Axis M3006-V~EOLFixed Mini Dome Camera 0514-001 User Manual

USER MANUAL

AXIS M3006–V Network Camera

About this Document

This manual is intended for administrators and users of AXIS M3006–V

Network Camera, and is applicable to ﬁrmware 5.40 and later. It

includes instructions for using and managing the product on your

network. Previous experience of networking will be of use when u sing

this product. Some knowledge of UNIX or Linux-based systems may also

be b e neﬁcial, for developing shell scripts and applications. Later version

of this document will be po sted to the Axis website, as require d. See

also the product’s on line help, a vailable via the web-ba sed interface.

Liability

Every care has been taken in the preparation of this manual. Please

inform your local Axis ofﬁce of any inaccuracies or omissions. Axis

Communications AB cannot be held responsible for any technical or

typographical errors and reserves the right to make changes to the

product and manuals without prior notice. Axis Communications AB

makes no warranty of any kind with regard to the material contained

within this docume nt, including, but not limited to, the implied

warranties of merchantability and ﬁtnes s for a particular purpose. Axis

Communications AB shall not be liable nor responsible for incidental or

consequential damages in connection with the furnishing, performance

or use of this mat erial. This product is on ly to be used for its inte nded

purpose.

Intellectual Property Rights

Axis AB has intellectual property rig hts relating to technology embo died

in the product described in this document. In particular, and without

limitation, these intellectual property rights may inclu de one or more

of the patents list e d at http://ww w.axis.com/paten t.htm and one or

more additional patents or pending patent applications in the US and

other countries.

This product contains licensed third-party software. See the menu item

“About” in the product’s user interface for more information.

This product contains source code copyright Apple Computer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

http://www.opensource.ap ple.com/apsl). The source code is available

from http://developer.apple.com/darwin/pro jects/ bon jour/

Equipment Modiﬁcations

This equipment must be installed and used in strict accordan ce with the

instructions given in the user documentation. This equipment contains

no user-serviceable components. Unauthorized equipment changes or

modiﬁcations will invalidate all applicable regulatory certiﬁcations

and approvals.

Trademark Acknowledgments

Apple, Boa, Bonjour, Ethernet, Interne t Explorer, Linux, Microsoft,

Mozilla, Real, SMPTE, QuickTime, UNIX, Windows, Windows Vista and

WWW are registered trademarks of the respe ctive holders. Java and

all Java-based trademarks and logos are trademarks or registered

trademarks of Oracle and/or its afﬁliates. UPnP

is a certiﬁc

ation

mark of the UPnP

Implementers Corporation.

Electromagnetic Compatibility (EMC)

This equipment has been designed and tested t

ofulﬁll applicable

standards for:

• Radio frequency emission w hen installed according to the

instructions and used in its intended environment.

• Immunity t o electrical and electromagnetic phenomena when

installed according to the instructions and used in its intended

environment.

USA

This equipment h as been tes ted using a shielde d netw ork cable (STP)

and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are des igned

to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if no t installed a nd used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will no t occur in a particular installation. If this equipment does

cause harmfu l interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect th e equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canada

This Cla ss B d igita l apparatus complies with Canadian I CES-003.

Europe

This digital equipment fulﬁlls the requirements for RF emission

according to the Class B limit of EN 55022.

This product fulﬁlls the requirements for immunity according

to EN 61000-6-1 residential, commercial and light-industrial

environments.

This product fulﬁlls the requirements for immu nity according to

EN 61000-6-2 industrial environments.

This product fulﬁlls the requirements for immu nity according to

EN 55024 ofﬁce and commercial environments.

Australia/New Zealand

This digital e quipme nt fulﬁlls the requiremen t s for RF emission

according to th e Class B limit of AS/NZS CISPR 22.

Japan

この装置は、クラスB 情報技術装置です。この装置は、家庭

環境で使用することを目的としていますが、この装置がラジ

オやテレビジョン受信機に近接して使用されると、受信障

害を引き起こすことがあります。取扱説明書に従って正し

い取り扱いをして下さい。

Safety

This product complies with IEC/EN 60950-1, Safety of Information

Technology Equipment.

Support

Should you require any technical assistance, please contact your Axis

reseller. If your questions cannot be answered immediately, your

reseller will forward your queri

es through the appropriate channels to

ensure a rapid response. If you are connected to the Internet, you can:

• download u ser documentation and software updates

• ﬁnd answers to resolved problem s in the FAQ database. Search

by product, category, or phrase

• report proble ms to Axis support staff by logging in to your private

support area

• chat with Axis support staff (selected countries only)

• visit Axis Support at www.axis.com/techsup/

Learn More!

Visit A xis learning center w ww.axis.com/academy for useful trainings,

webinars, tutorials and guides.

AXIS M3006–V Network Camera

Table of Contents

HardwareOverview .......................................... 4

Connectors .................................................... 4

LEDIndicators .................................................. 5

AccessingtheProduct ....................................... 6

AccessfromaBrowser ........................................... 6

AccessfromtheInternet .......................................... 7

SettheRootPassword ........................................... 7

TheLiveViewPage .............................................. 8

MediaStreams ............................................. 11

HowtoStreamH.264 ............................................ 11

MJPEG ........................................................ 11

AXISMediaControl(AMC) ........................................ 11

AlternativeMethodsofAccessingtheVideoStream .................... 12

SettingUptheProduct ...................................... 14

BasicSetup .................................................... 14

Video ..................................................... 15

VideoStream ................................................... 15

Stream Proﬁles ................................................. 16

CameraSettings ................................................ 17

ViewAreas ..................................................... 19

Overlay ........................................................ 19

PrivacyMask ................................................... 20

Live View Conﬁg ............................................ 21

PTZ(PanTiltZoom) ......................................... 23

PresetPositions ................................................. 23

GuardTour ..................................................... 24

Advanced ...................................................... 24

Detectors .................................................. 25

CameraTampering .............................................. 25

MotionDetection ............................................... 25

Applications ............................................... 28

Events .................................................... 29

SettingUpanActionRule ........................................ 30

Recipients ..................................................... 30

Schedules ...................................................... 31

Recurrences .................................................... 31

Recordings ................................................. 32

RecordingList .................................................. 32

ContinuousRecording ............................................ 32

SystemOptions ............................................. 34

Security ....................................................... 34

Date&Time .................................................... 35

Network ....................................................... 36

Storage ....................................................... 41

Maintenance ................................................... 42

Support ....................................................... 42

Advanced ...................................................... 43

ResettoFactoryDefaultSettings ................................... 44

Troubleshooting ............................................ 45

CheckingtheFirmware ........................................... 45

UpgradingtheFirmware .......................................... 45

EmergencyRecoveryProcedure .................................... 45

Symptoms,PossibleCausesandRemedialActions ..................... 46

Technical Speciﬁcations ...................................... 50

PerformanceConsiderations ....................................... 52

AXIS M3006–V Network Camera

Hardware Overview

Dome cover

Control button

Status LED

microSD card slot

Network connector (PoE) (comes attached with the product)

Connectors

For technical s peciﬁcations, see

page 50

Network connector - RJ-45 Ethernet connector. Supports Power over Ethernet (PoE).

AXIS M3006–V Network Camera

Hardware Overview

NOTICE

The product shall be connected using a shielded network cable (STP). All cables connecting the product to the network switch

shall be shielded (STP) and intended for their speciﬁc use. Make sure that the network switch is properly grounded. See

Electromagnetic Compatibility (EMC)

for regulatory requirements.

SD card slot - A standard or high-capacity microSD card (no t included) can be used for local recording with remo va ble storage.

NOTICE

To prevent corruption of recordings, the SD card should be unmounted before removal. To unmount, g o to Setup > System

Options > Storage > SD Card and click Unmount.

Control button - The control button is used for:

• ConnectingtoanAXISVideoHostingSystemservice.See

page 37

. To connect, press and hold the button for about

1 second until the Status LED ﬂashes gree n.

• ConnectingtoAXISInternetDynamicDNSService. See

page 37

. To connect, press and hold the button for

about 3 seconds.

• Resetting the product to factory default settings. See

page 44

LED Indicators

Color

Indication

Unlit

Connection and normal operation

Amber

Steady during startup. Flashes during ﬁrmware upgrade.

Amber/red Flashes amber/ re d if ne tw o rk connection is unavailable or lost.

Red Flashes red for ﬁrmware upgrad e failure.

Green Shows steady green for 10 seconds for normal operation after restart.

Note

• The Status LED c an be conﬁgured to ﬂash wh

ile an event is a ctive.

• The Status LED can be conﬁgured to ﬂash for identifying the unit. Go to Setup > System Options > Maintenance .

