INSTRUCTION
1.Snap a chalk line around the perimeter of the pool, 24” fro pool edge.
2. Determine the position of the initial pole of the swimming pool fence, and mark it
with X on the swimming pool floor with chalk. The spacing of each pole is 3 feet, and
then mark the hole position with “A” “B” “C” “D”. The connection spacing of the two
sets of fences is 6 cm, the shown as the picture:
3.Drill hole around the entire pool with 17mm drilling guide. All holes should be
drilled to a depth of 4”, and at a direct 90 angle to the deck.
4.When you have completed all the holes, clear the holes of any drilling dust. Insert
the plastic “feet” into the holes. Always insert the feet with care, so as not to damage
them. Confirm that plastic feet fit snugly into the holes. If you are having trouble
getting the feet to fit into the holes, tap them gently into place with a hammering, so
as not to break them. Complete this step for all the plastic feet.
5.Attach safety latch to end of each fence section, using the pre-drilled holes in the
pole. ---Insert your fence into the plastic feet. Fasten each section to the next with
the “safety latch”.
