Sealey CP20VRP SV20 Series 150mm Cordless Rotary Polisher User Manual

20V Ø150MM CORDLESS ROTARY POLISHER

- BODY ONLY

MODEL NO: CP20VRP

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. GENERAL POWER TOOL SAFETY WARNINGS

 WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock,

 reand/orseriousinjury.

 WARNING! Ensure that Health & Safety, local authority and general workshop practice regulations are adhered to when using this

polisher.

9 Save all warnings and instructions for future reference.

1.2. WORK AREA SAFETY

9 Keep work area clean and well lit. Cluttered or dark areas invite accidents.

8 DO NOT operate power tools in explosive atmospheres, such as in the presence of ammableliquids,gasesordust.Powertools

create sparks which may ignite the dust or fumes.

9  Keepchildrenandbystandersawaywhileoperatingapowertool.Distractionscancause you to lose control.

1.3. PERSONAL SAFETY

9 Stay alert, watch what you are doing and use common sense when operating a power tool. DO NOT use a power tool while you are

 tiredorundertheinuenceofdrugs,alcoholormedication.Amomentofinattentionwhileoperatingpowertoolsmayresultinserious

 personalinjury.

9  Usepersonalprotectiveequipment.Alwaysweareyeprotection.Protectiveequipmentsuchasdustmask,non-skidsafetyshoes,

 hardhat,orhearingprotectionusedforappropriateconditionswillreducepersonalinjuries.

9  Preventunintentionalstarting.Ensuretheswitchisintheo󰀨-positionbeforeconnectingtopowersourceand/orbatterypack,picking

up or carrying the tool.

9  Carryingpowertoolswithyourngerontheswitchorenergisingpowertoolsthathavetheswitchoninvitesaccidents.

9  Removeanyadjustingkeyorwrenchbeforeturningthepowertoolon.

8 DO NOToverreach.Keepproperfootingandbalanceatalltimes.Thisenablesbettercontrol of the power tool in unexpected

situations.

9 Dress properly. DO NOT wearlooseclothingorjewellery.Keepyourhair,clothingand gloves away from moving parts. Loose clothes,

 jewelleryorlonghaircanbecaughtinmovingparts.

9 If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.

1.4. POWER TOOL USE AND CARE

8 DO NOT forcethepowertool.Usethecorrectpowertoolforyourapplication.Thecorrectpowertoolwilldothejobbetterandsafer

at the rate for which it was designed.

8 DO NOTusethepowertooliftheswitchdoesnotturnitonando󰀨.Anypowertoolthatcannotbecontrolledwiththeswitchis 

 dangerousandmustberepaired.

 WARNING!Disconnecttheplugfromthebatterypackfromthepowertoolbeforemakinganyadjustments,changingaccessories,or

storing power tools.

9 Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to

 operatethepowertool.Powertoolsaredangerousinthehandsofuntrainedusers.

9  Maintainpowertools.Checkformisalignmentorbindingofmovingparts,breakageofpartsandanyotherconditionthatmaya󰀨ect

 thepowertool’soperation.Ifdamaged,havethepowertoolrepairedbeforeuse.Manyaccidentsarecausedbypoorlymaintained

power tools.

9  Usethepowertool,accessoriesandtoolbitsetc.inaccordancewiththeseinstructions,takingintoaccounttheworkingconditions

 andtheworktobeperformed.Useofthepowertoolforoperationsdi󰀨erentfromthoseintendedcouldresultinahazardous 

situation.

1.5. SERVICE

9  Haveyourpowertoolservicedbyaqualiedrepairpersonusingonlyidenticalreplacementparts.Thiswillensurethatthesafetyof

the power tool is maintained.Unauthorisedpartsmaybedangerousandwillinvalidatethewarranty.

1.6. SPECIFIC POLISHER SAFETY

9 WARNING!Disconnectthebatteryandensurethatthepadisatacompletestandstillbeforechangingaccessories,servicingor 

performing any maintenance.

 WARNING! Keep all guards and holding screws in place, tight and in good working order.

