Sealey VEN500 5m Ducting Portable Ventilator Ø500mm User Manual

PORTABLE VENTILATOR Ø500MM WITH 5M

DUCTING

MODEL NO: VEN500

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. ELECTRICAL SAFETY

 WARNING! It is the user’s responsibility to check the following:

Check all electrical equipment and appliances to ensure that they are safe before using.

Inspect power supply leads, plugs and all electrical connections for wear and damage.

Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.

8 DO NOT use worn or damaged cables, plugs or connectors.

9  Ensurethatanyfaultyitemisrepairedorisreplacedimmediatelybyaqualiedelectrician.

9  Ifthecableorplugisdamagedduringuse,switcho󰀨theelectricitysupplyandremovefromuse.

 Ensurethatrepairsarecarriedoutbyaqualiedelectrician.

9  SealeyrecommendthatanRCD(ResidualCurrentDevice)isusedwithallelectricalproducts.

Important:Ensurethatthevoltageratingontheappliancesuitsthepowersupplytobeusedandthattheplugisttedwiththe 

correct fuse.

8 DO NOT pull or carry the appliance by the power cable.

8 DO NOT pull the plug from the socket by the cable.

1.2. GENERAL SAFETY

9  Disconnecttheventilatorfromthemainspowerwhennotinuse,andbeforeservicingorperforminganymaintenance.

9 Use the fan in dry areas only. Do not use in wet or high condensation locations such as bathrooms, showers, or pools.

 WARNING! Ifaventilatorfallsintowater,immediatelyswitchoffatthemainsanddisconnectfromthemainspowersupply.

8 DO NOTtouchtheventilatoruntilthemainspowersupplyhasbeendisconnected.

9  Alwaysdisconnecttheventilatorfromthepowersupplywhenmovingitfromonelocationtoanother.

9  Keeptheventilatorcleanandmaintainingoodcondition(useanauthorisedserviceagent).

9  Userecommendedpartsonly(unauthorisedpartsmaybedangerous,andwillinvalidateyourwarranty).

8 DO NOTstandtheventilatorwhereitmaybeknockedoveroroffasurface,orwheretheleadmaycauseatriphazard.

8 DO NOTuseanextensioncordunlessithasbeenapprovedbyanelectricalauthority.

8 DO NOT insert any objects through the fan guard.

8 DO NOT allowchildrentooperatetheventilator.

8 DO NOTimmersetheventilatorinwateroranyotherliquid.

8 DO NOTusetheventilatoroutdoors.

8 DO NOTcovertheventilator.

9 When not in use store in a safe, dry, childproof location.

2. INTRODUCTION

Idealforusewherehigh-volumeairdeliveryisrequired.Especiallysuitableforventilatingconned,hotorfumeladenworksites,typically

foundinboats,cable/pipeductsandroofspaces;creatingacleanermorepleasantworkingenvironment.Lightweightandrobustconstruction

givestheportabilityanddurabilitynecessaryintheworkplace.Mountedonasteelframewith4castorwheels,2mcableand3-pinplug.

Suppliedwith5mducting,optional10mlengthavailable.

3. SPECIFICATION

Model No.: ................................................................VEN500

Airow: .............................. 9900m³/hr(5814cfm)-165m³/min

E󰀩ciencyCategory: ...................................................... Static

E󰀩ciencyGrade: ................................................................40

Electrical Class: .........................................................Class 1

Fan Diameter: ......................................................... Ø500mm

Fan Speed: ..............................................................1400rpm

Fuse Rating: ....................................................................13A

IP Rating: .................................................. IP54(FanisIP20)

VEN500Issue112/08/24

Original Language Version

Refer to

instruction

manual

Indoor use only Donotcover

Maximum Air Velocity: ..................................................14m/s

MaximumAirow: .............. 9900m³/hr(5814cfm)-165m³/min

Measurement Category: ...................................................... C

Nett Weight: .................................................52kgincducting

NoiseLevel: .............................................................. 74dB(A)

OverallE󰀩ciency(n): ................................................. 35.94%

Plug Type: ......................................................................3-Pin

Power: .........................................................................1100W

Power Supply Cable Length: ..........................................2.3m

Replacement Parts: ..VEN500AK1(5m)/VEN500AK2(10m)

Static Pressure:.........................................................4.5mbar

Supply: ........................................................................... 230V

4. ASSEMBLY

NOTE: Refer to Parts List

4.1.  Fixfourcastorwheels(item13)totheundersideofthemountingpadsontheframe(item12)usingsuppliedxings(items14,15,16).

4.2. TO EXTRACT AIR:attachtheductingtotheinletsideoftheventilator,ensuringatightt.Securebypullingthestringtightand 

knotting it. Locate the other end of the ducting in the area from which you wish to extract air.

4.3. TO VENTILATE:attachtheductingtotheoutletsideoftheventilatorandlocatetheotherendoftheductingintheareathatyou

 wishtoventilate.

4.4. Theangleoftheunitcanbeadjustedbylooseningtheknobs(item11),rotatingtheunittotherequiredangleandre-tightening.

NOTE: The ducting has locating lugs attached to it; these can be used to suspend the ducting if required.

4.5. Connect the mains plug to a suitable electric supply.

4.6. RotatethepowerswitchtotheONpositiontostarttheunit(item10).

VEN500Issue112/08/24

Original Language Version

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

waste authority for recycling information.

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentparts

without prior notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
