INSTRUCTIONS FOR
SLIDE HAMMER/PULLER SET 10PC
MODEL NO: PS983.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure all Health and Safety, local authority, and general workshop practice regulations are strictly adhered to when using
tools.
8 DO NOT use tools if damaged or worn.
9 Maintain the tools in good and clean condition for best and safest performance.
9 Ensure all threads are clean and well lubricated.
9 Always check that puller is correctly assembled and is square with the workpiece.
9 Ensure the nuts and bolts are tight on the jaw heads.
9 If vehicle is raised, ensure it is adequately supported with axle stands, ramps, etc. as appropriate.
9 Wear suitable clothing to avoid snagging. DO NOT wear jewellery. Tie back long hair.
9 Wear approved eye protection. A full range of personal safety equipment is available from your Sealey dealer.
9 Where possible shield workpiece with canvas or similar to provide protection against failed parts.
8 DO NOT heat puller jaws when heating a gear or bearing as this will affect the temper and, therefore, the strength of the material.
8 DO NOT hit workpiece with a hammer if workpiece has not moved with maximum puller force applied. Use a larger capacity puller.
9 Account for all tools and parts being used and do not leave them in or on the vehicle.
IMPORTANT: Always refer to the vehicle manufacturers service instructions, or proprietary manual, to establish the correct procedure and
data.
NOTE: This tool will exert strong forces on the object being worked on and may damage some objects depending on force required.
2. iINTRODUCTION
2.3kg Slide hammer with 580mm shaft. Use eight ways: external 3-leg puller, internal 3-leg puller, external 2-leg puller, internal 2-leg
puller, grip wrench adaptor, lip puller, hub puller, dent puller. Supplied in storage case.
3. i SPECIFICATION
PS983.V2 Issue 2 (3) 25/09/23
Original Language Version
© Jack Sealey Limited
Refer to
instruction manual
Wear protec-
tive gloves
Wear eye
protection
Model No: PS983. V2
Twin leg:
Internal Capacity: Ø35-110mm
Reach: 83mm
External Capacity: Ø35-110mm
Reach: 83mm
Triple Leg:
Internal Capacity: Ø30-110mm
Reach: 83mm
External Capacity: Ø30-110mm
Reach: 83mm
Wear ear
protection
4. CONTENTS
5. OPERATION
Prior to usage ensure that the unit is securely assembled and all moving parts are free to move as intended for the application required.
Original Language Version
© Jack Sealey Limited
PS983.V2 Issue 2 (3) 25/09/23
Item Part No. Description
1 PS983/601 T Bar
2 PS983/602 Hammer
3 PS983/603 Axle puller
4 PS983/604 Grip wrench adaptor
5 PS983/605 Nut
6 PS983/606 2 Jaw Head
7 PS983/607 3 Jaw head
8 PS983/608 Nut and Bolt (x3)
9 PS983/610 Attachment
10 PS983/611 Leg (x3)
11 PS983/612 Screw
12 PS983/613 Hook
13 PS983/614 Centre screw
15 PS983/B2 Deep Axle puller
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
Email or call our technical team on technical@sealey.co.uk or 01284 757505.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
