BC10071
Baby Playard
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
USA office: Fontana GBR office: Ipswich AUS office: Truganina
If you're having difficulty, our friendly
customer team is always here to help.
AUS:cs.au@costway.com
GBR:cs.uk@costway.com
Scan QR code for
assembly instructions
Attention: To prevent possible injury by entanglement, remove this toy
when the child starts trying to get up on its hands and knees in a
crawling position.
Danger! Keep all small parts and packaging materials for this product
away from babies and children, otherwise they may pose a choking
hazard.
The product must be installed and used under the supervision of an
adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware
before installation.
Please ensure that all parts are correctly installed, incorrect installation
can lead to a danger.
We recommend that, where possible, all items are assembled near the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Ensure a secure surface during installation, and place the product
always on a flat, steady and stable surface.
Before You Start
Please read all instructions carefully and keep it for future reference.
General Warnings
IMPORTANT!
To ensure safe operation of your baby playard, please follow these instructions
and keep for future reference.
IMPORTANT!
Before assembly and each use, inspect this product for damaged hardware,
loose joints, missing parts or sharp edges.
Never use if any parts are missing or broken.
1. In gaps between the mattress and the sides of the baby playard.
Ensure that the mattress is the correct size for your baby playard.
* You should not be able to fit more than 2 fingers between the sides of the
baby playard and the sides of the mattress.
2. On soft bedding, loose pillows, duvets, cot bumpers. Soft toys should be
removed from baby's sleep space.
Failure to follow these warnings and the instructions could result in serious
injury or death.
Infants can suffocate:
WARNING
WARNING
02 03
babyjoy
Attention: To prevent possible injury by entanglement, remove this toy
when the child starts trying to get up on its hands and knees in a
crawling position.
Danger! Keep all small parts and packaging materials for this product
away from babies and children, otherwise they may pose a choking
hazard.
The product must be installed and used under the supervision of an
adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware
before installation.
Please ensure that all parts are correctly installed, incorrect installation
can lead to a danger.
We recommend that, where possible, all items are assembled near the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Ensure a secure surface during installation, and place the product
always on a flat, steady and stable surface.
Before You Start
Please read all instructions carefully and keep it for future reference.
General Warnings
IMPORTANT!
To ensure safe operation of your baby playard, please follow these instructions
and keep for future reference.
IMPORTANT!
Before assembly and each use, inspect this product for damaged hardware,
loose joints, missing parts or sharp edges.
Never use if any parts are missing or broken.
1. In gaps between the mattress and the sides of the baby playard.
Ensure that the mattress is the correct size for your baby playard.
* You should not be able to fit more than 2 fingers between the sides of the
baby playard and the sides of the mattress.
2. On soft bedding, loose pillows, duvets, cot bumpers. Soft toys should be
removed from baby's sleep space.
Failure to follow these warnings and the instructions could result in serious
injury or death.
Infants can suffocate:
WARNING
WARNING
02 03
babyjoy
PRODUCT LIST
WHEN OPEN THE PARCEL, PLEASE CHECK IF IT HAS CONTAINED
THEM ALL LIKE BELOW:
Side storage tray
Mattress Changing table
Second layer tubes
Carry bagBasic playard
Carry Cot
Second layer with zipper
1. Unzip the carry bag and take
out all items.
2. Expand out 4 feet.
4. Press down from the
middle.
6. Put the mattress on the
second layer.
HOW TO OPEN THE BED
3.Pull up two short sides, and
then pull up two long sides.
5.Connect 4 tubes.
04 05
babyjoy
babyjoy
PRODUCT LIST
WHEN OPEN THE PARCEL, PLEASE CHECK IF IT HAS CONTAINED
THEM ALL LIKE BELOW:
Side storage tray
Mattress Changing table
Second layer tubes
Carry bagBasic playard
Carry Cot
Second layer with zipper
1. Unzip the carry bag and take
out all items.
2. Expand out 4 feet.
4. Press down from the
middle.
6. Put the mattress on the
second layer.
HOW TO OPEN THE BED
3.Pull up two short sides, and
then pull up two long sides.
5.Connect 4 tubes.
04 05
babyjoy
babyjoy
1.Zip on the bassinet and cover the zipper with the zipper cover to avoid
baby from getting injured.
2.Take out the two tubes and push the ends of the steel supports into the
textile tunnel, then lock the pairs of steel supports.
3.Once the bassinet is zipped on, the tubes are inserted and the bassinet is
firm, then put the mattress on it.
1. Put the all tubes into the four fabric holes .
2. Connect the all tube ends together .then together velcro straps.
3. Attach the changing table by hooking the plastic hooks on the
two long sides. Make sure all hooks are securely engaged with the rails.
SECOND LAYER INSTRUCTION
CHANGING TABLE INSTRUCTION
CARRY COT INSTRUCTION
Part List
A
B
c
B
A
1.Connect two A tubes end together.
2.Expand B tube vertically, and connect the
C tube to the middle of B tubes as shown.
4.Attach the canopy as shown .
3.Pull up the zippers of the two side top rails
as shown.
5.Expand the tube of handle vertically when your use it as shown.
