Superior image quality with up to
12 frames per second in 1.3 Megapixel
resolution (AXIS 207MW) or up to 30 in
VGA (AXIS 207/207W)
Simultaneous Motion JPEG and MPEG-4 for
optimized quality and bandwidth
Built-in microphone for synchronized audio
Wireless IEEE 802.11g and Ethernet for
flexible installation (AXIS 207W/207MW)
Built-in Web server for monitoring via
standard browser on Windows or Mac
AXIS 207/207W/207MW
Network Cameras
True bandwidth-efficient
MPEG-4 network cameras
The AXIS 207 Network Cameras offer compact and cost-effective
solutions for indoor surveillance and remote monitoring. The AXIS
207 family provides the best image quality in its class, with excellent
performance even in low light conditions. It offers VGA resolution with
AXIS 207/207W, and if greater detail or wider field of view is required,
Megapixel resolution with AXIS 207MW.
The AXIS 207 Network Cameras also provide the best band width
efficiency, thanks to its MPEG-4 implementation that includes motion
estimation. Simultaneous MPEG-4 and Motion JPEG streams allow
systems to be optimized for both image quality and bandwidth. The
built-in microphone enables remote users to not only view, but also
listen in on an area and increase the monitoring options.
Thanks to the built-in Web server, the AXIS 207 Network Cameras can
be monitored from a standard browser on a Windows computer or a
Macintosh. In addition to the included AXIS IP Utility tool for Windows,
the cameras support both UPnP and Bonjour, for easy location on the
network in a Windows or Macintosh environment.
Video can be recorded directly from the Web interface or via the
included video management software. Video can also be uploaded over
FTP, email or HTTP when the camera detects motion or is triggered by
a sensor connected to the alarm input.
The AXIS 207W/207MW Network Cameras are supplied with both
wireless IEEE 802.11g and Ethernet network interfaces for flexible
installation. They support the WPA (Wi-Fi Protected Access) and WPA2
protocols to provide the best security for wireless networks.
The wide
coverage provided by the high-performance wireless functionality
gives the freedom to place the camera where required, instead of
being restricted to network outlets.
These network cameras are ideal for securing small businesses, home
offices and residences over a local area network or the Internet.
30820/EN/R6/0801
AXIS 207/207W/207MW Network Cameras
Specifications
AXIS 207/207W/207MW
Network Camera with flexible
clamp - clamp included
The four-pin terminal connector provides the interface to 1 alarm input, 1 output and
alternative power connection. It can be used for connecting e.g. an external alarm
device for triggering an alarm notification via email.
AXIS 207/207W/207MW Network
Camera with camera stand -
stand included
Models
AXIS 207: VGA, wired interface
AXIS 207W: VGA, wired and wireless interface
AXIS 207MW: Megapixel, wired and wireless interface
Image sensor
AXIS 207/207W: 1/4” Micron Progressive Scan RGB VGA CMOS
AXIS 207MW: 1/3” Micron Progressive Scan RGB 1.3 Megapixel CMOS
Lens
AXIS 207/207W: 4.0 mm, F2.0, fixed iris, focus range: 0.5 m to infinity
AXIS 207MW: 3.6 mm, F1.8, fixed iris, focus range: 0.5 m to infinity
Angle of view
AXIS 207/207W: 55° horizontal
AXIS 207MW: 74° horizontal
Light
sensitivity
AXIS 207/207W: 1-10000 lux, F2.0
AXIS 207MW: 2-10000 lux, F1.8
Video
compression
Motion JPEG
MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation, profiles:
Simple Profile, level 0-3, and Advanced Simple Profile, level 0-5
Resolutions
AXIS 207/207W: 7 resolutions up to 640x480
AXIS 207MW: 15 resolutions up to 1280x1024
Frame rate
AXIS 207/207W: Up to 30 fps in all resolutions
AXIS 207MW: Up to 14 fps in resolutions up to 1280x720, up to 12 fps
in 1280x1024
Video
streaming
Simultaneous Motion JPEG and MPEG-4
Controllable frame rate and bandwidth
3GPP and ISMA compatible
Image settings
Compression levels: 100
Rotation: 0°, 180°
Configurable color level, brightness, contrast, white balance
Overlay capabilities: time, date and text
Shutter time
AXIS 207/207W: 1/2 - 1/10000 second
AXIS 207MW: 1/10 - 1/10000 second
