LED TWIST RECHARGEABLE INSPECTION LIGHT
1W & 1W SMD, 200lm / 2W & 1W SMD, 400LM
MODEL NOS.:LED201G / LED401G
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR
FUTURE USE.
1. SAFETY
1.1. GENERAL
9 Ensure the torch is fully charged before initial use.
8 DO NOT turn the torch on when it is being charged.
8 DO NOT shine directly into your, other person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT handle or move the torch whilst it is being charged.
8 DO NOT use the torch if you suspect that the battery, the torch casing or the cable is damaged. Consult your Sealey Stockist.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery,
subsequently recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, dismantle, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 40°C or below - 10°C.
8 DO NOT expose to direct sunlight for long periods of time.
8 DO NOT expose to moisture.
WARNING! DO NOT place the torch face down while in use.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, wash thoroughly with water. If it gets in your eyes, rinse thoroughly with cool water and
seek immediate medical attention.
2. INTRODUCTION
Super bright SMD LED top light and SMD LED torch. Light body twists 360° and light arm tilts 180° to provide light at any angle.
Features a magnet on the rear and rubber covered magnet on the base, which allow hands-free operation. Lithium-ion battery for
longer life, no memory eect and a much slower discharge than traditional Ni-MH batteries. Easy to read charge indicator displays the
battery level during use and while charging. Long operating times. Charges via a USB Type-C cable (Supplied).
3. SPECIFICATION
Attribute LED201G LED401G
Battery 3.7V 0.8Ah Li-ion 3.7V 2.0Ah Li-ion
Charging Time 2hr 2.5hr
IP Rating IP52 IP52
LED Type 1W SMD + 1W SMD 2W SMD + 1W SMD LED
Lumen Output Side(High/Low)/Top - (200/100)/100lm Side(High/Low)/Top - (400/200)/100lm
Nett Weight 0.094kg 0.143kg
Operating time Side(High/Low)/Top - (2/4)/2.5hr Side(High/Low)/Top - (2/4)/6hr
4. OPERATION
4.1. PRESS ON/OFF TO OPERATE (FIG.3)
4.1.1. First press: Low beam
4.1.2. Second press: High beam
4.1.3. Third press: switches on end torch
4.1.4. Fourth press: switches everything o.
4.2. CHARGING (FIG.2)
4.2.1. Open the cover on the side of the mini light.
4.2.2. Plug the USB-C into a 5V USB outlet.
4.2.3. Insert Type-C connector into the charging port on the side,
4.2.4. For a full charge, time is approximately 2 / 2.5hrs. depending on model.
Original Language Version
© Jack Sealey Limited
LED201G LED401G Issue 1 10/07/24
LED201G Shown
5. MAINTENANCE
5.1. Keep light clean and check for damage before every use.
5.2. If damage is observed, remove from use until unit is repaired.
5.3. The battery is not designed to be removed.
5.4. The battery fitted to this light is considered to be a consumable item and its ability to accept charge will reduce over time. We will warranty
it against mechanical and electrical defect for a period of one year, this does not cover fair wear and tear. If the battery is not properly
charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the battery even
if it is less than one year old.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Original Language Version
© Jack Sealey Limited
LED201G LED401G Issue 1 10/07/24
Swivel Foot with
Magnetic Base
USB Connection
Magnet on
Rear Face
ON / OFF
Rotatable Foot
g.3
g.2
Magnet on
Rear Face
