RECHARGEABLE INSPECTION LIGHT, 5W COB &
1W SMD LED, 600LM, WITH 180° MAGNETIC STAND
MODEL NO: LED601, LED601G
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the light is fully charged before initial use.
8 DO NOT turn the light on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the light.
8 DO NOT handle or move the light whilst it is being charged.
8 DO NOT use the light if you suspect that the battery or the light casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Super bright 5W COB LED light source producing 600 lumens and 1W SMD LED torch producing 100 lumens of light. Light body twists
360° and light arm tilts 180° to provide light at any angle. Features a swivel hanging hook and rubber covered magnet on the base, which
allow hands-free operation. 3.7V 2.6Ah lithium-ion battery for longer life, no memory effect and a much slower discharge than traditional
Ni-MH batteries. Long operating time of 3.5hrs at 600 lumens. Charges via a USB Type-C cable (Supplied).
3. SPECIFICATION
MODEL NO: LED601, LED601G
Battery: 3.7V 2.6Ah Li-ion
Charging Time: 4hr
IP Rating: IP52
LED Type: 5W COB + 1W SMD
Length: 180mm
Lumen Output: Side(High/Low)/Top - (600/300)/100lm
Operating Time: Side(High/Low)/Top - (3.5hr/7hr)/9hr
The battery tted to this lamp is considered to be a consumable item and its ability to accept a
charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this
does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regu larly conditioned, its capacity will
diminish. Under these circumstances we will not replace the battery regardless of whether it is
less than one year old.
NOTE: The lithium battery does not suer from memory eect and once fully charged may be
stored for up to six months without another charge.
4. OPERATION
4.1. CHARGING
4.1.1. Connect the USB cable to the USB INPUT on the side of the light.
4.1.2. Plug the USB cable into a suitable 5V 1A outlet or mains adapter (not included).
NOTE: ensure the light is turned OFF whilst charging.
4.2. OPERATION
WARNING! Direct the lens away from your eyes before switching on the light.
4.2.1. Use the ON/OFF button to cycle between the main light and torch on the end.
4.2.2. The light may be suspended by the hook on rear of the light or attached to any ferrous surface by using the magnet in the tilting base.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS
& CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO
DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS
SAFE FOR FUTURE USE.
LED601, LED601G Issue 1 03/06/24
Original Language Version
© Jack Sealey Limited
FIG.1
ON/OFF
USB INPUT
HANGING
HOOK
MAGNETIC
TILTING BASE
TORCH
LED601, LED601G Issue 1 03/06/24
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
