Aboutthismanual

Thisusermanualdescribesmultipleproducts.Someoftheinstructionsmaynotberelevantforyourproduct.

AXISM30Series

Productoverview

SDcardslot(microSD)

StatusLED

RJ45connector

Controlbutton

AXISM30Series

Howtoaccesstheproduct

AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproductsonthenetworkandassigning

themIPaddressesinWindows®.Bothapplicationsarefreeandcanbedownloadedfromaxis.com/support

Theproductcanbeusedwiththefollowingbrowsers:

•Chrome

(recommended),Firefox

,Edge

,orOpera

withWindows

•Chrome

(recommended)orSafari

withOSX

•Chrome

orFirefox

withotheroperatingsystems.

Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support

Howtoaccesstheproductfromabrowser

1.Startawebbrowser.

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.

ToaccesstheproductfromaMaccomputer(OSX),gotoSafari,clickonBonjourandselecttheproductfromthe

drop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout

howtodiscoverandassignanIPaddress,seethedocumentAssignanIPAddressandAccesstheVideoStreamonAxis

Supportwebataxis.com/support

Note

ToshowBonjourasabrowserbookmark,gotoSafari>Preferences.

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe

congured.

4.Theproduct’sliveviewpageopensinyourbrowser.

Aboutsecurepasswords

Important

Whensettingtheinitialpassword,thepasswordissentincleartextoverthenetwork.Ifthereisariskofnetworksnifng,

rstsetupasecureandencryptedHTTPSconnectionbeforeresettingthepasswords.

Thedevicepasswordistheprimaryprotectionforthedataandservices.Axis’productsdonotimposeapasswordpolicyasproducts

maybeusedinvarioustypesofinstallations,buttoprotectyourdatadothefollowing:

•Don’tusethedefaultpasswordthatcomeswiththeproducts.

•Useapasswordwithatleast8characters,preferablyusingapasswordgenerator.

•Don’texposethepassword.

•Changepasswordatarecurringinterval,atleastonceayear.

Setapasswordfortherootaccount

Important

Thedefaultadministratorusernamerootcannotbedeleted.Ifthepasswordforrootislost,theproductmustberesetto

thefactorydefaultsettings.

AXISM30Series

Howtoaccesstheproduct

Thedefaultrootaccounthasfullprivilegesandshouldbereservedforadministrativetasks.Alwayscreateauseraccountwithlimited

privilegesfordailyuse.Thisreducestheexposureoftheadministrativeaccount.

1.Makesuretofollowtheinstructionsaboutsecurepasswords,seeAboutsecurepasswordsonpage5.

2.Typeapasswordandthenretypeittoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

AXISM30Series

Setup

Abouttheproduct'sbuilt-inhelp

Youcanaccessthebuilt-inhelpthroughyourproduct’swebpage.Thehelpprovidesmoredetailedinformationontheproduct’s

featuresandtheirsettings.

Imagequality

Aboutcapturemodes

Acapturemodeconsistsofaresolutionandthecorrespondingframerateavailableintheproduct.Thecapturemodesetting

affectsthecamera’seldofviewandaspectratio.

Thelowerresolutioncapturemodeiscroppedoutfromthehighestresolution.

Theimageshowshowtheeldofviewandaspectratiocanchangebetweentwodifferentcapturemodes.

Howtoselectcapturemode

Whatcapturemodetochoosedependsontherequirementsofframerateandresolutionforthespecicsurveillancesetup.For

specicationsaboutavailablecapturemodes,seetheproduct’sdatasheet.Tondthelatestversionofthedatasheet,gotoaxis.com

Howtohidepartsoftheimagewithprivacymasks

Ifyouwanttohidepartsoftheimageduetoprivacyreasons,useoneorseveralprivacymasks.

Whatisaprivacymask?

AXISM30Series

Setup

Aprivacymaskisauser-denedareathatprohibitsusersfromviewingpartsofthemonitoredarea.Privacymasksappearasblocks

ofsolidcolorandareappliedonthevideostream.

Privacymasksarepresentonallsnapshots,recordedvideo,andrequestedstreams.TheycannotbebypassedthroughtheVAPIX®

applicationprogramminginterface(API).

Important

Ifyouaddmanyprivacymasks,thismayaffecttheproduct’sperformance.

Howtocreateaprivacymask

Tocreateoreditaprivacymask,gotoSettings>Privacymask.