Audio
Built-in microphone for one-way audio
Audio compression: AAC LC 8-32 kbit/s, G.711 PCM 64 kbit/s, G.726
ADPCM 32 or 24 kbit/s (AXIS 207W/207MW)
Wireless
interface
(AXIS 207W/
207MW)
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 20-22 dBm* (FCC), 11-14 dBm (CE)**
Receiver sensitivity: -90 dBm at 1 Mb
Modes: Infrastructure and ad-hoc
Antenna gain: 1.6 dBi
*Peak; without antenna gain; **Avg; without antenna gain
Security
Multiple user access levels with password protection
AXIS 207W/AXIS 207MW: IP address filtering, HTTPS encryption
WEP 64/128 bit, WPA-PSK*, WPA2-PSK*
*infrastructure mode only
Users
10 simultaneous unicast users
Unlimited users using multicast (MPEG-4)
Alarm
and event
management
Events triggered by video motion detection, audio detection or external
input
Upload of MPEG-4 video or Motion JPEG images over FTP, email and HTTP
Notification via email, HTTP and external output
Pre- and post alarm buffering in MPEG-4 file up to 4 MB
(AXIS 207/207W) / 2 MB (AXIS 207MW)
Connectors
Ethernet 10BaseT/100BaseTX, Auto-MDIX (AXIS 207W/207MW), RJ-45
Terminal block for 1 alarm input, 1 output and alternative power
connection
Processors and
memory
CPU, video processing and compression: ARTPEC-A
RAM: 32 MB, Flash: 4 MB (AXIS 207), 8 MB (AXIS 207W/207MW)
Power
AXIS 207: 4.9-5.1 V DC, max 2.5 W
AXIS 207W: 4.9-5.1 V DC, max 3.5 W
AXIS 207MW 4.9-5.1 V DC, max 4.0 W
Operating
conditions
5-50 °C (41-122 °F)
Humidity 20 - 80% RH (non-condensing)
Installation,
management
and
maintenance
Installation tool on CD and Web-based configuration
Configuration backup and restore
Video management software for recording
Firmware upgrades over HTTP or FTP, firmware available at
www.axis.com
Video access
from web
browser
Camera live view,
video recording to file (ASF),
customizable HTML pages
Minimum
web browsing
requirements
Pentium III CPU 500 MHz or higher, or equivalent AMD
128 MB RAM
AGP graphics card 32 MB RAM, Direct Draw
Windows XP, 2000, DirectX 9.0 or later
Internet Explorer 6.x or later
Mac OS X 10.3 or later and Safari 1.3 or later with QuickTime plugin
Other MPEG-4/AAC players supported: Packet Video, QuickTime,
RealPlayer standalone and browser plug-ins, Windows Media Player
For other operating systems and browsers see www.axis.com/techsup
System
integration
support
Open API for software integration including AXIS VAPIX API*, AXIS
Media Control SDK*, event trigger data in video stream and NAT
traversal.
Quality of Service (QoS) Layer 3, DiffServ Model. Embedded Linux
operating system
*Available at www.axis.com
Supported
protocols
IPv4, HTTP, TCP, ICMP, QoS, RTSP, RTP, UDP, IGMP, RTCP, SMTP, FTP,
DHCP, UPnP, Bonjour, ARP, DNS, DynDNS, SOCKS, NTP
Additional protocols in AXIS 207W/MW: IPv6, HTTPS, SSL/TLS*,
SNMPv1/v2c/v3 (MIB-II)
More information on protocol usage available at www.axis.com
*This product includes software developed by the Open SSL Project for use in the
Open SSL Toolkit
Accessories
(included)
Power supply, stand, clamp, connector block, Installation Guide,
CD with installation tool, software and User’s Manual, AXIS Camera
Explorer license, MPEG-4 licenses (1 encoder, 1 decoder),
MPEG-4 decoder (Windows)
Video
management
software
(not incl.)
AXIS Camera Station - Video management software for viewing,
recording and archiving up to 25 cameras
See www.axis.com/partner/adp_partners.htm for more software
applications via partners
Accessories
(not incl.)
AXIS 207: Indoor vandal-resistant housing
MPEG-4 Decoder multi-user license pack
Approvals
AXIS 207: EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024,
EN 61000-6-1, FCC Part 15 Subpart B Class B, ICES-003 Class B,
VCCI Class B, C-tick AS/NZS 3548, EN 60950
AXIS 207W/207MW: EN 300328, EN 301489, FCC Part 15 Subpart B
& C Class B, ICES-003 Class B, RSS210, VCCI Class B, TELEC, C-tick
AS/NZS 4771, MIC, EN 60950
Power supply: EN 60950, UL, CSA
Dimensions
(HxWxD) and
weight
AXIS 207: 85 x 55 x 34 mm, (3.3” x 2.2” x 1.3”), 177 g (0.39 lb) incl.
stand, excl. power supply
AXIS 207W/207MW: 85 x 55 x 40 mm (3.3” x 2.2” x 1.6”) antenna not
included, 190 g (0.42 lb) incl. stand, excl. power supply
