Washer Dryer / User Manual
EN
CLSV961422DRYEXC
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation
and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
CONTENTS
1. SAFETY INSTRUCTIONS ............................................................................................... .1
1.1 General Safety Warnings ...............................................................................................2
1.2 During Use .....................................................................................................................8
1.3 Packaging and Environment...........................................................................................9
1.4 Savings Information ........................................................................................................9
2. TECHNICAL SPECIFICATIONS ......................................................................................11
3. OVERVIEW OF YOUR MACHINE ................................................................................. .12
3.1 General Appearance.....................................................................................................12
4. INSTALLATION .............................................................................................................. .12
4.1 Removing the Transit Bolts...........................................................................................12
4.2 Adjusting the Feet / Adjusting Adjustable Stays............................................................13
4.3 Electrical Connection ....................................................................................................13
4.4 Water Inlet Hose Connection ........................................................................................13
4.5 Water Discharge Connection ........................................................................................14
5. CONTROL PANEL OVERVIEW ..................................................................................... .14
5.1 Detergent Drawer (*) ....................................................................................................15
5.2 Sections . ..................................................................................................................15
5.3 Program Dial.................................................................................................................16
5.4 Electronic Display ........................................................................................................ .16
6. USING YOUR WASHING MACHINE ............................................................................. .16
6.1 Preparing Your Laundry ................................................................................................16
6.2 Putting Laundry in the Machine ................................................................................... .17
6.3 Adding Detergent to the Machine .................................................................................17
6.4 Operating Your Machine .............................................................................................. .18
6.5 Selecting a Programme ............................................................................................... .18
6.6 Half-Load Detection System .........................................................................................18
6.7 Auxiliary Functions .......................................................................................................18
6.8 Child Lock . ..................................................................................................................24
6.9 If you want to pause/cancel a running program or add laundry: .................................24
6.10 Program End ..............................................................................................................24
7. PROGRAMME TABLE ................................................................................................... .25
7.1 Important Informations..................................................................................................30
8. CLEANING AND MAINTENANCE ................................................................................ .31
8.1 Warning ...................................................................................................................31
8.2 Water Inlet Filters .........................................................................................................31
8.3 Pump Filter . ..................................................................................................................32
8.4 Detergent Drawer .........................................................................................................32
9. Body / Drum .................................................................................................................. .33
10. TROUBLESHOOTING ................................................................................................. .34
11. AUTOMATIC FAULT WARNINGS AND WHAT TO DO .............................................. .36
1. SAFETY INSTRUCTIONS
Operating voltage / frequency
(220-240) V~/50Hz
Total current (A) 10
Water pressure (Mpa) Maximum 1 Mpa
/ Minimum 0.
1Mpa
Total power (W)
2200
Maximum washing capacity
(dry laundry) (kg)
9
Maximum drying capacity (kg)
6
• Do not install your machine on a carpet or such
grounds that would prevent the ventilation of its
base.
• The appliance is not intended for use by people
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge unless they have been
given supervision or instruction concerning use
of the appliance by a person responsible for their
safety.
• Children of less than 3 years should be kept away
unless continuously supervised.
• Call the nearest authorized service centre for a
replacement if the power cord malfunctions.
• Use only the new water inlet hose coming
with your machine when making water inlet
connections to your machine.Never use old, used
or damaged water inlet hoses.
EN - 1
• Children should not play with the appliance.
Cleaning and user maintenance should not be
made by children without supervision.
NOTE: For a softcopy of this user manual,
please contact the following address:
“[email protected]”. In your
e-mail, please provide the model name and serial
number (20 digits) which you can find on the
appliance door.
To ensure your safety and the safety of others,
please read the following safety precautions
before using or installing your Washer Dryer.
Your machine is for domestic use only.
Using it for commercial purposes will void
your warranty.
This manual has been prepared for more than
one model therefore your appliance may not
have some of the features described within.
For this reason, it is important to pay particular
attention to any figures whilst reading the
operating manual.
1.1 General Safety Warnings
Before setting up your Washer Dryer, remove
the four transit bolts and the rubber washers
from the rear of the machine.
• Your warranty does not cover damage caused by
external factors such as fire, flooding and other
sources of damage.
• Retain this user manual for future use and pass it
on to the next user.
EN - 2
• The necessary ambient temperature for operation
of your Washer Dryer is 15-25 °C.
• Where the temperature is below 0 °C, hoses
may split or the electronic card may not operate
correctly.
• Please ensure that garments loaded into your
Washer Dryer are free from foreign objects such
as nails, needles, lighters and coins.
• Lints must not to be allowed to accumulate
around the washer dryer.
• Residue may build up on detergent and softeners
exposed to air for a long period of time. Only
put softener or detergent in the drawer at the
beginning of each wash.
• Unplug your Washer Dryer and switch off the
water supply if the Washer Dryer is left unused for
a long time. We also recommend that you leave
the door open to prevent build up of humidity
inside the Washer Dryer.
• Some water may be left in your Washer Dryer as
a result of quality checks during production. This
will not affect the operation of your Washer Dryer.
• Keep the document bag that was supplied inside
your Washer Dryer and contained this user
manual out of the reach of children and babies to
prevent the risk of suffocation.
• The packaging of the machine could be
hazardous to children. Do not allow children to
play with the packaging or small parts from the
Washer Dryer.
• Only use pre-wash programmes for very dirty
laundry.
• Do not exceed the maximum load for the washing
EN - 3
or drying programme you have chosen.
• In the event of a fault, unplug your Washer Dryer
and switch off the water supply. Do not attempt
to repair your Washer Dryer yourself. Repairs
should only be undertaken by an approved
service agent.
• Never open the detergent drawer while your
Washer Dryer is running.
• Never force the door open when your Washer
Dryer is running.
• Please follow the manufacturers’ instructions
on the use of fabric conditioner or any similar
products that you intend to use in your Washer
Dryer.
• Do not stop your Washer Dryer before the drying
phase of a programme has been completed. If
you have to do so, quickly remove all of your
laundry and immediately spread the items on an
appropriate surface to allow them to cool.
• The appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched on
and off by a utility.
• This appliance must not be installed behind a
lockable door, a sliding door or a door with a
hinge on the opposite side to that of the washer
dryer, in such a way that a full opening of the
washer dryer door is restricted.
• Install your Washer Dryer in a location that can be
ventilated and has constant air circulation.
SAFETY WARNINGS
• You must read these warnings. Ignoring these
warnings may put you or others at risk of fatal
EN - 4
injuries.
RISK OF BURNS
• Do not touch the door, drain hose or any
discharged water while your Washer Dryer in
running. The high temperatures involved pose a
burn risk.
• Open the door fully after the drying process.
Do not touch the door glass. It will reach high
temperatures and pose a burn risk.
ELECTROCUTION RISK
Do not connect your Washer Dryer to the mains
electricity supply using an extension lead.
• A damaged power cord/plug can cause fire or give
you an electric shock. When damaged it must be
replaced, this should only be done by qualified
personnel.
• Never remove the plug from the socket by pulling
the cord. Always hold the plug.
• Never touch the power cord/plug with wet hands
as this could cause a short circuit or electric
shock.
• Do not touch your Washer Dryer if your hands or
feet are wet.
• Call the nearest authorised service company for
assistance if the power cord malfunctions.
Explosion Risk
• Thoroughly rinse off any chemicals, such as stain
remover, from your garments before beginning a
washing and drying programme. Failure to do so
may cause a risk of explosion when the drying
function is used.
EN - 5
Fire Risk
• Do not keep flammable or explosive liquids near
your machine.
• Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax
removers should be washed in hot water with an
extra amount of detergent before being dried in
the tumble dryer.
• Do not use a detergent ball/device if you have
selected a washing and drying programme as this
may cause a fire hazard.
• Do not dry your laundry under the conditions
specified below as they present a fire risk:
• If the laundry is not washed.
• If oil based stains are not pre-treated before
beginning a washing or drying programme.
• Laundry which has been cleaned with industrial
chemicals.
• Laundry that has a high amount of sponge,
foam, rubber or rubber-like parts and
accessories.
• Items such as foam rubber (latex foam), shower
caps, waterproof textiles, rubber backed articles
and clothes or pillows fitted with foam rubber
pads should not be dried in the drying process
of the appliance.
• Stuffed or damaged items (such as pillows or
jackets). The rubber sponge presents a fire risk
during the drying process.
• Never use products that contain solvents in your
machine.
EN - 6
• Please ensure that garments loaded into your
Washer Dryer are free from foreign objects such
as nails, needles, lighters, matches and coins.
Fall and Injury Risk
• Do not climb on your Washer Dryer.
• Make sure hoses and cables do not cause a trip
hazard.
• Do not turn your Washer Dryer upside down or on
its side.
• Do not lift your Washer Dryer using the door or
detergent drawer.
• Make sure hoses and cables do not cause a trip
hazard.
To avoid risk of injury, please take care when
moving your Washer Dryer. It is heavy and we
recommend that a minimum of two people move
your Washer Dryer.
Child Safety
• Do not allow children to play with the machine.
• Do not leave children unattended near the
machine. They might lock themselves in the
machine.
• The door glass and machine surface can become
extremely hot during operation. Do not allow
children to touch the machine; it may damage
their skin.
• The packaging of the machine could be
hazardous to children. Do not allow children to
play with the packaging or small parts from the
Washer Dryer.
• Poisoning and irritation may occur if detergent or
other washing aids are consumed or come into
EN - 7
contact with skin or eyes. Keep cleaning materials
out of reach of children.
1.2 During Use
• Do not allow pets near the machine.
• Please ensure that you have removed all of the
packaging materials and protective tape from the
outside of your Washer Dryer, inside the drum and
inside the detergent drawer before using. Check
for any external visible damage. Do not install or
use your Washer Dryer if it is damaged.
• Your Washer Dryer is for domestic use only and
is only intended to wash and dry items which
are specified by the manufacturer to be machine
washable and dryable on the label and textiles
composed of hand washable wool or wool blend
fabrics as well as satin, lace, silk and other hand-
washable garments. Do not use your Washer
Dryer for any purpose not expressly specified in
this user guide.
• This appliance can be used by children aged from
8 years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be done by children without supervision.
• Installation of your machine must only be carried
out by an authorised service agent. Installation by
anyone other than an authorised agent will void
your warranty.
EN - 8
NOTE: Specifications for the machine may vary
depending on the product purchased.
1.3 Packaging and Environment
DISPOSE OF PACKAGING AND YOUR OLD
MACHINE RESPONSIBLY
Removal of packaging materials
Packaging materials protect your machine from
any damage that may occur during transportation.
Please recycle the packaging materials.
Recycled material reduces raw material
consumption and lowers waste production.
1.4 Savings Information
Some important information to get the most efficient
use out of your machine:
• The amount of laundry you put in your Washer
Dryer should not exceed the maximum amount
indicated. Avoid overloading to allow your
machine to run more efficiently.
• Not using the pre-wash feature for normal and
lightly soiled laundry will save electricity and water
consumption.
EN - 9
1.5 TwinjeT sysTem
Detergent water in your machine will be circulated with 2 water injection mechanisms
and a mixing system via twinjet system. Circulated detergent water will be injected over
your laundries, which allows a better washing performance. Twinjet system will help you
wash higher amount of laundries in a shorter time with a better washing performance,
guaranteeing less energy and water consumption.
CE Declaration of conformity
We declare that our products meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
Disposal of your old machine
The symbol of the crossed-out wheeled bin shown on the product or its
packaging means that the device must not be disposed of with other household
waste but requires separate collection. You can dispose of the device free of
charge at your local waste return and collection system. The addresses can be
obtained from your responsible city council or local government. Alternatively,
you can return small waste electrical and electronic equipment (WEEE) with
an edge length of up to 25 cm free of charge to any retailer with a sales area
relating to electrical and electronic equipment (EEE) of at least 400 m2 or to a food retailer
that offers EEE at least several times a year with a total sales area of 800 m2. Larger
WEEE can be returned to a respective retailer free of charge when buying a new product
of the same type. Regarding the modalities of the collection of WEEE in case of shipment
of the newly bought product, please contact your retailer.
If possible, please remove all batteries and accumulators as well as all removable lamps
before disposing of the device.
Please note that you are responsible for deleting all personal data on the device to be
disposed of.
Twinjet
unit
Pump
Unit
EN - 10
2. TECHNICAL SPECIFICATIONS
Maximum washing capacity (dry laundry) (kg)
9
* Maximum drying capacity (kg)
6
Spin speed (rpm)
1400
Number of programmes 15
Operation voltage / Frequency (v/hz) 220-240 / 50
Water pressure (mpa)
Maximum: 1
Minimum: 0.1
Dimensions (HxWxD) (mm) 845x597x582
* You should not put dry laundry in your machine for drying.
EN - 11
EN - 12EN - 12
3. OVERVIEW OF
YOUR MACHINE
7 8
9
10
11
123
4
5
6
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
3.1 General Appearance
1. Touch buttons and Electronic display
2. Programme Button
3. Upper Tray
4. Detergent Drawer
5. Door
6. Pump Filter Cover
7. Power Cord
8. Drain Hose
9. Transport Screws
10. Adjustable Feet
11. Plastic Drain Hose Holder: (Do not
remove the holder; the operation of the
machine will be affected).
4. INSTALLATION
4.1 Removing the Transit Bolts
X X4 4
X
4
1
3
2
4
1. Before operating the washing machine,
remove the 4 transit bolts and rubber
spacers from the rear of the machine.
If the bolts are not removed, they
may cause heavy vibration, noise and
malfunction of the machine and void the
warranty.
2. Loosen the transit bolts by turning
them anticlockwise with an appropriate
spanner.
3. Remove the transit bolts with a straight
pull.
4. Fit the plastic blanking caps supplied in
the accessories bag into the gaps left
by the removal of the transit bolts. The
transit bolts should be stored for future
use.
NOTE: Remove the transit bolts
before using the machine for the first time.
Faults occurring due to the machine being
operated with transit bolts fitted are out of
the scope of the warranty.
EN - 13EN - 13
4.2 Adjusting the Feet /
Adjusting Adjustable Stays
1
1. Do not install your machine on a surface
(such as carpet) that would prevent
ventilation at the base.
• To ensure silent and vibration-free
operation of your machine, install it on a
firm surface.
• You can level your machine using the
adjustable feet.
• Loosen the plastic locking nut.
X
4
2 3
2. To increase the height of the machine,
turn the feet clockwise. To decrease
the height of the machine, turn the feet
anticlockwise.
• Once the machine is level, tighten the
locking nuts by turning them clockwise.
3. Never insert cardboard, wood or other
similar materials under the machine to
level it.
• When cleaning the ground on which
the machine is located, take care not to
disturb the level of the machine.
4.3 Electrical Connection
• Your Washing Machine requires a 220-
240V, 50 mains supply.