Howtoreducenoiseinlow-lightconditions

Toreducenoiseinlow-lightconditions,youcanadjustoneormoreofthefollowingsettings:

•Makesurethattheexposuremodeisautomatic.

Note

Increasingthemaxshuttervaluecanresultinmotionblur.

•Theshutterspeedshouldbeasslowaspossible,whichmeansyoushouldsetmaxshuttertothehighestpossiblevalue.

•Reducesharpnessintheimage.

•Tryloweringthemaxgainvalue.

Howtoselectexposuremode

Thereareseveralexposuremodeoptionsinthecamerathatadjustsaperture,shutterspeed,andgaintoimproveimagequalityfor

specicsurveillancescenes.GotoSettings>Image>Exposureandselectbetweenthefollowingexposuremodes:

•Formostusecases,selectAutomaticexposure.

•Forenvironmentswithcertainarticiallighting,forexampleuorescentlighting,selectFlicker-free.

Selectthesamefrequencyasthepowerlinefrequency.

•Forenvironmentswithcertainarticiallightandbrightlight,forexampleoutdoorswithuorescentlightingatnightand

sunduringdaytime,selectFlicker-reduced.

Selectthesamefrequencyasthepowerlinefrequency.

•Tolockthecurrentexposuresettings,selectHoldcurrent.

Howtomonitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallway,road,ortunnel.

AXISM30Series

Setup

1.Dependingonyourproduct,turnthecameraorthe3–axislensinthecamera90°or270°.

2.GotoSettings>Stream>Orientationontheproduct’swebpageandrotatetheview90°or270°.

Findoutmoreataxis.com/axis-corridor-format

Howtoenhancefacialrecognition

Tobetterrecognizethefaceofapersonpassingbythecamera,youcansettheoptimalpixelresolutionwiththecamera’spixel

counter.

1.GotoSettings>System>Orientationandclick.

2.Adjustthesizeandplacementoftherectangleinthecamera’sliveviewaroundtheareaofinterest,forexamplewhere

thefacesofpassingpersonsareexpectedtoappear.Youcanthenseethenumberofpixelsrepresentedbythesidesof

therectangle.

Note

Youcanuseanobjectofaknownsizeintheviewasareferencetodecidehowmuchresolutionisneededforrecognition.

AXISM30Series

Setup

Aboutviewarea

Aviewareaisacroppedpartofthefullview.Youcanstreamandstoretheviewareainsteadofthefullviewtominimizebandwidth

andstorageneeds.IfyouenablePTZfortheviewarea,youcanpan,tiltandzoomwithintheit.Byusingaviewareayoucan

removepartsofthefullview,forexamplesky.

Whenyousetupaviewarea,werecommendyoutosetthevideostreamresolutiontothesamesizeasorsmallerthantheviewarea

size.Ifyousetthevideostreamresolutionlargerthantheviewareasizeitimpliesdigitallyscaledupvideoaftersensorcapture,

whichrequiresmorebandwidthwithoutaddingimageinformation.

Howtohandlesceneswithstrongbacklight

UseWDRtomakebothdarkandbrightareasoftheimagevisible.

1.GotoSettings>Image.

2.TurnonWDRunderWidedynamicrange.

ImagewithoutWDR.

ImagewithWDR.

Note

IfyouuseWDR,youmayexperiencesomeWDRartifactsintheimage.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr

Overlays

Aboutoverlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,

orduringproductinstallationandconguration.

AXISM30Series

Setup

Howtoshowatextoverlaywhenthecameradetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthecameradetectsmotion:

1.GotoSettings>Overlay.

2.Enter#Dinthetexteld.

3.Choosealignment,textsizeandappearance.

4.Includethetextoverlay.

5.GotoSystem>Events>Actionrules.

6.CreateanactionrulewithAXISVideoMotionDetectionastrigger.

7.Fromthelistofactions,selectOverlaytext.

8.Type“Motiondetected”.

9.Settheduration.

Streamingandstorage

Howtochoosevideocompressionformat

Decidingwhichcompressionmethodtochoosedependsonyourviewingrequirements,andonthepropertiesofyournetwork.The

availableoptionsare:

MotionJPEG

MotionJPEGorMJPEGisadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen

displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion

videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.

H.264orMPEG-4Part10/AVC

Note

H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion

JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace

arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.

