TV
Manufacturer/Brand
Set-Up Code Number
MOTOROLA 002 148 206 253
PACE 001 005 002 206 217
PIONEER 001 103 034 051 063 076 105
SAMSUNG 001 030
SCIENTIFIC ATLANTA/CISCO
001 003 041 042 045 046
ADB 254
Amino 219 235 260 321
ARRIS 172 216 140 234 242
Bell Fibe 229
Blue Stream 238
BT Vision 232 960
Cincinnati Bell 220
Cox Digital Cable 223
Digital Multimedia Technology
222
Dish Network 122
Duoson 218
Entone 221 213
EVOLUTION 189 215
Foxtel 228
Frontier 239
Horizon 225
Humax 231
Layer3 226
Optimum 236 237
Pico Digital 224
Sky 240 241
Spectrum 231
TECHNICOLOR 365
Virgin Media 959
WINDSTREAM 212
ZeeVee 227
A MARK 112 143
ACCURIAN 036
ADMIRAL 072 251 333
AD NOTAM 672
ADVENT 247 388
ADVENTURA 002
AFFINITY 680
AKAI 116 248 404 405 473 475 323 387 391 615
ALBATRON 017
ALERON 028
AMERICA ACTION 043
AMPRO 073
AMSTRAD 052
ANAM 043 054 056 080 112
AOC 116 363 112 616
APEX 572
APEX DIGITAL 006 724
AQUAVISION 573 574 686 904
ASTAR 477
AUDIOVOX 076 454 388
AUVIO 689
AVENTURA 052
Avera 761
AVIELO 627 628
AVION 441
CBL
Manufacturer/Brand
Set-Up Code Number
*Note : To return TV device to CBL channel
repeat steps above replacing [TV] with
[CBL] in Step 3.
I. Programming a ‘Macro’ button.
If your remote model has custom-programmable
Macro buttons available(See Section 4), they
can be programmed to act as a ‘Macro’ or
Favorite Channel button in CABLE mode. This
allows you to program up to five 2-digit channels,
four 3-digit channels or three 4-digit channels
that can be accessed with one button press.
STEP1
Press the [CBL] button to select the CBL
mode.
STEP2
Press the [MACRO] button and
[OK/SEL] button simultaneously for 3
seconds. The [CBL] button will turn
on for 30 seconds.
STEP3
Enter the the 2, 3 or 4-digit code for the
channel you want programmed first (for
example, 007) using the Number Pad,
then press the [STOP] button. Then
enter the code for the next channel (for
example, 050), then press the [STOP]
button. Repeat this process for the third
channel. The [CBL] button will blink
once for each channel entered.
STEP4
Press the [CH5] button to store the
channels that were selected. The
[CBL] button will blink twice to confirm
the storage of commands.
To access the programmed channels, press
the [MACRO] button once. This will bring up
the first channel. Press once again and it will
bring up the second channel. Press again and
it will bring up the third channel.
J Low Battery Warning
When the batteries are low and need to be
replaced with fresh batteries, the Device LED
lights will blink 2 times in sequence whenever a
[POWER] button is pressed to turn on equipment.
K. Memory Lock System
This remote control is designed to retain pro-
grammed memory for 10 years even after bat-
teries are removed from the remote control.
L. Record Your Component Set-up Codes
TV Set-up Code Number:
VCR Set-up Code Number:
DVD Set-up Code Number:
AUX Set-up Code Number:
For additional information about your remote
control, go to www.universalremote.com
A. Quick Setup Method
It’s easy to program the remote control to oper-
ate your TV. Simply press the number buttons 0
through 9 that your TV brand is assigned to
using the following four steps.
STEP1
Manually turn on the TV you wish to
program.
STEP2 Press and hold simultaneously for 3
seconds both the TV and A (Yellow)
buttons or B (Blue) buttons, based
on the column your TV brand is
assigned to. The TV button LED light
will turn on for 30 seconds confirm-
ing that you are in the program
mode.