AXIS M3006–V Network Camera

Accessing the Product

To ins tall the Axis product, refer to the Installation Guide supplied with the product.

The product can be used with most operating systems and browsers. The recommended browsers are Interne t Explorer with W indows,

Safari with Macintosh and Firefox with other operating s yste m s. See

Technical Speciﬁcations on page 50

. To view streaming video in

Internet Explorer, allow ins tall ation o f AXIS Media Control (AMC ) whe n prompted.

The Axis product includes one (1) H.264 decoder license for view ing video streams. The license is automatically installed w ith A MC.

The adminis trator can disable the installation of the de coder s, to prevent installation of unlicensed copies.

Note

• QuickTime

is also supported for viewing H.264 streams.

• If your computer restricts the use of additional software components, the product can be conﬁgured to use a Java

applet for viewing Motion JPEG.

Access from a Browser

1. Start a browser (Internet Explorer, Firefox, Safari).

2. Enter the IP address or host name of the Axis product in the browser’s Location/Address ﬁeld. To access the product from a

Macintosh computer (Mac OS X), click on the Bonjour tab and select the product from the drop-down list.

If you do not know the IP address, use AX IS IP Utility to lo cate the product on the netw or k. For i nformation about how to

discover and assign an IP add ress, see the Installation and Management Software C D or the document

Assign an IP Address

and Access the Video Stream

on A xis Suppo rt web at www .axis.com/techsup

3. Enter your user name and p assword. If this is the ﬁrst tim e the product is accessed, the root passwo rd must ﬁrst be

conﬁgured. For instructions, see

Set the Root Password on page 7

4. The product’s Live View page appears in your bro wser.

Note

The controls a nd layout of the Live View page may have been customized to

meet speciﬁc installation requirements and

user preferences. Consequently, some of the examples and functions featured h ere may d iffer from those displayed in

your own Live Vie w page.

AXIS M3006–V Network Camera

Accessing the Product

Access from the Internet

Once connected, the Axis product is accessible o n your local network (LA N ). To access the product from the Inter n et you must

conﬁgure your netw ork router to allow incoming data trafﬁc to the product. To do this, enable the NAT-traversal feature, which

will attempt to automatically conﬁgure the router to allow a cces s to the product. This is e n able d from Setup > System Options >

Network > TCP/IP Ad va n c ed.

For more information, please see

NAT traversal (port mapping) for IPv4 on page 39

. See also AXIS Internet Dyna m ic DNS Service at

www.axiscam.net For Technical notes on this and other topics, visit the Axis Support w eb at ww w

.axis.com/techsup

Set the Root Password

To gain access to the A xis product, you must set the password for the default administrator user root. This is done in the Conﬁgure

Root Password dialog, which appears when the product is accessed for the ﬁrs t time.

To prevent network eavesdropping, the root password can be set via an encrypted H TTPS connection, which requires an HTTPS

certiﬁcate. HTTPS (Hypertext Transfer Protocol over SSL) is a protocol used to encrypt trafﬁc between web browsers and servers. The

HTTPS certiﬁcate ensures encrypted exchange of information.

To set the password via a standard HTTP connection, enter it directly in the ﬁrst dialog.

To set the p assword via an e ncrypted HTTPS connection, follow these steps:

1. Click Create self-signed certiﬁcate.

2. Provide the req u ested information and click OK.Thecertiﬁcate is created and the password can now be set securely. All

trafﬁc to and from the product is encrypted from this point on.

3. Enter a password and then re-enter to conﬁrm the spelling. Click OK. The password has now been conﬁgured.

Note

•Thede

fault a dministrator user name root is permanent and cannot be deleted.

• If the p assw ord for root is lost, the product must be reset to the factory default settings. See

Reset to Fa ctory Default

Settings on page 44

AXIS M3006–V Network Camera

Accessing the Product

Conﬁgure Capture Mode

Capture mode deﬁnes the maximum resolution and maximum frame rate available in the Axis product. The capture mode setting also

affects the camera’s an gle of view; if using a capture mode wi th a sma lle r maximum resolution, the angle of view is reduced.

Select the desired capture mode fro m the drop-down list and click OK.

See also the online help .

Basic Setup

Basic Setup provides shortcuts to the settings thatshouldbemadebeforeusingtheAxisproduct:

1. Users. See

page 34

2. TCP/IP. See

page 36

3. Date & T ime. See

page 35

4. Video Stream. See

page 15

The Basic Setup menu can be disabled from System Options > Security > Users.

AXIS M3006–V Network Camera

Video

It is possible to conﬁgure the following video features in your Axis product:

• Video stream. See

page 15

•Streamproﬁles. See

page 16

• Camera settings. See

page 17

•Viewareas.See

page 19

• Overlay image. See

page 19

•Privacymask.See

page 20

Video Stream

You can deﬁne the follow ing video stream settings fro m Video > Video Stream:

•Image.See

page 16

• H.264. See

page 16

•MJPEG.See

page 16

Pixel Counter

The pixel counter shows the number of pixels in an area of the image. The pixel counter is useful in situations where there is a

requirement that the image is a cer tain size, for exa m ple in face recog nition.

The pixel counter can be accessed from:

• Video > Video Stream.UnderPreview,clickOpen and select the Show pixel counter option to enable the rectangle in

the image. Use the mouse to move and resize the rectangle, o r enter the number of pixels in the Width and Height

ﬁelds and click Apply.

• The Live V iew page in Internet Explorer in Windows . Right-click in the imag e and select Pixel counter.Usethemouse

to move and resize the rectangle.

AXIS M3006–V Network Camera

Video


The de fault image setting s can be conﬁgured under Video> Video Stream. Select the Image tab.

The follo wi ng settings are available:

• Resolution. Select the default resolution.

• Compression. The compress ion lev el affe cts the image quality, bandwidth and ﬁle size of saved images; the lower the

compression, the higher the image quality with higher bandwidth requirements and larger ﬁle sizes.

• Rotate image. If required, the image can b e rotated.

• Mirror. If r equired, the image can be mirrored.

• Maximum frame rate. To avoid bandwidth problems, the frame rate allowed to e ach viewer can be limited .

• Overlay settings.See

Overlay on page 1 9

Click Save to apply the new settings.

H.264

H.264, also known as MPEG-4 Part 10/AVC, is a video compression standard that provides high quality video streams at low bit rates.

An H.264 video stream consists of different types of frames such as I-frames and P-frames. An I-fram e is a complete image whereas

P-frames only contain the differences from previous f ram e s .

The GOV length is the number of frames between two consecutive I-frames. Increasing the GOV length may save considerably on

bandwidth requirements in some cases, but may als o have an adverse affe ct on imag e quality.

The Axis product supports two H.264 proﬁles.TheMainproﬁ le provides highe r compression than the Baseline pr oﬁle with the same

video quality, bu t requires m or e processing power to decod e.

ThebitratecanbesetasVariable Bit Rate (VBR) or Constant Bit Rate (CBR). VBR adjusts the bit rate according to the image

complexity, using up more bandwidth for increased activity in the i

mage, a nd less for lower image activity. CBR allows you to set a

ﬁxed Target bit rate that consumes a predictable amount of bandwidth. As the bit rate would usually need to increase for increased

image activity, but in this case cannot, frame rate and image qualityareaffectednegatively. Topartly compensate for this, it is

possible to prioritize either frame rate or image quality. N

ot setting a priority means that frame rate and image quality are equally

affected. Yo u must save yo u r settings before t h ey can take effect.

The current bit rate can be set to appear as text overlay. To do this, select the Include text check box option under Overlay

Settings and enter the modiﬁer #b in the ﬁeld.

MJPEG

Sometimes the image size is

large due to low light or complex s cenery. Ad justing the maximum frame size helps to control the

bandwidth and storage used by the Motion JPEG video stream in these situations. Setting the frame size to the Default setting

provides consistently good im age quality at the expense of increased bandwidth and storage usage in low light. Limiting the frame

size optimizes b

andwidth and storage usag e, but may give poor im age quality. To prevent i ncreased bandwidth and storage usage,

the maximum frame size should be set to an optim a l value.

Stream Proﬁ les

Astreamproﬁle is a set of pre-conﬁgured stream settings including resolution, compression, frame rate and o ve rlay settings.

Stream pro ﬁles can b e used:

• When setting up recording using action rules, see

Events on page 29

• When setting up a continuous recording, see

Continuous Recording on page 32

• In the Live View page — select the stream proﬁle fro m the Stream proﬁle drop-down list.

AXIS M3006–V Network Camera

Video

Four pre-programmed stream proﬁles are availab le for quick se t up. Each pre-programm e d proﬁle has a d es criptive name, indicating

its purpose. If required, the pre-programmed stream proﬁles can b e modiﬁed and new customized stream pro ﬁles can be created .