9  Checkregularlyfordamagedparts.Aguardoranyotherpartthatisdamagedmustberepaired/replacedbeforethepolisherisnext

used.

9  Keepthepolishercleanforbestandsafestperformance.

CP20VRPIssue2(1,2,3)15/07/21

Original Language Version

Refer to

instructions

Wear eye

protection

Wear protective

gloves

Wear ear

protection

Wear protective

clothing

Wear a mask

9 Before each use check all attachments for condition. If worn or damaged replace immediately.

8 DO NOTswitchthepolisheronuntiltheheadisincontactwiththepanelandswitchtheunito󰀨beforeremovingtheheadfromthe

panel.

8 DO NOTusethepolisherwithabrasivecleanersorrubbingcompoundsasexcessivepaintremovalmayresult.

8 DO NOT get the polisher wet or use in damp or wet locations or areas where there is condensation.

8 DO NOT allow untrained persons to operate the polisher.

9 When not in use, unplug from the mains power supply and store in a safe, dry, childproof area.

2. INTRODUCTION

Digitaldisplayandvariablespeedcontrolfrom500-3000rpm.Featuresaslide-buttonon/o󰀨switchallowingforasmoothcomfortablemain

handlegrip.Spindlelockforfastandeasypadchanges.Doubleinjectioncompositehousingwithrubbergripforaddedcomfort.Supplied

withØ150mmbackingpadandsidehandle.Requirescompatible20Vbatteryandmainscharger,soldseparately.

3. SPECIFICATION

Model No ...............................................................CP20VRP

Battery ...................20V2Ah-6AhLithium-ion(notincluded)

Consumableparts:

PTC/150VA/M14-DABackingPadforHook-and-LoopDiscsØ148mmM14x2mm,

CP20VBP2-2AhBattery,CP20VBP4-4AhBattery,CP20VBP6-6AhBattery

Free speed ........................................................500-3000rpm

Noisepower/pressure .......................................... 85/74dB(A)

Padsize .................................................................. Ø150mm

Replacement parts:

............................. CP20VMC-MainsCharger(notincluded)

Threadsize ......................................................... M14x2mm

Vibration/uncertainty .......................................... 8.27/1.5m/s²

4. OPERATION

 WARNING: Removebatterybeforetting/removingpadsormaintenanceiscarried  out.

NOTE: Whennew,thebatteriesmayhavebeenshippedinalowchargestate.   Fullychargethe 

 batteriesbeforeusingyourtool.

4.1. Ensure that you have read, understood and comply with all the safety instructions in

 Section1.

4.2. POLISHING (FIG.1)

4.2.1. Holdingthepolisherrmlyoperatetheon/o󰀨switch.

4.2.2. Tosettherotationalspeedofthepolisherusethe +/- buttons.Toincreasespeed,

press ‘ + ‘, to decrease press ‘ - ‘.

4.2.3. Thereare7speedsettingsavailableandthecurrentonebeingusedisshowninthespeedsettingdisplaywindow.Thevalues 

 displayedare5,8,10,15,20,25,and30.EachstepindicatesanRPMofapproximately100timesthevalueshown.

4.2.4. When polishing, DO NOTapplytoomuchpressure,theweightofthepolishershouldbesu󰀩cient.AlsoDO NOT work for too long

 inoneareaoryoumaydamagethesurfacebeingworkedon.

4.3. BACKING PAD EXCHANGE (FIG.2)

 WARNING: Removebatterybeforetting/removingpadsormaintenanceiscarriedout.

4.3.1. Toremovethebackingpad,pressdownchucklockingbuttonandmanuallyunscrewthepadclockwise(whenviewedfromabove).

5. MAINTENANCE

 WARNING: Alwaysdisconnectthebatterybeforecarryingoutanyinspection,maintenanceorcleaning.

5.1. GENERAL INSPECTION

5.1.1. Regularlycheckthatallthexingscrewsaretight.

5.1.2. Repairsshouldbecarriedoutbyanauthorisedservicecentre.

5.2. CLEANING

 WARNING:Alwayswearprotectiveequipmentincludingeyeprotectionandgloveswhencleaningthistool.