STEP3
While the TV button LED is on, point
the remote control at the TV and
press the number button assigned to
your TV brand as shown in the table
(e.g. for Sharp TV, button 5 ). The TV
should turn off. If it does not, press the
same number button repeatedly until
the TV turns off.
*Note : The remote will exit the programming
mode automatically if it does not have
matching codes and the LED will turn off.
STEP4
Once the TV has turned off, press the
TV button once again to save the
code. The remote control is now
ready to control your TV.
Repeat the above steps for all other compo-
nents (TV, VCR, DVD, etc.).
*Note : If the matching code could not be found in
STEP3, use 3-Digit Code Method or Auto
Search Method.
Quick Set-up Code Tables
Cable Remote Control
Operating Instructions For
CLIKR
TM
-5
Universal Remote Control, Inc.
www.universalremote.com
OCE-0060L REV 27 (03/21/23)
1
Introduction
4
Button Functions
5
Programming the Remote Control
2
Replacing Batteries
3
Operations
The CLIKR
TM
-5 UR5U-8780L & UR5U-8790L is
designed to operate the CISCO / SA, Pioneer,
Pace Micro, Samsung and Motorola digital
set tops, Plus the majority of TV, VCR, DVD
and AUX equipment on the market as
shown below.
B. 3-Dight Code Method
STEP1
Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, VCR, DVD, etc.).
STEP2
Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The corresponding
device LED will turn on indicating that
it is ready to be programmed. The LED
will remain on for 30 seconds. The
next step must be entered while the
LED is on.
STEP3
Point the remote control toward the
equipment and enter the three-digit
code number assigned to your brand
from the code tables. If there are more
than one three-digit number listed for
your brand, try one code number at a
time until your equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.) to
ensure you have the correct code. If any
of the functions do not operate as they
should, repeat the instructions from
STEP 3 above using the next three digit
code number from the brand list.
STEP4
Store the three-digit code by pressing
the same [DEVICE] button once
again. The device LED will blink twice
to confirm that the code has been
stored.
C. Auto Search Method
If none of the three digit code numbers
assigned to your brand of equipment works, or
the code table does not list your brand, you can
use the Auto Search Method to find the correct
three-digit code number for your equipment by
following steps:
STEP1
Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, VCR, DVD, etc.).
STEP2
Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The device LED will
turn on indicating that it is ready to be
programmed. The LED will remain on
for 30 seconds. The next step must be
entered while the LED is on.
STEP3
Press the [CH5] or [CH6] button one
at a time or keep it pressed. The
remote will emit a series of Power
ON/OFF code signals. Release the
[CH5] or [CH6] button as soon as the
equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.) to
ensure you have the correct code. If any of
the functions do not operate as they should,
repeat the instructions from STEP 3 above
to continue the Auto Search Method.
STEP4
Press the same [DEVICE] button to
store the code. The Device LED will
blink twice to confirm that the code
has been stored.
D. To Identify the 3-Digit Code
Programmed for a Device
STEP1
Press the appropriate [DEVICE] button
and the [OK/SEL] button simultaneously
for three seconds. The device LED will
turn on for 30 seconds. The next step
must be performed while the LED is on.
STEP2
Press the [INFO] button. The device LED
will blink a number of times indicating
the number of each digit for the code.
Each digit is separated by a one second
interval of the LED being off.
Example : One blink, (pause) three blinks,
(pause) eight blinks indicates the
code number 138.
*Note : Ten blinks indicates the number 0.
E. Programming the AUX Device
You can take advantage of the AUX function to
program a devices such as a media PC, gam-
ing console or satellite radio receiver. Follow
the instruction in section B to program an AUX
device. You can also program the AUX button
for a second TV, VCR or DVD player. To do this
follow the instructions below.
STEP1
Turn on the 5th device you want to
program (TV, VCR, DVD, etc.).
STEP2
Press the [AUX] button and the
[OK/SEL] button simultaneously for 3
seconds. The [AUX] device LED will
turn on for 30 seconds.