To create a new proﬁle or modify an existing proﬁle, go t o Setup > Video > Stream Proﬁles.

To select a d e fa u lt stream proﬁle for the Live View page, go to Setup > Live View Conﬁg.

Camera Settings

The Video > Camera Settings page provides access to ad vanced image settings for the Axis product.

Capture Mode

Capture mode deﬁnes the maximum resolution and m aximum frame rate available in the Axis product. A capture mode with a large

maximum resolution has a reduced maximum frame rate and vice versa.

The cap ture mode setting also aff ects the camera’s angle of view as the effe ctive size of the image sensor differs between capture

modes. If using a capture mode w ith a smaller maximum resolution, the angle of view is reduced.

Capture mode is set the ﬁrst time the product is accessed . Select the desired capture mode and click OK.

Changing capture mode when the product has been conﬁgured is not recommended as most other settings will be either removed

or reset, for example:

1. Go to Setup > Video > Camera Settings.

2. Select the new capture mode.

3. Click Save.

4. Review and reconﬁgure all se ttings , for example:

-Viewareas

-Streamproﬁles

- PTZ settings including preset positions and guard tours

- Motion detection windows

-Privacymasks

- Image overlays

- Exposure zones

- White balance windows

-Actionrules

- Settings in u p loaded applications

Image Appeara nce

Increasing the Color level increases the color saturation. The value 100 gives maximum color saturation . The value 0 gives a

black and white image.

The image Brightness can be adjusted in the range 0–100, where a higher value produces a brighter image.

Increasing the Sharpness can increa se bandwidth usage. A sharper im age might incre ase image noise especially in low light

conditions. A lower setting reduces image noise, but the whole image will appear less sharp.

The Contrast changes the re lati ve differe nce betwee n light and dark. It can be adjusted using the slidebar.

AXIS M3006–V Network Camera

Video

White Balance

White balance is used to make colors in the image a ppe ar the same regardless of the color temperature of the light source. The Axis

product can be set to automatically identify the light source and compensate for its color. Alternatively, select the type of light

source f rom the drop-down list. For a description of each available setting, see the online help

The white balance window is enabled for the Automatic and Automatic outdoor options that appear in the White balance drop-down

list. Select one of the options from the drop-down list to set the white balance window properties. Select Automatic to use the

default settings for the Autom atic and Automatic outdoor options (in the White balance drop-down list). Select Custom to manually

set a re ference window for w h ite balance in the view area.

Wide Dynamic Range

Wide dynamic range (Dynamic Contrast) c an improve the exposure when there is a considerable contrast between light and dark

areas in the image. Enable WDR in intense backlight conditions. Disable WDR in low light conditions for optimal e xp osure .

Note

This setting is only pos sib le when using autom atic exposure control.

Exposure Settings

Conﬁgure the exposure s ettings to suit the image q uality requirements in relation to lighting, frame rate and bandwidth

considerations.

Exposure value - Click in the bar to ﬁne-tune the exposure.

Exposure control - These settings is used to adapt to the amount of light used. Automatic is the default settings can be used in m ost

situations. The shutter speed is automatically set to produce optimum image quality. Flicker-free 50 or 60 Hz is used to remove

ﬂicker which can be caused by ﬂuorescent and other l ight sources. The H old current option l ocks the current exposure settings.

Enable Backlight compensation - Enable this op tion if a bright spot of light, for example a ligh

t bulb, causes other areas in

the image to appear too dark.

Exposure zones - This settings determines which part of the image is used to calculate the exposure. For most situations, the Auto

setting can be used. For particular requirement, select a predeﬁned area.

Shutter & Gain

The shutter and gain settings affect the amount of mot

ion blur a nd nois e in the image. To adapt to different lighting, av aila ble

storage space and bandwidth, it is often necessary to prior itize either low motion blur or low noise. The Axis product allow s

using differe nt prioritization in normal light and in l ow light.

Shutter speed is related to the amount of time the shutter is opened and is measured in seconds (s). A slow shutter speed allows

more light to reach the sensor and can help

produce a brighter image in low light situations. On the other hand, a slow shutter

speedcancausemovingobjects to appear blurry.

Set Shutter to

• Auto to set the shutter speed automatically. If required, use Max shutter to limit the shutter speed to prevent the frame

rate from being reduced. For example, to get 30 fps, set Max shutter to 1/30.

• Fixed to use a ﬁxed shutter speed.

Gain, m easured in decibel (dB), is the amount of ampliﬁcation applie d to the image. A high gain may provide a better image in low

light si

tuations but will increase the amount of image nois e.

Set

Gain to

• Auto to set the gain automatically. If required, use Max gain to limit the applied gain.

• Fixed to use a ﬁxed gain.

AXIS M3006–V Network Camera

Video

When Shutter and Gain are both set to Auto, it is possible to set the Priority betw een low motion blur and low noise manually and to

use a diff erent Priority in Normal Light and in Low Light.

Example

Consider an area where people or vehicles move during the day, but where there should be no movements during night. To be able to,

for example, recognize faces or license plates, move the normal light prior ity slider toward low motion blur. At nighttim e, motion

detection is more important than identiﬁcation. Motion blur is a cceptable and since low light can cause a lot of noise, mo ve

the low light priority slider toward low noise.

Example

If storage space or bandw idth is limite d, try using a lower gain. This will reduce image noi se and produce smaller image ﬁle s.

View Areas

A view area is a cropped part of the full view. Each view area is treated as a video sourc e in Live View and has its own video

stream and PTZ settings.

To enable view areas, go to Video > Camera Settings and select Ena b le View Area s.

When setting up a view area it is re com m e nde d that the video stream re solution is the same size as or s m a ller than the vie w area

size. Setting the v ide o stream r es olution larger than the view area size implies digitally scaled up video after se nsor capture,

requiring more bandwidth without a dding image information.

To a dd a new view area:

1. Go to Video > View Areas.

2. Click Add.

3. The new view area appears under Selected view area. Enter a descriptive name in the Name ﬁeld.

4. Select an Aspect ratio and a Video stream resolution.

5. A new view area covers the whole image. Usethemousetomoveandresizetheviewarea.

6. Select Enable PTZ to enable digital PTZ for this view area.

7. Click Save to save the settings.

To mo d ify a view area, select the vie w area in the l ist and modify the settings as req uir ed. Click Save.

To remove a view area, select the view area a nd click Remove.

Note

The PTZ functionality is useful during installation of the Axis product. Use a view area to crop out a speciﬁcpartofthe

full view.

Overlay

Overlays are used to provide extra information, for example for forensic video analysis or during product installation an d

conﬁguration. Overlays are supe rimposed over the video stream.

An o verlay text can display the cur rent date and time, or a text string. When using a text string, modiﬁers can be used to display

information such as the current bit rate or the curre nt frame rate. For information about a vailable modiﬁers, see

File Naming &

Date/Time Formats

in the online help .

To e nable overlays:

1. Go to Video > Video Stream and select the Image tab.

AXIS M3006–V Network Camera

Video

2. To include an overlay image, select Include overlay image at the coordinates. The overlay image must ﬁrst be uploaded to

the Axis product, see

Overlay Image

3. To include date a nd time, select Include date and Include time.

4. To include a text string, select Include text and enter the text in the ﬁeld. Modiﬁers can be used, see

File Naming &

Date/Time Formats

in the online help .

5. Select the text color, the text background color and the position of the o verlay.

6. Click Save.

Tomodifythedateandtimeformat,gotoSystem Options > Date & Time.See

Date&Timeonpage35

Overlay Image

An overlay image is a static image superimposed over the video stream. The image, for example company log o, is used to provide

extra information or to mask a part of the image.

Since it is static, the position and size of an over lay image will remain the s ame regardless of re s olution and digital Pan/Tilt

movements. To set up a dynamic mask, which will always mask a speciﬁed part o f the monitored area, see

Privacy Mask

To use an overlay image, the image must ﬁrst be uploaded to the Axis product:

1. Go to Video > Overlay Image.

2. Click Browse andbrowsetotheﬁle.

3. Click Upload.

4. Select the image to use from the Use overlay image list.

5. Click Save.

To display the overlay image:

1. Go to Video > Video Stream and select the Image tab.

2. Under Overlay Settings,selectInclude overlay image at the coordinates and enter the X and Y coordinates.

3. Click Save.

For information about

supported image formats, see the online help

Privacy Mask

Apriv

acy mask is an area of solid color that prohibits users from viewing parts of the monitored area. Privacy masks canno t be

bypassed via the VAPIX® Application Pro gramming Interface (API).

