1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this product.
8 DO NOT open more than one drawer at a time.
8 DO NOT step on the drawers.
9 Ensure all drawers are fully closed before moving the cabinet.
9 Secure the brakes when cabinet is in the desired position.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
8 DO NOT use in damp work areas.
8 DO NOT use the cabinet for any purpose other than that for which it was designed.
8 DO NOT use the cabinet outdoors.
8 DO NOT clean the cabinet with any solvents which may damage the surfaces or the protective coating.
WARNING! The warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but
must be applied by the operator
2. INTRODUCTION
Use as part of a complete garage storage system or as an individual storage
unit. Five drawer mobile cabinet. All drawers tted with ball-bearing slides. Four
swivel castors with one brake. Aluminium handles. High quality lock with two
keys.
3. SPECIFICATION
Model No: .........................................................APMS58
Overall Size: .....................................650 x 460 x 860mm
Small Drawer (x2): .............................565 x 400 x 60mm
Large Drawer (x3): ...........................565 x 400 x 135mm
4. ASSEMBLY
4.1. FIT CASTORS
Carefully lay the cabinet onto its back. Use the outer packaging to prevent
damage. Use screws from underneath to x castors onto the cabinet. Fit the
braked castor on the front corner of unit.
4.2. REMOVE DRAWERS (FIG.1)
Push the tab down on the left side and up on right side. Pull the drawer from
the slide.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
APMS58 Issue 2 (H,2,3,F) 05/09/23
Original Language Version
© Jack Sealey Limited
FIG.1
MODULAR 5 DRAWER MOBILE CABINET 650MM
MODEL NO: APMS58
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 5 years from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