• The mains cord of your washing
machine is equipped with an earthed
plug. This plug should always be
inserted to an earthed socket of 10
amps.
• If you do not have a suitable socket and
fuse conforming with this, please ensure
the work is carried out by a qualified
electrician.
• We do not take responsibility for
damage that occurs due to the use of
ungrounded equipment.
NOTE: Operating your machine
with low voltage will cause the life cycle
of your machine to be reduced and its
performance to be restricted.
4.4 Water Inlet Hose Connection
3/4”
10 mm
1
3
2
4
1. Your machine may have either a
single water inlet connection (cold)
or double water inlet connection (hot
and cold) depending on the machine
specifications. The white capped hose
should be connected to cold water inlet
and red capped hose to the hot water
inlet (if applicable).
• To prevent water leaks at the joints,
either 1 or 2 nuts (depending on your
machine’s specifications) are supplied
in the packaging with the hose. Fit these
nuts to the end(s) of the water inlet hose
that connect to the water supply.
2. Connect new water inlet hoses to a ¾ ˝,
threaded tap.
• Connect the white capped end of the
water inlet hose to the white water inlet
valve on the rear side of the machine
and the red capped end of the hose to
EN - 14EN - 14
the red water inlet valve (if applicable).
• Hand tighten the connections. If in any
doubt, consult a qualified plumber.
• Water flow with pressure of 0. 1-1 Mpa
will allow your machine to operate at
optimum efficiency (pressure of 0. 1
Mpa means that more than 8 litres of
water per minute will flow through a fully
opened tap).
3. Once you have made all of the
connections, carefully turn the water
supply on and check for leaks.
4. Ensure that the new water inlet hoses
are not trapped, kinked, twisted, folded
or crushed.
• If your machine has a hot water inlet
connection, the temperature of the hot
water supply should not be higher than
70°C.
NOTE: Your Washing Machine
must only be connected to your water
supply using the supplied new fill hose. Old
hoses must not be reused.
4.5 Water Discharge Connection
• Connect the water drain hose to a
standpipe or to the outlet elbow of
a household sink, using additional
equipment.
• Never attempt to extend the water drain
hose.
• Do not put the water drain hose from
your machine into a container, bucket or
bathtub.
• Make sure that the water drain hose is
not bent, buckled, crushed or extended.
• The water drain hose must be installed
at a maximum height of 100 cm from the
ground.
5. CONTROL PANEL OVERVIEW
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
1 2 3
4
5
1. Detergent Drawer
2. Programme Dial: Use the programme
dial to select the washing / drying
programme for your laundry. Turn
the programme dial clockwise or
anticlockwise to select the required
programme. Make sure that the dial
is pointing exactly at the selected
programme.
3. Electronic Display
4. Additional Function Buttons: Use
these buttons to select additional
functions for the laundry programme.
See Additional Functions for more
information.
5. Start/Pause Button: Start or pause the
selected programme.
~ 95 cm ~ 140 cm
~ 145 cm ~ 95 cm
0 – max. 100 cm
˜
˜
95 cm
150 cm
EN - 15EN - 15
5.1 Detergent Drawer (*)
1
2
3
4
5
6
1. Liquid Detergent Attachments (*)
2. Main Wash Detergent Compartment
3. Softener Compartment
4. Pre-Wash Detergent Compartment
5. Powder Detergent Levels (*)
6. Powder Detergent Scoop (*)
(*) Specifications may vary depending on
the machine purchased.
5.2 Sections
Main wash detergent compartment:
This compartment is for liquid or powder
detergents or limescale remover. The fluid
detergent level plate will be supplied inside
your machine. (*)
Fabric conditioner, starch, detergent
compartment:
This compartment is for softeners,
conditioners or starch. Follow the
instructions on the packaging. If softeners
leave residue after use, try diluting them or
using a liquid softener.
Pre-wash detergent compartment:
This compartment should be used only
when the pre-wash feature is selected. We
recommend that the pre-wash feature is
used only for very dirty laundry.
(*) Specifications may vary depending on
the machine purchased.
EN - 16EN - 16
5.3 Program Dial
• To select the desired programme, turn
the programme dial either clockwise or
anti-clockwise until the marker on the
programme dial points to the chosen
programme.
• Make sure that the programme dial is
set exactly to the programme you want.
5.4 Electronic Display
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
9
8
21 3 5
4
6 7
1. Delayed start auxiliary function
2. Drying option selection
3. Duration Drying selection
4. Selecting the washing water
temperature
5. Spin speed selection
6. Options
7. Save+ / Speed (Eco washing, Quick
Wash auxiliary function)
8. Start Pause Button
9. Energy/Water Efficiency Bar
6. USING YOUR
WASHING MACHINE
6.1 Preparing Your Laundry
1
3
5
7
2
4
6
D
G
V
D
S
H
DGVDS
1. Follow the instructions given in the care
labels on the clothing.
• Separate your laundry according to type
(cotton, synthetic, sensitive, wool etc.
), washing temperature (cold, 30°, 40°,
60°, 90°) and the degree of dirtiness
(slightly stained, stained, highly stained).
2. Never wash coloured and white laundry
together.
• Dark textiles may contain excess dye
and should be washed separately
several times.
3. Ensure that there are no metallic
materials on your laundry or in the
pockets; if so, remove them.
CAUTION: Any malfunctions
which occur due to foreign materials
damaging your machine are not covered by
the warranty.
4. Close zips and fasten any hooks and
eyes.
5. Remove the metallic or plastic hooks of
EN - 17EN - 17
curtains or place them in a washing net
or bag.
6. Reverse textiles such as pants,
knitwear, t-shirts and sweat shirts.
7. Wash socks, handkerchiefs and other
small items in a washing net.
Maximum
ironing
temperature
150°C
Can be dry
cleaned
Drip dry
Dry cleaning
in gas oil,
pure alcohol
and R113 is
allowed
Maximum
ironing
temperature
200°C
No dry
cleaning
Hang to dry
Perchloroethylene
R11, R13,
Petroleum
Normal
washing
Do not iron
Dry flat
Do not tumble
dry
Perchlorinetyhlene
R11, R113, Gas
oil
Can be
bleached
Do not bleach
F P A
6.2 Putting Laundry in the Machine
• Open the door of your machine.
• Spread your laundry evenly in the
machine.
NOTE: Take care not to exceed
the maximum load of the drum as this will
give poor wash results and cause creasing.
Refer to the washing programme tables for
information on load capacities.
The following table shows approximate
weights of typical laundry items:
LAUNDRY TYPE WEIGHT (gr)
Towel 200
Linen 500
Bathrobe 1200
Quilt cover 700
Pillow slip 200
Underwear 100
Tablecloth 250
• Load each item of laundry separately.
• Check that no items of laundry are
trapped between the rubber seal and
the door.
• Gently push the door until it clicks shut.
click
• Make sure the door is fully closed,
otherwise the programme will not start.
6.3 Adding Detergent to the Machine
The amount of detergent you will need to
put in your machine will depend on the
following criteria:
• If your clothes are only slightly soiled,
do not pre-wash. Put a small amount
of detergent (as specified by the
manufacturer) into compartment II of the
detergent drawer.
• If your clothes are excessively soiled,
select a programme with pre-wash and
put ¼ of the detergent to be used into
compartment I of the detergent drawer
and the rest in compartment II.
• Use detergents produced for automatic
washing machines. Follow the
manufacturer’s instructions on the
amount of detergent to use.
• In areas of hard water, more detergent
will be required.
• The amount of the detergent required
will increase with higher washing loads.
