ADWFI603
EN
Dishwasher / User Manual
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly
Thank you for choosing this product.
This User Manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
CONTENTS
1.SAFETY INSTRUCTIONS ................................................................................................ 1
1.1. General Safety Warnings ..............................................................................................1
1.2. Installation Warnings .....................................................................................................2
1.3. During Use.....................................................................................................................3
2.INSTALLATION ................................................................................................................. 6
2.1. Machine Positioning .....................................................................................................6
2.2. Water Connection ..........................................................................................................6
2.3. Water Inlet Hose ............................................................................................................6
2.4. Electrical Connection ....................................................................................................7
2.5. Fitting the Machine Undercounter .................................................................................7
3.TECHNICAL SPECIFICATIONS ....................................................................................... 8
3.1. General Appearance......................................................................................................8
3.2. Technical Specifications ................................................................................................8
4.BEFORE USING THE APPLIANCE ................................................................................. 9
4.1. Preparing your Dishwasher for first use .......................................................................9
4.2. Detergent Usege ...........................................................................................................9
4.3. Filling the Detergent ...................................................................................................... 9
4.4. Using Combined Detergents ......................................................................................... 9
4.5. Rinse-aid Usege ............................................................................................................ 9
46. Filling the Rinse-aid and Setting ..................................................................................... 9
5.LOADING YOUR DISHWASHER ....................................................................................11
5.1. Recommendations....................................................................................................... 11
5.2. Alternative Basket Loads .............................................................................................13
6.PROGRAMME TABLE .................................................................................................... 14
7.THE CONTROL PANEL .................................................................................................. 15
7.1.
Changing a Programme .............................................................................................16
7.2. Cancelling a Programme .............................................................................................16
7.3. Switching the Machine Off ...........................................................................................16
8.CLEANING AND MAINTENANCE ................................................................................. 18
8.1. Filters ...........................................................................................................................18
8.2. Spray Arms ..................................................................................................................18
9.TROUBLESHOOTING .................................................................................................... 20
8.3. Drain Pump ..................................................................................................................19
EN - 1
1. SAFETY INSTRUCTIONS
1. General Safety Warnings
• Read these instructions carefully before using your
appliance and keep this manual for future reference.
Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed. Do
not operate the machine if it appears damaged or if
the packaging has been opened.
• Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly
as they are recyclable. Use of recycled material
reduces raw material consumption and decreases
waste production.
This appliance can be used by children aged from
8 years and above, and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand hazards
involved. Children should not be allowed to play with
the appliance.
Remove packaging and keep it out of reach of
children.
Keep children away from detergents and rinse
aids.
There may be some residue left in the machine
after washing. Keep children away from the machine
when it is open.
EN - 2
2. Installation Warnings
• Choose a suitable and safe place to install your
machine.
• Only original spare parts should be used with the
machine.
Unplug the machine before installation.
Your machine must only be installed by an
authorised service agent. Installation by anyone other
than an authorised agent may cause your warranty to
be void.
Check that the indoor electrical fuse system is
connected in line with safety regulations.
All electrical connections must match the values on
the plate.
Ensure the machine does not stand on the
electrical supply cable.
Never use an extension cord or a multiple socket
connection.
The plug should be accessible after the machine is
installed.
• After installation, run your machine unloaded for the
first time.
The machine must not be plugged in during
positioning.
Always use the coated plug supplied with your
machine.
If the electrical cable is damaged, it should only
be replaced by a qualified electrician.
• Connect the hose directly to the water inlet tap. The
pressure supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If the
EN - 3
pressure exceeds 1 MPa, a pressure relief valve
must be fitted between the connection.
3. During Usage
• This machine is for domestic use only; do not use
• it for other purposes. Commercial use will void the
guarantee.
Do not stand, sit or place loads on the open door of
the dishwasher.
Only use detergents and rinse aids produced
specifically for dishwashers. Our company is not
responsible for any damage that may occur due to
misuse.
Do not drink water from the machine.
Due to the danger of explosion, do not place any
chemical dissolving agents into the machine’s washing
section.
• Check the heat-resistance of plastic items before
washing them in the machine.
Only put items in the machine which are suitable for
dishwashing, and take care not to overfill the baskets.
Do not open the door while the machine is in
operation, hot water may spill out. Safety devices
ensure the machine stops if the door is opened.
The machine door should not be left open. It may
cause accidents.
Place knives and other sharp objects in the cutlery
basket in a blade-down position.
For models with the automatic door-opening
system, when the EnergySave option is active, the
door will open at the end of a program. To prevent
damage to your dishwasher, do not attempt to close
EN - 4
• Some machine components and packaging consist of recyclable materials.
• Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. )
• The cardboard parts consist of recycled paper. They can be put into waste paper
containers for recycling.
• Material unsuitable for domestic waste must be disposed of at recycling centres.
• Contact a relevant recycling centre to obtain information about disposal of different
materials.
PACKAGING AND THE ENVIRONMENT
• Packaging materials protect your machine from damage that may occur during
transportation. The packaging materials are environmentally friendly as they are
recyclable. The use of recycled material reduces raw material consumption and
therefore decreases waste production.
the door for one minute after it has opened. For
effective drying, keep the door open for 30 minutes
after a programme has ended. Do not stand in front of
the door after the auto-open signal sounds.
In the case of a malfunction, repair should only
be performed by an authorised service company,
otherwise the warranty will be void.
Before repair
work, the machine should be
disconnected from the mains. Do not pull the cable to
unplug the machine. Switch of
f the water tap.
Operation at a low voltage will cause a decline in
performance levels.
For safety
, disconnect the plug once
a program has
finished.
T
o avoid an electric shock, do not unplug the
machine with wet hands.
Pull the plug to disconnect the machine from the
mains, never pull on the cord.
RECYCLING
EN - 5
CE Declaration of Conformity
We declare that our products meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
Disposal of your old machine
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead, it shall be handed over to
the applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the shop
where the product was purchased.
EN - 6
2. INSTALLATION
2.1. Machine positioning
When positioning the machine, place it in
an area where dishes can be easily loaded
and unloaded. Do not put the machine in an
area where the ambient temperature falls
below 0°C.
Read all warnings located on the packaging
before removing the packaging and
positioning the machine.
Place the machine close to a water tap
and drain. Take into consideration that the
connections will not be altered once the
machine is in position.
Do not hold the machine by its door or
panel.
Leave an adequate distance around the
machine to allow ease of movement when
cleaning.
Ensure the water inlet and outlet
hoses are not squeezed or trapped
and that the machine does not stand
WARNING: Use the new water inlet
hose supplied with your machine, do not
use an old machine’s hose.
WARNING: Run water through the
new hose before connecting.
WARNING: Connect the hose
directly to the water inlet tap. The pressure
supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If
the pressure exceeds 1 MPa, a pressure
relief valve must be fitted between the
connection.
WARNING: After the connections are
made, turn the tap on fully and check
for water leaks. Always turn off the
water inlet tap after a wash program has
finished.
An Aquastop water spout is available
with some models. Do not damage it
or allow it to become kinked or
twisted.
on the electrical cable while positioning.
Adjust the feet so the machine is level and
balanced. The machine should be placed
on flat ground otherwise it will be unstable
and the door of the machine will not close
properly.
2.2. Water connection
We recommend fitting a filter to your water
inlet supply in order to prevent damage to
your machine due to contamination (sand,
rust, etc.) from indoor plumbing. This will
also help prevent yellowing and deposit
formation after washing.
Note printing on the water inlet hose!
If models are marked with 25°, the water
temperature may be max. 25 °C (cold
water).
For all other models:
Cold water preferred; hot water max.
temperature 60 °C.
2.3. Water inlet hose
2.4. Drain Hose
Connect the water drain hose directly to
water drain hole or to the sink outlet spigot.
This connection should be minimum 50 cm
and maximum 110 cm from flor plane.
IMPORTANT: Items will not wash
properly if a drain hose longer than 4
m is used.
EN - 7
In the absence of earthing
installation, an authorised
electrician should carry out an
earthing installation. In the case of use
without earthing installed, we will not be
responsible for any loss of use that may
occur.
The plug on this appliance may
incorporate 13A fuse depending on
the target country. (For Example UK,
Saudi Arabia)
2.5. Electrical connection
WARNING: Your machine is set to
operate at 220-240 V. If the mains voltage
supply to your machine is 110 V, connect a
transformer of 110/220 V and 3000 W
between the electrical connection.
Connect the product to a
grounded outlet protected by a fuse
complying with the values in the
"Technical Specifications" table".
The earthed plug of the
machine must be connected
to an earthed outlet supplied by
suitable voltage and current.
EN - 8
3. TECHNICAL SPECIFICATIONS
3.2. Technical specifications
Capacity
15 place
settings
Dimensions
Height
Width
Depth
820-
870(mm)
598(mm)
570(mm
Net weight 38 kg
Operating
voltage /
frequency
220-240V
50 (Hz)
Total current 10(A)
Total power 1900(W)
Water supply
pressure
Maximum:
1 (Mpa)
Minimum:
0.03 (Mpa)
6
1
2
3
4
5
7
8
9
10
11
3.1. General appearance
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control panel
8. Detergent and rinse-aid dispenser
9. Cutlery basket
10. Upper basket track latch
11. Active Drying Unit: This system
provides better drying performance
your dishes.
