2-IN-1 FAN-FORCED
HEATER
FOR MODEL:
1PHF9
Before using your 2-in-1 fan-forced heater
please read this manual carefully and keep
it for future reference, along with your receipt.
USER MANUAL
IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
1
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances,basic precautions should always be followed to
reduce the risk of fire,electric shock,and injury to persons,including the following:
Do not operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner. Discard heater or return heater to authorized
service facility for examination, electrical or mechanical adjustment, or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped over.
Always plug heaters directly into a wall outlet/receptacle. Never use
with an extension cord or relocatable power tap (outlet/power strip).
OFF
CAUTION:
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
A
B
C
C
Power and Setting Control
Power Indicator Light
Thermostat Control
18. Don't leave the heater on unattended.
19. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked.
SAVE THESE INSTRUCTIONS.
OPERATION INSTRUCTION
MODE SETTING
• Before using the heater, make sure that it is on a flat and stable surface. Damage
may occur if it is placed in an incline or decline.
• Avoid overloading your circuit by not using other high wattage appliances in the
same outlet. At 1500 Watts, this units draws 12.5Amps
• To start heater operation, turn Thermostat Control clockwise to the highest
setting.
2
L
M
H
L
M
in the
NOTE: It is normal for the heater to cycle ON and OFF as it maintains the preset
temperature. To prevent the unit from cycling, raise the temperature setting.
Thermal cut-off: This heater includes a thermal cut-off that shuts the heater off if it
overheats due to abnormal conditions. If this occurs, turn the heater off, unplug it,
inspect and remove any objects on or adjacent to the heater. Allow it to cool for a
few minutes, and then plug it back in and resume normal operation.
This is not a defect！
Tip over switch:This heater includes a safety tip over switch, which will shut the
heater off in case it is tipped over. If at any time, the heater does tip over, please put
the heater back in the upright position. The heater will resume its normal operation.
• Turn the thermostat control clockwise to the highest position to start heater.
Allow heater to operate and warm up the room.
• When the desired temperature/comfort level is reached, lower the temperature
setting by turning the Thermostat Control counter-clockwise until the heater
stops operating.
• The thermostat will automatically maintain the pre-set temperature level by
turning the heat ON and OFF.
THERMOSTAT CONTROL
SAFETY FEATURE
• Turn the power and setting switch to your desired heat settings:
• The power light will remain lit during operation.
3
For L 600W
For M 900W
For H 1500W
Model No.
Voltage:
Current:
Power.
Tolerances on all
specifications:
HF-1003
120V 60HZ
Maximum continuous draw:12.5 Amps
Approximately +5%
PLEASE OPERATE AS FOLLOWS.
CARE AND MAINTENANCE
power and setting
control
4
L=600W M=900W H=1500W
AND
1PHF9
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
Distributed by:
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
Specification and performance data is subject to change without notice.
Printed in China
PA/User_1PHF9/06102019
