715 English Instruction Sheet
Page 1
®
715
Volt/mA Calibrator
Instruction Sheet
Introduction
The Fluke 715 Volt/mA Calibrator is a source and measurement
tool for 0 to 24 mA current loop testing and dc voltage from 0 to
20/25 V. The calibrator does not source and measure
simultaneously.
Your calibrator is supplied with a holster, a set of test leads, an
installed 9 V alkaline battery, and this instruction sheet.
Summary of Calibrator Capabilities
Function Range Resolution
dc mV input
dc mV output
0 to 200 mV 0.01 mV
dc V input 0 to 25 V
dc V output 0 to 20 V
0.001 V
dc mA input
dc mA output
0 to 24 mA 0.001 mA
Loop power
output
24 V dc output N/A
PN 650314 July 1997 Rev. 3, 8/05
1997-2005 Fluke Corporation. All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies.
