacally uploaded to the client soware.
●
Aer the arming seng, you can view alarm records in the alarm events page.
●
When adding device to the client soware, the device will automacally enter
arming state by default.
3. Oponal: Click Arm All or Disarm All to arm or disarm devices.
Video Intercom Face Recognion Door Staon User Manual
87
A. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access
control and video intercom devices.
Figure A-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port
commands.
Note that the command list contains all commonly used serial ports
commands for all Hikvision access control and video intercom devices.
Figure A-2 Device Command
Video Intercom Face Recognion Door Staon User Manual
88
UD27981B-A