H.265orMPEG-HPart2/HEVC

Note

H.265islicensedtechnology.TheAxisproductincludesoneH.265viewingclientlicense.Installingadditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.265can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebyasmuchas50%morethanwith

theH.264standard.

Findoutmoreataxis.com/compression-formats

AXISM30Series

Setup

Howtoreducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlessdetailsinthepicture.

1.GotoliveviewandselectH.264/H.265.

2.GotoSettings>Stream.

3.Dooneormoreofthefollowing:

-TurnontheZipstreamfunctionalityandselectthedesiredlevel.

-TurnondynamicGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnondynamicFPS.

Howtosetupnetworkstorage

Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:

1.GotoSettings>System>Storage.

2.ClickSetupunderNetworkstorage.

3.EntertheIPaddressofthehostserver.

4.Enterthenameofthesharedlocationonthehostserver.

5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.

6.ClickConnect.

Events

Aboutevents

Theeventpagesallowyoutocongureyourproducttoperformactionswhendifferenteventsoccur.Forexample,theproduct

canstartarecordingorsendanemailnoticationwhenmotionisdetected.Thesetofconditionsthatdeneshowandwhen

theactionistriggerediscalledanactionrule.

Howtotriggeranaction

1.GotoSettings>System>Eventstosetupanactionrule.Theactionruledeneswhentheproductwillperformcertain

actions.Actionrulescanbesetupasscheduled,recurring,orforexample,triggeredbymotiondetection.

2.SelectwhatTriggermustbemettotriggertheaction.Ifyouspecifymorethanonetriggerfortheactionrule,all

ofthemmustbemettotriggertheaction.

3.SelectwhichActionthecamerashouldperformwhentheconditionsaremet.

Note

Ifyoumakechangestoanactiveactionrule,theactionruleneedstoberestartedforthechangestotakeeffect.

Note

Ifyouchangethedenitionofastreamproleusedinanactionrule,youneedtorestartanyactionrulesthatusethat

streamprole.

AXISM30Series

Setup

Howtorecordvideowhenthecameradetectsmotion

ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsmotionandto

stoponeminuteafter.

MakesuretheAXISVideoMotionDetectionapplicationisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Createanactionrule:

4.GotoSettings>System>Eventsandaddanactionrule.

5.Typeanamefortheactionrule.

6.Fromthelistoftriggers,selectApplicationsandthenselectAXISVideoMotionDetection(VMD).

7.Fromthelistofactions,selectRecordvideo.

8.Selectanexistingstreamproleorcreateanewone.

9.Setthepre-triggertimeto5seconds.

10.Setthepost-triggertimeto60seconds.

11.SelectSDcardfromthelistofstorageoptions.

12.ClickOk.

Applications

Aboutapplications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications

forAxisproducts.Tondoutmoreaboutavailableapplications,downloads,trialsandlicenses,gotoaxis.com/applications

TondtheusermanualsforAxisapplications,gotoaxis.com

Note

•Itisrecommendedtorunoneapplicationatatime.

•Avoidrunningapplicationswhenthebuilt-inmotiondetectionisactive.

AXISPeopleCounter

AXISPeopleCounterisananalyticapplicationthatcanbeinstalledonanetworkcamera.

Thecounterisembeddedinthecamerawhichmeansyoudonotneedadedicatedcomputertoruntheapplication.

AXISPeopleCounterisintendedforretailenvironments,likestoresorshoppingmalls,orotherenvironmentswhereyouwantto

countpeople.

AXISM30Series

Setup

AXISM30Series

Troubleshooting

Howtoresettofactorydefaultsettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to

thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonwhilereconnectingpower.SeeProductoverview.

3.Keepthecontrolbuttonpressedfor15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset

tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.UsetheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepassword,andaccessthevideostream.

Theinstallationandmanagementsoftwaretoolsareavailablefromthesupportpagesonaxis.com/support

Howtocheckthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga

problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular

problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu.

3.ClickAbout.

Howtoupgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein

thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Note

Whenyouupgradetheproductwiththelatestrmware,theproductreceivesthelatestfunctionalityavailable.Alwaysread

theupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthermware.Tondthelatest

rmwareandthereleasenotes,gotoaxis.com/support/rmware

1.Downloadthelatestrmwareletoyourcomputer,availablefreeofchargeataxis.com/support/rmware

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenanceintheproduct’swebpageandfollowtheinstructions.