EN - 18EN - 18
• Put softener in the middle compartment
of the detergent drawer. Do not exceed
the MAX level.
• Thick softeners may cause clogging of
the drawer and should be diluted.
• It is possible to use fluid detergents in
all programmes without a pre-wash. To
do this, slide the fluid detergent level
plate (*) into the guides in compartment
II of the detergent drawer. Use the lines
on the plate as a guide to fill the drawer
to the required level.
(*) Specifications may vary depending on
the machine purchased.
6.4 Operating Your Machine
1 2
1. Plug your machine in to the mains
supply.
2. Turn on the water supply.
• Open the machine door.
• Evenly spread your laundry in the
machine.
• Gently push the door until it clicks shut.
6.5 Selecting a Programme
Use the programme tables to select the
most appropriate programme for your
laundry.
6.6 Half-Load Detection System
Your machine features a half-load detection
system.
If you put less than half the maximum
load of laundry into your machine it will
automatically set the half-load function,
regardless of the programme you selected.
This means that the selected programme
will take less time to complete and will use
less water and energy.
6.7 Auxiliary Functions
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
Before starting the program,
you can select auxiliary functions if you
wish so.
• Press the key of the auxiliary function you
want to select.
• If the symbol of the auxiliary function is
continuously on in the electronic display, the
selected auxiliary function will be enabled.
• If the symbol of the auxiliary function
is flashing in the electronic display, the
selected auxiliary function will not be
enabled.
Reason for not enabling the function:
• That auxiliary function might not be
available for the selected washing
program.
• The machine might have passed the
step where that auxiliary function could
be applied.
• The auxiliary function might be
incompatible with another auxiliary
function you have previously selected.
1. Delayed start auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use this auxiliary function to delay
the start time of the washing cycle for 1 to
23 hours.
To use the delay function:
• Press the delay key once.
• “1h” will be displayed. will turn on in
the electronic display.
EN - 19EN - 19
• Press the delay key until you reach the
time after which you want the machine
to start the washing cycle.
• If you have skipped the delay time you
would like to set, you can keep pressing
the delay key until you reach that time
again.
• To use the time delay function, you need
to press the Start/Pause key to start the
machine.
NOTE: After selecting the delay
function, you can select other functions
without touching the “Start/Pause” key, and
then you can touch the “Start/Pause” key to
enable time delay.
To cancel the delay function:
• If you did not press the Start/Pause key,
keep touching the delay key until the
electronic display shows the duration
of the program you have selected.
Once you see the program time on the
electronic display, this means that the
delay has been cancelled.
• If you have pressed the Start/Pause
key to start the machine, you just need
to touch the delay key once. will go off
on the electronic display, press “Start/
Pause” key to start the washing cycle.
2. Drying option selection:
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
If you would like your laundry dried at the
end of a washing programme, press the
drying option button to select the desired
drying setting.
When you press the drying option button,
Iron Dry “ ”, Hanger Dry “ ” and
Cupboard Dry “ ” symbols will be shown
on the display.
• Iron dry “ ”: 80 min. : Recommended
for laundry that will be ironed before
using. To select the “ ” drying option,
press the drying option button until the “
” symbol is displayed.
• Hanger dry “ ”: 135 min. :
Recommended for laundry that requires
hanging. To select the “ ” drying
option, press the drying option button
until the “ ” symbol is displayed.
• Cupboard dry “ ”: 305 min. :
Recommended for laundry that will be
folded and put into a wardrobe at the
end of the programme. To select the “
” drying option, press the drying option
button until the “ ” symbol is displayed.
NOTE: If there are no changes
in the level when you touch the soiling
level key, it means there is no soiling level
selection in the program you have selected.
If you want your laundry dried for a fixed
period of time at the end of the washing
cycle:
• Press the drying duration option button
to select the desired Time Dry.
• Drying selections will be displayed on
your machine screen as 30’, 60’, 90’ and
120’ minutes.
EN - 20
2.1 Drying option selection:
PROGRAMME
SELECTABLE/
NOT
SELECTABLE
DRYING
PROFILE
FACTORY
PRESET
SELECTABLE OPTIONS
Eco 40-60 S Cotton Dry - Option 1 Option 2 Option 3
Cotton S Cotton Dry - Option 1 Option 2 Option 3
Cotton 20°C S Cotton Dry - Option 1 Option 2 -
Synthetics S Gentle Dry - Option 1 Option 2 Option 3
Wool&Silk NS - - - - -
Duvet NS - - - - -
Rinse S Cotton Dry - Option 1 Option 2 Option 3
Allergy Safe S Cotton Dry - Option 1 Option 2 -
Spin / Drain S Cotton Dry - Option 1 Option 2 Option 3
Rapid 12’ S Cotton Dry - Option 1 - -
Fast 60’/60°C S Cotton Dry - Option 1 Option 2 -
Gentle Dry S Gentle Dry Option 2 Option 1 - Option 3
Cotton Dry S Cotton Dry Option 2 Option 1 - Option 3
Quick Wash
& Dry
NS Cotton Dry Option 1 - - -
Cotton Wash
& Dry
S Cotton Dry Option 2 Option 1 - Option 3
S: Selectable NS: No Selection
Selectable drying duration levels
Eco 40-60 30 60 90 120
Cotton 30 60 90 120
Cotton 20°C 30 60 90 120
Synthetics 30 60 90 120
Wool&Silk - - - -
Duvet - - - -
Rinse 30 60 90 120
Allergy Safe 30 60 90 120
Spin / Drain 30 60 90 120
Rapid 12’ 30 60 90 120
Fast 60’/60°C 30 60 90 120
Gentle Dry 30 60 90 120
Cotton Dry 30 60 90 120
Quick Wash & Dry - - - -
Cotton Wash & Dry 30 60 90 120
EN - 21EN - 21
3. Drying With Duration selection :
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
If you continue pressing, duration options
(0:30, 0:60, 0:90, 120 minutes) will be
displayed. You can select the drying
duration you want.
NOTE: If one of the 30’ 60’ 90’
120’ above drying duration options is not
displayed when you press the Time Dry
button, it is not available for the selected
programme.
Table: Recommended drying durations
for load amounts:
Duration Drying Programmes
Amount of
laundry to dry
Recommended drying
time
1 kg 30 minutes
2 kg 60 minutes
3,0 kg 90 minutes
3.5 kg 120 minutes
If the amount of laundry to be dried
is above 3.5kg, we recommend that
you select Cupboard, Hanger or Iron
Drying.
4. Selecting the washing water
temperature
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use the washing water
temperature setting key to set the
temperature of the washing water for your
laundry.
• When you select a new program,
the selected program’s maximum
temperature will be displayed on the
washing water temperature display.
• You can press the washing water
temperature setting key to decrease
the washing water temperature
gradually between the maximum
water temperature of the selected
program and cold water wash ( ).
• If you have skipped the washing
water temperature you wanted to
set, keep pressing the washing water
temperature key to find the desired
temperature again.
5. Spin speed selection
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use the speed setting key to set
the spin speed for your laundry. When
you select a new program, the selected
program’s maximum spin speed will be
displayed on the spin speed display.
You can press the spin speed setting key
to decrease the spin speed gradually
between the selected program’s
maximum spin speed and the spin
cancelled ( ) option.
If you have skipped the spin speed you
wanted to set, you can keep pressing the
spin speed key to find the desired speed
again.