The Privacy Mask List (Video > Privacy Mask) shows all the masks that are currently conﬁgured in the A xis product and indicates

if they are enabled.

You can add a new mask, re-size the mask with the mouse, choose a color for the mask, and give the mask a n ame.

For more information, see the online help

Important

Adding many privacy masks may affect the product’s performance.

AXIS M3006–V Network Camera

Live View Conﬁg

Live View Con ﬁg

You can customize the Live View page and alter it to suit your requirements. It is possible to deﬁne the following features of

theLiveViewpage.

•StreamProﬁle. See

page 16

• Default Viewer for Browser. See

page 21

• Viewer Settings. See

page 22

• Action Buttons. These are the buttons described in

Controls o n the Live Vie w Page on page 9

•UserDeﬁned Links. See

page 22

Default Viewer for Browsers

From Live View Conﬁg > Default V iewer select the default method for viewing video images in your browser. The product attempts

to show the video images in the selected vid eo f orm a t and v ie we r. If this is not possible, the product overrides the settings and

selects the best available combination.

AXIS M3006–V Network Camera

Live View Conﬁg

Browser Viewer Description

AMC

Recommended viewer in Internet Explo rer (H.264/Motion JPEG).

QuickTime

H.264.

Java applet

A slower imaging alter native t o A MC (Motion JPEG ). Req uire s o ne of the

following install ed on the client:

• JVM (J2SE) 1.4.2 or higher.

• JRE (J2SE) 5.0 or higher.

Windows Internet Explorer

Still im a ge Displays still images only. Cl ick the Refresh button in yo ur brow se r to view a

new image.

Server Push

Recommended vi ew e r for other browsers (Motion JPEG).

QuickTime

H.264.

Java applet

A slow er imaging alternative to Server Push (M otion JPEG only).

Other browsers

Still im a ge Displays still images only. Cl ick the Refresh button in yo ur brow se r to view a

new image.

For more information, please see the online help .

Viewer Settings

To conﬁg ure options for the vie we r, go to Live View Conﬁg > Viewer Settings.

•SelectShow viewer toolbar to display the AXIS Media Control (AMC) or the Qu ickTime view e r toolbar under the video

image in your browser.

• H.264 decoder installation. The administrator can d isable installation of the H.264 decoder included with AXIS Media

Control. This is used to prevent installation of unlicensed copies. Further decoder licenses can be purchased from your

Axis reseller.

•SelectShow crosshair in PTZ joystick mode to enable a cross that will indicate the center of the im age in PTZ joystick m ode .

•SelectUse PTZ joystick mode as default to enable joystick mode. The mode can be changed temporarily from the PTZ

control panel.

•SelectEnable recording button to enable recording from the Live View p age. This button is a vailable when using

the AMC viewer. The recordings are saved to the location speciﬁed in the AMC Control Panel. See

AXIS Media Control

(AMC) on page 11

User Deﬁned Links

To display user-deﬁned links in the Live View page, select the Show custom link op tion, give the link a name and then enter the URL

to link to. When deﬁ ning a web link do not remove the 'http://' from the URL address. Custom links can be used to run scripts or

activate external devices connected to the product, or they can link to a web page. Custom links deﬁned as cgi links w ill run the

script in the background, in a hidden frame. Deﬁning the link as a we b link will o pen the link in a new window.

AXIS M3006–V Network Camera

PTZ (Pan Tilt Zoom)

PTZ (Pan T ilt Zoom )

The PTZ me nu is available if digital PTZ (pan, tilt and z oo m ) is enabled i n the selected view area. For more inform ation on view areas,

see

View Areas on page 19

Preset Positions

A preset position is a predeﬁned view that can be used to quickly steer the camera to a speciﬁc location. Preset positions can

be accessed in several ways:

• By selecting the preset from the Source drop-down list in the Live View Page.

• When setting up action rules. See

page 29

• When setting up Guard Tour. See

page 24

Each view area has its own preset positions.

To add a preset position:

1. Go to PTZ > Preset Positions.

2. Use the pan, tilt and zoom contro ls to steer the camera view to the desired position.

3. Enter a descriptive nam e in the Current position ﬁeld.

4. Click Add. The camera’s positio n is saved a s a preset position.

TheentireviewareaistreatedastheHome position which is readily accessible by clicking the Home buttonontheLiveView

page and in the Preset Positions setup w indo w.

The product can be conﬁgured to return to the Home position when the PTZ functionality h as been inactive for a speciﬁed le ngth of

time. Enter the length of time in the Return to home after ﬁeld and click Save. Setthetimetozerotopreventtheproductfrom

automatically r eturning to the Hom e position.

To include the preset position name in the overlay text, go to Video,selectInclude o ve rlay te xt and enter the modiﬁer #P in the ﬁeld.

For more information about modiﬁers, see

File Naming & Date/Time Formats

in the online help .

AXIS M3006–V Network Camera

PTZ (Pan Tilt Zoom)

Guard Tour

A guard tour displays the video stream from different preset positions, one-by-one, in a predetermined order or at random and for

conﬁgurable time periods. The enabled guard tour will keep running after the user has logged off or closed the browser.

Toaddaguardtour:

1. Go to PTZ>GuardTourand click Add.

2. Enter a descriptive name.

3. Specify the pause length between runs.

4. Select an available preset position and click Apply.

5. Specify the View Time in seconds or minutes.

6. Specify the View Order or select the Random view order option.

7. Click Save.

To modify or remove guard tours, go to PTZ>GuardTour, select the guard tour in the Guard Tour List and click Modify/Remove.

For more information see the online help

Advanced

Controls

Panel Shortcut Command Buttons can b e co nﬁg u red to p rovide direct access to com m ands issued via the VAPIX® Application

Programming Interface. The buttons will be displayed in the PTZ control panel, which is a vailable in the Live View page through

the Ctrl pa nel button, see

page 9

Note

Disabling PTZ controls will not affect preset positions. For example, if the tilt control is disa ble d, the product can still move to

preset positions that require a tilt movement.

AXIS M3006–V Network Camera

Detectors

Camera Tampering

Camera Tampering can gene ra te an alarm whenever the camera is repositioned, or when the lens is co vered, sprayed or severely

defocused. To send an alarm, for example an email, an action rule must be set u p.

To conﬁgure tampering:

1. Go to Detectors > Camera Tampering.

2. Set the Minim u m duration, that is, the time that must elapse before an alarm is generated. This can help prevent f als e

alarms for known conditions that affect the image.

3. Select Alarm for dark images if an alarm should be generated if lights are d immed or turned off, or if the lens is sprayed,

covered, or rendered severely out of focus.

4. Click Save.

To conﬁgure the product to send an alarm when tampering occurs:

1. Go to Events > Action Rules.

2. Click Add to set up a new action rule.

3. Enter a Name for the action rule.

4. Under Condition,selectDetectors from the Trigger list.

5. Select Tampering from the list of detectors.

6. Optionally, select a schedule and set additional conditions.

7. Select the action. To send an email, select Send Notiﬁcation a

nd select a Recipient from the list of d e ﬁned recipients.

Note

The While the rule is active option under Duration cannot be used w ith camera tampering, since camera tampering does not

have a duration and once it has been t riggered it will not automatically re turn to its untriggere d state.

For more information on actions rules, see

Events on page 29

Motion Detection

Motion detection is used to generate an alarm whenever movement starts or stops in the camera view.

Motion detection i s conﬁgured by deﬁning up to 10 Include and Exclude windows:

• Include windows —deﬁne areas where motion should be detected

• Exclude windows —deﬁne areas w ithin an Include window that should be ignored (areas outside Include w indows

are automatically ignored).

For instructions, see

Set Up Motion Detection Windows on page 26

To control the number of motion detection alarms, the parameters Object Size, History and Sensitivity can be a djusted. See

Motion Detection Parameters on page 26

Once motion detection windows are conﬁgured, the Axis product can be conﬁgured to p erform actions when motion is detected.

Possible actions include uploading images and start recording. For more information, see

Setting Up an Action Rule on page 30

AXIS M3006–V Network Camera

Detectors

Note

Using the motion detection feature may decrea se the product’s overall perform a nce.

Set Up Motion Detection Windows

To set up a motion detection Includ e W indow, follow thes e ins tructions:

1. Go to Detectors > M otion Detection.

2. Select a desired resolution for viewing while setting up Motion Detection from the View in list.

3. Select the Con ﬁgure Included Windows option and click New. Select the new window in the list of window s and enter

a descriptive name.

4. Adjustthesize(dragthebottomright-handcorner)andtheposition (click on the text a t the top and drag to the desired

position) of the window.

