16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
+
2
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety
instructions. Failure to do so may result in personal injury
or damage to the product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating instructions
before using this 16” Wall Fan.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children
• Children of less than 3 years should be kept away unless
continuously supervised.
3
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply
• Always use this appliance on solid, level, surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should be performed by a
qualified electrician. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified-after-sales
service in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliances other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than
intended use.
• DO NOT push objects (including fingers) into the fan grill or
any openings as this could risk injury or damage to the
appliance.
4
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Unplug after each use. Grasp the plug not the cord.
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This Class 2 symbol indicates that the product is electrically double
insulated and does not require an earth connection.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.
Waste batteries should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk enter your postcode to find out your nearest recycling
site.
This symbol provides useful additional information on the use of
this product.
Before first use of Your 16 Inch Wall Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present – see Description of Parts below.
Check that there is no damage to the mains cable or product.
5
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Positioning of Your 16 Inch Wall Fan
The Wall Fan should be mounted on a solid wall at a height that puts it out of reach
of young children and pets.
It should be mounted on brick or a concrete wall using the wall plug fixings supplied
or on a wooden wall using the screws supplied.
If the fan is to be mounted on a plasterboard stud wall it must be fixed to the
wooden studs behind the plaster board and not to the board as the movement of
the fan may cause the fixings to fail.
When siting the Wall Fan care should be taken to avoid curtains and other loose
furnishings that may become entangled in the mechanism.
Fitting the Wall Bracket
Fit the Wall Bracket (8) to the wall using supplied Wall Plugs and Screws (or
alternative appropriate fixings for the wall) as follows:
WARNING! Be careful whilst drilling the holes, care must be taken not to
damage concealed cables and pipes in the wall. If in doubt obtain the services
of a qualified tradesman to fit the wall bracket.
1. Front Guard
2. Blade Retaining Nut
3. Fan Blade
4. Rear Guard Fixing Nut
5. Rear Guard
6. Guard Clips
7. Protective Sleeving
8. Motor Spindle
1
2
3
4
5
7
8
6
9. Motor Housing
10. Fan Wall Mount
11. Control Panel
12. Fixing Screws
13. Wall Bracket
14. Guard Screw & Nut
15. Remote Control
11
9
13
12
10
14
15
6
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Assembling Your 16 Inch Wall Fan
1. Remove the Rear Guard Fixing Nut (4) from
the Motor Housing (9) by unscrewing
anticlockwise (arrowed left).
2. Place the Rear Guard (5) over the three pins on
the front of the Motor Housing (9) and replace
the Rear Guard Fixing Nut (4) by screwing it
back on clockwise as arrowed right.
Ensure that the guard is fitted such that the
Carry Handle is at the top.
3. Remove the Protective Sleeving (7) from
the Motor Spindle (8).
4. Take the Fan Blade (3) and slide it onto
the Motor Spindle (8) ensuring that
notches on the rear of the fan blade line
up with the splines on the spindle –
arrowed left.
Rear Guard (5) removed for clarity.
5. Secure the Fan Blade (3) to the Motor Spindle (8)
by screwing on the Blade Retaining Nut (2) in an
anticlockwise direction as shown right.
The Blade Retaining Nut (2) is reverse threaded.
7
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Remove the small Guard Screw & Nut (14) from
the Front Guard (1) using a suitable screwdriver
(not supplied).
7. Move the Guard Clips (6) around the outside
edge of the Front Guard (1) outwards.
8. Hang the Front Guard (1) over the top of the
Rear Guard (5).
9. Bring the Front Guard (1) down to meet the
Rear Guard (5) and push the Guard Clips (6)
inwards until the Front Guard (1) is fastened to
the Rear Guard (5).
10. Finally, fit the small Guard Screw & Nut (14)
through the holes in the bottom edge of both
the guards and tighten with a suitable
screwdriver (not supplied).
This Guard Screw & Nut (14) must be fitted so
that the guards cannot be removed
accidentally.
