1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the light is fully charged before initial use.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Smooth 90° ex with additional 360° twist function enables the light source to be positioned in any direction. Super bright 16W COB
LED provides up to 2000 lumens output with 120° spread of light, illuminating the whole work area. Includes an additional high power
1W SMD LED directional torch. Features a swivel hanging hook and rubber covered magnet on the base, which allow hands-free
operation. Two high quality 2.6Ah lithium-ion batteries for longer life. Supplied with Type-C USB cable.
3. SPECIFICATION
4. OPERATION
4.1. CHARGING THE LIGHT
4.1.1. Connect the USB cable to the USB INPUT on the rear of the light see g.2 on reverse.
4.1.2. Plug the USB cable into supply and turn on.
4.2. OPERATING THE LIGHT
WARNING! Direct the lens away from your eyes before switching on the light.
4.2.1. Toggle the light between main light (50-100%), torch and OFF by pressing the ON/OFF
switch (g.1).
4.2.2. The light may be suspended by the hook on rear of light or attached to any ferrous
surface by using the magnet in the base.
RECHARGEABLE INSPECTION LIGHT, 16W COB &
1W SMD LED, 2000LM, ROTATING MAGNETIC BASE
MODEL NO: LED2001 LED2001G
LED2001 LED2001G Issue 1 03/06/24
Original Language Version
© Jack Sealey Limited
MODEL NO: LED2001 / LED2001G
Battery: 3.7V 2.6Ah Lithium-ion (x2)
Charging Time: 5hr
IP Rating: IP54
LED Type: 16W COB + 1W SMD
Length: 240mm
Lumen Output: Side(High/Low)/Top: (2000/1000)/120lm
Nett Weight: 0.51kg
Operating Time: Side(High/Low)/Top: (3hr/5hr)/15hr
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
ON/OFF
Magnetic
swivel
base
FIG.1
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
IMPORTANT WARRANTY INFORMATION
The battery tted to this light is considered to be a consumable item and its ability to
accept a charge will reduce over time. We will provide warranty against mechanical and
electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its
capacity will diminish. Under these circumstances we will not replace the battery
regardless of whether it is less than one year old.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
LED2001 LED2001G Issue 1 03/06/24
Original Language Version
© Jack Sealey Limited
USB charging
port
FIG.2
Hanging hook
