English
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric product, basic
precautions should always be followed,
including the following:
Read all instructions before using this
product.
DANGER
To reduce the risk of electric shock:
- To charge the product, only use a USB power
source on a certied product with output
rating 5V, ≥ 1A. For safe charging in a moist
environment (e.g. in a bathroom), only use
an IPX4 (splash-proof) power source. A
suitable power source (e.g. Philips HQ87) is
available via www.philips.com/support. If
you need support nding the correct USB
power source, contact Philips support at
1-800-243-3050. Using a non-certied USB
power source may cause hazards or serious
injuries.
- Keep the USB cable, the USB power source
and the charging stand dry.
- Do not reach for a corded product that has
fallen into water. Unplug immediately from
the power outlet.
- Do not place or store the product where it
can fall or be pulled into a tub or sink. Do
not place or drop the product into water or
other liquid.
- This product does not work while it is
connected to the power outlet. Except
when charging, always unplug this product
from the power outlet.
- Remove USB power source from power
outlet and product before cleaning.
WARNING
To reduce the risk of burns, re, electric
shock, or injury to persons:
- This product is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the product
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the product.
- Use this product only for its intended
household use as described in this manual.
Misuse can lead to hazards or serious
injuries. Do not use attachments not
recommended by Philips North America
LLC. Accessories supplied may vary for
dierent products.
- Never operate this product if it has a
damaged USB power source, if it is not
working properly, after it has been dropped
or damaged, or after the product or the
USB power source has been dropped into
water. For assistance call 1-800-243-3050.
- Keep the USB cable and the USB power
source away from heated surfaces.
- Never drop or insert any object into any
opening.
- Do not use the USB power source in or near
a power outlet that contains an electric air
freshener to prevent damage to the USB
power source.
- Do not use product outdoors or operate
where aerosol (spray) products are
being used or where oxygen is being
administered.
- Always check shaving heads (guards and
cutters) before using the product. Do not
use the product if cutters or guards are
damaged, as injury may occur.
- Always attach the USB cable to the USB
power source and the product rst, then
attach the USB power source to the power
outlet. To disconnect, set all controls to
'o' position. Then remove the USB power
source from the power outlet.
- Plug USB power source directly into power
outlet. Do not use an extension cord.
- Unplug USB power source before plugging
in or unplugging the product.
- The batteries used in this product may
present a re or chemical burn hazard if
mistreated. Do not disassemble, heat above
100°C (212°F) or incinerate.
- Only use original Philips accessories or
consumables.
- Charge, use and store the product at a
temperature between 40 °F / 4.5°C and
95°F / 35°C.
- Keep product and batteries away from re
and do not expose them to direct sunlight
or high temperatures.
- If the product becomes abnormally hot or
smelly, changes color or if charging takes
longer than usual, stop using and charging
the product and contact Philips.
- Do not place products and their batteries in
microwave ovens or on induction cookers.
- Do not open, modify, pierce, damage or
dismantle the product or battery to prevent
batteries from heating up or releasing toxic
or hazardous substances. Do not short-circuit,
overcharge or reverse charge batteries.
- If batteries are damaged or leaking, avoid
contact with the skin or eyes. If this occurs,
immediately rinse well with water and seek
medical care.
- When you handle batteries, make sure that
your hands, the product and the batteries
are dry.
- To avoid accidental short-circuiting of
batteries after removal, do not let battery
terminals come into contact with metal
objects (e.g. coins, hairpins, rings). Do not
wrap batteries in aluminum foil. Tape
battery terminals or put batteries in a
plastic bag before you discard them.
SAVE THESE
INSTRUCTIONS
Introduction
Congratulations on your purchase and
welcome to Philips Norelco!
To fully benet from the support that Philips
Norelco oers, register your product at
www.philips.com/register
.
General description (Fig. 1)
1 Protective cap
2 Shaving unit
3 Shaving unit release button
4 On/o button
5 1-level charging light (S3145 only)
6 3-level charging light (S3242, S3243 and
S3341 only)
7 Pop-up trimmer
8 Trimmer release slide
9 USB cable
Note: A suitable power source
(e.g. Philips HQ87) is available via
www.philips.com/support.
10 Small plug
11 Charging stand (S3341only)
12 Travel pouch (S3243 and S3341 only)
Charge indications
S3145
Battery low
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
charging light ashes orange (Fig. 2).
When you switch o the product, the charging
light continues to ash orange for a few
seconds.