06 07
babyjoy
babyjoy
1.Zip on the bassinet and cover the zipper with the zipper cover to avoid
baby from getting injured.
2.Take out the two tubes and push the ends of the steel supports into the
textile tunnel, then lock the pairs of steel supports.
3.Once the bassinet is zipped on, the tubes are inserted and the bassinet is
firm, then put the mattress on it.
1. Put the all tubes into the four fabric holes .
2. Connect the all tube ends together .then together velcro straps.
3. Attach the changing table by hooking the plastic hooks on the
two long sides. Make sure all hooks are securely engaged with the rails.
SECOND LAYER INSTRUCTION
CHANGING TABLE INSTRUCTION
CARRY COT INSTRUCTION
Part List
A
B
c
B
A
1.Connect two A tubes end together.
2.Expand B tube vertically, and connect the
C tube to the middle of B tubes as shown.
4.Attach the canopy as shown .
3.Pull up the zippers of the two side top rails
as shown.
5.Expand the tube of handle vertically when your use it as shown.
06 07
babyjoy
babyjoy
When folding the bed (Figure 11), please press the bed body firmly.
Because the long side handrail is not fully compressed, you need to
fold it again to press the long side handrail button until its flank is at a
right angle (Figure 12).
1.Remove the mattress from
the bottom base to loosen the
structure.
2.Pull the plastic lock on the
bottom base up to loosen the
structure.
3.Hold the plastic lock and push
downward the side rails, do the
same thing for the four sides.
5.Place all parts and basic playard on the mattress, wrap up the baby
playard with the mattress and fasten them together with velcro straps, then
put it into the carry bag and zip it up.
4.Pull all four corners of the
basic playard together.
FOLDING THE BABY PLAYARD
SPECIAL NOTICE:
FIG.11 FIG.12
• This product must not be used for children weighing more than
33lbs(15kg).
• Always secure the baby on the changing table with the safety belt.
• NEVER leave baby unattended.
• Never use the baby changing table if any parts are defective, broken or
missing. When changing baby on the changing table, ensure that the
wheels are always in a locked position.
• Regularly check all assembly fittings.
• Please clean, maintain and check this product regularly.
• Any additional or replacement parts must be obtained exclusively from
the manufacturer.
• Keep the product away from the intense heat of open fires, electric or
gas heaters etc.
WARNING
08 09
babyjoy
babyjoy
When folding the bed (Figure 11), please press the bed body firmly.
Because the long side handrail is not fully compressed, you need to
fold it again to press the long side handrail button until its flank is at a
right angle (Figure 12).
1.Remove the mattress from
the bottom base to loosen the
structure.
2.Pull the plastic lock on the
bottom base up to loosen the
structure.
3.Hold the plastic lock and push
downward the side rails, do the
same thing for the four sides.
5.Place all parts and basic playard on the mattress, wrap up the baby
playard with the mattress and fasten them together with velcro straps, then
put it into the carry bag and zip it up.
4.Pull all four corners of the
basic playard together.
FOLDING THE BABY PLAYARD
SPECIAL NOTICE:
FIG.11 FIG.12
• This product must not be used for children weighing more than
33lbs(15kg).
• Always secure the baby on the changing table with the safety belt.
• NEVER leave baby unattended.
• Never use the baby changing table if any parts are defective, broken or
missing. When changing baby on the changing table, ensure that the
wheels are always in a locked position.
• Regularly check all assembly fittings.
• Please clean, maintain and check this product regularly.
• Any additional or replacement parts must be obtained exclusively from
the manufacturer.
• Keep the product away from the intense heat of open fires, electric or
gas heaters etc.
WARNING
08 09
babyjoy
babyjoy
In case a return is required, the item must be returned in original
box. Without this your return will not be accepted.
DO NOT discard the box / original packaging.
Take a photo of the box markings.
Take a photo of the damaged part (if applicable).
Send us an email with the images requested.
A photo of the markings (text) on the side of the box is required in
case a part is needed for replacement. This helps our staff identify
your product number to ensure you receive the correct parts.
A photo of the damage is always required to file a claim and get
your replacement or refund processed quickly. Please make sure
you have the box even if it is damaged.
Email us directly from marketplace where your item was purchased
with the attached images and a description of your claim.
Return / Damage Claim Instructions
10
In case a return is required, the item must be returned in original
box. Without this your return will not be accepted.
DO NOT discard the box / original packaging.
Take a photo of the box markings.
Take a photo of the damaged part (if applicable).
Send us an email with the images requested.
A photo of the markings (text) on the side of the box is required in
case a part is needed for replacement. This helps our staff identify
your product number to ensure you receive the correct parts.
A photo of the damage is always required to file a claim and get
your replacement or refund processed quickly. Please make sure
you have the box even if it is damaged.
Email us directly from marketplace where your item was purchased
with the attached images and a description of your claim.
Return / Damage Claim Instructions
10
BC10071
Baby Playard
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
USA office: Fontana GBR office: Ipswich AUS office: Truganina
If you're having difficulty, our friendly
customer team is always here to help.
AUS:cs.au@costway.com
GBR:cs.uk@costway.com
Scan QR code for
assembly instructions