12. Bras gicleur de la paroi supérieure:
Il apporte un meilleur lavage pour
les vaisselles au niveau du panier
supérieur.
ventilate
cher effica
12
ntilateur: Ce syst
efficacement vos
EN - 9
4. BEFORE USING
THE APPLIANCE
4.1. Preparing your
Dishwasher for first use
• Make sure the electricity and supply
water specifications match the values
indicated in the installation instructions
for the machine.
• Remove all packaging material inside
the machine.
• Fill the rinse aid compartment.
4.2. Detergent usage
Only use detergents specifically designed
for domestic dishwashers. Keep your
detergents in cool, dry places out of reach
of children.
Add the proper detergent for the selected
program to ensure the best performance.
The amount of detergent needed depends
on the cycle, load size, and soil level of
dishes.
Do not fill detergent into the detergent
compartment more than required; otherwise
you can see whitish streaks or bluish layers
on glass and dishes and may cause glass
corrosion. Continued use of too much
detergent may cause machine damage.
Using little detergent can result in
poor cleaning and you can see whitish
streaksin hard water. See the detergent
manufacturer’s instructions for a further
information.
4.3. Filling the detergent
Push the latch to open the dispenser and
pour in the detergent.
Close the lid and press it until it locks in
place. The dispenser should be refilled just
before the start of each programme. If the
dishes are heavily soiled, place additional
detergent in the pre-wash detergent
chamber.
DETERGENT
4.4. Using combined detergents
These products should be used according
to the manufacturer’s instructions.
Never put combined detergents into the
interior section or the cutlery basket.
Combined detergents contain not only
the detergent but also rinse-aid, salt
replacement substances and additional
components depending on the combination.
We recommend you do not use combined
detergents in short programmes.
Please use powder detergents in such
programmes.
If you encounter problems when using
combined detergents, please contact the
detergent manufacturer.
When you stop using combined detergents,
make sure that water hardness and rinse
aid settings are set to the correct level.
4.5. Rinse-aid usage
The rinse aid helps to dry the dishes without
streaks and stains. Rinse-aid is required for
stain-free utensils and clear glasses. The
rinse aid is automatically released during
the hot rinse phase. If rinse aid dosage
setting set too low, whitish stains remains
on dishes and dishes do not dry and
washed clean. If rinse aid dosage setting
set too height, you can see bluish layers on
glass and dishes.
4.6. Filling the rinse-aid and setting
To fill the rinse aid compartment, open
the rinse-aid compartment cap. Fill the
compartment with rinse aid to the MAX level
and then close the cap. Be careful not to
overfill the rinse aid compartment and wipe
up any spills.
In order to change the rinse aid level,
follow the below steps:
• Touch the programme button and hold
it down.
• Turn on the machine.
• Hold down the Programme button
until “rA” disappears. Rinse aid setting
follows water hardness setting.
• The machine will display the last setting.
• Change the level by touching the
programme button.
•
EN - 10
• Turn off the machine to save the setting.
The factory rinse aid level setting is “4”.
If the dishes are not drying properly or are
spotted, increase the level. If blue stains
form on your dishes, decrease the level.
Level Brightener Dose Indicator
1 Rinse-aid not
dispensed
r1 is shown on the
display
2 1 dose is
dispensed
r2 is shown on the
display
3 2 doses are
dispensed
r3 is shown on the
display.
4 3 doses are
dispensed
r4 is shown on the
display.
5 4 doses are
dispensed
r5 is shown on the
display.
EN - 11
WARNING: To avoid any possible
injuries, place long-handle and sharp-
pointed knives with their sharp points facing
down or horizontally on the baskets.
5. LOADING YOUR
DISHWASHER
For best results, follow these loading
guidelines.
Loading the household dishwasher up to
the capacity indicated by the manufacturer
will contribute to energy and water savings.
Manual pre-rinsing of tableware items leads
to increased water and energy
consumption and is not recommended
You can place cups, glasses, stemware,
small plates, bowls, etc. in upper basket.
Do not lean long glasses against one
another or they cannot remain steady and
may receive damage.
When placing long stem glasses and
goblets, lean them against the basket edge
or rack and not against other items.
Place all containers such as cups, glasses
and pots into the dishwasher with the
opening facing downwards otherwise water
can collect on items.
If there is cutlery basket in machine, you
are recommended to use the cutlery grid in
order to obtain the best result. Place all
large (pots, pans, lids, plates, bowls etc.)
and very dirty items in the lower rack.
Dishes and cutlery should not be placed
above each other.
WARNING: Take care not to obstruct
the rotation of spray arms.