STEP3
Press the [Device] button For the type of
device you want to setup. Point the
remote control toward the device and
enter the 3-digit code number assigned
to your brand.
*Note : To program a second TV press TV, etc.
STEP4
When the equipment turns off verify
that you have selected the correct
code by pressing the [POWER] button.
The equipment should turn back on.
Then try all of the functions on the
remote control (i.e. volume, mute, etc.)
to ensure you have the correct code.
If any of the functions do not operate
as they should, enter the next 3-digit
code number from the brand list.
STEP5
Once you have found the correct
3-digit code, save it by pressing the
[AUX] button one more time. The [AUX]
LED light will blink twice to confirm the
code was stored.
F. Programming the System
On/Off Button
This allows you to program the System On/Off
button so it can send up to five power On/Off
commands with one button press.
STEP1
Press the [CBL] button.
STEP2
Press the [SYSTEM ON/OFF] button
and the [OK/SEL] button simultaneously
for 3 seconds. The [CBL] button will turn
on for 30 seconds.
STEP3
Press the first [DEVICE] button you want
to store in the [SYSTEM ON/OFF] button
and then press [POWER]. Repeat this for
the other components you want to turn
on/off with the [SYSTEM ON/OFF] button.
STEP4
Press the [CH5] button to save the
power commands you stored. The
[CBL] button will blink twice to confirm
the commands have been saved.
G. Programming Volume Control
Volume and Mute control are factory programmed
to automatically transfer to the respective Device
mode You select, as follows:
CBL :TV T V :TV VCR :TV
DVD :TV AUX :AUX
If you wish to store the CBL volume control in
CBL mode, use the following steps.
STEP1
Press the [OK/SEL] button and [CBL]
button simultaneously for three
seconds. The device LED will turn on
for 30 seconds. The next step must
be performed while the LED is on.
STEP2
Press the [VOL5] button. The device
LED will blink.
STEP3
Press [CBL] button. The device LED will
blink twice to confirm the programming.
*Note : To return CBL device to TV volume
repeat steps above replacing [CBL]
with [TV] in Step 3.
H. Programming Channel Control
You can program the channel controls (Channel
Up, Channel Down, Last and Numbers) from
one Device to operate in another Device mode.
Default channel control settings on the remote
control are as follows:
CBL : CBL T V : CBL VCR : CBL
DVD :DVD AUX : AUX
If you wish to store the TV channel controls in
TV mode, use the following steps.
STEP1
Press the [OK/SEL] button and [TV] button
simultaneously for three seconds. The
device LED will turn on for 30 seconds.
The next step must be performed while
the LED is on.
STEP2
Press the [VOL6] button. The device
LED will blink.
STEP3
Press [TV] button. The device LED will
blink twice to confirm the programming.
Before you program or operate the remote control,
you must install two new AA alkaline batteries.
STEP1 Remove the battery compartment cover
on the back of your remote control.
STEP2 Check battery polarity carefully, and
install the batteries as shown in the
illustration below.
STEP3 Replace the battery compartment cover.
CBL : Cable Set-top Box TV : Televisions
VCR : VCRs and TV/VCRs DVD : DVD Players
AUX : Audio Equipment, Media PC, etc.
