Soundcore Sport X10
USER MANUAL
01 EN
Charging
• Fully dry off the earbuds and the USB port before charging.
• Use a certified USB-C charging cable and charger to prevent any damage.
• Fully charge both the earbuds and the charging case before the first use.
1. Place the earbuds in the charging case and close it.
2. Connect the charging case to the power supply by using a USB-C charging
cable.
The LED indicator on the charging case indicates the charging status.
1 2
3
Wearing
1. Choose the Ear Tips that fit your ears best.
2. Insert the earbuds into the inner canal of your ears and turn gently until you find
the most comfortable and secure position.
XL
M
XS S L
1 2 3
• Your earbuds come with 5 pairs of Ear Tips, among which Medium-sized are
pre-installed.
02 EN
Powering On/Off
• Open the charging case, the earbuds will automatically power on.
• To power off, place the earbuds into the charging case and close it.
ON
OFF
• The earbuds will automatically power off after 10 minutes if no device is
connected.
• To manually power on, press and hold the multi-function button on both
earbuds for 3 seconds.
Bluetooth Pairing
1. Open the charging case, and press the button on the charging case for 3
seconds to enter Bluetooth pairing mode.
• The 3 LED indicators on the charging case will flash white in sequence
continuously.
2. Select “Soundcore Sport X10” on your device’s Bluetooth list to connect.
• When successfully connected, the 3 LED indicators will turn white for 3
seconds and then turn off.
03 EN
Soundcore
Sport X10
Soundcore
Sport X10
PAIRING
CONNECTED
3s
3s
• Pairing with another device: Place the earbuds in the charging case and leave
the case open. To enter pairing mode, press and hold the button on the case
for 3 seconds until the 3 LED indicators flash white in sequence continuously.
• Each time you power on your Soundcore earbuds, they will automatically
connect to your last successfully connected device if available within the
Bluetooth range.
• Mono mode: When Bluetooth connected, you can use either one of the
earbuds only by placing the other one into the charging case.
• When powered on and connected, if either one of the earbuds is out of
battery and powered off, you can keep using the other one.
• When you are on a call, place either one of the earbuds into the charging case,
and the microphone in the other earbud will be activated.
Controls
Stereo Mode
Play/Pause Press twice (R)
Next track Press twice (L)
Volume up Press once (R)
Volume down Press once (L)
ANC Press and hold for 2 seconds(R/L)
04 EN
Answer a call Press once(R/L)
End a call/Reject a call Press and hold for 2 seconds(R/L)
Mono Mode
Play/Pause Press twice
Answer a call Press once
End a call/Reject a call
Press and hold for 2 seconds
Activate Siri or other voice assistant
software
Soundcore App
Download the Soundcore App to customize the user interface (e.g. adjust volume,
control playback, activate Siri), adjust EQ, switch ANC modes, update firmware,
and explore more.
Reset
• You might need to reset the earbuds if you experience any connectivity
problems or function issues.
05 EN
1. Place the earbuds in the charging case and leave the case open.
2. Press and hold the button on the charging case for 10 seconds until the LED
indicators on the case flash white 3 times and then flash in sequence. This
confirms that the reset was successful and your earbuds can be connected
normally.
1
2
10s
×3
Specifications
Specifications are subject to change without notice.
Input 5 V 0.5 A
Rated output power 5 mW (@1% THD)
Battery capacity
55 mAh x 2 (earbuds);
540 mAh (charging case)
Charging time 2 hours
Playtime
(varies by volume level and content)
Up to 8 hours
(Total 32 hours with the charging case)
Driver size 10 mm x 2
Frequency response 20 Hz - 20 kHz
Impedance 32 Ω
Waterproof level IPX7(earbuds)
Bluetooth version 5.2
Bluetooth range 10 m / 33 ft