WARNING: Make sure after loading
the dishes do not prevent opening the
detergent dispenser.
5.1. Recommendations
Remove any coarse residue on dishes
before placing the dishes in the machine.
Start the machine with full load.
Do not overload the drawers or place
dishes in the wrong basket.
Height Adjustable Rack (peg type)
The height adjustable racks enable
glasses and cups to be placed on or under
the racks. The racks can be adjusted to 2
different heights. Cutlery and utensils can
also be placed on the racks horizontally.
1
2
EN - 12
Lower Basket
Two Folding Racks (12 pc)
The folding racks on the lower basket allow
for the placement of larger items, such as
pots and pans. Each section can be folded
separately. They can either be folded down
or raised up, as shown in the images below.
a
b
1
2
Upper Basket
Height adjustment
Turn the Rail Stop Clips, at the ends of the
rails, to the sides to open them (as shown in
the image below), then pull out and remove
the basket. Change the position of the
wheels, then reinstall the basket to the rail,
making sure to close the Rail Stop Clips.
When the upper basket is in the higher
position, large items such as pans can be
placed on the lower basket.
Spoon rack
It allows your long-stemmed goblets to be
washed safely as well as it is a part to
provide your spoons and forks put easily to
spoon rack. Do not lean your long-stemmed
goblets and glasses against each other but
spoon rack, thus during the washing it is
ensured your glasses and goblets stay in
place and a safe washing by preventing
contact each other.
There are 4 different positions for your spoon
rack.
According to the status of your goblets and glasses, you can set your spoon rack to
the positions number 1 and 2.
Use it for your spoons and forks
while it was in position 1.
If you do not want to use spoon rack, you can bring it to the positions 3 or 4, so that
you can form larger-volume areas in the upper basket b.
a
b
a
EN - 13
EN - 14
5.2. Alternative basket loads
Lower basket
Upper basket
Unsuitable items for dishwashing
• Cigarette ashes, candle leftovers,
polish, paint, chemical substances, iron-
alloy materials.
•
•
Forks, spoons and knives with wooden,
bone, ivory or nacrecoated handles;
glued items, items soiled with abrasive,
acidic or base chemicals.
Temperature-sensitive plastics, copper
or tincoated containers.
• Aluminium and silver objects.
• Some delicate glasses, ornamental
printed porcelains; some crystal items,
adhered cutlery, lead crystal glasses,
cutting boards, synthetic fibred items.
• Absorbent items such as sponges or
kitchen rugs.
IMPORTANT: In future, purchase
dishwasher-proof kitchenware.
Important Note for Test Laboratories
For detailed information required for tests
according to EN normatives and a softcopy
of the manual, please send the model name
and serial number to the following address:
Incorrect Loads
Incorrect loading can cause poor washing
and drying performance. Please follow the
manufacturer's recommendations for a good
performans result.
Un chargement incorrect peut entraîner
de mauvaises performances de lavage et
de séchage. Veuillez suivre
les recommandations du fabricant pour
obtenir un bon résultat. Note importante
pour les laboratoires de test.
EN - 15
6. PROGRAMME TABLE
Programme
Duration
(min)
Description
P1 Eco 155
Standard program for normally soiled daily using dishes with reduced
energy and water consumptions.
P2
Intensive 65°C 122 Suitable for heavily soiled dishes
Auto 99 - 122 Auto program for heavily soiled dishes.
P3 Hygiene 70°C 127 Suitable for heavily soiled dishes requiring hygienic washing
P4 Super 50’ 50 Suitable for normally soiled daily dishes with faster program.
P5
Easy Care
60°C
94 Suitable for normally soiled daily dishes.
P6 Delicate 40°C 74 Suitable for lightly soiled delicate dishes.
P7 Quick 30’ 30 Suitable for lightly soiled dishes and quick wash.
P8 Mini 14’ 14
Fastest program for lightly soiled and recently used dishes and suitable
for 4 place settings.
NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT
OF DISHES, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL
FUNCTIONS.
• Only use powder detergent for short programmes.
• Short programmes do not include drying step.
• To assist drying, we recommend slightly opening the door after a cycle is complete.
EN - 16
7. THE CONTROL PANEL
(1) (2) (3) (4) (5)
(7)
(8) (6)
1. On/Off touch button
2. Programme touch button
3. Display
4. Delay touch button
5. Extra Rinse touch button
6. Half Load touch button
7. Extra Dry touch button
8. Rinse Aid lack warning indicator
1. On/Off Touch Button
Turn the machine on by pressing On/Off
button. When machine is on, "--" will be
shown on the Display (3).
2. Programme Touch Button
Select a suitable programme for your
dishes by touching Programme button. The
programme will start automatically when the
door is closed.