4.Theupgradetakesawhile,don'tbreakthepowertotheproduct.Whentheupgradeisnished,theproductrestarts

automatically.

AXISM30Series

Troubleshooting

AXISCameraManagementcanbeusedformultipleupgrades.Findoutmoreataxis.com/products/axis-camera-management

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,theproductreloadsthepreviousrmware.Themostcommonreason

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele

correspondstoyourproductandtryagain.

ProblemssettingtheIPaddress

Theproductislocatedona

differentsubnet

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe

productarelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork

administratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisproductfromthenetwork.Runthepingcommand(inaCommand/DOS

window,typepingandtheIPaddressoftheproduct):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingtheproduct.

Theproductcannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.

SeeHowtoresettofactorydefaultsettings.

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas

beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe

network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename

hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,gotoaxis.com/support.

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductmustbe

synchronizedwithanNTPserver.GotoSettings>System>Dateandtime

Theproductisaccessiblelocallybutnotexternally

Routerconguration

CheckthatyourrouterallowsincomingdatatrafctotheAxisproduct.Theroutermustsupport

UPnP

Firewallprotection

ChecktheInternetrewallwithyournetworkadministrator.

Problemswithstreaming

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

AXISM30Series

Troubleshooting

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore

information.

Lowerframeratethan

expected

•SeePerformanceconsiderationsonpage17.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Intheproduct’swebpage,setacapturemodethatprioritizesframerate.Changingthe

capturemodetoprioritizeframeratemightlowerthemaximumresolutiondepending

ontheproductusedandcapturemodesavailable.

•Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)of

theAxisproduct.

Can'tselectH.265encoding

inliveview

WebbrowsersdonotsupportH.265decoding.Useavideomanagementsystemorapplication

supportingH.265decoding.

Problemsretrievingadditionalvideostreams

‘VideoError’displayedin

AXISCompanion,or

‘Stream:Error.Something

wentwrong.Maybethere

aretoomanyviewers.’in

Chrome/Firefox,or

‘503serviceunavailable’

errorinQuickTime,or

‘Cameranot

available’displayedin

AXISCameraStation,or

‘Errorreadingvideostream’

messageinbrowserwhen

usingtheJavaapplet

Thiscameraisdesignedtodeliveruptofourdifferentstreams.Ifafthuniquestreamisrequested,

thecamerawillnotbeabletoprovideit,andanerrormessageisdisplayed.Theerrormessage

dependsonthewaythestreamisrequested.Thestreamsareusedonarstcome,rstserved

basis.Examplesofinstancesusingastreamare:

•Liveviewinginawebbrowserorotherapplication

•Whilerecording-continuousormotiontriggeredrecording

•Aneventusingimagesonthecamera,forexampleaneventsendingane-mailwithan

imageeveryhour

•Aninstalledapplication,suchasAxisVideoMotionDetection,willalwaysuseastream

regardlessofwhetheritisusedornot.

Thecameracandelivermorethanfoursimultaneousstreamsprovidedthecongurationofany

additionalstreamisidenticaltoanyoftherstfourstreams.Identicalcongurationimpliesexactly

thesameresolution,framerate,compression,videoformat,rotationetc.Formoreinformationsee

thewhitepaper“Maxnumberofuniquevideostreamcongurations”,availableataxis.com

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe

bandwidth.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand

bandwidth.

AXISM30Series

Troubleshooting

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat

streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand

thegeneralperformance.

AXISM30Series

Speciﬁcations

Tondthelatestversionoftheproduct’sdatasheet,gototheproductpageonaxis.comandlocateSupport&Documentation.

LEDindicators

StatusLED

Indication

Unlit

Connectionandnormaloperation.

GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.

Amber

Steadyduringstartup.Flashesduringrmwareupgradeorresettofactorydefault.

Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.

RedFirmwareupgradefailure.

SDcardslot

NO NO

TICE TICE

TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard

fromtheproduct’swebpagebeforeremoval.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).

ForSDcardrecommendations,seeaxis.com

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeHowtoresettofactorydefaultsettingsonpage15.

•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe

statusLEDashesgreen.

Connectors

Networkconnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

UserManualVer.M1.6

AXISM30SeriesDate:September2017

PartNo.1741648

Axis 01152-001 ~ EOL M3016 Recessed Mount Mini Dome Camera 01152-001

Product's Documents

Axis M3016 User Manual

Specifications

Axis 01152-001 ~ EOL Questions and Answers
