RECHARGEABLE HEAD TORCH 3W SMD LED
WITH AUTO-SENSOR
MODEL NO: HT102R.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the batteries.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
2. INTRODUCTION
Hands-free head torch with adjustable 3W SMD LED spotlight to direct light as required. Automatic sensor turns on and o when you
move your hand in front. Produces up to 125 lumens. Four lighting settings - full, 50% energy saving mode, ash and red light.
Powered by a rechargeable 3.7V 1.2Ah lithium-ion battery. Supplied with micro USB charging lead.
3. SPECIFICATION
Model No: .................................................... HT102R.V2
Battery: ......................................3.7V 1.2Ah Lithium-ion
Charging Time: ..........................................................4hr
LED Type: ........................................................3W SMD
Lumen Output: ............................. (High/Low): 125/73lm
Operating Time: ...............................(High/Low): 3hr/4hr
4. OPERATION
4.1. CHARGING(g.2)
4.1.1. Connect the USB lead to the port on the bottom of the head torch (g.2).
4.1.2. The red LED sections on the front face of the unit (g.1, g.3) will light in sequence whilst
the unit is charging.
4.1.3. When the unit is fully charged 5 red LEDs on the unit’s front face will light permanently.
4.2. BATTERYINDICATOR(g.3)
4.2.1. Depress Light mode switch and hold for 3 seconds. Right hand red LEDs turn on.
5 LEDs lit indicates 100%, 1 LED lit indicates 20%.
4.3. LIGHTING MODES (g.1)
4.3.1. 5 dierent operational modes are available. By depressing the Light mode switch (g.1)
within 3 seconds of each depression it is possible to cycle through them.
1st click - Maximum white light
2nd click - Dim white light (50% power saving)
3rd click - White light strobing
4th click - Red lights on
5th click - Red lights strobing
HT102R.V2 Issue 3 14/08/23
Original Language Version
© Jack Sealey Limited
g.1
g.2
g.3
Refer to
instruction
manual
4.4. SENSORMODE(g.4)
4.4.1. Turn Sensor mode on by depressing sensor switch (g.1) once to turn on.
4.4.2. A blue LED is lit on the top face of the unit which indicates that the motion sensor
facility is on. The white light will illuminate at full power.
4.4.3. Waving a hand in front of the unit will turn the light o or on.
4.4.4. Turning the sensor o is achieved by issuing a second click of the sensor switch (g.1).
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
HT102R.V2 Issue 3 14/08/23
Original Language Version
© Jack Sealey Limited
g.4
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