3. Display
The Display shows the number and total
time of the selected programme alternately
and the remaining time during operation.
4. Delay Touch Button
Press the Delay Start touch button to delay
the start time of a programme for 1 hour up
to 19 hours. Pressing once will delay the
start time for 1 hour, and continuing to press
the button will increase the delay duration.
Press the Delay button to change or cancel
the delayed start. If you turn off the machine
after activating the delay time, the delayed
time is cancelled.
NOTE: Press and hold the Delay
touch button to change the delayed start
time faster. The rate of change in time is
proportional to the how long the button is
pressed and held for. When the Delay Start
touch button is pressed for a long period of
time, the counter will stop at “h:00”.
Additional functions can also be selected.
5. Extra Rinse touch button
If Extra Rinse option is selected, washing-
rinsing steps will be added into the
selected program, so you can ensure that
your dishes will be extracted cleaner and
glosser.
6. Half Load Touch Button
Press the Half Load button to select the
area of the dishwasher that contains the
dishes to be washed. You can select both
baskets, the upper basket only, or the lower
basket only. Press the button until the light
corresponding to the basket contaning the
dishes to be washed illuminates.
7. Extra Dry Touch Button
Press the Extra Dry touch button to add
extra drying steps to a programme in order
to obtain drier dishes. This option increases
water temperature of the final rinse step
and duration of the drying step.
NOTE: Each time the machine is
turned off and on, the Eco programme will
be set as default. Options chosen before
will be cancelled.
NOTE:If an option is not compatible
with the selected program, a buzzer
sounds.
NOTE: If an extra feature has been
used on the most recent wash programme,
this feature will remain active on the next
selected programme. To cancel this feature
on the newly selected wash programme,
press the feature button until the light on
the button switches off.
EN - 17
8. Rinse Aid lack warning indicator
When there is insufficient rinse aid, the
Rinse Aid Lack Warning Indicator will
illuminate to indicate the rinse aid chamber
needs filling.
NOTE: If you decide not to start the
selected programme, please see the
"Changing a Programme" and "Cancelling a
Programme" sections.
7.1 Changing a Programme
Follow the steps below to change a
programme while in operation.
1. Open the door and press the
Programme touch button (2) to select a
new programme. If the door is opened
during operation, the time remaining of
the selected programme will show on
the display (3).
2. After closing the door, the newly
selected programme will resume the
course of the old programme.
NOTE: Open the door slightly at first
to stop a wash programme before it is
complete in order to avoid water spillage.
7.2. Cancelling a Programme
Follow the steps below to cancel a
programme while in operation or in standby
mode.
1. Open the door of the machine, the most
recently selected programme will be shown
on the display.
2. Press and hold the Programme touch
button (2) for 3 seconds. At the end of 3
seconds, '1' will show on the Display (3).
3. The water discharge process will start
after the door of the machine is closed
and will continue for 30 seconds. When
the programme is cancelled, a buzzer will
sound 5 times.
NOTE: When the door is opened after
the selected wash programme is complete,
a buzzer will sound and ‘0’ will be shown on
the Display (3).
(1) (2) (3) (4) (5)
(7)
(8)
(9) (6)
7.3. Switching the Machine Off
When the selected wash programme is
complete, a buzzer will sound 5 times. You
can then turn your machine off by using the
On/Off touch button (1).
NOTE: Do not open the door before a
programme is complete.
NOTE: Leave the door of your
machine slightly open at the end of a wash
programme to speed up drying.
NOTE: If the door of the machine
is opened or the power is cut off while a
programme is in operation, the programme
will continue when the door is closed or the
power returns.
NOTE: If the power is cut or the
machine door is opened during the drying
process, the programme will terminate.
Your machine will now be ready for a new
programme selection.
EN - 18
Buzzer Sound Control
To change the buzzer sound level, follow
the below steps:
1. Open the door and press Extra Dry /
Rinse (5,7) and Half Load (6) touch buttons
simultaneously for 3 seconds.
2. When sound setting is recognized,
buzzer gives a long sound and machine will
display last set level, from “S0” to “S3”.
3. To decrease sound level press Extra
Dry / Rinse touch button (5,7). To increase
sound level, press Half Load touch button
(6).
4. To save the selected sound level, turn off
the machine.
’’S0’’ level means all voices are off. Factory
setting is “S3”.
Save Power Mode
To activate or deactivate save power mode,
follow the below steps:
1. Open the door and press Delay (4) and
Extra Dry / Rinse (5,7) touch buttons
simultaneously for 3 seconds.
2. After 3 seconds, the machine will display
last Setting, “IL1” or “IL0”.
