1. SAFETY
1.1. GENERAL SAFETY
9 Ensure the lamp is fully charged before initial use.
8 DO NOT turn the torch on when it is being charged.
8 DO NOT shine directly into your, other person’s or animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT handle or move the torch whilst it is being charged.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately.
9 Before storage, fully recharge the battery, subsequently recharge the battery at least once every six months of non-use.1.2.
1.2. ELECTRICAL SAFETY
9 Use only the USB charging lead supplied to charge the battery.
WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions: You must ensure the
risk of electric shock is minimised by the installation of appropriate safety devices.
An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD
(Residual Current Device) is used with all electrical products, particularly portable equipment which is plugged into an electrical supply
not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.2.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualied
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.2.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
the safety of the appliance operator. If in any doubt about electrical safety, contact a qualied electrician.
1.2.3. You must ensure that you:
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply.
8 DO NOT use if worn or damaged.
1.3. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, disassemble, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 60°C (140°).
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin thoroughly wash with soap
and water. If it gets in your eyes, rinse thoroughly with cool water and
seek immediate medical attention.
2. INTRODUCTION
Display box includes 12 HT104R head torches. 5W COB LED Striplight
along front of adjustable headband with 3W LED on one side. COB
Lumen Output: 350lm. Side LED Output: 120lm. Turns on and o when
you move your hand in front. Operating Time: 2hr @ 100%, 6hr @ 30%.
Powered by rechargeable Li-Polymer 3.7V 1.2Ah battery. Supplied with
USB Type-C charging lead.
3. SPECIFICATION
HEAD TORCH 5W COB & 3W LED WITH AUTO-
SENSOR
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Original Language Version
© Jack Sealey Limited
Refer to
instructions
HT104RDB Issue1 04/04/25
MODEL NO: HT104RDB
Model No: HT104RDB
Battery: 3.7V 1.2Ah Lithium-Polymer
Charging Time: 2.5hr
LED Type: 5W COB + 3W LED Bulb
Lumen Output: COB; 350lm, 3W LED Bulb; 120lm
Nett Weight: 1.422kg
Operating Time: 2hr @ 100%, 6hr @ 30%.
4. OPERATION
4.1. Remove USB cover on the rear of the lamp unit to reveal the USB charging point and insert the power cable. Fig.1
4.2. Plug the cable into an appropriate power source. Charging will take approximately 2.5 hr.
4.3. When fully charged the Power LED will change from red to green.
4.4. When charged, remove USB cable and replace the USB cover.
4.5. Adjust the head band size for a comfortable and secure t using the adjusters. Fig.2
4.6. The unit has ve operating modes. These are On/O, Strip Light 100%, Strip Light 30%, Torch 100%, Torch 30%.
4.7. To switch the unit on, press On/O Mode Selector and the Strip Light will illuminate at 100%. Press the Selector again, and the strip
light will reduce to 30%. Press the Selector again and the Torch will illuminate at 100%. Press the Selector again and the Torch will
reduce to 30%. A further press on the Selector will turn the unit o.
4.8. To turn the Motion Sensor on, press the Motion Sensor Selector. The Power LED will illuminate to half red and half green.
4.9. The Sensor is activated by covering the Motion Sensors on the side of the lamp unit. Press the Motion Sensor Selector to turn the
function o.
5. MAINTENANCE
5.1. Keep the torch clean by wiping with a damp cloth.
5.2. Store torch in a dry childproof area.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
REGISTER YOUR
PURCHASE HERE
Original Language Version
© Jack Sealey Limited
HT104RDB Issue1 04/04/25
Li-Poly
g.2
g.1