8
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Operating Your Wall Fan
Once the Wall Fan has been correctly positioned and hung on its Wall Bracket (13)
as described above, operate the fan as follows:
1. Plug the fan into a suitable wall socket, taking care to
keep the power cable away from moving parts.
2. The fan can be tilted forwards and backwards to the desired angle of airflow,
this should not be carried out while the fan is running to avoid injury.
3. To operate the fan, press the ‘ON/SPEED’ button on the Control Panel (11),
repeated pressing of the button will select from Low (L), Medium (M) or High (H)
fan speeds which will be shown by the indicator lights.
4. The fan can be made to oscillate from side to side by pressing the ‘SWING’
button on the Control Panel (11), press the button again to cancel oscillating.
Using the Remote Control (15)
Fitting the Batteries
• Slide open the cover on the Battery Compartment in the direction of the
arrow on the Remote Control (19).
• Insert 2x AAA 1.5V Batteries (not supplied) into the Battery Compartment
being careful to observe the polarity markings
Battery Warnings
• Do not mix old and new batteries together.
• It is recommended that batteries are removed from the remote control if it is
not to be used for a long period of time.
• CAUTION: There is a danger of explosion if the batteries are incorrectly fitted.
• Replace only with the same or equivalent battery type.
• Do not expose the batteries to sunshine, fire, heat or similar.
• Do not dispose of batteries in a fire.
WARNING
• Do not ingest the batteries.
• Keep new and used batteries away from children and animals.
• If the battery compartment does not latch securely, stop using the product and
keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of the
body, seek immediate medical attention.
• If the batteries leak, remove them immediately to avoid damaging the product.
Do not remove the batteries with your bare hands or allow the battery fluid to
come into contact with your skin, eyes or mucous membranes. Wear normal
household gloves to do so. If, however, your skin has come into contact with the
battery fluid, wash your skin immediately, if necessary, seek medical attention.
9
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
The Remote Control (15) duplicates the buttons on
the Control Panel (11) allowing full remote control of
your wall fan.
The Remote Control also has two more features not
found on the Control Panel (11) – Fan Mode and Fan
Timer as described below:
1. Selecting the Fan Mode
Press the Mode Button on the Remote Control (15) to enter Normal, Nature, or
Sleep modes as described below:
Normal – The fan will run continuously at the fan speed set by the On/Speed
Button and the Normal (NOR) Indicator will illuminate on the
Control Panel (11).
Nature – in Nature mode, the Nature Mode Indicator (NAT) will illuminate on
the Control Panel (11). In this mode the fan will automatically run
at varying speeds simulating natural wind, the strength of the wind
depends on which speed high, medium or low, has been selected by
the On/Speed Button.
Sleep – in Sleep mode, the Sleep Mode Indicator (SLP) will illuminate. In this
mode the fan will automatically run at varying speeds from off to
high, medium or low speed, depending on which speed has been
selected by the On/Speed Button.
2. Using the Fan Timer
The Timer function allows the fan to stay on for a preset time of up to 7.5 hours
before switching off, the Timer is set as follows:
• Switch the Fan on as described in ‘Operating Your Wall Fan’ above.
• Press the Timer Button on the Remote Control (15) to enter the Timer mode,
each press of the button will select an on time of up to 7.5 hours in 0.5-hour
increments. The on time selected will be shown by the Timer Indicators on the
Control Panel (15).
• The fan will automatically switch off after the set time has elapsed.
Care and Maintenance
• Ensure that the fan is not connected to the mains supply before cleaning.
• Wipe the fan body clean with a clean, soft damp cloth.
• Do not immerse the fan or its cord in water or any other liquid.
10
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug-DISCONNECT FROM THE MAINS- and then cut it
off the mains lead an immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Model No.
COL1577
Voltage
220-240V AC 50/60Hz
Rated Power
45W
Protection Class
II
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
Waste batteries should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk enter your postcode to find out your nearest recycling
site.
11
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
12
16” White Wall Fan
Model No. COL1577
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