3. When Save Power Mode is activated,
“IL1” will be displayed. On this mode,
interior lights will turn off 4 minutes after the
door is opened, and the machine will turn
off after 15 minutes of no activity in order to
save energy.
4. When Save Power Mode is deactivated
“IL0” will be displayed. If Save Power Mode
is deactive, interior lights will be on as long
as the door is open, and the machine will
always be on unless it is turned off by user.
5. To save the selected setting, turn off the
machine.
In factory setting, Save Power Mode is
active.
Natural Ion Tech (Model Dependent)
This function provides extra hygiene to the
machine thanks to Ion Technology. Natural
Ion Tech function is activated by pressing
Half Load (6) touch button for 3 seconds.
Meanwhile display counts from 1 to 3. At
the end of 3 seconds, “Ion” will be displayed
which indicates Natural Ion Tech function is
activated. The button is released after “Ion”
is displayed. If no intervention by user, 24
hours after activation of Natural Ion Tech
function, it is automatically cancelled.
Note: If machine is turned off, Natural Ion
Tech function is cancelled.
Note: Natural Ion Tech function does not
work with any program.
Note: If Natural Ion Tech function is active,
Natural Ion Tech led lights up like dimming
during door is open.
Infoled 2.1 (Model Dependent)
LED Indicator State of the Machine
Red, continuous
The machine is running a
program.
Red, flashing A program is cancelled.
Red, flashing
rapidly
The machine has a fault. Refer
to section "Automatic fault
warnings and what to do".
Green, continuous A program is finished.
EN - 19
8. CLEANING AND
MAINTENANCE
Cleaning your dishwasher is important to
maintain the machine’s service life
Make sure that the water softening setting
(If available) is done correctly and correct
amount of detergent is used to prevent
limescale accumulation. Refill the salt
compartment when the salt sensor light
comes on.
Oil and limescale may build up in your
Dishwasher over time. If this occurs:
• Fill the detergent compartment
but do not load any dishes. Select
a programme which runs at high
temperature and run the Dishwasher
empty. If this does not clean your
Dishwasher sufficiently, use a
cleaning agent designed for use with
dishwashers.
• To extend the life of your dishwasher,
clean the appliance regularly on each
month
• Wipe the door seals regularly with a
damp cloth to remove any accumulated
residue or foreign objects.
8.1. Filters
Clean the filters and spray arms at least
once a week. If any food waste remains
or foreign objects on the coarse and
fine filters, remove them and clean them
thoroughly with water.
a)
Micro Filter b) Coarse Filter
c) Metal Filter
To remove and clean the filter combination,
turn it counter clockwise and remove it by
lifting it upwards (1).Pull the coarse filter out
of the micro filter (2).Then pull and remove
the metal filter (3).Rinse the filter with lots of
water until it is free of residue. Reassemble
the filters. Replace the filter insert, and
rotate it clockwise (4).
• Never use your dishwasher without a
filter.
• Incorrect fitting of the filter will reduce
the washing effectiveness.
• Clean filters are necessary for proper
running of the machine.
8.2. Spray arms
Make sure that the spray holes are not
clogged and that no food waste or foreign
object is stuck to the spray arms. If there is
any clogging,remove the spray arms and
clean them under water. To remove the
upper spray arm undo the nut holding it in
position by turning it clockwise and pulling
it downwards. Make sure that the nut is
properly tightened when refitting the upper
spray arm.
3 4
1 2
a
c
b
EN - 20
8.3 Drain Pump
Large food residues or foreign objects
which were not captured by the filters may
block the waste water pump. The rinsing
water will then be above the filter.
Warning Risk of cuts!
When cleaning the waste water pump,
ensure that you do not injure yourself
on pieces of broken glass or pointed
implements.
In this case:
1. First always disconnect the appliance
from the power supply.
2. Take out baskets.
3. Remove the filters.
4. Scoop out water, use a sponge if
required.
5.Check the area and remove any foreign
objects.
6. Install filters.
7. Re-insert baskets.
EN - 21
9. TROUBLESHOOTING
FAULT POSSIBLE CAUSE TROUBLESHOOTING
The programme does
not start.
Your Dishwasher is not plugged in. Plug your Dishwasher in.
Your Dishwasher is not switched on.
Switch your Dishwasher on by pressing the
On/Off button.
Fuse blown. Check your indoor fuses.
Water inlet tap is closed. Turn on the water inlet tap.
Your Dishwasher door is open. Close the Dishwasher door.
Water inlet hose and machine filters
are clogged.
Check the water inlet hose and machine
filters and make sure they are not clogged.
Water remains inside
the machine.
Water drain hose is clogged or
twisted.
Check the drain hose, then either clean or
untwist it.
The filters are clogged. Clean the filters.
The programme is not finished yet. Wait until the programme is finished.