EN - 22EN - 22
6. Options
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use auxiliary functions to make
the best washing selection for your
laundry. To do this, you can touch the
options key on the display panel to enable
the following:
6.1 Prewash auxiliary function
6.2 Extra rinse auxiliary function
6.3 Steam Assist auxiliary function
6.4 Anti-allergy auxiliary function
6.1 Prewash auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use this auxiliary function to
perform pre-wash before the main wash
cycle for your highly soiled laundry. When
you use this function, you need to add
detergent into the prewash dispenser
of the detergent drawer. To enable the
prewash auxiliary function, press the
options key until the prewash symbol
turns on. If the prewash LED is
constantly on in the electronic display,
it means that the auxiliary function is
selected.
NOTE: When you want to select
the prewash auxiliary function, if does
not appear on the display, this means that
this feature is not available in the selected
washing program.
6.2 Extra rinse auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use this auxiliary function for
extra rinsing on your laundry. To enable
the extra rinse function, keep pressing the
options key until the extra rinse symbol
turns on. If the extra rinse LED is
constantly on in the electronic display,
it means that the auxiliary function is
selected.
NOTE:When you want to select
the extra rinse auxiliary function, if
does not appear on the display, this
means that this feature is not available in
the selected washing program.
6.3 Steam Assist auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
Owing to the steam system ironing
has become quick and as easy. The
steam used dream washing penetrates
and loosens the fibres, eliminates creases
and leaves our clothes soft and delicate.
NOTE: When you want to select
the steam system auxiliary function, if
does not appear on the display, this
means that this feature is not available in
the selected washing program.
EN - 23EN - 23
6.4 Anti-allergy auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
You can use this auxiliary function to
add another rinse cycle for your laundry.
Your machine will use hot water in all
rinsing steps. (It is recommended for
sensitive skin clothing, baby clothes and
underclothes). To enable the anti-allergy
auxiliary function, keep pressing the
options key until the anti-allergy function
symbol turns on. If the anti-allergy
LED is constantly on in the electronic
display, it means that the auxiliary
function is selected.
NOTE: When you want to
select the anti-allergy auxiliary function,
if does not appear on the display, this
means that this feature is not available in
the selected washing program.
7. Eco/Quick Wash auxiliary function
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
Eco washing auxiliary function:
If you select this auxiliary function, your
machine will slightly extend the duration
of the washing program. However, it
will use less energy and water for the
washing cycle. To enable this function,
you can touch the Save+/Speed selection
key on the display panel to turn on the
LED light of the symbol .
Quick Wash auxiliary function:
If you select this auxiliary function, your
machine will shorten the duration of the
washing program. (It is recommended
to load the machine with half or less
than half of the capacity of the selected
washing program.) To enable this
function, you can touch the Save+/Speed
selection key on the display panel to turn
on the LED light of the symbol .
NOTE: If you load the machine
with half or less than half of the laundry
capacity of the selected washing program,
the machine will detect it thanks to the
half load detection system, and this way,
it will wash your laundry with less energy
and less water in a shorter time. When
your machine detects half load, LED light
of the symbol will automatically turn
on in the display panel.
(*) The appliance specifications may vary
depending on the purchased product.
• Energy/Water Efficiency Bar:
“ ” is an efficiency indicator
comprising 2 bars. The energy/water
efficiency bar shows the amount of
energy and water consumption. The
bigger the bar is, the more energy or
water consumption you will have. The
energy/water efficiency bar might extend
or shorten depending on the selected
program’s duration, temperature setting,
spin speed and other auxiliary functions.
Start/Pause button
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
By pressing on the Start/Pause button,
you may start the programme you have
selected or suspend a running
programme. If you switch your machine to
the standby mode, the Start/Pause led on
the electronic display will blink.
EN - 24EN - 24
6.8 Child Lock
The Child Lock function allows you to
lock the buttons so that the wash cycle
you have chosen cannot be changed
unintentionally.
To activate child lock, press and hold
button 6 and 7 simultaneously for at
least 3 seconds. ‘’CL’’ will flash on the
electronic display for 2 seconds when the
child lock is activated.
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
6 7
If any button is pressed or selected
programme is changed by the programme
dial while the child lock is active, the “CL”
symbol will flash on the electronic display
for 2 seconds.
If the child lock function is active and
a programme is running, when the
programme dial is turned to the “Off”
position and another programme
is selected the previously selected
programme continues from where it was
left.
To deactivate the child lock, press and
hold button 6 and 7 simultaneously for at
least 3 seconds until the “CL” symbol on
the electronic display disappears.
NOTE: Door remains unlocked
in case when child lock is active and
electricity is cut off
6.9 If you want to pause/cancel a
running program or add laundry:
• symbol key allows you to pause
or restart the selected program. When
you want to add laundry, you can use
this function.
• Touch symbol button for this. If
is displayed on the screen, you
can open the loading door and add
laundry.
• If is displayed on the screen, the
step where you can add laundry has
passed.
• If you want to cancel a running
program, turn the program knob to
“CANCEL” position. Your machine
will stop washing process and the
program will be cancelled. To drain
the water in the machine, turn
the program knob to any program
position. Your machine will drain the
water and cancel the program. You
can select a new program and start
the machine.
6.10 Program End
Dry
Option
Time
Dry
Temp. Spin Options
Delay
Save+/
Speed
Start/
Pause
Your machine will automatically stop
when the selected program ends.
• “End” will appear on the electronic
display.
• You can open the door and take
out the laundry. After taking out the
laundry, leave the door open so that
the inside of the machine can dry.
• Turn the program knob to CANCEL
position.
• Unplug the machine.
• Turn off the water tap.
EN - 25
7. PROGRAMME TABLE
Programme Eco 40-60 Cotton Cotton 20°C
Selectable
washing
temperatures
(°C)
40°*, 60° 60°*, 90°, 60°, 40° 20°*, (Cold water)
Maximum
washing/drying
capacity (kg)
9.0 / 6.0 9.0 / 6.0 4.5 / 4.5
Selectable spin
speed (rev /
min)
(No spin), 400, 600, 800,
1000, 1200, 1400*
(No spin), 400, 600, 800,
1000, 1200, 1400*
(No spin), 400, 600, 800,
1000, 1200, 1400*
Laundry type /
Descriptions
Heat resistant cotton and linen
textiles (underwear, bedding,
tablecloths and towels) (max
4,5 kg)
Cotton and linen textiles
(underwear, bed sheet,
tablecloth, towel (max. 4,5
kg)
Less dirty, cotton and
linen textiles. (bed sheet,
tablecloth, towel (max.
2.5 kg)
Selectable
additional
functions
* * *
Selectable
drying functions
**
Programme Synthetics Wool & Silk Duvet
Selectable
washing
temperatures
(°C)
40°*, 30°, (Cold wash) 30°*, (Cold wash) 40°*, 30°, (Cold wash)
Maximum
washing/drying
capacity (kg)
3.5 / 3.5 2.5 -
Selectable spin
speed (rev /
min)
(No spin), 400, 600, 800,
1000, 1200*
(No spin), 400, 600 ,800* (No spin), 400, 600, 800*
Laundry type /
Descriptions
Synthetic and synthetic mix
textiles. (synthetic content shirt,
blouse, socks etc.)
Woollen and wool mix
laundry with machine wash
labels.
For washing a fibre duvet
with a machine washable
label. (max. 2.5 kg)
Selectable
additional
functions
Selectable
drying functions
**
- -
NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE
AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED
ADDITIONAL FUNCTIONS.
(*) Programme factory default settings.
(**) When you want to select more than one additional function, the additional functions you wish to select may not comply with each
other.
Do not dry towels, cotton and linens, and synthetic and sythetic mix clothes together.
For drying select the most appropriate drying program for the clothes.
