RECHARGEABLE FLEXIBLE FLOODLIGHT WITH
TRIPOD, 24W COB LED & 5W SMD LED, 2000LM, BUILT-
IN POWER BANK
MODEL NO: LED240
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
USE ONLY THE SUPPLIED USB CABLE FOR CONNECTING FLOODLIGHT TO THE POWER SUPPLY.
WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An RCCB (Residual Current
Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD (Residual Current Device) is
used with all electrical products, particularly portable equipment which is plugged into an electrical supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT).
The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
Inspect the USB cable and connector for wear and damage to ensure items are safe before connecting to a power supply. If worn or
damaged DO NOT use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire: ,
8 DO NOT attempt to open, disassemble, modify or service the battery.
8 DO NOT expose to temperatures above 60°C (140°F).
8 DO NOT crush, puncture, short external contacts or dispose of in fire or water.
1.3. GENERAL SAFETY
9 Ensure the floodlight is correctly charged before initial use.
8 DO NOT cover or block the lens during use.
8 DO NOT turn the floodlight on when it is being charged.
8 DO NOT shine directly into your, other person’s or animal’s eyes.
8 DO NOT allow children to use the floodlight.
8 DO NOT handle or move the floodlight whilst it is being charged.
8 DO NOT use the floodlight if you suspect that the battery or the spotlight casing is damaged.
8 DO NOT immerse the floodlight in water.
9 Use tripod on a stable surface.
9 Ensure the floodlight is allowed to cool before attempting any cleaning or storage.
9 When not in use, store the floodlight in a safe, dry, childproof location.
2. INTRODUCTION
Three super bright 8W COB LED panels produce up to 2000 lumens and a smaller 5W SMD LED spotlight produces 400 lumens. Folding LED
panels create a 360° spread of light or rotate and tilt to create a focused beam of light. Mounted on a 1.1m tripod for simple positioning of light
and hands-free operation. Built-in power bank with 5V⎓1A USB output for providing power on the go. Features a magnetic base and hook which
provide more mounting options. 3.7V 4Ah lithium-ion battery for extended battery life with a long run time of 4hr. Easy to read charge indicator
displays the current battery level during use and while charging. Charges via USB-C cable
3. SPECIFICATION
Model No: .................................................................LED240
Battery: .................................................3.7V Lithium-ion 4Ah
Charging Time: ..................................................................6hr
Colour Temperature: .....................................3000K & 6000K
IP Rating: .......................................................................IPX3
LED Type: ...........................................COB LED + SMD LED
Lumen Output: ........................................................... 2000lm
Weight: ........................................................................ 1.78kg
Operating Time: .......................Side(High/Low)/Top: (2/4) 8hr
Power: ................................................................... 24W + 5W
USB Output: ................................................................5V⎓1A
Refer to
instruction
manual
LED240 Issue:2 17/09/24
Original Language Version
© Jack Sealey Limited
Thebatteryttedtothislampisconsideredtobeaconsumableitem
and its ability to accept a charge will reduce over time. We will provide
warranty against mechanical and electrical defect for a period of one
year - this does not cover fair wear and tear. If the battery is not properly
chargedbeforerstuse,orregularlyconditioned,itscapacitywill
diminish. Under these circumstances we will not replace the battery
regardless of whether it is less than one year old.
Note:
Thelithiumbatterydoesnotsuerfrommemoryeectandoncefully
charged may be stored for up to six months without another charge.
4. OPERATION
WARNING! Ensure that you read, and fully understand the safety instructions
before use.
4.1. BATTERY CHARGING
NOTE: Before initial use, fully charge the unit. Direct the lens away from your eyes
before switching on.
4.1.1. Ensuretheoodlightisturnedobeforecharging.
4.1.2. Battery charge level is indicated by the charge % display.
4.1.3. When full charge (100%) has been reached, unplug the charger cable from the
power supply.
4.2. SPOTLIGHT (Lefthand button)
First press: On full
Second press: On half
Third press: Flash
Fourthpress:O
4.3. LED PANELS (Righthand button)
First press: On full
Second press: On half
Third press: On yellow full
Fourth press: On yellow half
Fifthpress:Onfull(white)Sixthpress:O
4.4. FIT TRIPOD TO FLOODLIGHT
4.4.1. Screwthreadontopoftripodintobaseofoodlight.
5. MAINTENANCE
5.1. Wipe down dirty surfaces with damp cloth. DO NOT use abrasive or caustic
cleaning materials.
5.2. Dispose of broken unit in accordance with local authority battery regulations.
8 DO NOT dispose of with regular refuse.
5.3. STORAGE
5.3.1. Store the charger in a safe, dry location.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All
tools, accessories and packaging should be sorted, taken to a recycling
centre and disposed of in a manner which is compatible with the
environment. When the product becomes completely unserviceable and
requires disposal, drain any fluids (if applicable) into approved containers
and dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE).
When the product is no longer required, it must be disposed of in an
environmentally protective way. Contact your local solid waste authority
for recycling information.
REGISTER YOUR
PURCHASE HERE
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack
Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are
registered with Valpak’s registered compliance scheme. Jack Sealey Ltd’s
Batteries Producer Registration Number (BPRN) is BPRN00705.
LED240 Issue:2 17/09/24