Machine stops during
washing.
Power failure. Check mains power.
Water inlet failure. Check water tap.
Shaking and hitting
noises are heard during
a wash operation.
The spray arm is hitting the dishes in
the lower basket.
Move or remove items blocking the spray
arm.
Partial food wastes
remain on the dishes.
Dishes placed incorrectly, sprayed
water not reaching affected dishes.
Do not overload baskets.
Dishes leaning each another.
Place dishes as instructed in the section on
loading your dishwasher.
Not enough detergent used.
Use the correct amount of detergent, as
instructed in the programme table.
Wrong wash programme selected.
Use the information in the programme table
to select the most appropriate programme.
Spray arms clogged with food waste.
Clean the holes in the spray arms with thin
objects.
Filters or water drain pump clogged
or filter misplaced.
Check the drain hose and filters are
correctly fitted.
EN - 22
FAULT POSSIBLE CAUSE TROUBLESHOOTING
Whitish stains remains
on dishes.
Not enough detergent used.
Use the correct amount of detergent, as
instructed in the programme table.
Rinse aid dosage and/or water
softener setting set too low.
Increase rinse aid and/or water softener
level.
High water hardness level. Increase water softerner level and add salt.
Salt compartment cap not closed
properly.
Check that the salt compartment cap is
closed properly.
Dishes do not dry.
Drying option is not selected. Select a programme with a drying option.
Rinse aid dosage set too low. Increase rinse aid dosage setting.
Rust stains form on the
dishes.
Stainless-steel quality of the dishes
is insufficient.
Use only dishwasher-proof sets.
High level of salt in wash water.
Adjust the water hardness level using water
hardness table.
Salt compartment cap not closed
properly.
Check that the salt compartment cap is
closed properly.
Too much salt spilled in the
Dishwasher while filling it with salt.
Use funnel while filling salt to the
compartment to avoid spillage.
A poor mains grounding. Consult a qualified electrician immediately.
Detergent remains in the
detergent compartment.
Detergent was added when the
detergent compartment was wet.
Make sure detergent compartment is dry
before use.
AUTOMATIC FAULT WARNINGS AND WHAT TO DO
TROUBLE
CODE
POSSIBLE FAULT WHAT TO DO
FF
Water inlet system failure
Make sure the water inlet tap is open and water is flowing.
Separate the inlet hose from the tap and clean the filter of
the hose.
Contact for service if the error continues.
F5
Pressure system failure
Contact for service.
F3
Continuous water input
Close the tap and contact for service.
F2
Inability to discharge water
Water discharge hose and filters may be clogged.
Cancel the program.
If the error continues, contact for service.
F8 Heater error Contact for service.
F1 Overflow
Unplug the machine and close the tap.
Contact for service.
FE Faulty electronic card Contact for service.
F7 Overheating Contact for service.
F9 Diverter position error Contact for service.
F6 Faulty heater sensor Contact for service.
HI High voltage failure Contact for service.
LO Low voltage failure Contact for service.
EN - 23
Warranty Card
Worldwide Appliances Pty Limited
A.B.N. 45868077422
Distributed by Eurolinx pty Ltd
Oce:
48-50 Moore Street, Leichhardt N.S.W 2040
Post:
Locked Bag 3000, Annandale, N.S.W 2038
P: 1300 694 583
WARRANTY REGISTRATION
Your ongoing satisfaction with your artusi
product is important to us. We ask that you
complete the enclosed Warranty Registration
Card and return it to us so that we have a record
of the artusi product purchased by you.
PRIVACY
Worldwide Appliances respects your
privacy and is committed to handling your
personal information in accordance with the
National Privacy Principles and the Privacy
Act 1988 (Cth). A copy of the Worldwide
Appliances Privacy Policy is available at
www.artusi.com.au. Worldwide Appliances will
not disclose any personal information set out
in the Warranty Registration Card (“Personal
Information”) without your consent unless
required by:
1. law;
2. any Worldwide Appliances related company;
3. any service provider which provide services
to artusi or assist artusi in providing services
(including repair and warranty services) to
customers. Our purpose in collecting the
Personal Information is
to keep a record of the artusi product purchased
by you, in order to provide a better warranty
service to you in the unlikely event that there is
a problem with your artusi product. Worldwide
Appliances may contact you at any one or more
of the address, email address or telephone
numbers set out in the Warranty Registration
Card. Please contact artusi on 1300 694
583 should you not wish to be contacted by
Worldwide Appliances.
WARRANTY
1. Warranty
Worldwide Appliances warrants that each artusi
product will remain, for a period of either 12
months or 24 months of warranty. All Warranties
are valid from the original date of purchase, And
warranty claims must be accompanied by the
proof of purchase.