EN - 26
Programme Rinse Allergy Safe Spin / Drain
Selectable
washing
temperatures
(°C)
(Cold wash)* 60°*, 40°, 30°, (Cold wash) (Cold wash)*
Maximum
washing/drying
capacity (kg)
9.0 / 6.0 4.5 / 4.5 9.0 / 6.0
Selectable spin
speed (rev /
min)
(No spin), 400, 600, 800,
1000, 1200, 1400*
(No spin),400, 600, 800*
(No spin),400, 600, 800,
1000, 1200, 1400*
Laundry type /
Descriptions
This programme can be used
for additional rinsing after
washing.
Baby dresses
This programme can be used
for additional spinning after
washing.
Selectable
additional
functions
*
Selectable
drying functions
**
Programme Rapid 12’ Fast 60' 60°C Gentle Dry
Selectable
washing
temperatures
(°C)
30°*, (Cold wash) 60°*, 40°, 30°, (Cold wash) -
Maximum
washing/drying
capacity (kg)
2.0 / 2.0 4.5 / 4.5 3.5
Selectable spin
speed (rev /
min)
(No spin), 400, 600, 800*
(No spin), 400, 600, 800,
1000, 1200 1400*
-
Laundry type /
Descriptions
For washing less dirty cotton,
coloured and linen textiles in
a little as 12 minutes.
Note: As the washing time
is short, less detergent
is required than in
other programmes. The
programme period will
increase if your machine
detects unstable loading.
Dirty, cotton, coloured and
linen textiles. (The washing
duration for loads of 2kg and
under is 30 minutes)
Cotton laundry with machine
dryable label.
Selectable
additional
functions
* *
Selectable
drying functions
**
*
NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE
AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED
ADDITIONAL FUNCTIONS.
(*) Programme factory default settings.
(**) When you want to select more than one additional function, the additional functions you wish to select may not comply with each
other.
Do not dry towels, cotton and linens, and synthetic and sythetic mix clothes together.
For drying select the most appropriate drying program for the clothes.
EN - 27
Programme Cotton Dry Quick Wash & Dry Cotton Wash & Dry
Selectable
washing
temperatures
(°C)
- 30°*, (Cold wash)
40°*, 90°, 60°, 40°, 30°,
(Cold wash)
Maximum
washing/drying
capacity (kg)
6.0
0.5 / 0.5 kg (3 shirts)
6.0 / 6.0
Selectable spin
speed (rev /
min)
- 800* 1400*
Laundry type /
Descriptions
Cotton laundry with machine
dryable label.
Cotton, coloured and linen
laundry with machine dryable
label.
Note: The machine
automatically determines the
duration of the programme
according to the amount of
laundry in the machine.
Cotton and linen textiles
(underwear, bed sheets,
tablecloth, towel (max. 3.0
kg)
Selectable
additional
functions
Selectable
drying functions
**
*
*
*
NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF
LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.
(*) Programme factory default settings.
(**) When you want to select more than one additional function, the additional functions you wish to select may not comply with each
other.
Do not dry towels, cotton and linens, and synthetic and sythetic mix clothes together.
For drying select the most appropriate drying program for the clothes.
The Eco 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40°C
or 60°C, together in the same cycle, and that this programme is used to assess the compiance with the EU
ecodesign legislation.
The wash and dry cycle is able to clean normally soiled cotton laundry declared to be washable at 40°C or
60°C, together in the same cycle, and to dry it in such a way that it can be immediately stored in a cupboard,
and that this programme is used to assess the compliance with the EU ecodesign legislation.
EN - 28
• For household washer-dryers; the wash and dry cycle is able to clean normally
soiled cotton laundry declared to be washable at 40°C or 60°C, together in the
same cycle, and to dry it in such a way that it can be immediately stored in a
cupboard, and that this programme is used to assess the compliance with the EU
ecodesign legislation.
• The most efficient programmes in terms of energy consumption are generally those
that perform at lower temperatures and longer duration.
• Loading the household washer-dryer up to the capacity indicated by the
manufacturer for the respective programmes will contribute to energy and water
savings.
• Program duration, energy consumption and water consumption values may vary
according to wash load weight and type, selected extra functions, tap water and
ambient temperature.
• It’s recommended to use liquid detergent for the washing programmes at low
temperature. The amount of detergent to be used may vary depending on the
amount of laundry and the level of dirtiness of the laundry. Please follow the
detergent manufacturers’ recommendations for the amount of the detergent to be
used.
• The noise and remaining moisture content are influenced by the spinning speed.
The higher spinning speed in the spinning phase, the higher noise and the lower
remaining moisture content.
• You can access the product database where the model information is stored by
reading the QR code on the energy label.
EN - 29
Programme
Name
Rated
Capacity kg
Energy Consumption
kWh/cycle
Programme Duration
Hours:Minutes
Water
Consumption
Litres/Cycle
max.
Temperature
°C
Remaining
Moisture Content
%
1400 Rpm
Rated
Capacity
1/2 Load
1/4 Load
Rated
Capacity
1/2 Load
1/4 Load
Rated
Capacity
1/2 Load
1/4 Load
Rated
Capacity
1/2 Load
1/4 Load
Rated
Capacity
1/2 Load
1/4 Load
Cotton
90
9 2,20 03:21 76 81 53%
Cotton
60
9 1,05 03:55 49 46 53%
Eco
40-60
9 1,17 0,54 0,28 03:49 02:54 02:54 59 45 45 44 30 23 53% 53% 53%
Synthetic
3,5 0,72 01:50 52 42 53%
Fast 60’
60°C
4,5 0,85 01:00 36 58 53%
Cotton
20
4,5 0,22 01:43 46 20 53%
Wash
and Dry
6 4,63 2,46 09:00 05:00 100 66 38 27
EN - 30
7.1 Important Informations
• Use detergents, softeners and other additives suitable for automatic washing
machines only. Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
• We recommend that periodic cleaning for washing machine every 2 months. For
periodic cleaning please use Drum Clean programme. If your machine do not
have Drum Clean programme, use Cottons-90 programme. When required, use
limescale removers manufactured specifically for washing machines only.
• Never force the door open when your Washing Machine is running. You can open
the door of your machine 2 minutes after the completion of a washing operation. *
• Never force the door open when your Washing Machine is running. The door will
open immediately after the washing cycle has ended. *
• The installation and repairing procedures should always carried out by the
Authorised Service Agent in order to avoid possible risks. The manufacturer shall
not be held liable for damages that may arise from procedures carried out by
unauthorised persons.
(*) Specifications may vary depending on the machine purchased.
EN - 31EN - 31
8. CLEANING AND
MAINTENANCE
8.1 Warning
Turn your mains power
supply off and remove
the plug from the socket
before carrying out
maintenance and
cleaning of your
machine.
Turn off the water
supply before starting
maintenance and
cleaning of your
machine.
CAUTION: Do not
use solvents, abrasive
cleaners, glass cleaners
or all-purpose cleaning
agents to clean your
Washing Machine. They
may damage the plastic
surfaces and other
components with the
chemicals they contain.
8.2 Water Inlet Filters
Water inlet filters prevent dirt and foreign
materials from entering your machine.
We recommend that these filters are
cleaned when your machine is unable
to receive sufficient water, although your
water supply is on and the tap is open.
We recommend that you clean your water
inlet filters every 2 months.
• Unscrew the water inlet hose(s) from
the Washing Machine.
• To remove the water inlet filter from
the water inlet valve, use a pair of
long-nosed pliers to gently pull on the
plastic bar in the filter.