5. Adjust the Object Size, History and Sensitivity proﬁle s lide rs (see

Motion Detection Param eters

for details). Any detected

motion within an a ctive window is indicated by red peaks in the Activity window.

6. Click Save.

To exclude parts of the include w indow, select the Conﬁgure Excluded Windows and position the exclude window within the

include w indow.

To delete an include or exclude window, select the window in the list of windows and click Del.

Motion Detection Parameters

The parameters controlling motion detection are described in the table below:

Parameter

Object Size

History

Sensitivity

Description

Object size relative to window

size.

Object memory length.

Difference in luminance

between bac

kground and

object.

High level (100%)

Only very large objects trigger

moti

on detection.

An object that appears in

the window triggers motion

detection for a long time

before it is co nsidered as

non-moving.

Ordinary colored objects on

ordi

nary backgrounds trigger

motion detection.

AXIS M3006–V Network Camera

Detectors

Medium level (50%)

A large difference in luminance

is req u ire d to trigger motion

detection.

Low level (0%)

Even very small objects trigger

motion detection.

An object that appears in

the window triggers motion

detection only for a very short

time before it is considered as

non-moving.

Only very bright ob jects on

a dark background trigger

motion detection.

Recommen d ed values

5–15% 60–90% 75–95%

Default values

15% 90% 90%

Note

• To trigger on small objects or movements, use several small motion detection windows rather than o ne large window

and select a low object size.

• To avoid triggering on small obj ects, select a high object size.

• If no o bjects should appear in the Include W i ndow, select a high history level. This will cause m otion detection to

trigger as long as the object is present in the window.

• To only detect ﬂas hing light, sele ct a low sensitivity. In other cases hig h sensitivity is recom me nde d.

AXIS M3006–V Network Camera

Applications

Third party applications can be uploaded to and installed on the Ax is product. Fo r information about available applications,

downloads, trials and licenses, go to ww w.axis.com/applications

To upload an application, go to Applications > Overview, click Browse to locate the ﬁle and then click Upload Package. Click o n the

uploaded application’s name to open the menu options Settings, License and About.Forconﬁguration instructions, please refer to

the documentation provided with the application.

Most a pplica tions need a license to run. To install the license, select the License menu option. If the product is connected

to the Internet, Automatic Installation appears in the web page. If the product is not connected to the Internet, go to

www.axis.com/ applications to acquire a Li cens e key. You w ill need a license code and the product’s serial number (found on the label

and under System Options > Support > System Overview) to receive a license key.

Installed A pplications lists installed applications with inform a tion about the version and the ven dor, the status of the a pplication

(running or not running), and information about the license.

Use the Start and Stop buttons to start and stop the application.

To generate a log ﬁle for the application, select the a pplica tion and click Log.

Note

It is recommended to run one application at a time. Avoid running applications when motion detection is active.

AXIS M3006–V Network Camera

Events

The Axis product can be conﬁgure d to perform actions when di ffe rent events occur, for exa m ple , start a recording whe n motion is

detected. The set of conditions that deﬁnes how and when the action is triggered is called an Action Rule.

Available Action Rule triggers and conditions include :

• Applications — use installed applications to trigger the rule, see

Applications on page 28

• Detectors

- Motion Detection — trigger the rule w hen motion is detected, see

Motion Detection on page 25

- Tampering — trigger the rule when tampering is detected, see

Camera Tampering on page 25

• Hardware

- Network — trigger the rule if network connection is lost or restored. This can for example be u sed to start

recording to the SD card.

• Input Signal

- Manual Trigger — trigger the rule using the Manual Trigger button in the Live View page, see

Controls on

theLiveViewPageonpage 9

. This can for example be used to validate actions during product installation

and conﬁguration.

• PTZ

- Moving — trigger the rule when the camera view moves due to a PTZ o peration. This can for example be used

as an additional condition to pre vent an action rule triggered by motion detection to record video while the

camera view m oves due to a PTZ operation.

- Preset Reached —triggertherulewhenthecamerastopsatapresetposition.Thiscanbeforexamplebeused

with the Send Images action to upload images from the p reset posi

tion.

• Storage

- Available — trigger the rule when the storage dev

ice is unmounted or removed. This can for example be

used to send maintenance notiﬁca tio ns.

- Full — trigger the rule when the storage device is full. Under normal operation, the oldest recordings will be

overwritten to prevent the s torage device from becoming full.

- Locked — trigger the rule if the storage device is locked (write protected).

• System

- System Initializing — trigger the rule w he n the product is being started. This can for exam p le be used to send a

notiﬁ

cation when the product restarts.

• T

ime

- Recurrence — trigger the rule periodically, see

Recurrences on page 31

. This can for example be used to upload

an im a ge every 5 minutes.

- Use Schedule — trigger the rule a cco rding to the selected schedule, see

Schedules on page 31

Available actions include:

• PTZ Control

- Preset Position — go to a preset position.

- Guard Tour — start a guard tour, see

Guard Tour on page 24

AXIS M3006–V Network Camera

Events

• Record Video — record video to a selected storage.

• Send Images —sendimagestoarecipient.

• Send Notiﬁcations —sendanotiﬁcation message to a recipient.

• Status LED — ﬂash the LED indicator. This can for example be used to validate triggers such as motion detection during

product installation and co nﬁguration.

Setting Up an Action Rule

An action rule deﬁnes the conditions that must be met for the product to perfo rm an action, for example record video or send email

notiﬁcations. If multiple conditions are de ﬁned, all must be m et to trigger the action.

The following example describes how to set up an action rule to record video to a network share if there is movement in the

camera’s ﬁeld o f view.

Set up motion detection and add a network share:

1. Go to Detectors > Motion Detection and conﬁgure a motion detection w indow , see

page 26

2. Go to System Options > Storage and set up the network share, see

page 42

Set up the action rule:

1. Go to Events > Action Rules and click Add.

2. Select Enable rule and enter a descriptive nam e for the rule.

3. Select Detectors from the Trigger drop-down list.

4. Select Motion Detection from the drop-down list. Select the motion detection window to use.

5. Optionally, select a Schedule and Additional conditions,seebelow.

6. Under Actions, select Record Video from the Type drop-down list.

7. Select a Stream proﬁle and conﬁgure the Duration settings as described below.

8. Select Network Share from the Storage drop-down list.

To add additional criteria, select the Additional conditions option and add additional triggers. To prevent an action from b eing

triggered repeatedly, a Wait at least tim e can be set. Enter the time in hours, minutes and seconds, during w hich the trigger

should be ig nore d before the action rule can be activa ted again.

The recording Duration of some actions can be set to include time immediately before and after the event. Select Pre-trigger time

and/or Post-trigger time and enter the number of seconds. When While the rule is active is enabled and the action is triggered

again during the p ost-trigger time, the recording time w ill be extended with another post-trigger time period.

For more information, see the online help

Recipients

Recipients receive media ﬁles and notiﬁcation messages. The following recipients are available:

Recipient Use with action

Send Images

Send N otiﬁ cation

FTP

Send Images

AXIS M3006–V Network Camera

Events

HTTP

Send Images

Send N otiﬁ cation

Network Share Send Images

TCP Send N otiﬁcation

Note

A netw ork share can also b e used as a storage device for recorded video. Go to System Options > Storage to conﬁ gure a

network share before setting up a continuous recording or an action rule to record video. See

Storage on page 41

for more

information about storage devices.

To a dd a recipient:

1. Go to Events > Recipients and click Add.

2. Enter a descriptive name.

3. Select a recipient Type.

4. Enter the information needed for the recipient type.

5. Click Test to test the connection to the recipient.

6. Click OK.

Schedules

Schedules can be used as action rule triggers or as additional conditions, for example to record v ideo if motion is detecte d outside

ofﬁce hours. Use one of the predeﬁned s chedules or create a new schedule as described below.

To create a new schedule:

1. Go to Events > Schedules and click Add.

2. Enter a descriptive name and the information needed for a daily, wee kly, monthly or yearly sched ule.

3. Click OK.

To use the schedule in an Action Rule, select the schedule from the Schedule drop-down list in the Actio n Rule Setup page.

Recurrences

Recurrences are us e d to trigger Action Rul es repea tedl y , for example every 5 minutes or ev ery hou r.

To s et up a recurrence:

1. Go to Events > Recurrences and click Add.

2. Enter a descriptive name and recurrence pattern.

3. Click OK.

To use the recurrence in an Action Rule, ﬁrst se lect Time from the Trigger drop-down list in the Action Rule Setup page a nd

then select the recurrence from the second drop-down list.

To modif y or re m ove recurrences, select the recurr ence in the Recurrences List and click Modify or Remove.

