LED RECHARGEABLE HEAD TORCH, 10W SMD
MODEL NO: HT110R
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT leave batteries in a discharged state.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open the batteries.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°).
9 Replace only with the batteries designed for this product.
9 Recycle or dispose of used batteries as stipulated by local regulation.
9 If the electrolyte in the batteries gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
Super bright 10W SMD LED produces up to 1000 lumens with a wide spread of light, illuminating the whole work area. Easy to adjust
one-size ts all headband is made from comfortable, breathable elastic. Head torch features 180° of rotation, allowing the light to be
directed at the optimal angle for hands free working. Easy to read charge indicator displays the current battery level while charging.
Charges via a USB Type-C cable (supplied). Rechargeable 3.7V 2.2Ah lithium-ion battery for extended battery life with a long run time
of 4.5 hours.
3. SPECIFICATION
4. OPERATION
4.1. CHARGING (g.2).
4.1.1. Unscrew end cap to access the charging socket.
4.1.2. Connect supplied charger cable into charging socket,
a red indicator illuminates to indicate charging. Allow
4-5hrs to fully charge. A green light illuminates when
the head torch is charged.
4.2. LIGHT MODES
4.3. 3 dierent operational modes are available. By
depressing the light mode switch g.2
Function.
1st press: Full power.
2nd press: Half power.
3rd press: Low power.
4.4. HEAD STRAP ADJUSTMENT
4.4.1. Adjust the head strap using the adjustment buckles to
t the circumference of your head.
Refer to
instructions
Original Language Version
© Jack Sealey Limited
LED, 1000LM, 2.2AH BATTERY
Model No: HT110R
Battery: 3.7V 2.2Ah Lithium-ion
Charging Time: 4hr
LED Type: 10W SMD
Lumen Output: High/Med/Low: 1000/500/50lm
Nett Weight: 0.13kg
Operating Time: High/Med/Low: 4.5/8/18hr
HT110R Issue 1 05/09/24
Charging socket
ON/OFF light
mode switch
Adjustable head
strap
Battery
compartment
S
MD LED
g.1
g.2
T
urn to angle
LED light
5. MAINTENANCE
5.1. Keep the head torch clean by wiping with a damp cloth.
5.2. Store head torch in a dry childproof area.
HT110R Issue 1 05/09/24
Original Language Version
© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
