DC +12V RED
(GND)Black
3.Installation
The installation and position of the camera
Encase with insulating tape
VTB303
HEAVY DUTY CAMERA
Encase with insulating tape
S
ig
n
a
l Wi
re
Monitor
Power(Red)
Mirror
Audio(white)
Video(Yellow)
2.Accessories
21
Sequence Number Name
Camera
Technical term Technical Parameters
1/4”SONY CCD
12V
120 mA
1.5W
510(H)X492(V)
1/60-1/100000s
0LUX , LED When opening
≥48dB
480 TVL
NTSC
130° 105° 80°
1.0Vp-p 75ohm
IP 67
AUTO
AUTO
AUTO
-4°F～158°F
Image Sensor
Power Supply(DCV)
Current Consumption
Power
Effective pixels
Electionic shutter
Minimum illumination
Resolution(TV Lines)
TV System
Lens Angle(Deg.)
Video output
IP rating (Waterproof)
White Balance AUTO
AGC
BLC
Operating Temperature(°F)
S/N Ratio
1.Specification
Signal Wire (65ft)
User`s manual
①
②
③
④
⑤
①
②
Warranty Card
Registration Card
③
④ ⑤
⑥
⑥
Accessories