• A second water inlet filter is located
in the tap end of the water inlet hose.
To remove the second water inlet
filter, use a pair of long-nosed pliers
to gently pull on the plastic bar in the
filter.
• Clean the filter thoroughly with a soft
brush and wash with soapy water and
rinse thoroughly. Re-insert the filter by
gently pushing it back into place.
CAUTION: The filters at the
water inlet valve may become clogged
due to water quality or lack of required
maintenance and may break down.
This may cause a water leak. Any such
breakdowns are out of the scope of the
warranty.
EN - 32EN - 32
8.3 Pump Filter
1
3
5
2
4
6
The pump filter system in your Washing
Machine prolongs the life of the pump by
preventing lint from entering your machine.
We recommend that you clean the pump
filter every 2 months.
The pump filter is located behind the cover
on the front-lower right corner.
To clean the pump filter:
8. You may use the washing powder spade
(*) supplied with your machine or liquid
detergent level plate to open the pump
cover.
9. Lodge the end of the powder spade
or liquid detergent level plate in the
opening of the cover and gently press
backwards. The cover will open.
• Before opening the filter cover, place a
container under the filter cover to collect
any water left in the machine.
• Loosen the filter by turning anticlockwise
and remove by pulling. Wait for the
water to drain.
NOTE: Depending on the
amount of water inside the machine, you
may have to empty the water collection
container a few times.
10. Remove any foreign materials from the
filter with a soft brush.
11. After cleaning, re-fit the filter by inserting
it and turning clockwise.
12. When closing the pump cover, ensure
that the mountings inside the cover
meet the holes on the front panel side.
13. Close the filter cover.
WARNING: The water in the
pump may be hot, wait until it has cooled
down before carrying out any cleaning or
maintenance.
(*) Specifications may vary depending on
the machine purchased.
8.4 Detergent Drawer
The use of detergent may cause residual
build up in the detergent drawer over time.
We recommend that you remove the drawer
every 2 months to clean the accumulated
residue.
To remove the detergent drawer:
• Pull the drawer forwards until it is fully
extended.
• Press the region shown below inside
the detergent drawer you have pulled
all the way back, and continue pulling
and remove the detergent drawer from
its place
• Remove the detergent drawer and
disassemble the flush stopper. Clean
thoroughly to completely remove any
EN - 33EN - 33
softener residue. Refit the flush
stopper after cleaning and check that
it is seated properly.
• Rinse with a brush and lots of water.
• Collect the residues inside the
detergent drawer slot so that they
don’t fall inside your machine.
• Dry the detergent drawer with a towel
or dry cloth and place it back
Do not wash your detergent
drawer in a dishwasher.
Liquid detergent apparatus(*)
For the cleaning and maintenance of the
liquid level detergent apparatus, remove
the apparatus from its location as shown
in the picture below, and thoroughly
clean the remaining detergent residues.
Replace the apparatus. Make sure that
no residual material remains inside the
siphon.
(*) Specifications may vary depending on
the machine purchased.
9. Body / Drum
1 2
1. Body
Use a mild, non-abrasive cleaning agent,
or soap and water, to clean the external
casing. Wipe dry with a soft cloth.
2. Drum
Do not leave metallic objects such as
needles, paper clips, coins etc. in your
machine. These objects lead to the
formation of rust stains in the drum. To
clean such rust stains, use a non-chlorine
cleaning agent and follow the instructions
of manufacturer of the cleaning agent.
Never use wire wool or similar hard
objects for cleaning rust stains.
EN - 34
10. TROUBLESHOOTING
Repair of your machine should be carried out by an authorised service company.
If your machine requires repair or if you cannot solve an issue with the information
provided below, then you should:
• Unplug your machine from the mains power supply.
• Turn off the water supply.
FAULT POSSIBLE CAUSE TROUBLESHOOTING
Your machine does not start.
Machine not plugged in. Plug machine in.
Fuses are faulty. Replace the fuses.
No mains power supply. Check mains power.
Start/Pause button not pressed. Press the Start/Pause button.
Programme dial ‘stop’ position. Turn the programme dial to the desired position.
The machine door is not
completely closed.
Close the machine door.
Your machine does not
intake water.
Water tap is turned off. Turn tap on.
Water inlet hose may be twisted. Check water inlet hose and untwist.
Water inlet hose clogged. Clean water inlet hose filters. (*)
Inlet filter clogged. Clean the inlet filters. (*)
The machine door is not
completely closed.
Close the machine door.
Your machine does not
discharge water.
Drain hose clogged or twisted.
Check the drain hose, then either clean or
untwist.
Pump filter clogged. Clean the pump filter. (*)
Laundry is too tighly packed
together in the drum.
Spread your laundry in the machine evenly.
Your machine vibrates.
The feet have not been adjusted. Adjust the feet. (**)
Transit bolts fitted for
transportation have not been
removed.
Remove the transit bolts from the machine. (**)
Small load in the drum. This will not prevent operation of your machine.
Your machine is overloaded with
laundry or laundry is unevenly
spread.
Do not overload the drum. Spread laundry evenly
in the drum.
Your machine rests on a hard
surface.
Do not set up your Washing Machine on a hard
surface.
Excessive foam is formed in
the detergent drawer.
Excessive amount of detergent
used.
Press the Start/Pause button. To stop the foam,
dilute one tablespoon of softener into 1/2 litre of
water and pour into the detergent drawer. Press
the Start/Pause button after 5-10 mins.
Wrong detergent used.
Only use detergents produced for automatic
Washing Machines.
EN - 35
FAULT POSSIBLE CAUSE TROUBLESHOOTING
Unsatisfactory washing
result.
Your washing is too dirty for the
programme selected.
Use the information in the programme tables to
select the most appropriate programme.
Amount of detergent used
insufficient.
Use the amount of detergent as instructed on the
packaging.
There is too much laundry in your
machine.
Check that the maximum capacity for the
selected programme has not been exceeded.
Unsatisfactory washing
result.
Hard water.
Increase the amount of detergent following the
manufacturer’s instructions.
Your laundry is too tightly packed
together in the drum.
Check that your laundry is spread out.
As soon as the machine is
loaded with water, water
discharges.
The end of water drain hose is too
low for the machine.
Check that the drain hose is at a suitable height.
(**) .
No water appears in the
drum during washing.
No fault. Water is in the unseen
part of the drum.
. . . . . . . . . . . . . . . . . . . . .
Laundry has
detergent residue.
Non-dissolving particles of some
detergents may appear on your
laundry as white spots.
Perform an extra rinse, or clean your laundry with
a brush after it dries.
Grey spots appear on the
laundry.
There is untreated oil, cream or
ointment on your laundry.
Use the amount of detergent as instructed on the
packaging in the next wash.
The spin cycle does not take
place or takes place later
than expected.
No fault. The Unbalanced load
control system has been activated.
The Unbalanced load control system will try to
spread your laundry. The spinning cycle will begin
once your laundry is spread. Load the drum
evenly for the next wash.
Laundry remains damp after
the drying operation.
Appropriate drying programme
is not selected. The maximum
load capacity for the selected
programme might be exceeded.
Select a drying programme appropriate for your
laundry (see page 21 for the programme table)
(*) See the chapter regarding maintenance and cleaning of your machine.
(**) See the chapter regarding installation of your machine.
EN - 36
11. AUTOMATIC FAULT WARNINGS AND WHAT TO DO
Your Washing Machine is equipped with a built-in fault detection system, indicated by
a combination of flashing wash operation lights. The most common failure codes are
shown below.
