The parameter name
specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
cmos
Sensor type
Photosensitive size
Effective pixels
1/4''
The white balance
Automatic gain control AGC
Backlight compensation
The noise reduction
S/N Ratio
Video formats
Video output
Ng code correction
voltage operating
operating current
power
Working temperature
Whole plate thickness
1280(h)x720(V)
automatic
Yes
3DDNR
automatic
> 52dB(AGC OFF)
CVBS PAL/NTSC
AHD 720P@25FPS
AHD 720P@30FPS
1.0Vp-p/75ohm
0.45
9VDC
〜36VDC
160mA〜180mA
0.55W(U=3.3V)
-40℃～＋70℃
4.8mm
Installation dimensions
Eight to edge 17mm
Video
Power12VDC
Ground
V T B 2 0 2 M I N I Q U I C K I N S T A L L A T I O N G U I D E
VTB202MINI
VTB202MINI
Install the VTB202MINI as follows:
2
IP69K Waterproof Rating
160 degree Wide Viewing Angle