Charging
When the shaver is charging, the charging
light ashes white (Fig. 2).
Battery fully charged
When the battery is fully charged, the charging
light lights up white continuously (Fig. 3).
Note: After approx. 30 minutes, the charging
light goes out to save energy.
Quick charge
When you start charging the empty battery,
the charging light ashes white quickly. After
approx. 5 minutes the charging light ashes
white slowly. The shaver now contains enough
energy for a 5-minute shave.
S3242, S3243, S3341
Battery low
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
bottom charging light starts to ash orange
(Fig. 4).
Tripleheader shaver
S3145
S3243
S3242
S3341
T
ri
p
leheader shaver
BC
NOT INCLUDED
1
2
2
1
NOT INCLUDED
>75 % recycled paper
>75 % papier recyclé
Manufactured for:
Philips Personal Health
a division of Philips North America LLC
P.O. Box 10313, Stamford, CT 06904
This symbol on the product’s
nameplate means it is listed by
Underwriters’ Laboratories, Inc.
Norelco and Tripleheader are registered
trademarks of Philips North America LLC.
PHILIPS and Philips shield are registered
trademarks of Koninklijke Philips N.V.
©2023 Philips North America LLC. All rights
reserved.
3000.105.8965.2 (10/10/2023)
2
5
8
11
14
17
20
23
26
29
3
6
9
12
15
18
21
24
27
30
28
4
7
10
13
16
19
22
25
2
1
8
7
9
10
11
12
3
4
65
1
When you switch o the shaver, the bottom
charging light continues to ash orange for a
few seconds.
Charging
While the shaver charges, rst the bottom
charging light ashes and then lights up
continuously. Next the second charging light
ashes and then lights up continuously, and so
on until the shaver is fully charged (Fig. 4).
Battery fully charged
When the battery is fully charged, all charging
lights light up white continuously (Fig. 5).
Note: After approx. 30 minutes, the charging
lights go out to save energy.
Quick charge
When the shaver is in quick charge mode, the
charging lights light up one after the other.
After approx. 5 minutes, the bottom charging
light ashes white. The shaver now contains
enough energy for a 5-minute shave.
Charging
- If the product is subjected to a major
change in temperature, pressure or
humidity, let it acclimatize for 30 minutes
before using.
- Do not charge the shaver in a pouch or
travel case.
Charge the shaver before you use it for
the rst time and when the charging light
indicates that the battery is almost empty.
- Charging takes approx. 1 hour.
- Quick charge: After approx. 5 minutes of
charging, the battery contains enough
energy for a 5-minute shave.
- When the product is fully charged it
has a cordless operating time of up to
60minutes.
Note: You cannot use the product while it is
charging.
Danger: Keep the USB cable, the USB
power source and the charging stand dry.
Charging with a USB power source
1 Make sure that the product is switched o.
2 Insert the small plug of the USB cable into
the socket in the bottom of the product.
3 Insert the USB plug into the USB power
source (not included) (Fig. 6).
4 Insert the USB power source into the power
outlet (Fig. 7).
5 The charging light on the product will
indicate the charging status (see 'Charge
indications').
6 After charging, remove the USB power
source from the power outlet and pull the
small plug out of the product.
Charging with charging stand (S3341 only)
1 Make sure that the product is switched o.
2 Connect the small plug of the USB cable to
the charging stand.
3 Insert the USB plug into the USB power
source (not included) (Fig. 6).
4 Insert the USB power source into the power
outlet (Fig. 7).
5 Place the shaver in the charging stand in
upright position, making sure the charging
contacts in the bottom of the stand t into
recess in the bottom of the shaver (Fig. 8).
6 The charging light on the product will
indicate the charging status (see 'Charge
indications').
7 After charging, remove the shaver from the
charging stand by lifting it straight up. Do
not tilt the shaver.
Using the product
Always check the product and all
accessories before using. Do not use the
product or any accessory if it is damaged,
as this may cause injury. Always replace
a damaged part with one of the original
type.
Note: This product is waterproof (Fig. 9). It is
suitable for use in the bath or shower and for
cleaning under the tap with water. For safety
reasons, this product can only be used without
cord.
Use this product for its intended household
use as described in this manual.
For hygienic reasons, the product should
only be used by one person.
witching the product on and o
To switch the product on or o, press the on/
o button once (Fig. 10).
Shaving
For the best results on skin comfort, pre-trim
your beard if you have not shaved for 3 days
or longer.