5.2.1. Keepyourtoolcleanatalltimes.Dirtanddustwillcauseinternalpartstowearquicklyandshortenthedevice’sservicelife.

5.2.2. Cleanthebodyofyourmachinewithasoftbrush,ordrycloth.

5.2.3. Neverusecausticagentstocleanplasticparts.Ifdrycleaningisnotsu󰀩cient,amilddetergentonadampclothisrecommended.

5.2.4. Watermustnevercomeintocontactwiththetool.Ensurethetoolisthoroughlydrybeforeusingit.

5.2.5. Ifavailable,useclean,drycompressedairtoblowthroughtheventilationholes(whereapplicable).

5.3. LUBRICATION

5.3.1. Lightlylubricateallmovingpartsatregularintervalswithasuitablelubricant.

5.4. STORAGE

5.4.1. Store this tool carefully in a secure, dry place out of the reach of children.

 WARNING! – Risk of Hand Arm Vibration Injury.

 ThistoolmaycauseHandArmVibrationSyndromeifitsuseisnotmanagedadequately.

 ThistoolissubjecttothevibrationtestingsectionoftheMachineryDirective2006/42/EC.

 Thistoolistobeoperatedinaccordancewiththeseinstructions.

 Measuredvibrationemissionvalue(a)............................8.27m/s²

 Uncertaintyvalue(k):......................................................1.5m/s²

 Pleasenotethattheapplicationofthetooltoasolespecialisttaskmayproduceadi󰀨erentaveragevibrationemission.We 

 recommendthataspecicevaluationofthevibrationemissionisconductedpriortocommencingwithaspecialisttask.

 Ahealthandsafetyassessmentbytheuser(oremployer)willneedtobecarriedouttodeterminethesuitabledurationofusefor

each tool.

Original Language Version

g.1

g.2

CP20VRPIssue2(1,2,3)15/07/21

 NB:StatedVibrationEmissionvaluesaretype-testvaluesandareintendedtobetypical.

 Whilstinuse,theactualvaluewillvaryconsiderablyfromanddependonmanyfactors.

 Suchfactorsinclude;theoperator,thetaskandtheinsertedtoolorconsumable.

 NB:ensurethatthelengthofleaderhosesissu󰀩cienttoallowunrestricteduse,asthisalsohelpstoreducevibration.

 Thestateofmaintenanceofthetoolitselfisalsoanimportantfactor,apoorlymaintainedtoolwillalsoincreasetheriskofHandArm

 VibrationSyndrome.

Health surveillance.

 Werecommendaprogrammeofhealthsurveillancetodetectearlysymptomsofvibrationinjurysothatmanagementprocedurescan

 bemodiedaccordingly.

 Personalprotectiveequipment.

 Wearenotawareofanypersonalprotectiveequipment(PPE)thatprovidesprotectionagainstvibrationinjurythatmayresultfromthe

 uncontrolleduseofthistool.Werecommendasu󰀩cientsupplyofclothing(includinggloves)toenabletheoperatortoremainwarm

 anddryandmaintaingoodbloodcirculationinngersetc.Pleasenotethatthemoste󰀨ectiveprotectionisprevention,pleasereferto

 theCorrectUseandMaintenancesectionintheseinstructions.Guidancerelatingtothemanagementofhandarmvibrationcanbe

 foundontheHSCwebsitewww.hse.gov.uk-Hand-ArmVibrationatWork.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

waste authority for recycling information.

BATTERY REMOVAL

UndertheWasteBatteriesandAccumulatorsRegulations2009,JackSealeyLtdarerequiredtoinformpotentialpurchasersofproducts

containingbatteries(asdefinedwithintheseregulations),thattheyareregisteredwithValpak’sregisteredcompliancescheme.Jack

SealeyLtdBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis36monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

Original Language Version

CP20VRPIssue2(1,2,3)15/07/21
