DS-1696ZJ-Y3(OS)
Pendant Mount
Feature
Stainless steel with anti-corrosion spray treatment
With cable outlet(s)
Dimension
Φ 12 mm
(0.47'')
85 mm
(3.35'')
85 mm
(3.35'')
331 mm (13.03'')
3-M6
10 mm
(0.39'')
Φ 53 mm
(2.09'')
Φ 63 mm
(2.48'')
Φ 47.6 mm (1.87'')
Depth 20 mm (0.79'')
Available Model
DS-1696ZJ-Y3(OS)
Parameter
Model
Parameters
DS-1696ZJ-Y3(OS)
Pendant Mount
Appearance
Silver moon grey
Material
Stainless steel
Dimension
160 mm × 160 mm × 331 mm (6.30’’ × 6.30’’ × 13.03’’)
Weight
Approx. 1892 g (4.17 lb.)
Note
The mount should be installed on a flat surface.
Waterproof rubber is necessary for the outdoor application.
The wall should be capable of supporting at least 3 times as much as the total weight of the camera and the mount.
The maximum load capacity of the mount is 15 kg (33.07 lb.).