AXIS M3006–V Network Camera

Recordings

TheAxisproductcanbeconﬁgured to record video continuously or according to an action rule:

• To start a continuous recording, see

page 32

• To set up action rules, see

page 30

• To access recordings, see

Recording List on page 32

•Toconﬁgure camera controlled storage, see

Storage on page 41

Recording List

Recorded videos are listed on the Recordings > List page. The list shows each recording’s start date and time, duration and the

event that triggered the recording.

To play or download a recording, follow these steps:

1. Go to Recordings > List.

2. Use the ﬁlte r to narrow the list of recordings. Enter the desired ﬁlter criteria and click Filter. Som e ﬁlters may take

a long time to complete.

3. Select the recording.

4. Click Play to play the recording, or click Download to download the recording.

Multiple recordings can be downloaded at the same time. Selec t the recordings and click Download. The dow nloaded ﬁle is a zip ﬁle

containing a minimum of three ﬁles, of which the Matroska (mkv) ﬁlesaretheactualrecordings.The recordings are time-stamped

with the date and time they were downloaded (that is, not the date the

recordings were made).

Note

To play recordings in Windows M edia Player, A XIS M atroska File S plitte r must be installed. AXIS Matroska File Spl itter

can be downloaded from www.axis.com/techsup/software

For de tai led recor ding and video information, se lect a recording a nd click Properties.

To remove a recording, select the recording and click Remove.

Continuous Recording

TheAxisproductcanbeconﬁgured to continuously save video to a storage device. See

Storage on page 41

for more information

about s torage devices. To prevent the disk from becoming full, it is recommended to conﬁgure the disk to automatically rem ove

old recordings.

To start a continuous recording, follow these steps:

1. Go to Recordings > Continuous.

2. Select Enabled.

3. Select type of storage device from the Disk list.

4. Select a Stream proﬁle to use for continuous recordings.

5. Click Save to save and start the recording.

AXIS M3006–V Network Camera

Recordings

Note

If a new stream proﬁle is selected while a recording is ongoing, the recording will be stopped and saved in the recording list

and a new recording with the new stream proﬁle will star t. All previous continuous recordings will remain i n the recording

list until the y are remove d m anua lly or through automatic r em o val o f old recordings .

AXIS M3006–V Network Camera

System Op tion s

System Options

Security

Users

User access control is enabled by default and can be conﬁgured under System Options > Security > Users. An administrator can

set up other users by giving them user names and passwords. It is also po ssible to allow anonymous viewer login, which means

that anybody may access the Live View page.

The user list displays authorized users and user g roups (access levels):

Viewer - Access to the Live View page

Operator - Access to the Live View page and to all settings except System Options

Administrator - Unrestricted access to all s ettings; can add, modify and remove other users.

Under HTTP/RTSPPasswordSettings, select the type of password to allow. You may need to allow unencrypted passwords if there

are viewing clients that do not support encryption, or if you upgraded the ﬁrmware and existing clients support encryption but need

to log in again and be conﬁguredtousethisfunctionality.

Under User Settings, select the Enable anonymous viewer login option to allow anonymous users access to the Live View page.

Select the Enable anonymous PTZ control login to allow anonymo us users access to the PTZ controls.

Deselect the Enable Basic Setup option to hide the Basic Setup menu. Basic Setup pr ovides quick access to settings that should be

made before using the Axis product.

ONVIF

ONVIF (Open Network Video Interface Forum) is a g lobal interfa ce standard tha t makes it eas ie r for e n d users, integrators, consultants,

and m a nufactur ers to take advantage of the p o ssibiliti es offered by network vide o technology. ONV IF ena bles intero per abli ty betwe e n

different vendor products, increased ﬂexibility, red

uced cost and future-proof systems.

By creating a user you automa ticall

y enable ONVIF communication. Use the user name and password with all ONVIF comm unication

with the product. For more information see www.onvif.org

IP Address Filter

IP address ﬁltering is ena bled on the System Options > Security > IP Address F ilter page. Once enabled, the listed IP address are

allowed or denied a cces

s to the Axis product. Select Allow or Deny from the list and click Apply to e n able IP ad dre ss ﬁltering.

The administr

ator can add up to 256 IP address entries to the list (a single e ntry can conta in multiple IP addre sses) .

HTTPS

The Axis product supports encrypted browsing using H TTPS. This is conﬁgured on the System Options > Security > HTTPS page.

A self-signed certiﬁcate can be used until a Certiﬁcate Authority-issued certiﬁcate has been obtained. Click Create self-signed

certiﬁcate to ins tall a self-signe d certiﬁcate. Although self-signed certiﬁcates are free and offer some protection, true security is only

implemented a fter the installation of a signed certiﬁcate issued by a Certiﬁca te Authority.

To o btain a signed certiﬁcate from an issuing Certiﬁcate Authority, click Create Certiﬁcate Request. When the signed certiﬁca te

is re turned, c lick Install signed certiﬁcate to import the certiﬁcate. The prop erties of any certiﬁcate request currently resident in

the product or installed can be viewed by clicking Properties.

To enable HTTPS in the Axis p roduct, the HTTPS Connection Policy must be set for each user group.

For more information, see the online help

AXIS M3006–V Network Camera

System Op tion s

IEEE 802.1X

IEEE 802.1X is a standard for port-based Network Admission Control p roviding secure authentication of wired and wireless network

devices. IEEE 802.1X is based on EAP (Extensible Authentication Protocol).

To access a network protected by IEEE 802.1X, devices must authenticate themselves. The authentication is performed by a

third-party entity called an authe nti cation s e rver , typically a RADIUS server, examples of which are FreeRADIUS and Microsoft

Internet Authentication Service.

In Axis' im plementation, the network device and the authentication server authenticate themselves with the help of digital

certiﬁcates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security). The certiﬁcates are provided by an

Certiﬁcation Authority (CA). You need:

•aCAcertiﬁca te to validate the identity of the authentication server

• a CA -signed c lie nt certiﬁca te and a private key to authenticate the network device.

To allow the network device to access a network protected by IEEE 802.1X:

1. Obtain a CA certiﬁcate, a client certiﬁcate and a client private key (contact your network administrator).

2. Go to Setup > System Options > Security > IEEE 802.1X and upload the CA certiﬁ cate, the client certiﬁcate and the

client private key.

3. Under Settings, select the EAPOL version, provide your EAP identity and private key password.

4. Check the box to enable IEEE 802.1X and click Save.

Certiﬁcates

CA Certiﬁcate The CA certiﬁcate is used to validate the identity of the authentication server. Enter the path to

the certiﬁcate directly, or locate the ﬁle using the Browse button. Then click U

pload.Toremove

acertiﬁcate , click Remove.

Client certiﬁcate

Client private key

The client certiﬁcate and private key are used to authen tica te the network device. They can be

uploaded as separate ﬁles or in one combined ﬁle (e.g. a PFX ﬁle or a PEM ﬁle). Use the Client

private key ﬁeld i f uploading one combined ﬁle. For each ﬁle, enter the path to the ﬁ le

, or locate the

ﬁle using the Browse button. Then click Upload.Toremoveaﬁle, click Remove.

Settings

EAPOL version

SelecttheEAPOLversion(1or2)asusedinyournetworkswitch.

EAP identity

Enter the user identity (maximum 16 chara cters) associated with your certiﬁcate.

Private key password

Enter the password (maximum

16 characters) for the private key.

Enable IEEE 802.1X

Check the box to enable the IEEE 802.1X protocol.

Date & T ime

The Axis product’s date and time settings are conﬁgured under System Options > Date & Time.

Current Server Time displays the current date and time (24h clock). The time can be d isplayed in 12h clock in the text overlay (see

below).

To cha n ge the date and time setting s, select the preferred Time mode under New Server Time:

• Synchronize with computer time sets date and time according to the com puter’s clock. W ith this option, date a nd

time are set once and w ill not be upd ated automatically.

• Synchronize with NTP Server obtains date and time from an NTP server. With this option, date a nd time settings are

updated con tinuously. F or information on NTP settings, see

NTP Conﬁguration on page 38

AXIS M3006–V Network Camera

System Op tion s

If using a host name for the NTP server, a DNS server must be conﬁgured. See

DNS Conﬁguration on page 38

• Set manually allow s you to manually set date an d time.

If using an NTP server, select your Time zone from the drop-down list. If required , check Automatically a djust for daylight saving

time changes.

The Date & Time Format Used in Images is the date and time format displayed as a text overlay in the video stream. Use the

predeﬁned formats or see

File Naming & Date/Time Formats

in the online help for information on how to create custom date and

time formats. To include date and time in the overlay text, go to Video and select Include date and Include time.