You can use this product either wet or dry,
or even in the shower. For a wet shave, apply
some water and shaving foam or gel to your
skin and rinse the shaving heads under the tap
with warm water before following the steps
below.
1 Switch on the shaver.
2 Move the shaver in circular movements
over your skin to catch hair growing in all
directions (Fig. 11). Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable
shave.
Note: Do not press too hard, as this can
cause skin irritation.
Note: If you are shaving with gel or foam,
rinse the shaving unit regularly during your
shave to ensure that it continues to glide
smoothly over your skin (Fig. 12).
3 Use the narrow sides of the shaving unit to
shave in hard-to-reach areas such as along
your jawline and under your nose (Fig. 13).
4 Switch o and clean the product after each
use (see 'Cleaning and maintenance').
5 Put the protective cap on the product to
protect shaver heads during storage and
travel (Fig. 21).
Note: Make sure you rinse all foam or shaving
gel o the product.
21-Day adaptation process
- 21 Day Trial and Conversion Process. It is a
fact that your skin and beard need time to
adjust to a new grooming system.
- Use your new shaver exclusively for 3 weeks
to fully enjoy the closeness of a Philips
Norelco shave.
- At rst you may not get as close a shave as
you expect, or your face may even become
slightly irritated. This is normal since your
beard and skin will need time to adjust.
Invest 3 weeks and you'll soon experience
the full joy of your new shaver.
- Stick with it! If you alternate shaving
methods during the adjustment period, it
may make it more dicult to adapt to the
Philips Norelco shaving system.
- If you are still not convinced after 21 days,
Philips Norelco will refund you the full
purchase price as long as the request is
received within 45 days of purchase.
Trimming with pop-up trimmer
You can use the trimmer to groom your
sideburns and moustache.
1 Push the trimmer release slide downwards
to open the trimmer (Fig. 14).
2 Press the on/o button once to switch on
the product (Fig. 10).
3 Hold the trimmer perpendicular to the
skin and move the product downwards,
exerting gentle pressure (Fig. 15).
4 Switch o the product and clean the
trimmer after each use to prevent
clogging and damage (see 'Cleaning and
maintenance').
5 Close the trimmer ('click') (Fig. 16).
Cleaning and maintenance
Regular cleaning guarantees better
shaving results.
Never clean, remove or replace the
shaving unit while the shaver is
switched on.
Do not touch shaving heads with hard
objects as this may dent or damage the
precision-made slotted shaving head.
Do not use abrasives, scourers or
aggressive liquids such as gasoline or
acetone to clean the shaver.
Cleaning the shaver
Clean the shaver after every shave for optimal
shaving performance.
Always check if the water is too hot, to
prevent burning your hands.
While rinsing shaving heads, water may drip
out of the base of shaver. This is a normal
occurrence. Internal electric parts are in a
waterproof compartment so the shaver will be
protected against water damage.
1 Press the on/o button once to switch on
the product (Fig. 10). Rinse the shaving unit
with cold or lukewarm water (Fig. 12).
2 Press the on/o button to switch o the
product. Press the shaving unit release
button to open the shaving unit (Fig. 17).
Rinse the shaving unit and hair chamber
with lukewarm water (Fig. 17).
3 Rinse the outside of the shaving unit with
lukewarm water (Fig. 18).
4 Carefully shake o excess water and let the
shaver air dry.
Never dry the shaving unit with a
towel or tissue, as this may damage the
shaving heads (Fig. 19).
5 Close the shaving unit.
Cleaning the pop-up trimmer
Caution: Never dry the trimmer teeth with
a towel or tissue, as this may damage the
trimmer teeth.
Clean the trimmer after each use to prevent
clogging and damage.
1 Switch o the shaver.
2 Push the trimmer release slide downwards
to open the trimmer (Fig. 14).
3 Switch on the shaver and rinse the pop-up
trimmer under warm water (Fig. 20).
4 Switch o the shaver after cleaning.
5 Carefully shake o excess water and let the
pop-up trimmer air dry.
6 Close the trimmer ('click') (Fig. 16).
Tip: For optimal performance, lubricate the
teeth of the pop-up trimmer with a drop of
mineral oil every six months (oil not included).
Replacement
Replacing the shaving heads
For maximum shaving performance, replace
the shaving heads once a year (Fig. 22).
Replace damaged shaving heads immediately.
Always replace the shaving heads with
original Philips Norelco shaving heads (see
'Accessories').
