SET UP GUIDE
MODEL: 308-1415v4
WIRELESS
TEMPERATURE STATION
Power Up
2
Outdoor Sensor
TX141-Bv4
AA
AA
1. Insert 2-AA batteries into your Outdoor Sensor.
2. Insert the 5 volt power cord into the outlet, then into your
Temperature Station. Optional: Insert 2-AA batteries for backup.
3. Once the Outdoor Sensor is reading to your station, place it
outside in a shaded location to protect from the sun’s heat.
Watch the sensor mounting video: bit.ly/th_sensor_mounting
AA
AA
Temperature Station
308-1415v4
Press the MODE button to select between full Weekday or Calendar
(Weekday, Month, Date) display.
Custom Date Display
Settings Menu
1. Hold the MODE button to enter the Settings Menu.
2. Use the + / - button to adjust, and MODE to confirm.
Settings Menu order:
• Language (English, Spanish, French)
• Beep ON/OFF
• 12/24 Hour Time
• Hour
• Minutes
• Year
• Month
• Date
• Fahrenheit/Celsius
Language: When Español or Francais is selected, the following instructions
and weekday will be presented in that language.
Weekday: Weekday sets automatically when Year, Month and Date are set.
3
4
Adjustable Backlight
• When operating with the power cord, the backlight is constant and
adjustable.
• Press the LIGHT button to change the backlight brightness (HI/LO/OFF)
• When operating on batteries alone, press the LIGHT button to activate the
backlight for 10 seconds.
MODE
Press to view full Weekday or Calendar display.
Hold to enter the Settings Menu.
+ (PLUS)
Press to view HI/LO Records.
When viewing HI/LO Records: Hold to delete a record.
Settings Menu: Press to increase value.
Hold to increase quickly.
- (MINUS)
Settings Menu: Press to decrease value.
Hold to decrease quickly.
Search for Sensor: Hold to search for outdoor sensor.
LIGHT Press to adjust backlight HI-LO-OFF.
The buttons are located on the front of your station.
Button Functions
5
HI/LO Temperature Records
The indoor and outdoor HI/LO temperature records will reset daily at
midnight. This provides a daily 24 hour HI/LO reading.
View: Press the + button to view HI and LO Records since midnight.
Reset: While viewing individual records, hold the + button to reset to current
temperatures.
Temperature Trend Arrows
Both the Indoor and Outdoor temperature have Trend Arrows to indicate
temperature changes (2°F / 1°C) over the past three hour period.
Temperature has risen over the past 3 hours.
Temperature has been steady over the past 3 hours.
Temperature has fallen over the past 3 hours.
6
Search for Outdoor Temperature
If you are seeing dashes for your outdoor readings, please try the
following steps:
1. Hold the (-) MINUS button to search for your outdoor sensor.
The Reception Indicator will begin to animate.
2. If after 3 minutes the sensor still isn’t connected, bring the sensor inside
next to the display and remove power from both the sensor and station.
3. Press any button on the station 20 times and leave the parts sit for a few
moments with the power o.
4. Install a new set of alkaline batteries into the sensor, then into your
station. For additional help visit: bit.ly/basic_restart
5. If your outdoor data is still not appearing after these steps, please
contact our support sta via the links on page 7.
Low Battery Indicator
Low Battery Indicator by Indoor Temperature, replace batteries in the
Station.
Low Battery Indicator by the Outdoor Temperature replace batteries in
the Outdoor Sensor.
7
Designed in La Crosse, Wisconsin • Made in China • Printed in China • DC 061424
If you require additional assistance, get in touch with our
friendly customer support team based in La Crosse, WI.
Self Help: bit.ly/308-1415v4_support
Online: bit.ly/contact_techsupport
Phone: 1.608.782.1610
Our knowledgable customer support team is available:
Mon-Fri 8am-6pm CST
We’re Here to Help
SCAN HERE
Additional Info
and Support
Stay in Touch!
• The Sensor Weather Shield is designed to protect your
outdoor sensor from rain and snow.
• This shield will oer limited protection from the sun’s heat.
• Optional purchase at: bit.ly/925-1418
Sensor Shield (not included)
Ask questions, watch set up videos, and provide feedback on our social media
outlets. Follow La Crosse Technology on Youtube, Facebook, Instagram, and
X (Twitter).
Specifications
308-1415v4
Temperature Range: 32°F to 122°F
(0°C to 50°C)
Power: 5-volt power adapter included
AC6#: GPU280500150WA00
Optional: 2-AA batteries sold separately
The plug on the power adapter is intended to serve as the
disconnect device, the socket-outlet shall be installed near
the equipment and shall be easily accessible.
Battery Life: Over 24 months
Dimensions:
3.24 in L x 2.16 in W x 5.98 in H
(8.23 cm L x 5.48 cm W x 15.19cm H)
TX141-Bv4
Outdoor Temperature Range: -40°F to 140°F
(-40°C to 60°C)
Transmission Range: 330 ft (100m) open air,
RF 433MHz
Power: 2-AA batteries sold separately
Battery Life: Over 24 months
Dimensions: 1.58 in L x 0.83 in W x 5.08” H
(3.99 cm L x 2.1 cm W x 12.99 cm H)
8
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Caution!
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed using electronic, mechanical or chemical
process without the written permission of the publisher. This booklet may contain errors or misprints. The information it contains is regularly checked
and corrections are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or their consequences. All
trademarks and patents are recognized. The manufacturer is not responsible for any radio or TV interference caused by unauthorized changes or
modifications to this equipment. Such changes or modifications could void the user authority to operate the equipment.
FCC Statement
Care & Maintenance
When batteries of dierent brand or type are used together, or new and old batteries are used together, some batteries may
be over-discharged due to a dierence of voltage or capacity. This can result in venting, leakage, and rupture and may cause
personal injury.
• Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
• Always purchase the correct size and grade of battery most suitable for the intended use.
• Always replace the whole set of batteries at one time, taking care not to mix old and new ones, or batteries of dierent
types.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure the batteries are installed correctly with regard to polarity (+ and -).
• Remove batteries from product during periods of non-use. Battery leakage can cause corrosion and damage to this item.
• Remove used batteries promptly.
• For recycling and disposal of batteries, and to protect the environment, please check the internet or your local phone
directory for local recycling centers and/or follow local government regulations.
Warranty & Patents
La Crosse Technology Ltd. provides a 1-year limited-time warranty on this product relating to manufacturing defects in
materials & workmanship. Per the Song-Beverly Act, in the state of California, the warranty on this item becomes effective on
the date of delivery. La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601
For Full Warranty Details, Visit: www.lacrossetechnology.com/pages/warranty
Patents: www.lacrossetechnology.com/pages/patents
9