Network

Basic TCP/IP Settings

The Axis product supports IP version 4 and IP version 6. Both versions can be enabled simultaneo usly, and at least one version

must always be enabled.

IPv4 Address Conﬁguration

By default, the Axis product is set to use IPv4 (IP version 4) and to obtain the IP address automatically via D HCP. The IPv4 settings are

conﬁgured under System Options > Network > TCP/IP > Basic.

DHCP (Dynamic Host Conﬁguration Protocol) allows network administrators to centrally manage and automate the assignment of

IP addresses. DHCP should only be enabled if using dynamic IP address n otiﬁcatio n, or if the DHCP can update a DN S server. It is

then possible to access the Axis product by name (host name).

If DH CP is enabled and the p roduct cannot be accessed, run A X IS IP Utility to search the network for connected Axis products, or reset

the product to the factory d efa ult settings (see

page 44

) and then perform the installation again.

To use a static IP addres s, check Use the following IP a ddress and specify the IP address, subnet mask and d efault router.

IPv6 Address Conﬁguration

If IPv6 (IP version 6) is enabled, the Axis product will receive an IP address according to the conﬁguration in the network router.

To enable IPv6, go to System O ptions > Network > TCP/IP > Basic. Other settings for IPv6 should be conﬁgured in the network router.

ARP/Ping

The product’s IP address can be assigned usingARPandPing.Forinstructions,see

Assign IP Address using ARP/Ping on page 36

The ARP/Ping service is enabled by default but is automatically disabled two minutes after the product is s tarte d, or as s oon as an IP

address is assigned. To re-assig n IP address using ARP/Ping, the product must be restarted to enable ARP/Ping for an additional

two m inutes.

To disable the service, go to System Options > Network > TCP/IP > Basic and clear the option Enable ARP/Ping setting of IP address.

Pinging the product is still possible when the service is disabled.

Assign IP Address using ARP/Ping

The product's IP address can be assigned using ARP/Ping . The command must be issued within 2 m inutes of connecting power.

1. Acquire a free static IP address on the same network segment a s the computer .

2. Locate the s erial number (S/N) o n the product label.

3. Open a com mand prompt and enter the following commands:

AXIS M3006–V Network Camera

System Op tion s

Linux/Unix syntax

arp -s <IP address> <serial number> temp

ping -s 408 <IP address>

Linux/Unix example

arp -s 192.168.0.125 00:40:8c:18:10:00 temp

ping -s 408 408 192.168.0.125

Windows syntax (this may require that you run the command prompt as an administrator)

arp -s <IP address> <serial number>

ping -l 408 -t <IP address>

Windows example (this m ay require that you run the command prompt as an administrator)

arp -s 192.168.0.125 00-40-8c-18-10-00

ping -l 408 -t 192.168.0.125

4. Check that the network cable is connected to the Axis product and then restart the product by disconnecting and

reconnecting power.

5. Close the command promp t when the product responds with Reply from 192.168.0.125:... or sim ilar.

6. Open a browser and type http://<IP address> in the Location/Address ﬁeld.

For other methods of assigning the IP address, see the Installation and Management Software CD or the document

Assign an IP

Address a nd Access the Video Stream

on Axis Su pport web at www.axis.com/techsup

Note

• To open a command prompt in Windows, open the Start menu and type cmd in the Run/Search ﬁeld.

• To use the ARP command in Window s 7/Windows Vista, right-click the com m and prompt icon and select Run as

administrator.

• To open a command prompt in Mac O S X, open the Terminal utility from Application > Utilities.

AXIS Video Hosting System (AVHS)

AVHS used in conjunction with an AVHS service, provides easy and secure Internet access to live and recorded video accessible from

any location. For more information and help to ﬁnd a local AVHS Service Provider go to www .axis.com/hosting

AVHS i s enabled by default. The settings are conﬁgured under System Options > Network > TCP IP > Basic.

One-click enabled - Press the product’s control button (see

Hardware Overvi ew on pag e 4

) to connect to an AVHS service over the

Internet. Once registered, Always will be enabled and the Axis product stays connected to the AVHS service. If the product is not

registered within 24 hours from when the b utton is pressed, the product will disconnect from the AVHS service.

Always - The Axis product will constantly attempt to connect to the AVHS service over the Internet. Once registered the product will

stay connected to the service. This option can be used when the product is already installed and it is not convenient to use the

one-click installation.

AXIS Internet Dynam ic DNS Service

AXIS Internet Dynamic D NS Service assigns a host name for easy access to the product. For more informati o n, s ee www.axiscam .ne t

To regis ter the Axis product with AXIS Inte rne t Dynamic DNS Service, go to System Options > Network > TCP/IP > Basic.Under

Services, click the AXIS Internet Dynamic D N S Service Settings button (requires access to the Internet). The domain name currently

registered at AXIS Internet Dynamic DNS service for the product can at any time be removed.

AXIS M3006–V Network Camera

System Op tion s

Advanced TCP/IP Settings

DNS Conﬁ guration

DNS (Domain Name Service) provides the translation of host names to IP addresses. The DNS settings are conﬁgured under System

Options > Network > TCP/IP > Advanced.

Select Obtain DNS server address via DHCP to use the DNS settings pro vided by the DHCP server.

To make manual settings, select Use the following DNS server address and specify the following:

Domain na me - Enter the do main(s) to search for the host name used by the Axis product. Multiple domains can be separ ate d by

semicolons. The host name is always the ﬁrstpartofafullyqualiﬁed domain name, for example, myserver is the host nam e in the

fully qualiﬁ e d domai n name myserver.mycompany.com where mycompany.com i s the domain name.

Primary/Secondary DNS server - Enter the IP addresses of the primary and secondary DNS servers. The secondary DNS serve r is

optional and will be used if the primary is unavailable.

NTP Conﬁguration

NTP (Netwo rk Time Protocol) is used to synchronize the clock times of devices in a network. The NTP settings are conﬁgured under

System Options > Network > TCP/IP > Advanced.

Select Obtain NTP server address via DHCP to use the NTP settings provided by the DHCP server.

To make manual settings, select Use the following NTP server address and enter the host name or IP address of the N TP server.

Host Name Conﬁguration

The Axis p r odu c t can be accessed u s in g a host name in s tead of an IP addres s. The host name is u su a lly the same as the assigned DNS

name. The host name is conﬁgured under System Options > Network > TCP/IP > Advanced.

Select Obtain host name via IPv4 DHCP to use host name provided by the DHCP server running on IPv4.

Select Use the host name to set the host name manually.

Select Enable dynamic DNS updates to dynam ically update local DNS servers whenever the Axis product’s IP address changes.

For more information, see the online help

Link-Local IPv4 Address

Link-Local Address is enabled by default and assigns the Axis product an additional IP address whichcanbeusedtoaccess

the product from other hosts on the same segment on the local network. The product can have a Link-Local IP and a static

or DHCP-supplie d IP address at the same time.

This f unction can be disa ble d under System Options > N etwork > TCP/IP > Advanced.

HTTP

The HTTP port used by the Axis product can be changed under System Options > Network > TCP/IP > Advanced. In addition to the

default s etting, w hich is 80, any port in the range 1024–65535 can be used.

HTTPS

The HTTPS port used by the Axis product can be changed under System Options > Network > TCP/IP > Advanced. In addition to

the default setting, which is 443, any port in the range 1024–65535 can be used.

To enab le HTTPS, go to System Options > Security > HTTPS. For m ore inform a tion, see

page 34

AXIS M3006–V Network Camera

System Op tion s

NAT traversal (port mapping) for IPv4

A network router all ows devices on a private netw ork (LAN) to share a single connection to the Interne t. This is done by forwarding

network trafﬁc from the private network to the “outside”, that is, the Internet. Security on the private network (LAN) is increased

since most routers are pre-conﬁgured to stop attempts to access the private netw ork (LAN) from the public network (Internet).

Use NAT traversal when the Axis product is located on an intranet (LAN) and you wish to make it a va ila ble from the other

(WAN) side of a NAT ro u te r. With NAT trave rs al prope rly c onﬁgured, all HTTP trafﬁc to an external HTTP port in the NA T router

isforwardedtotheproduct.

NAT traversal is con ﬁgured under System Options > Network > TCP/IP > Advanced.

Note

• For NAT traversal to work, this m us t be sup porte d by the router. The router must also support UPnP

• The router has many different names: “NAT router”, “Network ro uter”, “Internet Gateway”, ”Broa dband router ”, “Broadband

sharing device” or “Home ﬁ rewall” but the essential purp ose of the device is the same.

Enable/Disable - W hen enabled, the Axis product attempts to conﬁgure port mapping in a NAT router on your network, using UPnP

Note that UPnP

must be enabled in the product (see System Options > Network > UPnP).

