Approx 168x168x215MM
Approx 470G
AC100-240V 50/60Hz DC24V 650mA
Approx 170CM
Approx 14W
1H/3H/6H/ON
400ML
PP/ABS/PC
AC Adapter and manual
2.4MHz
Dimensions
Weight(excluding adaptor)
Power: lnput/Output
Length of cord
Power
Time Mode
Tank Capacity
Material
Accessory
Working frequency
1H 3H 6H 0N
1H 3H 6H 0N
1H 3H 6H 0N
1. Position the Aroma Diffuser upright, pull vertically
upwards to remove cover. (Fig. 1)
2. Connect AC adaptor power cord into the DC input jack
at the base of the Aroma Diffuser. It is suggested to
route cable via track provided. (Fig. 2)
3. Pour water and essential oil into Aroma Diffuser. DO
NOT fill in excess of 'MAX' marking 400ml. DO NOT
use boiling water. DO NOT fill when power is on. It is
recommended to add 2-3 drops of essential oil for
each 100ml of water. (Fig. 3)
4. Re-install cover. Spout is adjustable to guide aroma
into desired direction. Aroma Diffuser must NOT be
operated without the cover. (Fig. 4)
5. Connect AC adaptor with power from wall socket.
6. To switch on, press “MIST” and choose operation time
required (1 hour, 3 hour, 6 hour or ON Continuous).
Mist level is adjustable by hard-pressing “MIST” until
the Aroma Diffuser beeps (One beep for high and two
beeps for low). To switch off, press 'MIST' through
following cycle until it is off. (1 hour -> 3 hour -> 6 hour
-> ON Continuous -> Off) (Fig. 5)
7. Press “LIGHT” to switch on LED light. Brightness is
adjustable through the following cycle. (Bright ->
Dim -> Off) (Fig. 6)
8. It is recommended to drain water from tank and keep dry
for extended idle period.
9. When connect with power,the original state of aroma
diffuser is still off.
10. Misting operation and light will switch off automatically
when there is insufficient water, even press
“MIST”
,
aroma diffuser is also switch off automatic.
OPERATION
SPECIFICATIONS
User Manual
Aroma Diffuser Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
Cover
LIGHT Button MIST Button
Air Intake
DC Socket
LIGHT
MIST
LIGHT
MIST
LIGHT
MIST
Aroma Diffuser
User Manual
Fig1 Fig2
Fig3 Fig4
Fig6Fig5
LIGHT
MIST
1H 3H 6H 0N
LIGHT
MIST
1H 3H 6H 0N
This Aroma Diffuser uses Ultrasonic principle which can atomize the
water and essential oil in the water tank, and produces a cool, humid
and fragrant mist.
Water Outlet
Water Outlet
Air Outlet
Water Line
Water Tank
Main Body
Drainage
Outlet
MAINTENANCE
PRECAUTIONS
TROUBLESHOOTING
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
User Manual
Aroma Diffuser
After using 5-6 times, or 3-5 days, please clean the product as follow:
Please check below to avoid malfunction of the unit:
1. Unplug the unit and remove cover.
2. Pour out any remaining water from the tank.
3. Add a small amount of warm kitchen detergent to clean, use swab to wipe it gently, and then
use cleaning cloth to dry it lightly.
4. Refer to the following pictures, to avoid water flow into the air outlet, pour off water abide by
the left picture, not the right one.
5. Do not use other acids or enzymes detergent, as this may give off poisonous
gas or cause malfunction.
●
It is not allow to change, dismantle, or repair the uint if you are not the technicist. Please
contact the selling department to repair if necessary.
●
Do not switch on power when the tank is empty.
●
Do not touch the atomization piece.
●
Clean regularly as per Maintenance instructions to avoid malfunction.
●
Always unplug before maintenance.
●
For hygiene reasons, after use, pour away remaining water from “DRAINAGE SIDE” of tank,
and wipe with a clean dry cloth.
●
Essential oil can corrode in the event of spillage of contact, please wipe away with a soft cloth.
●
Only use the measuring cup to add water into the tank, do not fill water directly
from the water pipe.
●
Do not let mist directly to the furniture, clothing, walls etc.
●
Keep away from direct sunshine heat sources and air conditioners or fans.
●
Always keep on stable plat surface do not put on carpet, duvet or unstable area.
●
Keep away from electronic equipment, such as TV and Audio equipment.
●
Wait 60 minutes before restart to avoid damage atomization piece.
●
Don't use sparkling water, tap water and mineral water are available.
●
Never move product when it is working.
●
Do not touch any part of the product with wet hands.
●
Keep away from the child and pet, child is not allow to play without supervisor. This product is
not suitable for the child and people who don't know the product and have no experience.
●
If the cable is smoking, burning, unplug immediately.
Please refer to the table below in the event of the product operating abnormally：
Note: Be sure to use a mild detergent.
If product doesn’t work well, please refer to the following points
before requesting repairs:
Will not switch
on or switch off
No mist or
abnormal mist
Water leakage
from product
●
Is there enough water in the tank?
--Please add water to the tank
●
Is the power cord connected property?
--Please disconnect, check cables and re-connect carefully.
●
Not enough water? or too much water?
--Please add suitable amount of water in the tank, water must
never be filled over 400ML (MAX)line.
●
Dirt on the atomization piece?
--Please refer to maintenance instructions remove and re-install
correctly, so mist can be released freely.
●
Cover and inner cover are not installed properly? Dirt on the air
suction port on the underside of the base?
--If too much dust in the air suction port, the mist will be
restricted to come out.Just clean it.
●
Cover and inner are not installed properly?
--Remove and reinstall correctly, so mist can be released
freely.
●
Low temperature or high humidity?
--Under these conditions, the mist may condense quickly into
water droplets.
●
The amount and intensity of mist produced will vary, but this is not unusual and should not
be considered as a fault.
●
Factors that affect this include water type, humidity, temperature, air currents.
●
Auto power off when water runs out.
●
Applies only 100% natural essential oil, if they contain chemical ingredients, flavors or
impurities may cause damage to the product.
●
Before replacing another essential oil, follow the maintenance part to clean the product.
ATTENTION
ACCIDENTAL LEAKAGE
User Manual
Aroma Diffuser
In the event of the unit being knocked over or tipped during use, please
follow the steps as below to avoid malfunction:
1. Unplug the unit and remove cover.
2. Pour out any remaining water from the water tank.
3. Shake the unit gently to drain water,and then keep it natural air drying for at least
24 hours.
No
1
2
3
4
5
6
Button
ON/OFF
Intermittent
Continuous
Light
Big/small
Timing
Function
ON/OFF
High Mist/Low Mist
Press it to turn on the LED light,
seven light color option
To select 1H/3H/6H or ON mode
To continuous spray
Press to enter intermittent mode
DIFF-519W-LW
WARNING
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed, a lithium button battery can cause severe or
fatal injuries within 2 hours.
Keep batteries out of reach of children.
If you think batteries may have been swallowed or placed
inside
any part of the body, seek immediate medical attention.
