2-IN-1 FAN-FORCED
HEATER
FOR MODEL:
1PHM11
Before using your 2-in-1 fan-forced heater
please read this manual carefully and keep
it for future reference, along with your receipt.
USER MANUAL
When using electrical appliances,basic precautions should always be followed to
reduce the risk of fire,electric shock,and injury to persons,including the following:
1. Read all instructions before using heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surface. If provided, always use handles when moving this heater. Keep
combustible materials such as furniture, pillows, bedding, papers, clothes and
curtains at least 3 feet (0.9m) from the front of the heater and keep them away
from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
4. Always unplug the heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Discard heater or
return heater to authorized service facility for examination, electrical or
mechanical adjustment, or repair.
6. Do not use the heater outdoors.
7. This heater is not intended for use in bathroom, laundry areas and similar moist
indoor locations. Never locate heater where it may fall into a bathtub or other
water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
9.
CAUTION:
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of shock, this plug is intended to fit only one way in a
polarized outlet. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. DO NOT attempt to defeat this
safety feature. To do so could result in an electric shock hazard.
10. This heater draws 12.5 amps during operation. To prevent overloading a
circuit, do not plug the heater into a circuit that already has other appliances
working.
11.
CAUTION:
It is normal for the plug to feel warm to the touch; however, a loose
fit between the AC outlet (receptacle) and plug may cause overheating and
distortion of the plug. Contact a qualified electrician to replace loose or worn
outlet.
1
IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
2
12. To disconnect the heater, first turn controls to off, then remove plug from
outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes or exhaust in any manner.
Do not use on soft surface, like a bed, where openings may become blocked.
15. A heater has hot and arcing or sparking parts inside. Do not use it in the areas
where gasoline, paint, or flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to
persons.
17.
CAUTION:
Always plug heaters directly into a wall outlet/receptacle. Never
use with an extension cord or reloadable power tap (outlet/power strip).
18. The output of this heater may vary and its temperature may become intense
enough to burn exposed skin. Use of this heater is not recommended for
persons with reduced sensitivity to heat or an inability to react to avoid burns.
19. Disposal of oil contained within should be in accordance with applicable
regional, national, and local laws and regulations.
20.
In order to avoid overheating, do not cover the heater.
21.
CAUTION:
to prevent electric shock, match wide blade of plug to wide slot
and fully insert.
22.
“SAVE THESE INSTRUCTIONS”
3
OPERATING INSTRUCTIONS
● Check before turning on the machine
1. Check if the power wire is under good condition.
2. The product adopts 120V 60Hz AC power supply, before use, please confirm if the rated current of
the power socket meets the local requirements with safe grounding device, otherwise, please
replace it with the qualified socket.
● Put the machine on the flat place
Uneven place may possibly cause the turnover switch at abnormal position, then the heater
can’t work after turning on, therefore, please put the heater on the flat place, at least the surface
below the base of the heater must be flat.
● Power Switch Knob
Turn the Power selection knob to select between 4 functions: (Heat) 900W LOW, (Heat) 1500W HIGH,
(Fan) LOW, (Fan) HIGH.
● Turn off the Heater
A. Turn the Power Switch Knob to OFF position.
B. Remove the power plug, store the heater after the entire machine has become cool.
● Safety Protection
1.Overheat protection:This heater includes an Overheat Protection System that shuts the unit off if it
overheats due to abnormal conditions. If this occurs turn the heater “OFF”, unplug it, and inspect and
remove any objects on or adjacent to the heater. Allow it to cool for a few minutes, plug it back in,
and resume normal operation.
2.Inversion protection: When the whole heater is inverted, the safety system will
automatically cut off the power, and return to the work state before inversion after
the body is placed upright.
Pilot light
Power selection knob
Safty grill
OFF
（Fan）LOW
（Fan）HIGH
（Heat）LOW
（Heat)HIGH
DO NOT COVER
Safety Grill
4
ADDITIONAL FEATURES
This heater has additional features:
• Convenient Carry Handle – allows for easy transport from room to room.
TROUBLESHOOTING
If your heater fails to operate, please follow these instructions:
• Ensure that your circuit breaker or fuse is working properly.
• Be sure the heater is plugged in and that the electrical outlet is working properly.
• Check for any obstruction. If you find any obstruction, turn the heater “OFF”. Unplug
the heater and wait a few minutes for it to cool down. Carefully remove the
obstruction. Plug the heater in and turn it on again by referring to the OPERATING
INSTRUCTIONS.
NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HEATER, PLEASE SEE THE WARRANTY
INFORMATION FOR INSTRUCTIONS. PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE
HEATER YOURSELF. DOING SO MAY VOID THE WARRANTY AND COULD CAUSE DAMAGE OR
PERSONAL INJURY. IF THE PROBLEM STILL PERSISTS, PLEASE CONTACT US BY REFERRING TO
THE SERVICE & SUPPORT INFORMATION
ON THE FOLLOWING PAGE.
CLEANING AND STORAGE
It is recommended that the heater be cleaned at least one time during the operating season in
order to provide the optimum level of performance. ALWAYS TURN THE POWER SWITCH OFF
AND UNPLUG THE HEATER BEFORE CLEANING. Be sure to save the box for off-season storage.
• Turn the heater “OFF”, unplug it and wait for the heater to cool down.
• Use a dry cloth to clean only external surfaces of the heater.
• Do not use any cleaning agents or detergents.
• Never immerse the heater in water.
• Pack the heater in the original carton and store it in a cool and dry place.
SPECIFICATIONS
Model No.: 1PHM11
Voltage: 120V, 60Hz
Current: Maximum continuous draw: 12.5 Amps.
Output: 5200 BTUs
Power: LO = 900 Watts, HI = 1500 Watts
Tolerances on all specifications: Not exceeded than 105%.
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
Distributed by:
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
Specification and performance data is subject to change without notice.
Printed in China
PA/User_1PHM11/05102019