Use m a nua lly selected NAT router - Select this option to manually select a N AT router and enter the IP address for the router in

the ﬁeld. If no router is speciﬁed, the product automatically searches for NAT routers on yo ur network. If more than one router is

found, the d efault router is selected.

Alternative HTTP port - Select this op tion to manually de ﬁne an external HTTP port. Enter the port number in the ﬁeld. If no port is

entered here, a port numbe r is automat ically sele cte d when NA T trave rs al is enable d.

Note

• An alternative H TTP port can be used or be active even if NA T traversal is disabled. This is useful if your NAT router does

not support UPnP and you need to manually con ﬁgure p ort forwarding in the NAT router.

• If you attem pt to m anual ly enter a port that is already in use , another a vailable port is automatically selected.

• When the port is selected automatically it is displaye d in this ﬁeld. To change this, enter a new port number and click Save.

FTP

The FTP server running in the Axis product enables upload o f new ﬁrmware, user applications, etc . The FTP server can be disabled

under System Options > Network > TCP/IP > Advanced.

Note

This FTP server has nothing to do w ith the product’s ability to trans fe r images via FTP to othe r l ocations and servers .

RTSP

The RTSP server running in the Axis product allows a connecting client to start an H.264 stream. The RTSP port number can be

changed under System Options > Network > TCP/IP > Advanced. The default port is 554.

Note

H.264 video streams will not be a va ilable if the RTSP server is disabled.

SOCKS

SOCKS is a networking proxy protocol. The Axis product can be conﬁgured to use a SOCKS server to reach networks on the other

side of a ﬁrewall or proxy server. This functionality is useful if the Axis product is located on a lo cal network behind a ﬁrewall, and

notiﬁcations, uploads, alarms, etc need to be sent to a destination outside the local netw ork (for example the Internet).

SOCKS is conﬁgured under System Options > Network > SOCKS. For more information, see the online help

AXIS M3006–V Network Camera

System Op tion s

QoS (Quality of Service)

QoS (Quality of Service) guarantees a certain level of a speciﬁed resource to selected trafﬁc on a network. A QoS-aware network

prioritizes netw o rk trafﬁc a nd provides a gre ate r network reliability by controlling the amount of bandwidth an application m ay use.

The QoS settings are conﬁgured under System Options > Network > QoS. Using DSCP (Differentiated Services Codepoint) values, the

Axis product can mark the fo llow ing types of trafﬁc: live v ide o, event/alarm trafﬁc and management trafﬁc.

SMTP (email)

To send email messages from the Axis pro d uct via SMTP (Simple Mail Transfer Protocol), an SMTP mail server must be set up. This

is done under System O ptions > Network > SMTP (email).

Enter the host names or IP ad dresses and port numbers for the primary and secondary mail servers in the ﬁelds provided. A From

email address is also required . If the mail server re quires authentication, check Use authentication to log in to this server and enter

the ne ces sa ry information.

SNMP

The Simple Network Manag ement Protocol (SNMP) allows remote manag ement of network devices. An SNM P community is the

group of devices and management station running SNMP. Community names are used to identify groups.

The Axis product can be conﬁgured to support SNMP on the System Options > Network > SNMP page.

Depending on the level of security required, select the version on SNMP to use.

SNMP v1/v2 provides the lowest level of security. The community name can be speciﬁed as a password for read or read/write

access to all supported SNMP devices. The default passw ord for the Read community is public and the default passw ord for the

Write community is write.

Note

If HTTPS is enabled, SNM P v1 and SNMP v2c should be disabled.

Traps for SNMP v1/v2 are used by the Axis product to send message s to a manageme nt sy

stem on im porta nt events and status

changes. Check Enable traps and enter the IP address where the trap m essage should be sent and the Trap community that

should receive the message.

The follow ing traps are available:

•Coldstart

•Warmstart

•Linkup

• Authentication failed

SNMP v3 provid es encryption and secure passw ords. To use traps with SNMP v3, an SNMP v3 management application is required.

To use SNMP v3, HTTPS must be enabled, see

HTTPS on page 34

. To enable SNMP v3, check the box and provide the initial user

password.

Note

The initial password can only be set once. If the p assword is lost, the Axis product must be reset to factory default, see

Reset to Factory Default Settings on page 44

UPnP

The Axis pro duct includes support for UPnP

.UPnP

is enabled by default and the product is automatically detected by operating

systems and clients that support this protocol.

UPnP

can be disa ble d under System Options > Network > UPnP

AXIS M3006–V Network Camera

System Op tion s

RTP/H.264

The RTP port range and multicast s etting s are conﬁgured under System Options > Network > RTP.

The RTP port range de ﬁne s the range of ports from which the video ports are automatically selecte d. For multicast strea m s, only

certain IP addresses and po rt numbers should be used.

Select Alw ays Multicast Video to start mul ticast stream ing without opening an RTSP session.

Bonjour

The Axis product includes support for Bonjour. Bonjour is enabled by default and the product is automatically detected by operating

systems and clients that support this protocol.

Bonjour can be disabled under System Options > Network > Bonjour .

Storage

SD Card

NOTICE

To prevent corruption of recordings, the SD card should a lways be unmounted befo re it is ejected.

The Axis product supports SD cards with the follow ing ﬁle systems:

• ext4 — recom m e nde d due to its resilience against data loss if the card is ejected or if there is abrupt pow er loss. To a ccess

data stored on the card f rom the Window s operating system, a third- party ext4 driver or application is r equired.

• vFAT — most SD cards are pre-formatted with vFAT when purchased.

If required , the SD card can be re-formatted to the desired ﬁle system. To format the SD card:

1. Insert the SD card in the SD card slot.

2. Go to System Options > Storage an d click SD Card.

3. Click Format and select the desired ﬁle system.

Note

During formatting any pre vious data stored on the disk will be los t.

Mounting is done automatically when the card is inserted or when the product is started . A manual mount is only required if the

card has been unmounted and not ejected a nd re-inserted.

To unmount the SD card:

1. Go to System Options > Storage an d click SD Card.

2. Click Unmount.

3. The card can now be removed.

The SD card is managed on the System Options > Storage page. Click SD Card to open Storage Management.

If the c ard’s status shows as failed, click Check disk to see if the problem can be found and then try Repair. This option is only

available for S D cards w ith ext4. For SD cards with vFAT, use a card reader or computer to troubleshoot the card.

To avoid ﬁlling the card, it is recom m e nde d to remove recordings continuously. U nder Recording Settings, select Remove recordings

older than and select the number of days or weeks.

To stop writing to the card and protect recordings from being remove d, select Lock under Recording Settings.

AXIS M3006–V Network Camera

System Op tion s

Network Share

Network share allow s you to add network storage such as a NAS (Network Attached Storage) or any server that uses CIFS (Common

Internet File System) and use them for storage of recordings.

To add a network share:

1. Go to System Options > Storage.

2. Click Network Share.

3. Enter the IP address, DNS or Bonjour name to the host server in the Host ﬁeld.

4. Enter the name of the share in the Share ﬁeld.

5. If required, select The share requires login and enter the user name and password .

6. Click Connect.

To clear all recordings a nd data f rom the A xis product’s folder on the designated share, click Clear under Storage Tools.

To a void ﬁlling the share, it is recommended to remove recordings continuously. Under Re cording Settings,selectR emove recordings

older than and select the number of days or weeks.

To stop w riting to the share and protect recordings fro m being removed, select Lock under Recording Settings.

Maintenance

The Axis product provides several maintenance functions. These are available under System Options > Maintenance.

Click Restart to perform a co rrect restart if the Axis product is not b ehaving as expected. This will not affect any of the current

settings.

Click Restore to reset most settings to the factory defa u lt values. The following settings a re not affected:

• the boot protocol (DHCP or static)

• the static IP addr ess

• the default router

• the subnet mask

•thesystemtime

• the IEEE 802.1X settings

Click Default to reset all settings, including the IP address, to the factory default values. This button should be used with caution. The

xis product can also be reset to factory default using the control button, see

Reset to Factory Defa ult Settings on page 44

To identify the product or test the Status LED, click Fla sh LED under Identify and specify the duration in seconds, minutes or hours.

This can be useful for identifying the product am ong other products installed in the same locati on.

For information about ﬁrmware upgrade, see

Upgrading the Firmw are on pag e 45

Support

Support Overview

The System Options > Support > Support Overview page provides information on troubleshooting and contact information,

should you require technical assistance.

Axis M3006-V~EOLFixed Mini Dome Camera 0514-001

Product's Documents

User Manual

Specifications

Axis M3006-V~EOL Questions and Answers