1 Switch o the shaver.
2 Press the shaving unit release button to
open the shaving unit. Pull the shaving unit
o the shaver (Fig. 23).
3 Turn the lock counterclockwise (1) and
remove the retaining frame (2). Place it
aside in a safe place (Fig. 24).
4 Remove the shaving heads from the
shaving unit. Discard the used shaving
heads immediately to avoid mixing them
with the new shaving heads (Fig. 25).
5 Place new shaving heads in the shaving unit
(Fig. 26).
Note: Make sure that the shaving heads
with the projections t exactly onto the
hooks of the shaving head holder when
placing them (Fig. 27). The shaving heads
supplied with the shaver either have
notches or projections. Both shaving
systems are the same.
6 Put the retaining frame back into the
shaving unit (1) and turn the lock clockwise
(2) (Fig. 28).
7 Insert the hinge of the shaving unit into the
slot in the top of the shaver. Then close the
shaving unit (Fig. 29).
Note:If the shaving unit does not close
smoothly, check if you have inserted the
shaving heads properly and if the retaining
frame is locked.
This product has no other user-serviceable
parts. For assistance call
1-800-243-3050.
Storage
- Make sure the product is switched o.
Remove the USB power source from the
power outlet and the product before
storing the product in a safe, dry location
where it will not be crushed, banged, or
subject to damage.
- Do not wrap cord around the product
when storing.
- Store cord and other accessories in a safe
location where these will not be cut or
damaged.
- Do not place or store the product where
it can fall or be pulled into a tub or sink,
water or other liquid while plugged in.
Put the protective cap on the shaver to
prevent damage (Fig. 21).
Note: Always let the shaver dry completely
before storing.
Storage in travel pouch
(S3243 and S3341 only)
Store the shaver in the travel pouch supplied.
Note: Make sure the shaver is dry before you
store it in the travel pouch.
Accessories
Replacement parts and accessories may
be purchased at a store near you or on our
website www.philips.com/store.
The following accessory is available:
- SH30 Philips Norelco replacement blades.
Assistance
For assistance, visit our website:
www.philips.com/support or call toll free
1-800-243-3050.
Disposal
- This product contains a rechargeable
lithium-ion battery which must be disposed
of properly.
- Contact your local town or city ocials
for battery disposal information. You
can also call 1-800-822-8837 or visit
www.call2recycle.org for battery
drop-o locations (Fig. 30).
- For assistance, visit our website
www.philips.com/support or call
1-800-243-3050 toll free.
- Your product is designed and manufactured
with high quality materials and
components, which can be recycled and
reused. For recycling information, please
contact your local waste management
facilities or visit www.recycle.philips.com.
Full Two-Year Warranty
Philips North America LLC warrants this
new product against defects in materials or
workmanship for a period of two years from
the date of purchase, and agrees to repair or
replace any defective product without charge.
IMPORTANT: This warranty does not cover
damage resulting from accident, misuse or
abuse, lack of reasonable care, the axing of
any attachment not provided with the product
or loss of parts or subjecting the product to
any but the specied voltage.*
The shaving heads (cutters and guards) are not
covered by the terms of this warranty because
they are subject to wear and tear.
NO RESPONSIBILITY IS ASSUMED FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
In order to obtain warranty service, simply go
to www.philips.com/support. It is suggested
that for your protection you return shipments
of product by insured mail, insurance prepaid.
Damage occurring during shipment is not
covered by this warranty.
NOTE: No other warranty, written or oral, is
authorized by Philips North America LLC.
This warranty gives you specic legal rights,
and you may also have other rights which
vary from state to state. Some states do not
allow the exclusion or limitation of incidental
or consequential damages, so the above
exclusion and limitations may not apply to you.
*Read enclosed instructions carefully.
45-DAY MONEY-BACK GUARANTEE
If you are not fully satised with your product
send the product back and we’ll refund you
the full purchase price.
The product must be shipped prepaid by
insured mail, insurance prepaid, have the
original sales receipt, indicating purchase
price and date of purchase.
We cannot be responsible for lost mail.
The product must be postmarked no later
than 45 days after the date of purchase.
Philips reserves the right to verify the
purchase price of the product and limit
refunds not to exceed suggested retail
price.
To obtain the money-back guarantee
service, please go to www.
PhilipsMoneyBack.com and follow the
simple 3-step process.
Delivery of refund check will occur 6–8 weeks
after receipt of returned product.
Loading ...