0 RCA
1 SAMSUNG
2 SONY
3LG
4 VIZIO
5 SHARP
6 PANASONIC
7 SANYO
8 TOSHIBA
9 PHILIPS
0 COBY
1 MITSUBISHI
2 HITACHI
3 MAGNAVOX
4 JVC
5 ZENITH
6 INSIGNIA
7 EMERSON
8 WESTINGHOUSE
9TCL
TV
Manufacturer/Brand
Set-Up Code Number
AXESS 711
AXION 039
BELCOR 116
BELL&HOWELL 333 072
BENQ 423 600
BOXLIGHT 266
BRADFORD 043
BROCKWOOD 116
BROKSONIC 238
BYDESIGN 031 032
CANDLE 116 002 003 363
CARY AUDIO DESIGN 266
CELEBRITY 001
CENTURION 116
CETRONIC 043
CHANGHONG 247
CIELO 714
Ciil 732
CITIZEN 116 002 003 363 043 258 143
CLARION 043
CLASSIC 043
CLP CLASSIC 333
COBY 640 641 671 363
COLORTYME 116
CONCERTO 363
CONCIERGE 073
CONTEC 043 050 051
Continu-us 161 746 747
CORNEA 116
CORONADO 143
CRAIG 043 054
CROSLEY 164
CROWN 043 143
CURTIS MATHES 116 258 363 143
CXC 043
CYBERHOME 015
DAEWOO 363 043 076 143
DAYTRON 363 143
DELL 320 164 363 618
DIGITAL PROJECTION 570
DIMENSIA 333
DREAMVISION 235
DUKANE 011
DUMONT 116 073
DURABRAND 096 052
DWIN 257
DYNASTY 043
DYNEX 400
EIKI 187
ELECTROBAND 001
ELECTROGRAPH 466
ELECTROHOME 143 024 076
ELEKTRA 072
ELEMENT 363 494 526 622 690
F
MEMORY BUTTONS
They’ve been programmed by the Cable MSO
to provide quick access to the most popular channels.
TRANSPORT KEYS
UR5U-8780L & UR5U-8790L
DEFAULT STATE:
Device Default: Cable Set-Top Box (STB)
Channel Default: CABLE channel and numbers
through the CABLE STB. You have the option of
controlling your CABLE channel and numbers
through the TV or VCR. Refer to section H for
programming steps.
Volume Default: Volume and Mute control are
automatically transferred to the respective
Component based on the Device selected:
CBL:TV ; TV:TV ; VCR:TV. DVD:TV ; AUX:AUX.
You have the option of controlling CABLE
Volume and Mute through the TV, VCR or
AUX. Refer to section G for programming
steps.
IMPORTANT SETUP NOTE!
In this section when you are instructed to press a [DEVICE] button, that means to press either the CBL, TV, VCR,
DVD or AUX button, depending on what device you are programming the remote to operate.
There are three ways you can program your remote:
* Quick Setup Method
* 3-Digit Code Method
* Auto Search Method
Quick Setup Method is a unique feature that enables the fastest and easiest setup by using a one digit code. This
is the quickest way to set up devices made by popular manufacturers.
3-Digit Code Method allows you to setup by entering 3-digit code numbers that correspond with the compo-
nents manufacturer/brand. Code tables for this method are on the backside of the operating instructions.
Auto Search Method scans through all of the codes in the remote control, one at a time allowing you to identi-
fy the correct code.
IMPORTANT SETUP NOTE!
This pertains to all programming steps. When you are in setup mode the device LED will light for 30 seconds. If you do
not press a button within 30 seconds, the LED light will turn off and exit setup mode, and you will need to start over.
6
Setup Code Tables
TV&A
Button
TV&B
Button
VCR
0 MITSUBISHI
1HP
2 PHILIPS
3 JVC
4 SAMSUNG
5 PANASONIC
6 PHILIPS MAGNAVOX
7 TOSHIBA
8 PIONEER
9LG
VCR&A
Button
DVD
0 HITACHI
1 SONY
2 PHILIPS
3 SAMSUNG
4 PHILIPS MAGNAVOX
5 PANASONIC
6LG
7 JVC
8 DENON
9 PIONEER
AUX
0 BOSE
1HP
2 ONKYO
3 APPLE / iPod
4 MICROSOFT / XBOX
5 SONY / PS2
6 LUTRON
7 X-10
8 YAMAHA
9 ROKU
DVD&A
Button
AUX&A
Button
TV
Button Press
Button Number
Brand
Button Press
Button Number
Brand
Button Press
Button Number
Brand
Button Press
Button Number
Brand
Loading ...