TROUBLE CODE POSSIBLE FAULT WHAT TO DO
Er 01
The door of your machine is not shut
properly.
Shut the door properly until you hear a click. If
your machine persists to indicate fault, turn off
your machine, unplug it and contact the nearest
authorised service agent immediately.
Er 02
The water pressure or the water level
inside the machine may be low.
Check the tap is fully turned on. Mains water
may be cut-off. If the problem still continues, your
machine will stop after a while automatically. Unplug
the machine, turn off your tap and contact the
nearest authorised service agent.
Er 03
The pump is faulty or pump filter is
clogged or electrical connection of the
pump is faulty.
Clean the pump filter. If the problem persists,
contact the nearest authorised service agent. (*)
Er 04
Your machine has excessive amount of
water.
Your machine will discharge water by itself. Once
the water has drained, turn off your machine and
unplug it. Turn off the tap and contact the nearest
authorised service agent.
(*) See the chapter regarding maintenance and cleaning of your machine.
52396315
The minimum period which
must supply the spare parts
for the household
washer-dryer
is 10 years.
WWW.CORBERO.ES
Servicruz SL
Vidal i Ribes 8-10 08950 Esplugues de Llobregat
Barcelona
Telf. 911 08 08 08
The minimum period which must supply the spare parts
for the household washing machine is 10 years.
CERTIFICADO DE GARANTÍA
Imprescindible la presentación de la factura de compra acompañada del presente certicado de garantía.
Riesgos cubiertos.
Este aparato está garantizado contra cualquier defecto de funcionamiento, siempre que se destine a uso doméstico,
procediéndose a su reparación dentro del plazo de garantía y sólo por la red de SAT autorizados.
Nuestros electrodomésticos Corberó cuentan con la garantía legal del fabricante que cubre cualquier avería o defecto durante36
meses, desde su fecha factura de 1 de enero del 2022. En caso de que fuera necesario, nosotros nos ocupamos de cualquier posible
incidencia siempre que se deba a un componente defectuoso o fallo de fabricación.
Excepciones de garantía.
• Que la fecha del certicado no coincida con la fecha de venta de la factura original.
• Averías producidas por golpe, por caída o cualquier otra causa de fuerza mayor.
• Si el apa
rato ha sido manipulado por personal no autorizado.
• Las averías producidas o derivadas como consecuencia de un uso inadecuado, por defectos de instalación,
por introducir modicaciones en el aparato que alteren su funcionamiento.
• Puestas en marcha, mantenimiento, limpiezas, componentes sujetos a desgaste, lámparas, piezas estéticas,
oxidaciones, plásticos, gomas, carcasas y cristales.
“ESTAS EXCEPCIONES ANULAN LA GARANTÍA, SIENDO LA REPARACIÓN CON CARGO AL CLIENTE”
Periodo amparado en aparatos según ley de garantias en la venta de bienes de consumo Ley vigente es “RD 7/2021”
Horario de atención Lunes a Viernes de 9h00 a 19h00. Teléfono de contacto_ 911 08 08 08 Mail de contacto_ [email protected] web_ www.corbero.es
Dirección de Servicio técnico oficial_Vidal i Ribes 8-10 08950 Esplugues de Llobregat Barcelona
Sevicio Técnico Ocial: 911 08 08 08
Los hornos microondas (a excepción de los integrables) y los hornos sobremesa en el caso de cualquier incidencia de
funcionamiento, deben de llevarse al servicio técnico más próximo por parte del cliente. No se recojen ni reparan en el
domicilio.
•
Garantía termos eléctricos. Garantía de 3 años incluyendo los costes de desplazamiento y mano de obra que
correspondan de la reparación del producto, teniendo que tener un mantenimiento una vez cada 12 meses.
Especialmente si Ud. ha instalado un aparato a gas, tenga presente como titular de la instalación, la obligatoriedad de
realizar una revisión completa de los equipos, (según Real Decreto 238 / 2013, del 5 Abril. RITE. IT3, M. Lo termos
eléctricos y calderas que incluyen depósitos acumuladores de agua caliente, para que se aplique la prestación de la
Garantía, es obligatorio que el ánodo de magnesio esté operativo y que realice la función de protección
adecuadamente. Para ello es recomendable que el ánodo se revise bianualmente por el Servicio Oficial y sea renovado
cuando fuera necesario. Periodicidad que deberá ser anual en aquellas zonas con aguas críticas (contenido de CaCO3
superiores a 200mg/L, es decir a partir de 20ºfH de dureza). Depósitos sin el correcto estado del ánodo de protección, no
tienen la cobertura de la garantía. Independientemente del tipo de depósito o producto, todas las válvulas de
sobrepresión de calefacción o a.c.s., deberán ser canalizadas para evitar daños en Ia vivienda por descargas de agua. La
garantía del producto no asume los daños causados por Ia no canalización del agua derramada por esta válvula.
•
CERTIFICATE OF GUARANTEE
The presentation of the purchase invoice accompanied by this guarantee certificate is essential.
Covered Risks.
This appliance is guaranteed against any malfunction, provided that it is intended for domestic use, proceeding to its repair within
the warranty period and only by the authorized SAT network.
Our Corberó appliances have the manufacturer's legal warranty that covers any breakdown or defect for 36 months, from the
invoice date of January 1, 2022. If necessary, we take care of any possible incident whenever it is due to a defective component or
manufacturing fault. Warranty Exceptions
Warranty Exceptions
•
That the date of the certificate does not coincide with the date of sale of the original invoice.
•
Faults produced by blow, by fall or any other cause of force majeure.
•
If the device has been manipulated by unauthorized personnel.
•
Faults produced or derived as a consequence of improper use, installation defects, or modifications to the device that
alter its operation.
•
Start-up, maintenance, cleaning, components subject to wear, lamps, aesthetic parts,
oxidation, plastics, rubbers, housings and crystals.
“THESE EXCEPTIONS VOID THE WARRANTY, THE REPAIR BEING CHARGED TO THE CUSTOMER”
Period covered in devices according to the law of guarantees in the sale of consumer goods Current law is “RD 7/2021”
Hours of operation Monday to Friday from9h00 a 19h00. Telephone contact_ 911 08 08 08 Contact email_ [email protected] web_ www.corbero.es
Official Technical Service Address_Vidal i Ribes 8-10 08950 Esplugues de Llobregat Barcelona
Official Technical Service: 911 08 08 08
Microwave ovens (with the exception of built-in ones) and tabletop ovens in the event of any incident of
operation, they must be taken to the nearest technical service by the customer. They are not collected or repaired at
home.
•
Electric thermos guarantee. 3-year warranty including travel and labor costs that correspond to the repair of the
product, having to have maintenance once every 12 months. Especially if you have installed a gas appliance, keep in
mind as the owner of the installation, the obligation to carry out a complete review of the equipment, (according to
Royal Decree 238 / 2013, of April 5. RITE. IT3, M. Lo thermos electrical and boilers that include hot water storage tanks,
for the benefit of the Guarantee to apply, it is mandatory that the magnesium anode is operational and that it performs
the protection function adequately.For this, it is recommended that the anode be checked biannually by the Official
Service and is renewed when necessary Periodicity that must be annual in those areas with critical waters (CaCO3
content greater than 200mg/L, that is, from 20ºfH of hardness) Deposits without the correct state of the protection
anode are not covered by the warranty Regardless of the type of tank or product, all heating or DHW overpressure
valves must be channeled to avoid damage and n the house due to water discharges. The product warranty does not
cover damages caused by not channeling the water spilled by this valve.
•