24 months warranty products:
All Built-in Appliances – Limited to Ovens,
Gas, Induction and Electric Cooktops, and All
Rangehoods. Freestanding Cookers - Gas and
Electric Models (900mm Width).
artusi.com.au
Dishwashers - Freestanding, Fully Integrated,
Semi Integrated and built-in. All Wine coolers. All
Dryers. Freestanding Cookers - Gas and Electric
Models in 50cm, 54cm and 60cm Widths
Portable Appliances* – Benchtop Models and
Portable Gas Models
2. What is not Covered by the Warranty.
The Warranty does not apply if an artusi product
is defective by a factor other than a defect arising
in the manufacture of the artusi product, including
but not limited to:
(a) damage through misuse (including failure
to maintain, service or use with proper care),
neglect, accident or ordinary wear and tear
(including deterioration of parts and accessories
and glass breakage);
(b) use for purpose for which the artusi product
was not sold or designed;
(c) use or installation which is not in accordance
with any specied instructions for use or
installation;
(d) use or operation after a defect has occurred or
been discovered;
(e) damage through freight, transportation or
handling in transit (other than when Worldwide
Appliances is responsible);
(f) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental
factors outside the control or Worldwide
Appliances;
(g) repair, modication or tampering by the
purchaser or any person other than Worldwide
Appliances, an employee of Worldwide
Appliances or an authorised artusi service
contractor*;
(h) use of parts, components or accessories
which have not been supplied or specically
approved by artusi.
(i) damage to surface coatings caused by cleaning
or maintenance using products not recommended
in the artusi product handbook provided to the
purchaser upon purchase of the artusi product;
(j) damage to the base of an electric oven due to
items having been placed on the base of the oven
cavity or covering the base, such as aluminium
foil (this impedes the transfer of heat from the
element to the oven cavity and can result in
irreparable damage); or
(k) damages, dents or other cosmetic
imperfections not aecting the performance of the
artusi in respect of an artusi product purchased
as a “factory second” or from display
The Warranty does not extend to light globes
used in artusi products.
3. Domestic Use
Each artusi product is made for domestic use.
This Warranty may not extend to artusi products
used for commercial purposes.
Continued over...
4. Time for Claim under the Warranty
You must make any claim under this Warranty
within twenty eight (28) days after the occurrence
of an event which gives rise to a claim pursuant
to the Warranty, by booking a service call on the
telephone number below.
5. Proof of Purchase
Customers must retain proof of purchase in order
to be eligible to make a warranty claim in respect
of an artusi product.
6. Claiming under the Warranty
Customers will bear the cost of claiming under
this Warranty unless Worldwide Appliances
determines the expenses are reasonable, in which
case the customer must claim those expenses
by providing written evidence of each expense
to Worldwide Appliances at the address on the
Warranty Registration Card.
7. Statutory Rights
(a) These terms and conditions do not aect your
statutory rights.
(b) The limitations on the Warranty set out in this
document do not exclude or limit the application
of the consumer guarantees set out in the Act or
any other equivalent or corresponding legislation
in the relevant jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction;
or
(ii) cause any part of the Warranty to be void.
(c) Worldwide Appliances excludes indirect or
consequential loss of any kind (including, without
limitation, loss of use of the artusi product) and
(other than expressly provided for in these terms
and conditions) subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of Worldwide Appliances to you
for a breach of any express or non-excludable
implied term, condition or warranty is limited at
the option of Worldwide Appliances to:
(i) replacing or repairing the defective part of the
artusi product;
(ii) paying the cost of replacing or repairing the
defective part of the artusi product;
(iii) replacing the artusi product; or
(iv) paying the cost of replacing the artusi
product.
(e) Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
8. Defects
Any part of an artusi product deemed to be
defective and replaced by Worldwide Appliances
is the property of Worldwide Appliances.
Worldwide Appliances reserves the right to
inspect and test artusi products in order to
determine the extent of any defect and the
validity of a claim under the Warranty.
All warranty service calls must be booked via
the customer care department. The team can
be contacted on 1 300 85 64 11 option 1 or
customercare@eurolinx.com.au
01082016
Warranty Card continued
artusi.com.au
2
Please complete and send to ARTUSI at: REPLY PAID 83617
LEICHHARDT NSW 2040
Last Name: First Name:
Address:
State: Postcode: Email:
Home Phone: Mobile:
Purchase Date: / /
(Please attach proof of purchase to validate warranty)
MODEL NUMBER
SERIAL NUMBER
(if you cannot locate the serial number please call ARTUSI on 1300 856 411)
1
2
3
4
WARRANTY REGISTRATION CARD
01052016
01082016
Warranty Card tear off
52231106 R35
