Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs
and all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with
all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately
by a qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensure that repairs are carried out by a qualied electrician.
1.2. GENERAL SAFETY
9 Disconnect the ventilator from the mains power when not in use, and before servicing or performing any maintenance.
9 Use the fan in dry areas only. Do not use in wet or high condensation locations such as bathrooms, showers, or pools.
WARNING! If a ventilator falls into water, immediately switch off at the mains and disconnect from the mains power supply.
8 DO NOT touch the ventilator until the mains power supply has been disconnected.
9 Always disconnect the ventilator from the power supply when moving it from one location to another.
9 Keep the ventilator clean and maintain in good condition (use an authorised service agent).
9 Use recommended parts only (unauthorised parts may be dangerous, and will invalidate your warranty).
8 DO NOT stand the ventilator where it may be knocked over or off a surface, or where the lead may cause a trip hazard.
8 DO NOT use an extension cord unless it has been approved by an electrical authority.
8 DO NOT insert any objects through the fan guard.
8 DO NOT allow children to operate the ventilator.
8 DO NOT immerse the ventilator in water or any other liquid.
8 DO NOT use the ventilator outdoors.
8 DO NOT cover the ventilator.
9 When not in use store in a safe, dry, childproof location.
2. INTRODUCTION
Ideal for use where high-volume clean air delivery is required. Especially designed to easily ventilate hot or fume laden work
areas, creating a cleaner and more pleasant working environment. Supplied with 5m ducting (VEN200AK1). Optional 10m ducting
(VEN200AK2) available, but not included. Can be used across multiple industries including, but not exclusive to; marine, roof spaces
and building sites, cable/pipe ducts and workshops. Lightweight in construction with large carry handle for portability. Fitted with 2m
cable and 3-pin plug.
3. SPECIFICATION
MODEL NO: VEN200.V4 VEN250.V2 VEN300.V3
Airow: 1500m³/hr(882cfm) - 25m³/min 2700m³/hr(1589cfm) - 45m³/min 3900m³/hr(2295cfm) - 65m³/min
Fan Diameter: Ø200mm Ø250mm Ø300mm
Fan Speed: 2800rpm 2800rpm 2800rpm
Fuse Rating: 13A 13A 10A
IP Rating: IP55 IP55 IP55
Maximum Airow: 1500m³/hr(882cfm) - 25m³/min 2700m³/hr(1589cfm) - 45m³/min 3900m³/hr(2295cfm) - 65m³/min
Noise Level: 61db(A) 66dB(A) 61db(A)
Power: 180W 300W 500W
Replacement Parts: VEN200AK1/VEN200AK2 VEN250AK1/VEN250AK2 VEN300AK1/VEN300AK2
Overall Eciency (n): 45.8% 42.8% 51%
Measurement Category: C C C
PORTABLE VENTILATORS WITH DUCTING
MODEL NOs: VEN200.V4, VEN250.V2, VEN300.V3
Original Language Version
© Jack Sealey Limited
VEN200.V4, VEN250.V2, VEN300.V3 Issue 4 (1,3) 06/10/23
Eciency Category: Static Static Static
Eciency Grade: 40 40 40
Static Pressure: 3.1mbar 3.0mbar 3.9mbar
Supply: 230V 230V 230V
4. 230V ~ 50HZ OPERATION
4.1. Decide on the direction of air ow, depending on your requirement (ventilate or extract). See g 1 for direction of air ow.
4.2. Ducting can be attached to either end of the ventilator depending on whether you wish to remove/extract fumes or deliver fresh air into
a work space.
4.3. To change direction of air ow rotate the unit 180° as the air ow is a xed direction.
4.4. Secure ducting by pulling the string tight then move the toggle switch to start the unit; select a low or high fan speed as required.
NOTE: The ducting has locating lugs attached to it; these can be used to suspend the ducting if required.
DIAGRAM SHOWS VENTILATION OPERATION
g.1
Ventilation side
Extraction side
Air Flow
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Original Language Version
© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
VEN200.V4, VEN250.V2, VEN300.V3 Issue 4 (1,3) 06/10/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
